Pictorial Index

For safety and

1

security

Instrument clus-

2

ter

Operation

3

each component

4

5

Interior Features

6

Maintenance and

7

care

When

8

arises

Vehicle

9

cations

LC150_OM_OM60K29E_(EE)

Search by illustration

Make sure to read through them

How to read the gauges and meters, the variety of

Warning Lights And Indicators, etc.

of

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advices which are necessary for driving

Operating the audio system

Usage of the interior features, etc.

Caring for your vehicle and maintenance procedures

trouble

What to do in case of malfunction or emergency

specifi-

Vehicle Specifications, customizable features, etc.

Search by symptom

Search alphabetically

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Land Cruiser Prado 2013 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota Land Cruiser Prado 2013

Page 1 Pictorial index Search by illustration For safety and Make sure to read through them security Instrument clus- How to read the gauges and meters, the variety of warning lights and indicators, etc. Operation Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information .......8 Operation of each compo- Reading this manual.....10 nent How to search ......11 Pictorial index .......12 3-1. Key information Keys ........124 For safety and security 3-2. Opening, closing and locking the doors Side doors ......130 1-1.
Page 3: Table Of Contents
& Rear view monitor sys- start sys- tem........322 tem)........240 Toyota parking assist moni- Engine (ignition) switch(vehi- tor........333 cles with a smart entry & start Driving assist systems..360 sys- tem)........243 (Blind Spot Monitor) ..366 Automatic transmission..251...
Page 4: Table Of Contents
TABLE OF CONTENTS 5-7. “SETUP” menu Audio system Using the “SETUP” menu(blue- tooth*menu)......431 Using the “SETUP” menu ("TEL" 5-1. Basic Operations menu)........435 Audio system types....392 5-8. Bluetooth® Audio Steering wheel audio Operating a Bluetooth® enables switches......393 portable player....439 AUX port/USB port.....394 5-9.
Page 5: Table Of Contents
6-2. Using the interior lights Maintenance and care Interior lights list....476 • Personal/interior lights main switch.......477 7-1. Maintenance and care • Personal/interior lights ...477 Cleaning and protecting the vehicle exte- • Lounge illumination control rior........506 switches......478 Cleaning and protecting the 6-3.
Page 6: Table Of Contents
TABLE OF CONTENTS 7-3. Do-it-yourself maintenance 8-2. Steps to take in an emergency Do-it-yourself service (precau- If your vehicle needs to be tions).........516 towed.........587 Hood ........519 If you think something If you think something Fuel Engine compartment..520 pump shut off system (gasoline Tires........539 engine Tire inflation pressure ..552...
Page 7 Vehicle specifications 9-1. Specifications Maintenance data ((fuel, oil level, etc.))......676 Fuel information ....702 9-2. Customization Customizable features ..705 9-3. Items to initialize Items to initialize ....715 Index What if... (Troubleshoot- ing)..........718 Alphabetical index ......722 For vehicles with a navigation system or a multimedia system, refer to the “Navigation system owner’s manual”...
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota Both genuine Toyota and a wide variety of other spare parts and accessories for Toyota vehicles are currently available on the market. Should it be deter-...
Page 9 Scrapping of your Toyota The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be...
Page 10: Reading This Manual
Reading this manual CAUTION: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 11: How To Search
How to search Searching by name  • Alphabetical index ..P. 722 Searching installation  position • Pictorial index ....P. 12 Searching by symptom or  sound • What to do if... (Troubleshooting) ..P. 718 Searching by title ...
Page 12: Pictorial Index
Pictorial index Pictorial index  Exterior Side doors ........P. 130 Locking/unlocking .
Page 13 Pictorial index Windshield wipers ....... . . P. 279 Precautions against winter season ..... P. 387 To prevent freezing (windshield wiper de-icer) .
Page 14 Pictorial index  Instrument panel (Left-hand drive vehicles) Engine switch ....... . P. 240, 243 Starting the engine/changing the modes .
Page 15 Pictorial index Multi-information display ..... . . P. 109, 114 Display........P. 109, 114 When the warning messages are displayed .
Page 16 Pictorial index  Switches (Left-hand drive vehicles) Power window switches ......P. 203 Door lock switch .
Page 17 ..... . P. 473 Toyota parking assist-sensor switch ....P. 312 VSC OFF switch.
Page 18 Pictorial index 1, 2 Audio remote control switches ....P. 393 1, 2 Talk switch Menu switch ........P. 115 1, 2 Telephone switches .
Page 19 Pictorial index Front seat heater switches ......P. 474 1, 3 Center differential lock/unlock switch Four-wheel drive control switch 1, 3 “DAC”...
Page 20 Pictorial index  Interior (Left-hand drive vehicles) SRS airbags ........P. 41 Floor mats .
Page 21 Pictorial index Inside rear view mirror ......P. 198 Sun visors ........P. 495 Vanity mirrors .
Page 22 Pictorial index  Instrument panel (Right-hand drive vehicles) Engine switch ........P. 243 Starting the engine/changing the modes .
Page 23 Pictorial index Multi-information display ..... . . P. 109, 114 Display........P. 109, 114 When the warning messages are displayed .
Page 24 Pictorial index  Switches (Right-hand drive vehicles) Outside rear view mirror switches ....P. 200 Lounge illumination control switches ....P. 478 Windshield wiper de-icer switch .
Page 25 VSC OFF switch........P. 362 Toyota parking assist-sensor switch .
Page 26 Pictorial index 1, 2 Audio remote control switches ....P. 393 1, 2 Talk switch Menu switch ........P. 115 1, 2 Telephone switches .
Page 27 Pictorial index 1, 3 Height control OFF button 1, 3 Height control button 1, 3 Multi-terrain Select ON/OFF switch 1, 3 Crawl Control ON/OFF switch 1, 3 Center differential lock/unlock switch 1, 3 Rear differential lock/unlock switch Four-wheel drive control switch 1, 3 Multi-terrain Select mode selector dial 1, 3...
Page 28 Pictorial index  Interior (Right-hand drive vehicles) SRS airbags ........P. 41 Floor mats .
Page 29 Pictorial index Inside rear view mirror ......P. 198 Sun visors ........P. 495 Vanity mirrors .
Page 30 Pictorial index LC150_OM_OM60K29E_(EE)
Page 31 For safety and security 1-1. For safe use Before driving.......32 For safety drive ....34 Seat belts......36 SRS airbags......41 Airbag manual on-off system .......54 Safety information for children......56 Child restraint systems ..57 Installing child restraints ..70 Exhaust gas precautions ..81 1-2. Theft deterrent system Engine immobilizer system .......82 Double locking system..90...
Page 32: For Safe Use Before Driving
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 33 When installing the driver’s floor mat  Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats.  Only use floor mats designed for the driver’s seat. ...
Page 34: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 35 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 198, 200) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ...
Page 36: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts  Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 37 1-1. For safe use Adjusting the seat belt shoulder anchor height (front and outer second [5-door models] seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 38  Seat belt regulations If seat belt regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for seat belt replacement or installation. LC150_OM_OM60K29E_(EE)
Page 39 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always  use a seat belt and/or an appropriate child restraint system.
Page 40 Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 41: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. LC150_OM_OM60K29E_(EE)
Page 42 1-1. For safe use  SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS driver knee airbag (if equipped) Can help provide driver protection ...
Page 43 1-1. For safe use Airbag system components Front impact sensors Driver airbag Side impact sensors (front) Safing sensor (rear) (if equipped) (if equipped) Airbag manual on-off switch Driver’s seat belt buckle (if equipped) switch Curtain shield airbags Driver knee airbag (if equipped) (if equipped) Front passenger airbag...
Page 44 1-1. For safe use The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
Page 45 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 46 1-1. For safe use CAUTION SRS airbag precautions   Vehicles without SRS curtain shield air- bags: Do not lean against the front door. Vehicles with SRS curtain shield air- bags: Do not lean against the door, the roof side rail or the front, center and rear pil- lars.
Page 47 1-1. For safe use CAUTION SRS airbag precautions   Vehicles with SRS curtain shield air- bags: Do not attach anything to areas such as the door, windshield glass, side door glass, front, center or rear pillars, roof side rail and assist grip. ...
Page 48 If the areas where the SRS airbags are stored, such as the steering wheel  pad and front, center and rear pillar garnishes, are damaged or cracked, have them replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 49  Do not dispose of your vehicle or perform any of the following modifications without consulting any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 50 1-1. For safe use SRS airbag deployment conditions (SRS front airbags)   The SRS front airbag will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 20 - 30 km/h [12 - 18 mph] frontal collision with a fixed wall that does not move or deform).
Page 51 1-1. For safe use Types of collisions that may not deploy the SRS airbags (SRS front air-  bags) The SRS front airbags are generally not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low- speed frontal collision.
Page 52  duly qualified and equipped professional In the following cases, the vehicle will require inspection and/or repair. Con- tact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible.  Any of the SRS airbags have been inflated.
Page 53 1-1. For safe use Vehicles with SRS side airbags:  The surface of the seats with the side airbag is scratched, cracked or other- wise damaged.  Vehicles with SRS curtain shield air- bags: The portion of the front pillars, center pil- lars, rear pillars or roof side rail gar- nishes (padding) containing the curtain shield airbags inside is scratched,...
Page 54 1-1. For safe use  Airbag manual on-off system This system deactivates the front passenger airbag. Only deactivate the airbag when using a child restraint system on the front passenger seat. Airbag off indicator This indicator light turns on when the engine switch is in IGNITION ON mode.
Page 55 Airbag off indicator If any of the following problems occur, it is possible that there is a malfunction in the system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
Page 56: Safety Information For Chil Dren
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 57: Child Restraint Systems
Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installation.  Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44. LC150_OM_OM60K29E_(EE)
Page 58 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44. Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0+: Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II:...
Page 59 1-1. For safe use Child restraint system suitability for various seating positions Information provided in the table shows your child restraint system suitability for various seating positions. 3-door models  Seating Front passenger seat position Second seat Airbag manual on-off switch Standard Outboard Center...
Page 60 1-1. For safe use Key of letters inserted in the above table: U: Suitable for “universal” category child restraint system approved for the use in this mass group. UF: Suitable for forward-facing “universal” category child restraint sys- tem approved for the use in this mass group. X: Not suitable seat position for children in this mass group.
Page 61 1-1. For safe use 5-door models  Seating Front passenger position seat Second seat Third Airbag manual seat (if on-off switch Stan- equipped) dard Out- Center Mass groups board Up to 10 kg Never Never (22 lb.) (0 - 9 months) Up to 13 kg Never Never...
Page 62 L1: Suitable for “TOYOTA G 0+, BABYSAFE PLUS” (0 to 13 kg [0 to 28 lb.]) and “TOYOTA MINI” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group.
Page 63 1-1. For safe use NOTE: : Adjust the seatback to the most upright position. If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove the head restraint. If the passenger seat is equipped with a vertical height adjuster, it must be placed in the upper most position.
Page 64 1-1. For safe use Child restraint system suitability for various seating positions (with ISOFIX rigid anchors) Information provided in the table shows your child restraint system suitability for various seating positions. 3-door models  Vehicle ISOFIX positions Mass groups Size class Fixture Outboard second seat Right-hand...
Page 65 IUF: Suitable for ISOFIX forward-facing child restraint systems of uni- versal category approved for use in this mass group. IL1: Suitable for “TOYOTA MINI with BASE” (0 to 13 kg [0 to 28 lb.]) and “TOYOTA MIDI” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group.
Page 66 1-1. For safe use 5-door models  Vehicle ISOFIX positions Mass groups Size class Fixture Outboard second seat ISO/L1 Carrycot ISO/L2 ISO/R1 Up to 10 kg (22 lb.) (0 - 9 months) ISO/R1 ISO/R2 Up to 13 kg (28 lb.) ISO/R3 (0 - 2 years) ISO/R2...
Page 67 IUF: Suitable for ISOFIX forward-facing child restraint systems of uni- versal category approved for use in this mass group. IL1: Suitable for “TOYOTA MINI with BASE” (0 to 13 kg [0 to 28 lb.]) and “TOYOTA MIDI” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group.
Page 68  Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 69 1-1. For safe use CAUTION Child restraint precautions   Vehicles without airbag manual on-off switch: Never install a rear-facing child restraint system on the front passenger seat. In the event of an accident, the force of the rapid inflation of the front pas- senger airbag can cause death or serious injury to the child.
Page 70: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts (An ELR belt requires a locking clip) Vehicles for Ukraine, Kazakhstan, Azerbaijan and Georgia: Seat...
Page 71 1-1. For safe use Anchor brackets (for the top strap) An anchor bracket is provided for each second seat. Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing Baby seat/child seat  Adjust the seats as follows: 3-door models ...
Page 72 1-1. For safe use Place the child restraint sys- tem on the second seat fac- ing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 73 1-1. For safe use Place the child restraint sys- tem on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and allow it to retract to put it in lock mode.
Page 74 1-1. For safe use Junior seat  Adjust the seats as follows: 3-door models  Fold the seatback forward and then back to the 1st lock posi- tion (most upright position) until it locks into place. Adjust the seatback to the 5th lock posi- tion.
Page 75 1-1. For safe use Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the buckle. Make sure that the belt is not twisted. Check that the shoulder belt is correctly positioned over the child’s shoulder, and that the lap...
Page 76 1-1. For safe use Installation with ISOFIX rigid anchors (ISOFIX child restraint system) Adjust the seats as follows: 3-door models  Fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Adjust the seat- back to the 5th lock position.
Page 77 If your child restraint sys- tem does not provide a locking clip, you can purchase the following item from any authorized Toyota dealer or repairer, or another duly qualified and equipped professional: Locking clip for child restraint system (Part No.
Page 78 1-1. For safe use CAUTION When installing a junior seat on an outboard second seat (vehicles for  Ukraine, Kazakhstan, Azerbaijan and Georgia) To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child.
Page 79 1-1. For safe use CAUTION When installing a child restraint system   Vehicles without an airbag manual on- off switch: Never install a rear-facing child restraint system on the front pas- senger seat. The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 80 When installing a child restraint system   If child restraint system regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installa- tion. ...
Page 81: Exhaust Gas Precautions
If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible.
Page 82 1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 83 1-2. Theft deterrent system Certifications for the engine immobilizer system  Vehicles without a smart entry & start system  Hereby, Tokai Rika Co., Ltd., declares that this RI-33BTY is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Page 84 1-2. Theft deterrent system LC150_OM_OM60K29E_(EE)
Page 85 1-2. Theft deterrent system LC150_OM_OM60K29E_(EE)
Page 86 1-2. Theft deterrent system Vehicles with a smart entry & start system  Hereby, Toyota Motor Corporation, declares that this TMIMB-2 is in compli- ance with the essential requirements and other relevant provisions of Direc- tive 1999/5/EC. LC150_OM_OM60K29E_(EE)
Page 87 1-2. Theft deterrent system LC150_OM_OM60K29E_(EE)
Page 88 1-2. Theft deterrent system LC150_OM_OM60K29E_(EE)
Page 89 1-2. Theft deterrent system NOTICE To ensure the system operates correctly  Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. LC150_OM_OM60K29E_(EE)
Page 90: Double Locking System
1-2. Theft deterrent system  Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this system have labels on the window glass of both front doors.
Page 91: Alarm
1-2. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set:  A locked door or glass hatch (if equipped) is unlocked or opened in any way other than using the entry function or the wireless remote control.
Page 92 1-2. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm.  Unlock the doors using the entry function or the wireless remote control.  Start the engine. (The alarm will be deactivated or stopped after a few seconds.) ...
Page 93 1-2. Theft deterrent system The battery is recharged or replaced  when the vehicle is locked. (P. 667) Alarm-operated door lock   When the alarm is operating, the doors are locked automatically to prevent intruders.  Do not leave the key inside the vehicle when the alarm is operating, and make sure the key is not inside the vehicle when recharging or replacing the battery.
Page 94 1-2. Theft deterrent system Intrusion sensor and tilt sensor (if equipped)  The intrusion sensor detects intruders or movement in the vehicle.  The tilt sensor detects changes in vehicle inclination, such as when the vehicle is towed away. (vehicles for U.K.) This system is designed to deter and prevent vehicle theft but does not guarantee absolute security against all intrusions.
Page 95 1-2. Theft deterrent system  Canceling and automatic re-enabling of the intrusion sensor and tilt sen- sor (if equipped)  The alarm will still be set even when the intrusion sensor and tilt sensor are canceled.  After the intrusion sensor and tilt sensor are canceled, pressing the engine switch or unlocking the doors using the entry function or wireless remote control will re-enable the intrusion sensor and tilt sensor.
Page 96 1-2. Theft deterrent system Tilt sensor detection considerations (if equipped)  The sensor may trigger the alarm in the following situations:  The vehicle is transported by a ferry, trailer, train, etc. The vehicle is parked in a parking garage. ...
Page 97: 2. Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......98 Gauges and meters ...105 Multi-information display (Type A)......109 Multi-information display (Type B)......114 Fuel consumption information.......122 LC150_OM_OM60K29E_(EE)
Page 98: Warning Lights And Indica Tors
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 99 2. Instrument cluster Vehicles with the multi-information display type B  The units used on the speedometer and some indicators may differ depending on the target region. LC150_OM_OM60K29E_(EE)
Page 100 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Master warning light Open door warning light (P. 598) (P. 597) (if equipped) Brake system warning Seat belt reminder light light (P. 594) (P.
Page 101 There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional.
Page 102 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator “SET” indicator (P. 263) (P. 292, 296) (if equipped) Dynamic radar cruise Headlight high beam control indicator indicator (P. 267) (P.
Page 103 2. Instrument cluster Automatic transmission Toyota parking second start indicator assist-sensor indicator (automatic (P. 254) (P. 312) (if equipped) transmission) 1, 3 Low speed four-wheel Pre-crash safety system drive indicator light warning light (P. 378) (if equipped) BSM (Blind Spot...
Page 104 There may be a malfunction in a system if a light does not turn on, or if the lights do not turn off. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 105: Gauges And Meters
2. Instrument cluster Gauges and meters Vehicles with the multi-information display type A  Vehicles with the multi-information display type B  The units used on the speedometer may differ depending on the tar- get region. LC150_OM_OM60K29E_(EE)
Page 106 2. Instrument cluster Tachometer Displays the engine speed in revolutions per minute Multi-information display Presents the driver with a variety of driving-related data (P. 110, 115) Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven.
Page 107 2. Instrument cluster Changing the display Vehicles with the multi-information display type A  P. 110 Vehicles with the multi-information display type B  Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the button will reset the trip meter.
Page 108 2. Instrument cluster  The meters and display illuminate when Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system  The engine switch is in IGNITION ON mode. ...
Page 109: Multi-Information Display (Type A)
2. Instrument cluster  Multi-information display (Type A) Display contents The multi-information display presents the driver with a variety of driv- ing-related data including the current outside air temperature. Automatic Manual transmission transmission  Outside temperature display (P. 112)  Trip information contents (P.
Page 110 2. Instrument cluster Switching the display Items displayed can be switched by pressing the “ODO/TRIP” but- ton. Trip information contents Odometer  Displays the total distance the vehicle has been driven. Trip meters A and B  Displays the distance the vehicle has been driven since the meter was last reset.
Page 111 2. Instrument cluster Average vehicle speed  Displays the average vehicle speed since the engine was started or the function was reset The function can be reset by pressing the “ODO/TRIP” button for longer than 1 second when the average vehicle speed is displayed. Outside temperature display ...
Page 112 2. Instrument cluster  Eco Driving Indicator (vehicles with an automatic transmission) Eco Driving Indicator Light During Eco-friendly acceleration (Eco driving), Eco Driving Indicator Light will turn on. Eco Driving Indicator Zone Display Suggests Zone of Eco driving with cur- rent Eco driving ratio based on acceler- ation.
Page 113 2. Instrument cluster When disconnecting and reconnecting battery terminals  The following information data will be reset:  Trip meter Average fuel consumption   Average vehicle speed If the trip meter was displayed last, the ODO screen will be displayed after resetting.
Page 114: Multi-Information Display(Type B)
2. Instrument cluster  Multi-information display (Type B) Display contents The multi-information display presents the driver with a variety of driv- ing-related data including the current outside air temperature.  Trip information contents (P. 116) Displays driving range, fuel consumption and other cruising related infor- mation ...
Page 115 2. Instrument cluster Switching the display Menu switch Changes modes to electronic fea- tures control mode, customization mode or back to normal display mode “ENTER” switch Changes trip information items. This switch is also used to turn on/ off electronic features controls and to change customization settings.
Page 116 Refer to the “Off-road Driving Owner’s Manual” Display off  A blank screen is displayed Electronic features control contents Toyota parking assist-sensor (if equipped) (P. 312)  BSM (Blind Spot Monitor) (if equipped) (P. 366)  Second start mode (if equipped) (P. 254) ...
Page 117 2. Instrument cluster Other contents Shift position and shift range (if equipped) (P. 251)  Rear height control air suspension display (if equipped)  Refer to the “Off-road Driving Owner’s Manual” Multi-terrain Select display (if equipped)  Refer to the “Off-road Driving Owner’s Manual” Crawl Control display (if equipped) ...
Page 118 In the following situations, the electronic features control will end automati- cally:  The menu switch is pressed  Toyota parking assist-sensor starts operating (if equipped)  The Crawl Control is operated (if equipped)  The dynamic radar cruise control is operated (if equipped) ...
Page 119 2. Instrument cluster Eco Driving Indicator (vehicles with an automatic transmission)  Eco Driving Indicator Light During Eco-friendly acceleration (Eco driving), Eco Driving Indicator Light will turn on. Eco Driving Indicator Zone Display Suggests Zone of Eco driving with cur- rent Eco driving ratio based on acceler- ation.
Page 120  When “--” or “E” is displayed The system may be malfunctioning. Take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional.  When disconnecting and reconnecting battery terminals ...
Page 121 2. Instrument cluster CAUTION The multi-information display at low temperatures (vehicles with an  automatic transmission) Allow the interior of the vehicle to warm up before using the multi-informa- tion display. At extremely low temperatures, the multi-information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’s shifting and the new gear number appearing on the display.
Page 122: Fuel Consumption Informa Tion
2. Instrument cluster  Fuel consumption information The fuel consumption information can be displayed on the navi- gation system or multimedia system screen. Display the screen Press the “CAR” button, and then select “Trip information” on the screen. Fuel consumption Cruising range Previous fuel consumption per minute...
Page 123 Operation of each component 3-1. Key information Keys........124 3-2. Opening, closing and locking the doors Side doors......130 Back door......140 Glass hatch......147 Smart entry & start system ......153 3-3. Adjusting the seats Front seats......170 Rear seats ......173 Driving position memory ..188 Head restraints ....192 3-4.
Page 124: Keys
3-1. Key information Keys The keys The following keys are provided with the vehicle. Vehicles without a smart entry & start system (type A)  Master keys Valet key Wireless remote controls Operating the wireless remote control function Key number plate LC150_OM_OM60K29E_(EE)
Page 125 3-1. Key information Vehicles without a smart entry & start system (type B)  Master keys Operating the wireless remote con- trol function Valet key Key number plate Vehicles with a smart entry & start system  Electronic keys • Operating the smart entry & start system (P.
Page 126: The Doors
(P. 130) Opens the glass hatch (P. 147) : These settings must be customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Vehicles without a smart entry & start system (type B: 2 switches) ...
Page 127 (P. 130) Opens the glass hatch (P. 147) : These settings must be customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Vehicles with a smart entry & start system  Locks the doors (P. 130)
Page 128 Keys  New genuine keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional using a master key (vehi- cles without a smart entry & start system) or the other key (vehicles with a smart entry &...
Page 129 If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional immediately with all remaining electronic keys that were provided with your vehicle.
Page 130: Side Doors
3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control, key or door lock switch. Locking and unlocking the doors from the outside  Smart entry & start system (if equipped) Carry the electronic key to enable this function.
Page 131 Press and hold to close the windows and moon roof.* Unlocks all the doors Press and hold to open the windows and moon roof.* : These settings must be customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 132 Unlocks all the doors Turn and hold to open the win- dows and moon roof. : These settings must be custom- ized at any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. Vehicles with a smart entry & start system ...
Page 133 3-2. Opening, closing and locking the doors Door lock buzzer  If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle once more.
Page 134 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside  Door lock switch Locks all the doors Unlocks all the doors  Inside lock button Locks the door Unlocks the door The driver’s door and front pas- senger’s door (for some models only) can be opened by pulling the inside handle even if the...
Page 135 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door while pulling the door handle. Vehicles without a smart entry & start system ...
Page 136 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems (if equipped) The following functions can be set or canceled: Function Operation Shift position linked door Shifting the shift lever out of P locks all the locking function doors.
Page 137 3-2. Opening, closing and locking the doors Setting and canceling the functions  To switch between setting and canceling, follow the procedure below. Close all the doors and turn the engine switch to IGNITION ON mode. (Perform step 2 within 20 seconds.) Shift the shift lever to P or N, and press and hold the driver’s...
Page 138 3-2. Opening, closing and locking the doors  Changing the door unlock function setting (vehicles with a smart entry & start system) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. Cancel the intrusion sensor and tilt sensor of the alarm system to prevent unintended triggering of the alarm during the setting change.
Page 139 3-2. Opening, closing and locking the doors Impact detection door lock release system (if equipped)  In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 140: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the fol- lowing procedures. Locking and unlocking the back door from the outside  Smart entry & start system (if equipped) Carry the electronic key to enable this function. Vehicles with back door mounted spare tire ...
Page 141 3-2. Opening, closing and locking the doors Locking and unlocking the back door from the inside  Door lock switch Locks all the doors Unlocks all the doors  Inside lock button (vehicles with longitudinal type third seats) Locks the door Unlocks the door LC150_OM_OM60K29E_(EE)
Page 142 3-2. Opening, closing and locking the doors Opening the back door from the outside Vehicles with back door mounted spare tire  Pull the handle Open the back door The back door can be kept open at a desired position. Vehicles with under floor mounted spare tire ...
Page 143 3-2. Opening, closing and locking the doors Back door child-protector lock (vehicles with longitudinal type third seats) The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock This lock can be set to prevent chil- dren from opening the back door.
Page 144 3-2. Opening, closing and locking the doors CAUTION While driving   Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 145 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. LC150_OM_OM60K29E_(EE)
Page 146 Failure to do so may cause damage to the back door damper stay, resulting in malfunction.  Do not attach any accessories other than genuine Toyota parts to the back door.  Do not lean against, climb on or place luggage on the damper stay, or apply lateral forces to it.
Page 147: Glass Hatch
3-2. Opening, closing and locking the doors  Glass hatch The glass hatch can be opened using the glass hatch opener or wireless remote control. Opening the glass hatch  Glass hatch opener Press the button to pop up the glass hatch. Raise The glass hatch cannot be opened when the back door is...
Page 148 3-2. Opening, closing and locking the doors  Wireless remote control Press and hold the button to open the glass hatch. The glass hatch will pop up. Vehicles without a smart entry Vehicles without a smart entry   & start system (type A) &...
Page 149 3-2. Opening, closing and locking the doors  When opening the glass hatch  Open the glass hatch slowly and carefully. Use the glass hatch opener or wireless remote control when the back door  is closed. Operation signals (when opening with the wireless remote control) ...
Page 150 3-2. Opening, closing and locking the doors CAUTION While driving   Keep the glass hatch closed while driving. If the glass hatch is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 151 Doing so may cause hands to be caught or the glass hatch damper stay to break, causing an accident.  Do not attach any accessories other than genuine Toyota parts to the glass hatch. Such additional weight on the glass hatch may cause the glass hatch to suddenly shut again after it is opened.
Page 152 Do not touch the damper stay rod with gloves or other fabric items.  Do not attach any accessories other than genuine Toyota parts to the glass Damper stays hatch.  Do not place your hand or foot on the damper stay or apply lateral forces to it.
Page 153 3-2. Opening, closing and locking the doors  Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ...
Page 154 3-2. Opening, closing and locking the doors Effective range (areas within which the electronic key is detected)  When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the outside front door handle.
Page 155 3-2. Opening, closing and locking the doors The following table describes circumstances and correction procedures when only alarms are sounded. Alarm Situation Correction procedure Interior alarm An attempt was made to lock Retrieve the electronic pings once and the doors using the smart key from the vehicle exterior alarm...
Page 156 3-2. Opening, closing and locking the doors Battery-saving function  The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ...
Page 157 3-2. Opening, closing and locking the doors Note for the entry function   Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 158 3-2. Opening, closing and locking the doors The lock sensor may not work properly if it comes into contact with ice,  snow, mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock sensor on the lower part of the door handle. Fingernails may scrape against the door during operation of the door han- ...
Page 159 3-2. Opening, closing and locking the doors Electronic key battery depletion   The standard battery life is 1 to 2 years.  If the battery becomes low, an alarm will sound in the cabin when the engine stops. (P. 155, 620) As the electronic key always receives radio waves, the battery will become ...
Page 160 3-2. Opening, closing and locking the doors Certification for the smart entry & start system  Hereby, Toyota Motor Corporation, declares that this TMLF8-15 is in compli- ance with the essential requirements and other relevant provisions of Direc- tive 1999/5/EC.
Page 161 3-2. Opening, closing and locking the doors LC150_OM_OM60K29E_(EE)
Page 162 3-2. Opening, closing and locking the doors LC150_OM_OM60K29E_(EE)
Page 163 3-2. Opening, closing and locking the doors Hereby, Tokai Rika Co., Ltd., declares that this B74EA is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/ The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ LC150_OM_OM60K29E_(EE)
Page 164 3-2. Opening, closing and locking the doors LC150_OM_OM60K29E_(EE)
Page 165 3-2. Opening, closing and locking the doors LC150_OM_OM60K29E_(EE)
Page 166 3-2. Opening, closing and locking the doors Hereby, Tokai Rika Co., Ltd., declares that this B72UA is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/ The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ LC150_OM_OM60K29E_(EE)
Page 167 3-2. Opening, closing and locking the doors LC150_OM_OM60K29E_(EE)
Page 168 3-2. Opening, closing and locking the doors LC150_OM_OM60K29E_(EE)
Page 169 (P. 155) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 170: Front Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Vertical height adjustment lever (driver’s side only) Seatback angle adjustment lever Lumbar support adjustment switch (driver’s side only) Power seat (driver’s side only)  Seat position adjustment switch Vertical height adjustment...
Page 171 3-3. Adjusting the seats Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward and upward to help reduce the risk of whiplash on the seat occupant. Moving a front passenger’s seat for second seat access (3-door models) Getting in the vehicle...
Page 172 3-3. Adjusting the seats  Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 173: Rear Seats
3-3. Adjusting the seats  Rear seats Adjustment procedure Second seats (3-door models) (if equipped)  Seatback angle adjustment lever Second seats (5-door models without third seats and vehicles with  longitudinal type seats) (if equipped) Seatback angle adjustment lever Second seats (5-door models with third seats) (if equipped) ...
Page 174 3-3. Adjusting the seats Third seats (power seat) (if equipped)  Seatback angle adjustment switch Moving a second seat for third seat access (5-door models with third seats) Getting in the vehicle (right side only [left-hand drive vehicles]  or left side only [right-hand drive vehicles]) Pull the seatback angle adjust- ment lever and fold down the seatback.
Page 175 3-3. Adjusting the seats Tumbling the second seats (3-door models) Before tumbling the second seats  Lower the head restraints to the lowest position. Use the seat belt hangers to prevent the belts from being tangled. LC150_OM_OM60K29E_(EE)
Page 176 3-3. Adjusting the seats Tumbling the second seats  Pull the seatback angle lever and fold them down. Pull the seat lock release lever on the back and swing the whole seat up and for- ward. Returning the second seats ...
Page 177 3-3. Adjusting the seats Folding down the second seatbacks (5-door models without third seats and vehicles with longitudinal type seats) Before folding down the second seatbacks  Stow the center seat belt buckle with the hook-and-loop fastener and lower the head restraints to the lowest position.
Page 178 3-3. Adjusting the seats Folding down the second seatbacks (5-door models with third seats) Before folding down the second seatbacks  Lower the head restraints to the lowest position. Folding down second seatbacks  Pull the seatback lock release lever and fold them down. To return the second seatbacks to their original positions, lift them up until they lock.
Page 179 3-3. Adjusting the seats  Folding down second center seatback only (5-door models) Pull the center seatback lock release lever behind the seatback and fold it down. To return the center seatback to its origi- nal position, lift it up until it locks. If you cannot raise the seatback ...
Page 180 3-3. Adjusting the seats Folding the third seats (longitudinal type seat) Folding the third seats  Swing the seat cushion fully Take the holding strap of its pocket on the back of the seatback and secure the seat hooking the strap onto the hook in the back of the seat cushion.
Page 181 3-3. Adjusting the seats Folding down the third seats (manual seat) Before folding down the third seats  Lower the head restraints to the lowest position. Use the seat belt hangers to prevent the belts from being tangled. Folding down the third seats ...
Page 182 3-3. Adjusting the seats From rear door side  Pull the seat cushion lock release lever. The seat cushion is stowed automatically. Pull seatback lock release lever and fold them down. ITN13M096 Returning the third seats  From rear door side, unlock the seatbacks by pulling the lock release lever, and lift them up until they lock.
Page 183 3-3. Adjusting the seats Folding down the third seats (power seat) Left-hand drive vehicles Right-hand drive vehicles   Right seat return switch Right seat fold switch Left seat return switch Left seat fold switch The switches can be operated from both the rear door side and the back door side.
Page 184 3-3. Adjusting the seats Folding down the third seats  Press and hold . Two beeps sound and the seat- back will rise. When operating is completed, two beeps sound again. ITN13M132 Press and hold again. Two beeps sound, the head restraints will fold forward, and the seat will be stowed.
Page 185 3-3. Adjusting the seats  The third power seats can be operated when  The engine switch is off. The shift lever is in P position (vehicles with an automatic transmission) or  the parking brake is applied (vehicles with a manual transmission) with the engine switch in IGNITION ON mode.
Page 186 3-3. Adjusting the seats Press and hold on the rear door side. While holding , press forward on 5 times within 10 seconds and keep holding until 3 beeps sound. The beep will then sound con- tinuously again. Repeat step CAUTION When folding the seatbacks down ...
Page 187 3-3. Adjusting the seats CAUTION When stowing the third seats  Observe the following precautions. Failure to do so may result in death or serious injury.  Check that there is no luggage and that there are no other people around the seat before stowing operation.
Page 188: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seats and steer- ing wheel to make entering and exiting the vehicle easier or to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat and steering wheel) can be memorized and recalled with the touch of a button.
Page 189 3-3. Adjusting the seats Recall procedure  Vehicles with an automatic transmission: Check that the shift lever is in P. Vehicles with a manual transmission: Check that the parking brake is set. Vehicles without a smart entry & start system: Turn the engine switch to the “ON”...
Page 190 3-3. Adjusting the seats Memory recall function (vehicles with a smart entry & start sys- tem) Each electronic key can be registered to recall your preferred driving position. Registering procedure  Record your driving position to button “1” or “2” before performing the following: Carry only the key to which you want to register, and then close the driver’s door.
Page 191 3-3. Adjusting the seats Cancelation procedure  Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing “SET”...
Page 192: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front, second and third manual seats (if equipped) Lock release button Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Third power seats (if equipped) To fold the head restraints, pull the lock release strap.
Page 193 3-3. Adjusting the seats Installing the head restraints (front, second and third manual seats)  Align the head restraint with the installa- tion holes and push it down to the lock position. Adjusting the height of the head restraints  Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 194 3-3. Adjusting the seats CAUTION Head restraint precautions  Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury.  Use the head restraints designed for each respective seat.  Adjust the head restraints to the correct position at all times. ...
Page 195: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Manual adjustment type  Hold the steering wheel and pull the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 196 3-4. Adjusting the steering wheel and mirrors Auto tilt away (power adjustment type) When the engine switch is turned off, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry and exit. Turning the engine switch to ACCESSORY or IGNITION ON...
Page 197 3-4. Adjusting the steering wheel and mirrors CAUTION Caution while driving  Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ...
Page 198: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 199 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 200 3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left LC150_OM_OM60K29E_(EE)
Page 201 3-4. Adjusting the steering wheel and mirrors Folding the mirrors Manual type  Push the mirror back in the direc- tion of the vehicle’s rear. Power type  Press the switch to fold the mir- rors. Press it again to extend them to the original position.
Page 202 3-4. Adjusting the steering wheel and mirrors CAUTION Important points while driving  Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ...
Page 203 3-5. Opening and closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 204 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 205 Door lock linked window operation  The power windows can be opened and closed using the wireless remote control or key if customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 127, 131) ...
Page 206: Moon Roof
3-5. Opening and closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 207 Door lock linked moon roof operation The moon roof can be opened and closed using the wireless remote control or key if customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 127, 131) ...
Page 208 3-5. Opening and closing the windows and moon roof When the moon roof does not close normally  Perform the following procedure:  If the moon roof closes but then re-opens slightly Stop the vehicle. Press and hold “” on the The moon roof will close, re-open and pause for approximately 10 sec- onds.
Page 209 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
Page 210 3-5. Opening and closing the windows and moon roof CAUTION Observe the following precautions. Failing to do so may cause death or serious injury. Opening the moon roof   Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 211 Engine (ignition) switch assist-sensor ....312 (vehicles with a smart entry & start system)..243 Rear view monitor system ......322 Automatic transmission ..251 Toyota parking assist Manual transmission..258 monitor......333 Turn signal lever ....263 Driving assist systems ..360 Parking brake ....264 Diesel Particulate Filter (Blind Spot Monitor)..366...
Page 212: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 240, 243 Driving Automatic transmission  With the brake pedal depressed, shift the shift lever to D. (P. 251) Release the parking brake. (P. 264) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 213 4-1. Before driving Parking the vehicle Automatic transmission  With the shift lever in D, depress the brake pedal. Shift the shift lever to P. (P. 251) Set the parking brake. (P. 264) Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 214 4-1. Before driving Starting off on a steep uphill Automatic transmission  Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. Manual transmission  With the parking brake firmly set and the clutch pedal fully depressed, shift the shift lever to 1.
Page 215 This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drum are replaced. Have any authorized Toyota dealer or repairer, or another duly qualified and equipped professional perform the bedding-down operation.
Page 216 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. When starting the vehicle  On vehicles with an automatic transmission, always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehi- cle from creeping.
Page 217 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. When driving the vehicle   During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 218 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. When driving on slippery road surfaces   Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ...
Page 219 Failure to do so may result in death or serious injury. If you hear a squealing or scraping noise (brake pad wear indicators)  Have the brake pads checked and replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible.
Page 220 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. When the vehicle is parked   Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 221 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. When taking a nap in the vehicle  Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 222 4-1. Before driving NOTICE When driving the vehicle  Automatic transmission   Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque.  Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 223 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have any authorized Toyota dealer or repairer, or another duly qual- ified and equipped professional check the following: ...
Page 224: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: Roof luggage carrier (if equipped) Roof luggage carrier components  Roof rail Cross rail CAUTION  Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ...
Page 225 4-1. Before driving CAUTION Storage precautions  Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or pas- sengers, possibly causing an accident. ...
Page 226  To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. Follow the manufacturer’s instructions and precautions when installing the cross rails or their equivalent.
Page 227: Trailer Towing
Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Ask your local authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details before towing, as there are additional legal requirements in some countries.
Page 228 4-1. Before driving Selecting a trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 229 4-1. Before driving Important points regarding trailer loads Total trailer weight and permissible drawbar load  Total trailer weight Weight of the trailer itself plus the trailer load should be within the maximum towing capacity. Exceeding this weight is danger- ous.
Page 230 The values for towing capacity were derived from testing conducted at sea level. Take note that engine output and towing capacity will be reduced at high altitudes. : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Type A Type B ...
Page 231 100 km/h (62 mph), whichever is lower. Failing to observe this precaution may lead to an accident causing death or serious injury. : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 232 4-1. Before driving Installation positions for the towing hitch/bracket and hitch ball 5-door models  78 mm (3.0 in.) 78 mm (3.0 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 1219 mm (48.0 in.) 137 mm (5.4 in.) 141 mm (5.6 in.) 79 mm (3.1 in.)
Page 233 4-1. Before driving 3-door models  78 mm (3.0 in.) 78 mm (3.0 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 1110 mm (43.7 in.) 142 mm (5.6 in.) 84 mm (3.3 in.) 59 mm (2.3 in.) 327 mm (12.9 in.) 199 mm (7.8 in.)
Page 234 Directly wiring up to your vehicle may damage the electrical system and stop the lights from functioning correctly.  Break-in schedule Toyota recommends that vehicles fitted with new power train components should not be used for towing trailers for the first 800 km (500 miles). LC150_OM_OM60K29E_(EE)
Page 235 4-1. Before driving Safety checks before towing   Check that the maximum load limit for the towing hitch/bracket hitch ball is not exceeded. Bear in mind that the coupling weight of the trailer will add to the load exerted on the vehicle. Also make sure that the total load exerted on the vehicle is within the range of the weight limits.
Page 236 4-1. Before driving CAUTION To avoid accident or injury   Vehicles with the rear height control air suspension: Set the vehicle height to the low mode and turn off the rear height control air suspension to prevent the vehicle height from automatically changing. ...
Page 237 4-1. Before driving Guidance Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: Checking connections between trailer and lights  Stop the vehicle and check the operation of the connection between the trailer and lights after driving for a brief period as well as before starting off.
Page 238 4-1. Before driving Important points regarding stability  Vehicle movement resulting from uneven road surfaces and strong crosswinds will affect handling. The vehicle may also be rocked by passing buses or large trucks. Frequently check behind when mov- ing alongside such vehicles. As soon as such vehicle movement occurs, immediately start to decelerate smoothly by slowly applying the brakes.
Page 239 4-1. Before driving CAUTION Follow all the precautions described in this section. Failure to do so could cause an accident resulting in death or serious injury. Trailer towing precautions   When towing, make sure that none of the weight limits are exceeded. (P.
Page 240 4-2. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) Starting the engine Automatic transmission  Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START”...
Page 241 Push in the key and turn it to the “LOCK” position.  If the engine does not start The engine immobilizer system may not have been deactivated. (P. 83) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 242  Do not race a cold engine.  If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. LC150_OM_OM60K29E_(EE)
Page 243 4-2. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Automatic transmission ...
Page 244 4-2. Driving procedures Manual transmission  Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the clutch pedal. The engine switch indicator will turn green. If the indicator does not turn green, the engine cannot be started. Press the engine switch.
Page 245 4-2. Driving procedures Stopping the engine Automatic transmission  Stop the vehicle. Shift the shift lever to P. Set the parking brake. (P. 265) Press the engine switch. Release the brake pedal and check that the indicator on the engine switch is off.
Page 246 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal (vehicles with an automatic transmission) or clutch pedal (vehi- cles with a manual transmission) released. (The mode changes each time the switch is pressed.) The emergency flashers can be used.
Page 247 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P (Vehicles with an automatic transmission) If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
Page 248  When the engine switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped profes- sional immediately.  If the electronic key battery is depleted P.
Page 249 4-2. Driving procedures CAUTION When starting the engine  Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ...
Page 250 Do not race a cold engine. If the engine becomes difficult to start or stalls frequently, have your vehi-  cle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. Symptoms indicating a malfunction with the engine switch ...
Page 251: Automatic Transmission
4-2. Driving procedures  Automatic transmission Shifting the shift lever Standard type  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 252 4-2. Driving procedures Multi-mode type  While the engine switch is in IGNITION ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped. LC150_OM_OM60K29E_(EE)
Page 253 4-2. Driving procedures Shift position purpose Purpose and condition Shift position Standard type Multi-mode type Parking the vehicle/starting the engine Reversing Condition in which the power is not transmitted Normal driving S mode driving — (P. 256) Position for engine —...
Page 254 4-2. Driving procedures Selecting the second start mode Use second start mode for accelerating and driving on slippery road surfaces such as snow. Vehicles with the multi-information display type A  Turn the “2nd STRT” button on. Press the button again to cancel second start mode.
Page 255 4-2. Driving procedures Press the “ENTER” switch to change to “ON”. The “2nd STRT” indicator will be displayed. Each pressing of the switch turns second start mode on and off. Press the menu switch to change to the normal display. Changing shift ranges in S mode (multi-mode type) When the shift lever is in the S position, the shift lever can be oper- ated as follows:...
Page 256 4-2. Driving procedures  Downshifting restrictions (standard type) The maximum allowable speeds are as follows. Maximum speed Downshifting Transfer position km/h (mph) 105 (65) 3  2 35 (21) 50 (31) 2  1 10 (6)  Driving on a downhill On declines, there may be case where the vehicle shifts down automatically to obtain engine braking.
Page 257 S (multi-mode type) This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 258: Manual Transmission
4-2. Driving procedures  Manual transmission Shifting the shift lever 5-speed transmission  Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 259 4-2. Driving procedures 6-speed transmission  Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Gear Shift Indicator (if equipped) The Gear Shift Indicator display is a guide to help the driver achieve improved fuel economy and reduced exhaust emissions within limits of engine performance.
Page 260 4-2. Driving procedures  Gear Shift Indicator display  The Gear Shift Indicator will not be displayed when the four-wheel drive con- trol switch is in L4.  The Gear Shift Indicator may not be displayed when your foot is placed on the clutch pedal.
Page 261 4-2. Driving procedures 6-speed transmission (5-door models)  Maximum speed (km/h [mph]) Shift position Transfer position Transfer position 38 (24) 15 (9) 77 (48) 30 (19) 105 (65) 41 (25) 131 (81) 51 (32) 157 (98) 61 (38) 6-speed transmission (3-door models) ...
Page 262 4-2. Driving procedures NOTICE To prevent damage to the transmission   Do not shift the shift lever to R without depressing the clutch pedal.  Shift the lever to R only when the vehicle is stationary. LC150_OM_OM60K29E_(EE)
Page 263: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The turn signal lever can be used to show the following intentions of the driver: Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 264: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. To release the parking brake, slightly raise the lever and lower it completely while press- ing the button.  Usage in winter time P.
Page 265 A) or the DPF system warning message “DPF FULL ENGINE SERVICE REQUIRED” appears on the dis- play (vehicles with the multi-information display type B), have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, immediately. (P. 594, 607) ...
Page 266 REQUIRED” appears on the display (vehicles with the multi-information dis- play type B). In this event, damage may be caused to the vehicle or an acci- dent may occur. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, immediately.
Page 267: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: Vehicles without day- time running light sys- tem: Off. Vehicles with daytime running light system:...
Page 268 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 269 4-3. Operating the lights and wipers Guide to dial settings  Vehicle category M1  Occupancy and luggage load conditions Dial position 9-seat 7-seat Occupants Luggage load models models Driver only, or driver and one passenger in None the front seat Driver, front passen- ger and all passen- None...
Page 270 4-3. Operating the lights and wipers : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. : KDJ150L-GKFEY, KDJ150L-GKAEY and GRJ150L-GKAEK models : TRJ150L-GKPEK and TRJ150L-GKMEK models : TX and TXL grades with a sub fuel tank of KDJ150L-GKFEY,...
Page 271 4-3. Operating the lights and wipers Vehicle category M1  Occupancy and luggage load conditions Dial position 5-door, 3-door, Occupants Luggage load 5-seat 5-seat models models Driver only, or driver and one passenger in None the front seat Driver, front passen- ger and all passen- None gers in the rear seats...
Page 272 4-3. Operating the lights and wipers : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. : TX and TXL grades of KDJ150R-GKAEY model, and TXL grade of the following models:...
Page 273 Driver Full luggage loading :To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. :TX grade without a spare tire of KDJ155L-GJAEYW model, and TX grade with a spare tire and TXL grade of the following models:...
Page 274 4-3. Operating the lights and wipers  Daytime running light system (if equipped) Vehicles with LED headlights: To make your vehicle more visible to other driv- ers, the front position lights turn on automatically whenever the engine is started. Vehicles with halogen headlights: To make your vehicle more visible to other drivers, the headlights (at a reduced intensity) and tail lights turn on automati- cally whenever the engine is started.
Page 275 4-3. Operating the lights and wipers Type B   When the light switch is in : All lights turn off automatically if the engine switch is turned to ACCESSORY mode or turned off and a door or the glass hatch (if equipped) is opened and closed.
Page 276  If the automatic headlight leveling system warning light flashes (if equipped) It may indicate a malfunction in the system. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Light reminder buzzer (if equipped) A buzzer sounds when the engine switch is turned off or turned to ACCES- SORY mode and the driver’s door is opened while the tail lights remain on.
Page 277: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Front and rear fog light switch  Turns the front and rear fog lights off Turns the front fog lights Turns both front and rear fog lights on...
Page 278 4-3. Operating the lights and wipers Rear fog light switch  Turns the rear fog lights off Turns the rear fog lights on Releasing the switch ring returns it Fog lights can be used when  Vehicles with front and rear fog lights ...
Page 279: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Intermittent windshield wipers with interval adjuster  Intermittent operation Low speed operation High speed operation Temporary operation LC150_OM_OM60K29E_(EE)
Page 280 4-3. Operating the lights and wipers Wiper intervals can be adjusted when intermittent operation is selected. Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts.
Page 281 4-3. Operating the lights and wipers Rain-sensing windshield wipers  Rain-sensing operation (“AUTO”) Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wip- ers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain vol- ume and vehicle speed.
Page 282 4-3. Operating the lights and wipers The sensor sensitivity can be adjusted when “AUTO” is selected. Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation The wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to prevent dripping.) Vehicles with headlight cleaners: If the headlights are on, the headlight...
Page 283 4-3. Operating the lights and wipers  The windshield wiper and washer can be operated when Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system ...
Page 284 4-3. Operating the lights and wipers If no windshield washer fluid sprays  Check that the washer nozzles are not blocked if there is washer fluid in the windshield washer fluid reservoir. CAUTION  Caution regarding the use of windshield wipers in “AUTO” mode (vehi- cles with rain-sensing windshield wipers) The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in “AUTO”...
Page 285: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer. Intermittent operation Normal operation Washer/wiper dual opera- tion Washer/wiper dual opera- tion  The rear window wiper and washer can be operated when ...
Page 286: Headlight Cleaner Switch
4-3. Operating the lights and wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights.  The headlight cleaners can be operated when Vehicles without a smart entry & start system ...
Page 287 4-3. Operating the lights and wipers Windshield washer linked operation  Vehicles without a smart entry & start system  When the windshield washer is operated with the engine switch is in the “ON” position and the headlight on, the headlight cleaners will operate once. (P.
Page 288 Diesel fuel that contains 50 ppm or less of sulfur and has a cetane number of 48 or higher. : To determine whether or not your vehicle has a DPF system, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 289 Use of ethanol blended gasoline in a gasoline engine  Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10 %. Make sure that the ethanol blended gasoline to be used has a Research octane number that follows the above.
Page 290 4-4. Refueling CAUTION When refueling  Observe the following precautions to prevent fuel overflowing from the fuel tank:  Securely insert the fuel nozzle into the fuel filler neck.  Stop filling the tank after the fuel nozzle automatically clicks off. ...
Page 291 CAUTION  When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 292: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 293 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 294 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 295 4-5. Using the driving support systems CAUTION To avoid operating the cruise control by mistake  Switch the cruise control off using the “ON-OFF” button when not in use.  Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 296: Dynamic Radar Cruise Con Trol
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-vehicle distance control. In vehicle-to-vehicle dis- tance control mode, the vehicle automatically accelerates or deceler- ates in order to maintain a set following distance from vehicles ahead. Display Set speed Indicators...
Page 297 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Dynamic radar cruise control indi- cator will come on. Press the button again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set...
Page 298 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 299 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance Pressing the button changes the Preceding vehicle vehicle-to-vehicle distance as fol- mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 300 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the cruise control. The speed setting is also canceled when the brakes are applied. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 301 4-5. Using the driving support systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehi- cle-to-vehicle distance can also be set by operating the vehicle-to- vehicle distance control.
Page 302 4-5. Using the driving support systems Approach warning When your vehicle is too close to a vehicle ahead, and sufficient auto- matic deceleration via the cruise control is not possible, the display will flash and the buzzer will sound to alert the driver. An example of this would be if another driver cuts in front of you while you are follow- ing a vehicle.
Page 303 4-5. Using the driving support systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed control mode is selected, your vehicle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 304 Bad weather causes the detection function to become extremely unstable. If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. LC150_OM_OM60K29E_(EE)
Page 305 4-5. Using the driving support systems Automatic cancelation of constant speed control  The cruise control will stop maintaining the vehicle speed in the following situ- ations:  Actual vehicle speed is more than approximately 16 km/h (10 mph) below the set vehicle speed.
Page 306 4-5. Using the driving support systems Certification  The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: http://www.globaldenso.com/en/products/oem/index.html#2 LC150_OM_OM60K29E_(EE)
Page 307 4-5. Using the driving support systems LC150_OM_OM60K29E_(EE)
Page 308 4-5. Using the driving support systems CAUTION Before using dynamic radar cruise control  Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 309 4-5. Using the driving support systems CAUTION Situations unsuitable for dynamic radar cruise control  Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 310 4-5. Using the driving support systems CAUTION Conditions under which the vehicle-to-vehicle distance control may  not function correctly Apply the brakes as necessary in the following conditions as the radar sen- sor may not be able to correctly detect vehicles ahead, and a fatal or seri- ous accident may result: ...
Page 311 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 312: Toyota Parking Assist-Sen Sor
Front center sensors equipped) Rear corner sensors Rear center sensors Toyota parking assist-sensor switch 4 sensor type  Turns Toyota parking assist-sen- sor on/off When on, the indicator light come on and the buzzer sounds to inform the driver that the system is opera- tional.
Page 313 4-5. Using the driving support systems 8 sensor type  Display the Toyota parking assist-sensor on/off screen. Press the menu switch. multi-information dis- play will change modes to electronic features control mode. Press the “ENTER” switch upwards or downwards until...
Page 314 4-5. Using the driving support systems Display When the sensors detect an obstacle, the following indicator or dis- plays inform the driver of the position and distance to the obstacle. Toyota parking assist-sensor indicator (if equipped)  Vehicle indicator Rear corner indicator...
Page 315 4-5. Using the driving support systems Navigation system or multimedia system screen (if equipped)  Toyota parking assist-sensor display When the rear view monitor system , Toyota parking assist monitor or Multi-terrain Moni- is not displayed. A graphic is automatically dis- played when obstacle detected.
Page 316 4-5. Using the driving support systems Sensor detection display, obstacle distance Distance display  Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Insert Front corner Rear corner sen- Indicator Display display sensor / front sor / rear center center sensor sensor...
Page 317 4-5. Using the driving support systems : Except for 4 sensor type : Multi-information display : Navigation system or multimedia system screen Buzzer operation and distance to an obstacle  A buzzer sounds when the sensors are operating.  The buzzer sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.
Page 318 Select “Vehicle” on the screen. Select the desired item.  The buzzer sound volume can be adjusted.  On or off can be selected for Toyota parking assist-sensor dis- play.  Front or rear center sensors display and tone indication can be set.
Page 319 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of clothing.
Page 320 If the vehicle indicator remains on while the rear corner and rear center indi-  cators flash and the malfunction beep sounds for approximately 8 seconds, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
Page 321 Have the vehicle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  A beep does not sound when you turn the Toyota parking assist-sensor  If the area around a sensor collides with something, or is subjected to strong impact.
Page 322 4-5. Using the driving support systems  Rear view monitor system The rear view monitor system assists the driver by displaying guide lines and an image of the view behind the vehicle while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 323 The line shows distance behind the vehicle, a point approximately 1 m (3 ft.) from the edge of the bumper. Toyota parking assist-sensor display (if equipped) If an obstacle is detected while the Toyota parking assist-sensor is on, a display is shown at the top right corner of the screen. LC150_OM_OM60K29E_(EE)
Page 324 4-5. Using the driving support systems Rear view monitor system precautions Area displayed on screen  The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted, refer to the “Naviga- tion system owner’s manual”.
Page 325 4-5. Using the driving support systems Rear view monitor system camera  Vehicles with back door Vehicles with under floor   mounted spare tire mounted spare tire  Using the camera If the camera lens becomes dirty, it cannot transmit a clear image.
Page 326 4-5. Using the driving support systems  When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 327 4-5. Using the driving support systems  When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixation guide lines on the screen and the actual dis- A margin of error...
Page 328 4-5. Using the driving support systems  Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 329 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Likely cause Solution ...
Page 330 4-5. Using the driving support systems Likely cause Solution  The fixed guide lines are very far out of alignment Have the vehicle inspected by any The camera position is out of align- authorized Toyota dealer or repairer, ment. another duly qualified equipped professional.
Page 331 4-5. Using the driving support systems CAUTION When using the rear view monitor system  The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 332  Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible.
Page 333: Toyota Parking Assist Moni Tor
4-5. Using the driving support systems  Toyota parking assist monitor The parking assist monitor assists the driver by displaying an image of the view behind the vehicle while backing up, for exam- ple while parking. The parking assist monitor assists with the following 2 backing-up operations: •...
Page 334 Display mode switch screen button Switches the display mode. (P. 336) Toyota parking assist-sensor display If an obstacle is detected while the Toyota parking assist-sensor is on, a display is shown in the top right corner of the screen. Parking mode switch screen button...
Page 335 4-5. Using the driving support systems Using the system when perpendicular parking  Use any of the following modes when perpendicular parking (for example, when parking in a garage). Each time you select the dis- play mode switch screen but- ton, the display mode switches in the following order: Estimated course...
Page 336 4-5. Using the driving support systems  Estimated course line display mode (P. 339) Estimated course lines are displayed which move in accordance with the opera- tion of the steering wheel.  Parking assist guide line display mode (P. 341) The steering wheel return points (parking assist guide lines) are displayed.
Page 337 4-5. Using the driving support systems Using the system when parallel parking  Screen display beep sounds provide an estimation of the point at which you should turn the steering wheel when parallel parking. If the position the vehicle is to be parked in is narrower than usual, narrow mode can be used.
Page 338 4-5. Using the driving support systems Perpendicular parking (estimated course line display mode) Screen description  Vehicle width extension guide line The line indicates a guide path when the vehicle is being backed straight up. The displayed width is wider than the actual vehicle width. The line aligns with the estimated course lines when the steering wheel is straight.
Page 339 4-5. Using the driving support systems Parking operation  When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Turn the steering wheel so that the estimated course lines are within the parking...
Page 340 4-5. Using the driving support systems Once the vehicle width extension guide lines and the parking space lines are parallel, straighten the steering wheel and back up slowly until the vehicle has completely entered the parking space. Stop the vehicle in an appropriate place, and finish parking. Perpendicular parking (parking assist guide line display mode) Screen description ...
Page 341 4-5. Using the driving support systems Parking operation  When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Back up until the parking assist guide line meets the edge of the left-hand divid-...
Page 342 4-5. Using the driving support systems Parallel parking Vehicle movement procedure  Approx. 1 m (3 ft.) Keeping parallel with the road, stop the vehicle leaving a gap of approximately 1 m (3 ft.) between your vehicle and the parked vehicle (Step in “Parking operation”).
Page 343 4-5. Using the driving support systems Parking operation  The following example describes the procedure for pulling into a parking space on the right. For pulling into a parking space on the left, substitute left for right and vice versa in all steps. Stop the vehicle in the position as described below, and straighten the steering wheel.
Page 344 4-5. Using the driving support systems With the steering wheel straight, back up slowly to a position at which the black and yellow vertical pole just overlaps the rear end of the parked vehicle. Then stop the vehicle. Black and yellow vertical pole Back the vehicle up to here...
Page 345 4-5. Using the driving support systems Turn the steering wheel with the vehicle stopped until the blue outline meets the desired parking space. Blue outline Black and yellow vertical pole Extended line If the extended line from the blue outline is displayed, the parallel parking assist is oper- ational.
Page 346 4-5. Using the driving support systems A curved blue line will appear on the screen. Keep the steering wheel in its current position and back up slowly. Stop when the curved blue line meets the corner of the desired parking space. Curved blue line Back up keeping the steer- ing wheel in its current...
Page 347 If Toyota parking assist-sensor detects an object while you attempt to park in a parking space on the left, the black and yel- low vertical pole could be obscured by Toyota parking assist- sensor display. In this event, turn Toyota parking assist-sensor switch off (P.
Page 348 4-5. Using the driving support systems Narrow mode  If the position the vehicle is to be parked in is narrower than usual, narrow mode can be used. Normal mode Narrow mode The engine switch is turned off when the parking assist monitor is canceled with narrow mode, the caution screen is displayed first when the parallel parking...
Page 349 4-5. Using the driving support systems  Operating narrow mode Select while in parallel parking assist mode. Confirm the warning on the caution screen. If you agree, select “I Agree”. To cancel narrow mode, select When the system is switched to narrow mode, the indicator on will be turned on.
Page 350 4-5. Using the driving support systems Toyota parking assist monitor precautions Area displayed on screen  The parking assist monitor dis- plays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted, refer to the “Naviga-...
Page 351 4-5. Using the driving support systems Toyota parking assist monitor camera  Vehicles with back door Vehicles with under floor   mounted spare tire mounted spare tire  Using the camera If the camera lens becomes dirty, it cannot transmit a clear image.
Page 352 4-5. Using the driving support systems  When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 353 4-5. Using the driving support systems  When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the guide lines on the screen and the actual distance/course on A margin of error...
Page 354 4-5. Using the driving support systems  Distance guidelines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 355 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Likely cause Solution ...
Page 356 4-5. Using the driving support systems Likely cause Solution  The guide lines are very far out of alignment Have the vehicle inspected by any The camera position is out of align- authorized Toyota dealer or repairer, ment. another duly qualified equipped professional.
Page 357 4-5. Using the driving support systems CAUTION When using the Toyota parking assist monitor system  The parking assist monitor is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 358 Estimated course line display mode: If the steering wheel is straight and the vehicle width extension guide lines and the estimated course lines are not in alignment, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 359  Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible.
Page 360: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 361 4-5. Using the driving support systems  Hill-start assist control (if equipped) Refer to the “Off-road Driving Owner’s Manual”  KDSS (Kinetic Dynamic Suspension System) (if equipped) Refer to the “Off-road Driving Owner’s Manual”  PCS (Pre-Crash Safety system) (if equipped) P.
Page 362 4-5. Using the driving support systems Disabling the TRC/VSC/Trailer Sway Control systems If the vehicle gets stuck in fresh snow or mud, the TRC/VSC/Trailer Sway Control systems may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 363 The system judges from the vehicle deceleration that is not a sudden brak- ing operation.  If the slip indicator comes on... It may indicate a malfunction in the TRC or VSC/Trailer Sway Control system. Consult any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 364 4-5. Using the driving support systems CAUTION The ABS does not operate effectively when   The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road).  The vehicle hydroplanes while driving at high speed on the wet or slick road.
Page 365 The ABS, TRC and VSC/Trailer Sway Control will not function correctly if different tires are installed on the vehicle. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further information when replacing tires or wheels.
Page 366: The Blind Spot Monitor Func
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions;  The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ...
Page 367 4-5. Using the driving support systems The Blind Spot Monitor on/off screen and indicator. The Blind Spot Monitor system can be turned on/off on the multi-informa- tion display. When the system is set to on, the indicator illuminates in the meter.
Page 368 4-5. Using the driving support systems Turning the Blind Spot Monitor system on Display the Blind Spot Monitor on/off screen. Press the menu switch. multi-information dis- play will change modes to electronic features control mode. Press the “ENTER” switch upwards or downwards until “BSM”...
Page 369 4-5. Using the driving support systems  The outside rear view mirror indicators visibility When under strong sunlight, the outside rear view mirror indicator may be dif- ficult to see.  Rear Crossing Traffic Alert buzzer hearing Rear Crossing Traffic Alert function may be difficult to hear over loud noises such as high audio volume.
Page 370 4-5. Using the driving support systems For vehicles sold in Europe  The latest “DECLARATION of CONFORMITY” (DoC) is available at the following: DoC address: http://continental.automotive-approvals.de/index.php?produkt=SRR2-A LC150_OM_OM60K29E_(EE)
Page 371 4-5. Using the driving support systems LC150_OM_OM60K29E_(EE)
Page 372 If the sensor or surrounding area is subject to a strong impact, always have the area inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 373 4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 374 4-5. Using the driving support systems  The Blind Spot Monitor function is operational when  The Blind Spot Monitor system turned on. Vehicle speed is greater than approximately 16 km/h (10 mph).   The Blind Spot Monitor function will detect a vehicle when ...
Page 375: Tion
4-5. Using the driving support systems Instances of the Blind Spot Monitor function unnecessarily detecting a vehi-  cle and/ or object may increase under the following conditions: • When there is only a short distance between your vehicle and a guardrail, wall etc.
Page 376 4-5. Using the driving support systems The Rear Crossing Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 377 4-5. Using the driving support systems Conditions under which the Rear Crossing Traffic Alert function will not  detect a vehicle The Rear Crossing Traffic Alert function is not designed to detect the follow- ing types of vehicles and/or objects. ...
Page 378 4-5. Using the driving support systems  PCS (Pre-Crash Safety system) When the radar sensor detects possibility of a frontal collision, the pre-crash safety system such as the brakes and seat belts are automatically engaged to lessen impact as well as vehicle damage.
Page 379 4-5. Using the driving support systems Disabling pre-crash braking (if equipped) Pre-crash braking disabled Pre-crash braking enabled The “PCS” warning light turns on when pre-crash braking is dis- abled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and determines whether a collision is imminent based on the position, speed, and...
Page 380 4-5. Using the driving support systems  The pre-crash safety system is operational when  Pre-crash seat belts (situation 1): • Vehicle speed is greater than about 5 km/h (4 mph). • The speed at which your vehicle is approaching the obstacle or the vehi- cle running ahead of you is greater than about 30 km/h (19 mph).
Page 381 4-5. Using the driving support systems Conditions that may trigger the system even if there is no possibility of a  collision  When there is an object by the roadside at the entrance to a curve  When passing an oncoming vehicle on a curve When driving over a narrow iron bridge ...
Page 382 4-5. Using the driving support systems Situations in which the pre-crash safety system does not function prop-  erly The system may not function effectively in situations such as the following:  On roads with sharp bends or uneven surfaces If a vehicle suddenly moves in front of your vehicle, such as at an intersec- ...
Page 383 4-5. Using the driving support systems Certification  The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: http://www.globaldenso.com/en/products/oem/index.html#2 LC150_OM_OM60K29E_(EE)
Page 384 4-5. Using the driving support systems LC150_OM_OM60K29E_(EE)
Page 385 4-5. Using the driving support systems CAUTION Limitations of the pre-crash safety system  Do not overly rely on the pre-crash safety system. Always drive safely, tak- ing care to observe your surroundings and checking for any obstacles or other road hazards. Failure to do so may cause an accident resulting in death or serious injury.
Page 386 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 387: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Pre-winter preparations  Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 388 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle (in the winter time or in the cold lati- tudes) Park the vehicle and move the shift lever to P (automatic transmis- sion) or 1 or R (manual transmission) without setting the parking...
Page 389 4-6. Driving tips Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road. Always check local regulations before installing chains. Tire chain installation  Observe the following precautions when installing and removing chains: ...
Page 390 Repairing or replacing snow tires (vehicles with the tire pressure warn-  ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 391 Audio system 5-1. Basic Operations 5-7. “SETUP” menu Audio system types ...392 Using the “SETUP” menu (“Bluetooth ” menu)..431 Steering wheel audio switches......393 Using the “SETUP” menu (“TEL” menu) ....435 AUX port/USB port ....394 ® 5-8. Bluetooth Audio 5-2. Using the audio system ®...
Page 392: Audio System Types
5-1. Basic Operations  Audio system types Vehicles with a navigation system or a multimedia system  Refer to the “Navigation system owner’s manual”. Vehicles without a navigation system or a multimedia system  CD player with AM/FM radio This illustration is for left-hand drive vehicles. Some button positions are reversed for right-hand drive vehicles.
Page 393: Steering Wheel Switches
5-1. Basic Operations  Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 394: Aux Port/Usb Port
5-1. Basic Operations AUX port/USB port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Press the “MODE” button to select “iPod”, “USB” or “AUX”. Connecting using the AUX port/USB port iPod ...
Page 395 5-2. Using the audio system Optimal use of the audio system The sound quality, volume balance and ASL settings can be adjusted. Displays the “SETUP” menu/ Selecting the mode Changes the following settings • Sound quality and volume balance P. 397 The sound quality and balance setting can be changed to pro- duce the best sound.
Page 396 5-2. Using the audio system Using the audio control function Changing sound quality modes  Press the tune/scroll knob. Turn the knob to select “Sound Setting”. Press the knob. Turn the knob as corresponds to the desired mode. “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” can be selected. Press the knob.
Page 397 5-3. Using the radio Radio operation Press the “MODE” button until “AM” or “FM” is displayed. AM/FM mode button Station selectors Tune/scroll knob Displaying the station list (FM Press: AF/region code/TA mode only) mode setup Power/volume knob Turn: Adjusting the frequency Press: Turning the audio sys- Seeking the frequency tem on or off...
Page 398 5-3. Using the radio Using the station list Updating the station list  Press (LIST). The station list will be displayed. Press (UPDATE) to update the list. “Updating” is displayed while the searching is in process, and then avail- able stations will be listed on the display. To cancel the updating process, press (BACK).
Page 399 5-3. Using the radio Traffic information  Press the tune/scroll knob. Turn the knob to “RADIO” and press the knob. Turn the knob to “FM TA” mode. Press the knob to select “ON” or “OFF”. TP mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received.
Page 400 5-3. Using the radio  EON (Enhanced Other Network) system (for traffic announcement func- tion) If the RDS station (with EON data) you are listening to is not broadcasting a traffic information program and the audio system is in the TA (traffic announcement) mode, the radio will be switched automatically to a station broadcasting a traffic information program in the EON AF list when traffic information begins.
Page 401 5-4. Playing an audio CD and MP3/WMA discs CD player operation Insert a disc, press the “MODE” button to begin listening to a Disc eject Repeat play Changing the audio source/ Selecting a folder (MP3/WMA playback discs only) Tune/scroll knob Displaying track/folder list Selecting a track/file Displaying text message...
Page 402 5-4. Playing an audio CD and MP3/WMA discs Using the CD player Selecting a track  Turn the tune/scroll knob or press the “<” or “>” button of “SEEK TRACK” to move up or down until the desired track number is dis- played.
Page 403 5-4. Playing an audio CD and MP3/WMA discs Playing back MP3 and WMA discs Selecting folders one at a time  Press (<FOLDER) or (FOLDER>) to select the desired folder. Selecting a folder and file from folder list  Press (LIST).
Page 404 If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Message...
Page 405 5-4. Playing an audio CD and MP3/WMA discs If a CD is left inside the CD player or in the ejected position for extended  periods The CD may be damaged and may not play properly.  Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. ...
Page 406 5-4. Playing an audio CD and MP3/WMA discs Compatible media  Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 407 5-4. Playing an audio CD and MP3/WMA discs MP3 and WMA playback  When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 408 5-4. Playing an audio CD and MP3/WMA discs NOTICE Discs and adapters that cannot be used  Do not use the following types of discs. Also, do not use 8 cm (3 in.) disc adapters, DualDiscs or printable discs. Doing so may damage the player and/or the disc insert/eject function. ...
Page 409: Listening To An Ipod
5-5. Using an external device Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Press the “MODE” button until “iPod” is displayed. Connecting an iPod P. 395 Control panel Changing the audio source/ iPod menu mode, playback playback Displaying song list...
Page 410 5-5. Using an external device Selecting a play mode Press (MENU) to select iPod menu mode. Turning the tune/scroll knob clockwise changes the play mode in the following order: “Playlists” “Artists” “Albums” “Songs” “Podcasts”  “Genres” “Composers” “Audiobooks” Press the knob to select the desired play mode. Play mode list ...
Page 411 5-5. Using an external device Selecting songs Turn the tune/scroll knob or press the “<” or “>” button of “SEEK TRACK” to select the desired song. Selecting a song from the song list Press (LIST). The song list will be displayed. Turn the tune/scroll knob to select a song.
Page 412 5-5. Using an external device  About iPod  “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance stan- dards.
Page 413 If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Message...
Page 414 5-5. Using an external device Compatible models  ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system.  Made for • iPod touch (5th generation) •...
Page 415 5-5. Using an external device CAUTION While driving  Do not connect iPod or operate the controls. Doing so may cause an acci- dent, resulting in death or serious injury. NOTICE  To prevent damage to iPod or its terminal ...
Page 416 5-5. Using an external device Listening USB memory device Connecting a USB memory enables you to enjoy music from the vehicle speakers. Press the “MODE” button until “USB” is dis- played. Connecting a USB memory P. 395 Control panel Changing the audio source/ Selecting a folder playback Displaying folder list...
Page 417 5-5. Using an external device Selecting a folder Selecting folders one at a time  Press (<FOLDER) or (FOLDER>) to select the desired folder. Selecting a folder and file from folder list  Press (LIST). The folder list will be displayed. Turn and press the tune/scroll knob to select a folder and file.
Page 418 5-5. Using an external device Fast-forwarding and rewinding files Press and hold the “<” or “>” button of “SEEK TRACK”. Random play Pressing (RDM) changes modes in the following order: Folder randomAll folder randomOff Repeat play Pressing (RPT) changes modes in the following order: Off File repeatFolder repeat : Available except when RDM (random play) is selected...
Page 419 If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Message...
Page 420 5-5. Using an external device MP3 and WMA files  MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 421 5-5. Using an external device File names  The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma.  ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
Page 422 5-5. Using an external device Playback  • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of playback may result.
Page 423: Using The Aux Port
5-5. Using an external device Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Press the “MODE” button until “AUX” is displayed. Connecting a portable player P.
Page 424 5-6. Using Bluetooth® devices  ® Bluetooth audio/phone  The following can be performed using Bluetooth wireless com- munication:  ® Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication.
Page 425 5-6. Using the radio Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio system (P. 431) ® 2. Connect the registered Bluetooth device to be used (P. 431, 432) 3. Set automatic connection of the device (P.
Page 426 5-6. Using Bluetooth® devices Audio unit Power/volume knob Press: Turning the audio sys- tem on or off Turn: Adjusting the volume ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc. is displayed. Lower-case characters and special characters may not be dis- played.
Page 427 5-6. Using the radio ® Menu list of the Bluetooth audio/phone To enter a menu, press the tune/scroll knob and navigate menus by using the knob. First menu Second menu Third menu Operation details Registering “Pairing” ® Bluetooth device Listing the registered “List phone”...
Page 428 5-6. Using Bluetooth® devices First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
Page 429 5-6. Using Bluetooth® devices Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone, or portable digital audio player (portable player). ® Operating Bluetooth phone using the steering wheel switches Volume The voice guidance volume cannot be adjusted using this button.
Page 430 5-6. Using Bluetooth® devices ® Registering a Bluetooth device  Before using the Bluetooth audio/phone, it is necessary to reg-  ister a Bluetooth device in the system. You can register up to 5  Bluetooth devices. ® How to register a Bluetooth device Press the tune/scroll knob and select “Bluetooth ”...
Page 431 5-7. “SETUP” menu Using the “SETUP” menu (“Bluetooth*” menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: Registering a portable player Select “Pairing” using the tune/scroll knob (P. 428), and perform the procedure for registering a portable player.
Page 432 5-7. “SETUP” menu Listing the registered portable players Select “List Audio” using the tune/scroll knob. (P. 428) The list of registered portable players will be displayed.  Connecting the registered portable player to the audio system Select the name of the portable player to be connected using the tune/scroll knob.
Page 433 5-7. “SETUP” menu Changing the passkey Select “Passkey” using the tune/scroll knob. (P. 428) Select a 4 to 8-digit passkey using the knob. Input the number 1 digit at a time. When the entire number to be registered as a passkey has been input, press (ENTER).
Page 434 5-7. “SETUP” menu Initialization Select “Initialize” using the tune/scroll knob. (P. 428)  Initializing the sound settings Select “Sound setting” using the tune/scroll knob and press (YES). For details about sound settings: P. 436  Initializing the device information Select “Car device info” using the tune/scroll knob and press (YES).
Page 435 5-7. “SETUP” menu Using the “SETUP” menu (“TEL” menu) Adding a new phone number Select “Add contacts” using the tune/scroll knob. (P. 428)  Transferring all contacts from the cellular phone Select “Overwrite all” using the tune/scroll knob and press (YES).
Page 436 5-7. “SETUP” menu  Deleting incoming call history Select “Incoming Calls” using the tune/scroll knob. Select the desired phone number using the knob and press (YES). To delete all incoming call history data, press (ALL) and then press (YES).  Deleting missed call history Select “Missed Calls”...
Page 437 5-7. “SETUP” menu Deleting a registered phone number Select “Delete contacts” using the tune/scroll knob. (P. 428) Select the desired phone number using the knob and press (YES). To delete all the registered phone numbers, press (ALL) and then press (YES).
Page 438 5-7. “SETUP” menu Setting ring tone volume Select “Ringtone volume” using the tune/scroll knob. (P. 428) Change the ring tone volume. To decrease the volume: Turn the knob counterclockwise. To increase the volume: Turn the knob clockwise. To set the volume, press (BACK).
Page 439 5-8. Bluetooth® Audio ® Operating a Bluetooth enabled portable player Changing the audio source/ Selecting an album playback Playback/pause Selecting a track, fast-forward- Displaying text message ing or rewinding Power/volume knob Random play or back button Press: Turning the audio sys- Repeat play tem on or off Turn: Adjusting the volume...
Page 440 5-8. Bluetooth® Audio Selecting an album Press (<FOLDER) or (FOLDER>) to select desired album. Selecting a track Press the “<” or “>” button of “SEEK TRACK” to select the desired track. Fast-forwarding and rewinding tracks Press and hold the “<” or “>” button of “SEEK TRACK”. Repeat play Pressing (RPT) changes modes in the following order:...
Page 441: Making A Phone Call
5-9. Bluetooth® Phone Making a phone call To enter the “TEL” mode, press the off-hook switch. Dialing by selecting a name Select “Phonebook” using the tune/scroll knob. Select the desired name using the knob and press the off-hook switch. By pressing (Add S.
Page 442 5-9. Bluetooth® Phone Dialing by entering the number Select “Dial by number” using the tune/scroll knob. Enter the phone number and press the off-hook switch. Dialing from call histories Select “All Calls”, “Missed Calls”, “Incoming Calls” or “Outgoing Calls” using the tune/scroll knob. Select a desired number using the knob and press the off-hook switch.
Page 443: Receiving A Phone Call
5-9. Bluetooth® Phone Receiving a phone call Answering the phone Press the off-hook switch. Refusing the call Press the on-hook switch. Receiving a call when on another call Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Adjusting the ring tone volume when receiving a call To decrease the volume: Turn the power/volume knob counterclock- wise.
Page 444: Speaking On The Phone
5-9. Bluetooth® Phone Speaking on the phone Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the opera- tion of the phone.
Page 445 5-9. Bluetooth® Phone  When talking on the phone  Do not talk simultaneously with the other party. Keep the volume of the received voice down. Otherwise, voice echo will  increase. Automatic volume adjustment  When vehicle speed is 80 km/h (50 mph) or more, the volume automatically increases.
Page 446 Bluetooth® 5-10. ® Bluetooth ® When using the Bluetooth audio/phone   In the following situations, the system may not function. ® • The portable player does not support Bluetooth • The cellular phone is located outside the service area ®...
Page 447 Bluetooth® 5-10. When transferring ownership of the vehicle  Be sure to initialize the system to prevent personal data from being improperly accessed. (P. 435) ® About Bluetooth  The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Fujitsu Ten Limited is under license.
Page 448 Bluetooth® 5-10. LC150_OM_OM60K29E_(EE)
Page 449 Bluetooth® 5-10. LC150_OM_OM60K29E_(EE)
Page 450 Bluetooth® 5-10. CAUTION While driving  Do not use the portable audio player, cellular phone or connect a device to ® the Bluetooth system.  Caution regarding interference with electronic devices ® Your audio unit is fitted with Bluetooth antennas. People with implanted ...
Page 451: 6-1. Using The Air Conditioning Sys
Interior features 6-1. Using the air conditioning 6-3. Using the storage features system and defogger List of storage features ..480 Front manual air • Glove box ......481 conditioning system ..452 • Card holder....482 Front automatic air • Console box ....482 conditioning system ..458 •...
Page 452: Front Manual Air Conditioning System
6-1. Using the air conditioning system and defogger  Front manual air conditioning system The illustration below is for left-hand drive vehicles. The button positions and shapes may differ slightly for right-hand drive vehicles. Adjusting the temperature setting  Turn clockwise (warm) or counterclockwise (cool).
Page 453 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes  Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time the button is pressed. Defogging the windshield ...
Page 454 6-1. Using the air conditioning system and defogger Windshield wiper de-icer (if equipped)  This feature is used to prevent ice from building up on the wind- shield and wiper blades. Turns on/off The windshield wiper de-icer will automatically turn off after a period of time.
Page 455 6-1. Using the air conditioning system and defogger Power heater (if equipped)  This feature is used to heat the engine coolant, speed up warming of the cab in cold weather, and keep the cab warm. Turns the power heater on/off If you do not turn the switch to off, engine...
Page 456 6-1. Using the air conditioning system and defogger  Fogging up of the windows  Vehicles with the “A/C” button: The windows will easily fog up when the humidity in the vehicle is high. Turning the “A/C” button on will dehumidify the air from the outlets and defog the windshield effectively.
Page 457 6-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up   Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 458: Front Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger  Front automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. The illustration below is for left-hand drive vehicles. The button positions and shapes may differ slightly for right-hand drive vehicles.
Page 459 6-1. Using the air conditioning system and defogger Air conditioning controls Using the automatic mode  Press the “AUTO” button. Adjust the temperature setting. To stop the operation, press the “OFF” button. If the system is operated manually in automatic mode ...
Page 460 6-1. Using the air conditioning system and defogger Changing the rear seat settings (vehicles with rear automatic air conditioning system) Adjusting the temperature setting  Press the “REAR” button. “REAR” is shown on the display. Turn clockwise to increase the temperature and turn the knob counterclockwise to decrease the temperature.
Page 461 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes  Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time the button is pressed. Defogging the windshield ...
Page 462 6-1. Using the air conditioning system and defogger Pollen removal mode  Pollen is removed from the air and the air flows to the upper part of the body. Press In order to prevent the windshield from fogging up when the outside air is cold, the dehumidification function may operate.
Page 463 6-1. Using the air conditioning system and defogger Heater idle up (if equipped)  This feature is used to boost heating effect in extremely cold condi- tions when the vehicle is not moving. Press the switch to increase engine speed. Press the switch again to return the engine to the normal idle speed.
Page 464 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets  The air outlets and air volume changes according selected air flow mode. : Some models Adjusting the position of and opening and closing the air out- ...
Page 465 6-1. Using the air conditioning system and defogger  Using automatic mode Fan speed is adjusted automatically according to the temperature setting and ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after the “AUTO”...
Page 466 6-1. Using the air conditioning system and defogger Air conditioning filter  P. 557  Customization Settings (e.g. A/C automatic mode button operation) can be changed. (Customizable features P. 705) CAUTION  To prevent the windshield from fogging up  Do not use during cool air operation in extremely humid weather.
Page 467 6-1. Using the air conditioning system and defogger  Rear manual air conditioning system Press the “REAR” button on the front manual air conditioning control panel to use the rear manual air conditioning system. Adjusting the temperature setting  Turn clockwise (warm) or counterclockwise (cool).
Page 468 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets  The air outlets and air volume changes according selected air flow mode. Adjusting the position of and opening and closing the air out-  lets Direct air flow to the left or right, up or down.
Page 469: Rear Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger  Rear automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Vehicles without outer second Vehicles with outer second   seat heaters seat heaters Adjusting the temperature setting ...
Page 470 6-1. Using the air conditioning system and defogger Air conditioning controls Using the automatic mode  Press the “AUTO” button. Adjust the temperature setting. To stop the operation, press the “OFF” button. If the system is operated manually in automatic mode ...
Page 471 6-1. Using the air conditioning system and defogger NOTICE To prevent battery discharge  Do not leave the air conditioning system on longer than necessary when the engine is off. LC150_OM_OM60K29E_(EE)
Page 472 6-1. Using the air conditioning system and defogger   Heated steering wheel /seat heaters Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats. CAUTION  Care should be taken to prevent injury if anyone in the following categories comes in contact with the steering wheel and seats when the heater is on: •...
Page 473 6-1. Using the air conditioning system and defogger Heated steering wheel (if equipped) Turns the steering wheel heater on/off The indicator light comes on when the heater is operating.  The heated steering wheel can be used when Vehicles without a smart entry & start system ...
Page 474 6-1. Using the air conditioning system and defogger Seat heaters (if equipped) Front seats  Vehicles with an automatic transmission  Vehicles with a manual transmission  Turns the seat heater on The indicator light comes on. Adjusts the seat temperature The further you turn the dial upward, the warmer the seat becomes.
Page 475 6-1. Using the air conditioning system and defogger Outer second seat heaters  For left second seat For right second seat High heating temperature Low heating temperature To turn on the seat heater, press “HI” or “LO”.  The seat heaters can be used when Vehicles without a smart entry &...
Page 476 6-2. Using the interior lights Interior lights list Personal/interior lights (P. 478) Ornament illumination (if equipped) Inside door handle lights (if equipped) Shift lever light Footwell lights (if equipped) Engine switch light Door pocket lights (if equipped) Running board lights (if equipped) : The brightness of the lights can be adjusted (P.
Page 477 6-2. Using the interior lights Personal/interior lights main switch The personal/Interior lights and interior light can be individually turned on or off. Door position The personal/interior lights come on when a door is opened. They turn off when the doors are closed. The personal/interior lights cannot be individually turned off.
Page 478 6-2. Using the interior lights Rear (without personal lights)  Turns the lights on Turns the door position on Door position: When the personal/ interior light main switch is in the “OFF” position, the lights will not turn on. Rear (with personal lights) ...
Page 479 6-2. Using the interior lights  Illuminated entry system Vehicles without a smart entry & start system  The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed.
Page 480 6-3. Using the storage features List of storage features Cup holders (P. 485) Bottle holders/door pockets (P. 486) Auxiliary boxes (P. 488) Glove box (P. 482) Card holder (right-hand drive vehicles) (P. 483) Console box (if equipped) (P. 483) Cool box (if equipped) (P. 493) LC150_OM_OM60K29E_(EE)
Page 481: Glove Box
6-3. Using the storage features CAUTION Do not leave glasses, lighters or spray cans in the storage spaces, as this  may cause the following when cabin temperature becomes high: • Glasses may be deformed by heat or cracked if they come into contact with other stored items.
Page 482 6-3. Using the storage features Card holder (right-hand drive vehicles) The card holder is located in the glove box. Console box (if equipped) Your vehicle is equipped with either a console box or cool box. For vehicles with the cool box, refer to P. 493. Lift the lid while pulling up the knob to release the lock.
Page 483 6-3. Using the storage features  Using the console box vent (if equipped) Air from the air conditioner can be distrib- uted into the console box by opening and closing the vent. Open Close Items unsuitable for the console box ...
Page 484 6-3. Using the storage features Cup holders/bottle holders/door pockets Cup holders  Front (vehicles with an auto- Front (vehicles with a manual   matic transmission) transmission) Press down and release the Press down and release the cup cup holder lid. holder lid.
Page 485 6-3. Using the storage features Rear (type C) (if equipped) Rear (type D) (if equipped)   Push the lid. Bottle holders/door pockets  Front Rear (if equipped)    Removing the holder, separate tray and adapter of the cup holder Front (vehicles with an automatic transmission) ...
Page 486 6-3. Using the storage features Front (vehicles with a manual transmission)  Pull up the separate tray. Rear (type A)  Pull up the adapter. When storing a bottle in the bottle holder   Close the cap.  The bottle may not be stored depending on its size or shape. CAUTION ...
Page 487: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes Type A Type B (if equipped)   Press in the lid. Push the lid. The auxiliary box is useful for tem- porarily storing sunglasses and similar small items. Type C (if equipped) Type D (if equipped) ...
Page 488 6-3. Using the storage features Type E (vehicles with an auto- Type F (vehicles with a man-   matic transmission) ual transmission) CAUTION  Do not place cups, beverage cans or bottles in the box. They may be thrown out of the box in the event of sudden braking, sudden swerving or an accident, resulting in injury.
Page 489: Tures
6-3. Using the storage features Luggage compartment features Deck rail (if equipped) To attach the deck hooks, use the deck rails. The deck hook itself is not included as an original equipment. Vehicles with the third seats (power seat): When using the deck rail, the third seat must be fold down.
Page 490 6-3. Using the storage features Secure the warning reflector. The warning reflector itself is not included as an original equipment. Cargo net hooks Type A Type B To hang the cargo net, use the cargo net hooks. The cargo net itself is not included as an original equipment. Auxiliary box (if equipped) Type A Type B...
Page 491 6-3. Using the storage features Auxiliary tray (if equipped) Luggage cover (if equipped) Installing the luggage cover  Attach the hooks to the head restraints. Vehicles with the third seats: When using the luggage cover, the third seat must be fold down. (P. 182, 184) 3-doors models 5-doors models ...
Page 492 6-3. Using the storage features Removing the luggage cover  Retract the cover and release both ends, then lift it out. After removing luggage cover, place it somewhere other than the passenger compart- ment. Adjusting the sub cover (if equipped) ...
Page 493: Using The Other Interior Fea Tures
6-4. Using the other interior features Other interior features Cool box (if equipped) Lift the lid while pulling up the knob to release the lock. Turns the cool box on/off When on, the indicator light comes  The cool box can be operated when Vehicles with a manual air conditioning system ...
Page 494 If the indicator light continues to flash, there may be a malfunction in the sys- tem. Turn the air conditioning system off and have it inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 495: Vanity Mirror
6-4. Using the other interior features Sun visors Type A  To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Type B ...
Page 496: Conversation Mirror
6-4. Using the other interior features Conversation mirror The conversation mirror can provide the driver and the front passen- ger with a view of the rear seat area without the need to turn around. Press in the button. To use the overhead console when the conversation mirror is open, further extend down the lid.
Page 497 6-4. Using the other interior features Clock Vehicles with a front manual air conditioning system  Adjusts the hours Adjusts the minutes Vehicles with a front automatic air conditioning system  Adjusts the hours Adjusts the minutes Rounds the nearest hour : e.g.
Page 498: Power Outlet
6-4. Using the other interior features Power outlet The power outlet can be used for the following components: 12 V DC: Accessories that run on less than 10 A. Accessories that run on less than 10 A should be used when using several power outlets at the same time.
Page 499 6-4. Using the other interior features Luggage compartment (12 V DC) (if equipped)  3 door models 5 door models   Luggage compartment (220 V AC) (if equipped)  3 door models 5 door models    The power outlet can be used when Vehicles without a smart entry &...
Page 500 6-4. Using the other interior features NOTICE To avoid damaging the power outlet  Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit.
Page 501: Armrest
6-4. Using the other interior features Armrest (if equipped) Fold down the armrest for use. NOTICE To prevent damage, do not apply too heavy a load on the armrest. Coat hooks The coat hooks are provided with the rear assist grips. CAUTION Vehicles with SRS curtain shield airbags: Do not hang coat hangers or other hard or sharp objects on the hook.
Page 502: Assist Grips
6-4. Using the other interior features Assist grips An assist grip (Type A) can be used to support your body while sitting on the seat. An assist grip (Type B) can be used when getting in or out of the vehi- cle and others.
Page 503: Ashtray
6-4. Using the other interior features Ashtray (if equipped) The ashtray can be installed in the auxiliary box (type E and F: P. 488) or cup holder (P. 485). CAUTION  When not in use Keep the ashtray closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open ashtray or ash flying out.
Page 504 6-4. Using the other interior features LC150_OM_OM60K29E_(EE)
Page 505 Maintenance and care 7-1. Maintenance and care 7-3. Do-it-yourself maintenance Cleaning and protecting Do-it-yourself service the vehicle exterior ..506 precautions ......516 Cleaning and protecting Hood ........519 the vehicle interior ...510 Engine compartment..520 7-2. Maintenance Tires........539 Maintenance Tire inflation pressure ..552 requirements....513 Wheels.......554 Air conditioning filter ..557...
Page 506 7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition:  Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 507 7-1. Maintenance and care  Automatic car washes  Fold the mirrors back before washing the vehicle. Start washing from the front of the vehicle. Make sure to extend the mirrors before driving.  Brushes used in automatic car washes may scratch the vehicle surface and harm your vehicle’s paint.
Page 508 Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 509 7-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo-  nents (aluminum wheels etc.)  Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 510 7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 511 7-1. Maintenance and care  Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior.  Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 512 7-1. Maintenance and care NOTICE Cleaning detergents   Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 513 Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule. For full details of your maintenance schedule, refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”. Do-it-yourself maintenance What about do-it-yourself maintenance? Many maintenance items are easy to do yourself if you have a little mechanical ability and a few basic automotive tools.
Page 514  Engine coolant temperature continually higher than normal (P. 107) If you notice any of these clues, take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. Your vehicle may need adjustment or repair.
Page 515 7-2. Maintenance CAUTION If your vehicle is not properly maintained  Improper maintenance could result in serious damage to the vehicle and possible serious injury or death.  Handling of the battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 516 Battery condition • Conventional wrench (for terminal clamp bolts) (P. 532) • Distilled water • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology. “Toyota Super level (P.
Page 517 7-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions:  When working on the engine compartment  Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 518 7-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner filter  Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air.  If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 519: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Move the auxiliary catch lever to side direction and lift the hood.
Page 520: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment 2TR-FE engine  Discharging dust valve Engine oil level dipstick (P. 538) (P. 525) Engine coolant reservoir Fuse box (P. 564) (P. 529) Battery (P. 532) Cooling fans Radiator (P. 531) Engine oil filler cap (P. 527) Condenser (P.
Page 521 7-3. Do-it-yourself maintenance 1GR-FE engine  Discharging dust valve Engine oil filler cap (P. 527) (if equipped) (P. 538) Fuse box (P. 564) Engine oil level dipstick Battery (P. 532) (P. 525) Cooling fans Engine coolant reservoir Condenser (P. 531) (P.
Page 522 7-3. Do-it-yourself maintenance 1KD-FTV engine  Discharging dust valve Radiator (P. 531) (P. 538) Fuse box (P. 564) Battery Fuel filter (P. 539, 672) (if equipped) (P. 529) Battery (P. 529) Engine coolant reservoir Intercooler (P. 531) (P. 529) Condenser (P.
Page 523 7-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover  Installing the clips  Push up center portion Insert Press NOTICE  After installing an engine compartment cover Make sure the cover is securely installed in its original position. LC150_OM_OM60K29E_(EE)
Page 524 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil  Park the vehicle on level ground. After warming up the engine and turning it off, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 525 7-3. Do-it-yourself maintenance Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive Type A Type B   The shape of the dipstick may differ depending on the type of vehicle or engine.
Page 526 7-3. Do-it-yourself maintenance Adding engine oil  If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 527 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, service station or auto parts store for information concerning recycling or disposal.
Page 528 7-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage  Check the oil level on regular basis.  When replacing the engine oil  Be careful not to spill engine oil on the vehicle components.  Avoid overfilling, or the engine could be damaged. ...
Page 529 “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion- ized water. (Enabled: -35C [-31F]) For more details about engine coolant, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 530 Check the radiator, condenser and intercooler (if equipped) and clear any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. CAUTION ...
Page 531 7-3. Do-it-yourself maintenance Battery Check the battery as follows. Caution symbols  The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid flames, no sparks Note operating Shield eyes instructions Keep away from chil- Explosive gas...
Page 532 7-3. Do-it-yourself maintenance Checking battery fluid  Check that the level is between the “UPPER LEVEL” and “LOWER LEVEL” lines. “UPPER LEVEL” line “LOWER LEVEL” line If the fluid level is at or below the “LOWER LEVEL” line, add dis- tilled water.
Page 533 Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 534 7-3. Do-it-yourself maintenance CAUTION Chemicals in the battery  Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near battery: ...
Page 535 7-3. Do-it-yourself maintenance NOTICE When recharging the battery  Never recharge the battery while the engine is running. Also, be sure all accessories are turned off.  When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
Page 536 7-3. Do-it-yourself maintenance  Using the gauge (if equipped) The washer fluid level is checked by observing the position of the level on the liquid covered holes in the gauge. If the level falls below the second hole Current from the bottom (“LOW” position), refill the fluid level washer fluid.
Page 537 7-3. Do-it-yourself maintenance Discharging dust valve (if equipped) Squeeze rubber remove the dust if the discharging dust valve is dirty. Shape of the valve differs slightly in accordance with the engine. NOTICE  To prevent damaging the engine Do not drive with the discharging dust valve removed. Doing so causes excessive engine wear.
Page 538 7-3. Do-it-yourself maintenance Draining the fuel filter water (diesel engine only) The water in the fuel filter must be drained immediately if the following symptom occurs: Vehicles with the multi-information display type A  The fuel system warning light flashes and buzzer sounds or the fuel filter warning light comes on.
Page 539: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recommends that you rotate your tires approximately every 5000 km (3000 miles). Do not fail to initialize the tire pressure warning system after tire rotation.
Page 540 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 543) ...
Page 541 7-3. Do-it-yourself maintenance How to initialize the tire pressure warning system  Park the vehicle in a safe place and turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry & start system). Initialization cannot be performed while the vehicle is moving.
Page 542 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 543  In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 544 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 545 7-3. Do-it-yourself maintenance Certification for tire pressure warning system  The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: DoC address: http://www.pacific-ind.co.jp/eng/products/car/tpms/doc/ LC150_OM_OM60K29E_(EE)
Page 546 7-3. Do-it-yourself maintenance LC150_OM_OM60K29E_(EE)
Page 547 7-3. Do-it-yourself maintenance LC150_OM_OM60K29E_(EE)
Page 548 7-3. Do-it-yourself maintenance The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing address: http://www.globaldenso.com/en/products/oem/index.html LC150_OM_OM60K29E_(EE)
Page 549 7-3. Do-it-yourself maintenance For vehicles sold in Serbia  LC150_OM_OM60K29E_(EE)
Page 550 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear.  Do not use tire sizes other than those recommended by Toyota.  Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 551 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
Page 552: Tire Inflation Pressure
 Reduced safety  Damage to the drive train If a tire needs frequent refilling, have it checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 553 7-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance  Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury:  Excessive wear  Uneven wear ...
Page 554: Wheels
 Used wheels  Bent wheels that have been straightened Aluminum wheel precautions (if equipped)  Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels.  When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 555  When replacing wheels (vehicles with the tire pressure warning system) The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and transmitters must be installed.
Page 556 Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional or other qualified service shop. In addition, make sure to...
Page 557: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK” position. Vehicles with a smart entry & start system: Turn the engine switch off.
Page 558 Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”.)  If air flow from the vents decreases dramatically The filter may be clogged.
Page 559: Tronic (Key Bat Tery)
7-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items:  Flathead screwdriver  Small flathead screwdriver (vehicles with a smart entry & start sys- tem) ...
Page 560 7-3. Do-it-yourself maintenance Vehicles without a smart entry & start system (type B)  Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the module. Open the case cover using a coin protected with tape etc.
Page 561 7-3. Do-it-yourself maintenance Vehicles with a smart entry & start system  Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the depleted battery. Insert a new battery with the “+” terminal facing up.
Page 562 Vehicles without a smart entry & start system (type B): CR2016 Vehicles with a smart entry & start system: CR1632  Batteries can be purchased at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, local electrical appliance shops or camera stores.
Page 563: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 564 Replace the blown fuse with one of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type B, C, D and E Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Type A Type B ...
Page 565 7-3. Do-it-yourself maintenance Type C Type D   Type E  LC150_OM_OM60K29E_(EE)
Page 566 (P. 568)  If the replaced fuse blows again, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.  If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 567: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. For more information about replacing other light bulbs, contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional.
Page 568 7-3. Do-it-yourself maintenance Bulb locations Front  Headlight high beam Front fog light (if equipped) Front position light Front turn signal light (halogen headlights) Headlight low beam/daytime running lights (halogen headlights) LC150_OM_OM60K29E_(EE)
Page 569 7-3. Do-it-yourself maintenance Rear  Vehicles with under floor mounted spare tire  Running board lights Back-up light (if equipped) Rear fog light (if equipped) Rear turn signal light License plate lights Vehicles with back door mounted spare tire  Running board lights Back-up light (if equipped)
Page 570 7-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams/daytime running lights (halogen head-  lights) Turn the bulb base counter- clockwise. Unplug the connector while pushing the lock release. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 571 7-3. Do-it-yourself maintenance Headlight high beams  Turn the bulb base counter- clockwise. Unplug the connector while pushing the lock release. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base.
Page 572 7-3. Do-it-yourself maintenance Front position lights (halogen headlights)  Turn the bulb base counter- clockwise. The shape of the bulb base dif- fers slightly on the left and right sides. Remove the light bulb. LC150_OM_OM60K29E_(EE)
Page 573 7-3. Do-it-yourself maintenance Front turn signal lights  Remove the fender liner bolts. To allow enough working space, turn the steering wheel to the opposite side of the bulb to be replaced. Open the fender liner. LC150_OM_OM60K29E_(EE)
Page 574 7-3. Do-it-yourself maintenance Turn the bulb base counterclockwise. Vehicles with halogen head- Vehicles with LED headlights   lights Remove the light bulb. Vehicles with halogen head- Vehicles with LED headlights   lights LC150_OM_OM60K29E_(EE)
Page 575 7-3. Do-it-yourself maintenance Front fog lights (if equipped)  Remove the fender liner bolts and open the fender liner. (P. 574) Unplug the connector while pushing the lock release. Turn the light bulb counter- clockwise. Replace the light bulb. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 576 7-3. Do-it-yourself maintenance Turn and secure the bulb base. Install the bulb base. Shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting.
Page 577 7-3. Do-it-yourself maintenance Rear turn signal lights and back-up lights  Open the back door. Left-hand side  Remove the bolts and lamp assembly. Right-hand side  Remove the bolts. Close the back door half way and remove the lamp assembly.
Page 578 7-3. Do-it-yourself maintenance Unplug the connector while pushing the lock release. Turn the bulb bases counter- clockwise. Rear turn signal light Back-up light Remove the light bulb. Rear turn signal light Back-up light LC150_OM_OM60K29E_(EE)
Page 579 7-3. Do-it-yourself maintenance Rear fog lights (if equipped)  Remove the under cover bolts and pull down the under cover. Turn the bulb base counter- clockwise. Remove the light bulb. LC150_OM_OM60K29E_(EE)
Page 580 7-3. Do-it-yourself maintenance License plate lights  Vehicles with under floor mounted spare tire and without spare  tire Remove the screws. Remove lens license plate light unit. Remove the light bulb. Vehicles with back door mounted spare tire  Remove the screws.
Page 581 Lights other than the above  If any of the lights listed below has burnt out, have it replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Headlight low beams (LED headlights)  Front position lights/daytime running lights (LED headlights) ...
Page 582 (LED headlights), side turn signal lights, high mounted stoplight, stop/tail lights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to any authorized Toyota dealer or repairer, or another duly qual- ified and equipped professional to have the light replaced.
Page 583: 8-1. Essential Information
When trouble arises 8-1. Essential information If you have a flat tire (vehicles without a Emergency flashers...584 spare tire) ......641 If your vehicle has to If the engine will be stopped in an not start......657 emergency.......585 If the shift lever cannot 8-2.
Page 584: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 585: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 586 8-1. Essential information Vehicles with a smart entry & start system: To stop the engine, press and hold the engine switch for 2 consecutive seconds or more, or press it briefly 3 times or more in succession. Press and hold for 2 seconds or more, or press briefly 3 times or more Stop the vehicle in a safe place by the road.
Page 587: Towed
Before towing The following may indicate a problem with your transmission. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional before towing.  The engine is running but the vehicle will not move.
Page 588 8-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling type truck to prevent body damage. Towing with a wheel lift-type truck From the front From the rear   Use a towing dolly under the rear Use a towing dolly under the wheels.
Page 589 8-2. Steps to take in an emergency Using a flat bed truck If your Toyota is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 590 8-2. Steps to take in an emergency CAUTION Caution while towing   Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing hooks and the cables or chains. Always be cautious of the surroundings and other vehicles while towing.
Page 591 8-2. Steps to take in an emergency NOTICE To prevent causing serious damage to the transmission and transfer  when towing using a wheel-lift type truck Never tow this vehicle with any of the wheels in contact with the ground. ...
Page 592: If You Think Something
If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible.
Page 593 8-2. Steps to take in an emergency Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 594: If A Warning Light Turns On Or A
However, if this continues to occur, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Warning light and warning buzzer list...
Page 595 SRS warning light Indicates a malfunction in: • The SRS airbag system; or • The seat belt pretensioner system.  Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. ABS warning light Indicates a malfunction in: •...
Page 596 • The Crawl Control. The light will flash when any of the above systems other than the Multi-terrain Select are operating.  Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
Page 597  P. 539 • Malfunction in the fuel system if the light comes on.  Have the vehicle inspected by any authorized Toyota (If equipped) (Comes on or dealer or repairer, or another duly qualified and flashes) equipped professional immediately.
Page 598 When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system  Have the system checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 599 Warning light/Details/Actions Automatic headlight leveling system warning light Indicates a malfunction in the automatic headlight leveling system  Have the vehicle inspected by any authorized Toyota (If equipped) dealer or repairer, or another duly qualified and equipped professional immediately. Toyota...
Page 600  Have the engine oil and oil filter checked and/or (Remains on) changed by any authorized Toyota dealer or repairer, (If equipped) or another duly qualified and equipped professional. After changing the engine oil, the oil change system should be reset.
Page 601 8-2. Steps to take in an emergency Smart entry & start system warning light and buzzer procedures (If equipped) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Warning Details/Actions buzzer buzzer light...
Page 602 8-2. Steps to take in an emergency Interior Exterior Warning Details/Actions buzzer buzzer light Indicates that a door other than the driver’s door has been opened or closed with the engine switch in any mode other than off, the shift lever was in P (auto- Sounds matic transmission) or N (manual trans- Once...
Page 603 “ON” position (vehicles without a smart entry & start system) or IGNITION ON mode (vehicles with a smart entry & start system), have it checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 604 The warning message will disappear when regeneration is complete. How- ever, if this driving cannot be carried out, or if the message does not disap- pear even after driving, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional imme- diately.
Page 605  Stop your vehicle in a safe place immediately and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 606 Multi-information display If any of the warning lights comes on again after the following actions have been performed, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 607 8-2. Steps to take in an emergency Warning message and warning buzzer list Warning message Details/Actions Indicates that: • There is a high possibility of a frontal collision; • The pre-crash braking function is operating A buzzer also sounds.  Slow the vehicle by applying the brakes. (Flashes rapidly) (If equipped) Indicates that your vehicle is nearing the vehicle...
Page 608 8-2. Steps to take in an emergency Warning message Details/Actions Indicates a malfunction in the Toyota parking assists-sensor All assist-sensors flash. A buzzer also sounds.  Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 609 A buzzer also sounds.  Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. Indicates a malfunction in the steering lock sys- A buzzer also sounds.
Page 610 Indicates a malfunction in the BSM (Blind Spot Monitor) system A buzzer also sounds.  Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another (If equipped) duly qualified and equipped professional. Indicates abnormal engine oil pressure The warning light may come on if the engine oil pressure is too low.
Page 611 A buzzer also sounds.  Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another (If equipped) duly qualified and equipped professional immediately. Indicates a malfunction in the automatic headlight leveling system A buzzer also sounds.
Page 612 Indicates a malfunction in the rear height control air suspension A buzzer also sounds.  Immediately stop the vehicle in a safe place and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (If equipped) Indicates that the Crawl Control is not available ...
Page 613 Details/Actions Indicates a malfunction in the fuel system A buzzer also sounds.  Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. (If equipped) Indicates that the timing belt is scheduled to be changed.
Page 614 (If equipped) Indicates that the VSC, the 4WD system, the Multi-terrain Select system or the EFI system malfunctions  Consult any authorized Toyota dealer or repairer, or another duly qualified and (If equipped) equipped professional. Indicates that the engine oil is scheduled to...
Page 615 Regenerate the filter.  P. 617 (If equipped) Malfunction in the DPF system if the light flashes.  Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. (If equipped) LC150_OM_OM60K29E_(EE)
Page 616 The warning message will disappear when regeneration is complete. How- ever, if this driving cannot be carried out, or if the message does not disap- pear even after driving, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional imme- diately.
Page 617 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The electronic key was carried outside the vehicle and a door other than the driver’s door was opened and closed while the engine switch was in a mode other than off.
Page 618 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The driver’s door was opened Con- when the shift lever was not in  tinu- P and the engine switch was not turned off.  Shift the shift lever to P. (Flashes) (If equipped) The driver’s door was opened...
Page 619 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to lock either front door by opening a door and putting the inside lock Sounds button into the lock position, once then closing the door by pulling Once for 5 on the outside door handle with...
Page 620 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer Power was turned off due to the automatic power off function.  Next time when starting the engine, increase the   engine speed slightly and maintain that level...
Page 621 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The steering lock could not be released within 3 seconds of engine switch being pressed.   Press the engine switch Once while depressing the brake pedal moving (Flashes)
Page 622: With (A Spare Tire))
8-2. Steps to take in an emergency If you have a flat tire (vehicles with a spare tire) Remove the flat tire and replace it with the spare provided. For details about tires: P. 540 CAUTION  If you have a flat tire Do not continue driving with a flat tire.
Page 623 8-2. Steps to take in an emergency Location of the spare tire, jack and tools Vehicles with under floor mounted spare tire  Jack Tool box Spare tire LC150_OM_OM60K29E_(EE)
Page 624 8-2. Steps to take in an emergency Vehicles with back door mounted spare tire  5-door models 3-door models Jack Spare tire Tool box LC150_OM_OM60K29E_(EE)
Page 625 8-2. Steps to take in an emergency CAUTION Using the tire jack  Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury.  Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 626 8-2. Steps to take in an emergency Taking out the jack Remove the cover. 3-door models 5-door models   Unhook the rubber band and take out the jack. For loosening For tightening 3-door models 5-door models   LC150_OM_OM60K29E_(EE)
Page 627 8-2. Steps to take in an emergency Taking out the tool box Open the cover. Take out the tool box. LC150_OM_OM60K29E_(EE)
Page 628 8-2. Steps to take in an emergency Taking out the spare tire cover (if equipped) Remove the bolt cover Bolt cover Remove the bolt which fixes the spare tire cover. Unlock the latch and unhook the spare tire cover. Opening the back door makes unlocking the latch easier.
Page 629 8-2. Steps to take in an emergency Taking out the spare tire Vehicles with back door mounted spare tire  Unlock the spare tire lock sys- tem. Insert the key into the cylin- der. Remove the key and the cyl- inder.
Page 630 8-2. Steps to take in an emergency Vehicles with under floor mounted spare tire  Assembling the jack handle. Remove the jack handle and the jack handle extension bar from the tool box and assemble by following these steps. Loosen the bolt and the screw using either the jack handle end or a screwdriver.
Page 631 8-2. Steps to take in an emergency Insert the jack handle extension into the lowering screw. Lower Raise Place a rag under the jack han- dle extension to protect the rear bumper. Lower the spare tire completely to the ground. Pull out the spare tire and remove the holding bracket.
Page 632 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 633 8-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Assembling the jack handle. Remove the jack handle, jack handle extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolt and the screw using either the jack handle end or a screwdriver.
Page 634 8-2. Steps to take in an emergency Position the jack at the jack points as shown. Front Under the chassis frame side rail Rear Under the rear axle housing Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire.
Page 635 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. • When installing a tire, only use wheel nuts that have been specifically designed for that wheel.
Page 636 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire to come off.
Page 637 8-2. Steps to take in an emergency Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 112 N•m (11.4 kgf•m, 83 ft•lbf) Reinstall the wheel ornament. Steel wheels Aluminum wheels   Stow the flat tire, tools and jack securely, and replace all covers.
Page 638 8-2. Steps to take in an emergency Stowing the flat/spare tire, jack and tools Vehicles with back door mounted spare tire  Install the tire and loosely tighten each nut by hand to approximately same amount. Spare tire lock nut Firmly tighten each nut two or three times in the order shown in the illustration.
Page 639 8-2. Steps to take in an emergency Vehicles with the spare tire cover: Install the spare tire cover in the reverse order of removal. Tightening torque: 14 N•m (1.4 kgf•m, 10 ft•lbf) Stow the tools and jack securely, and replace all covers. Vehicles with under floor mounted spare tire ...
Page 640 8-2. Steps to take in an emergency CAUTION After using the tools and jack  Before driving, make sure all the tools and jack are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden braking.
Page 641 8-2. Steps to take in an emergency If you have a flat tire (vehicles without a spare tire) Your vehicle is equipped with an emergency tire puncture repair kit. A puncture caused by a nail or screw passing through the tire tread can be repaired temporarily with the emergency tire punc- ture repair kit.
Page 642 8-2. Steps to take in an emergency Location of the emergency tire puncture repair kit, jack and tools 3-door models  Jack Emergency tire puncture repair kit 1, 2 Tool box : If equipped : Use of the jack (P. 635) LC150_OM_OM60K29E_(EE)
Page 643 8-2. Steps to take in an emergency 5-door models  Jack Emergency tire puncture repair kit 1, 2 Tool box : If equipped : Use of the jack (P. 635) LC150_OM_OM60K29E_(EE)
Page 644 8-2. Steps to take in an emergency Emergency tire puncture repair kit components Bottle Stickers Air pressure gauge Hose Compressor switch Power plug Air release cap Insertion key LC150_OM_OM60K29E_(EE)
Page 645 8-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit 3-door models  Remove the cover. Take out the emergency tire puncture repair kit. 5-door models  Open the console box. Take out the emergency tire puncture repair kit.
Page 646 8-2. Steps to take in an emergency Before performing emergency repair Check the degree of the tire damage. A tire should only be repaired with emergency tire puncture repair kit if the damage is caused by a nail or screw passing through the tire tread.
Page 647 8-2. Steps to take in an emergency Return the kit to an upright position and make sure that the compressor switch is off. Use the kit with the top facing upward. Connect the power plug to the power outlet socket. (P. 499) Open the cover and connect the power plug.
Page 648 8-2. Steps to take in an emergency Remove the valve cap from the valve of the punctured tire. Remove the air release cap from the hose. Connect the hose to the valve. Screw the end of the hose clock- wise as far as possible. LC150_OM_OM60K29E_(EE)
Page 649 8-2. Steps to take in an emergency Check the specified tire inflation pressure Tire inflation pressure is specified on the label as shown. (P. 699) Left-hand drive vehicles Right-hand drive vehicles   Start the engine. (P. 244) To inject the sealant and inflate the tire, turn the compressor switch on.
Page 650 10 minutes with the switch on, the tire is too dam- aged to be repaired. Turn the compressor switch off and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. • If the tire inflation pressure exceeds the recommended level, let out some air to adjust the tire inflation pressure.
Page 651 If the tire inflation pressure is below 130 kPa (1.3 kgf/cm or bar, 19 psi): The puncture cannot be repaired. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. If the tire inflation pressure is between 130 kPa (1.3 kgf/cm bar, 19 psi) and a point below the recommended level: The tire can be repaired.
Page 652 Store the kit and then attach the 2 stickers as shown. Taking precautions to avoid sud- den braking and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest authorized Toyota dealer repairer, another duly qualified equipped...
Page 653 The sealant has a limited lifespan. The expiry date is marked on the bottle. The sealant should be replaced before the expiry date. Contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional for replacement.
Page 654 8-2. Steps to take in an emergency If the tire is inflated to more than the recommended level  Disconnect the hose from the valve. Install the air release cap to the end of the hose and push the protrusion on the air release cap into the valve to let some air out.
Page 655 8-2. Steps to take in an emergency CAUTION When fixing the flat tire   Stop your vehicle in a safe and flat area.  Connect the valve and hose securely with the tire installed on the vehicle.  If the hose is not properly connected to the valve, air leakage may occur or sealant may be sprayed out.
Page 656 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 657: If The Engine Will (Not Start)
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 241, 244), consider each of the fol- lowing points: The engine will not start even when the starter motor operates normally.
Page 658  There may be a malfunction in the steering lock system. (vehicles with a smart entry & start system) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional if the problem cannot be repaired, or if repair procedures are unknown.
Page 659: Shifted From P (Automatic Transmission)
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
Page 660 Closes the windows and moon roof (turn and hold) Unlocks all doors Opens the windows and moon roof (turn and hold) : These settings must be customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 661 Press the engine switch within 10 seconds of the buzzer sounding, keeping the brake pedal depressed. In the event that the engine switch still cannot be operated, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Manual transmission ...
Page 662 8-2. Steps to take in an emergency  Stopping the engine Vehicles with an automatic transmission  Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. Vehicles with a manual transmission ...
Page 663 You can call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your Toyota following the steps below. Open the hood. (P. 520) Remove the engine cover.
Page 664 8-2. Steps to take in an emergency Vehicles with 1KD-FTV engine  Remove the bolts. Raise the front of the engine cover and then pull the cover to detach it from the bracket on the rear bar as shown in the illustration.
Page 665 8-2. Steps to take in an emergency 2TR-FE engine  1GR-FE engine  LC150_OM_OM60K29E_(EE)
Page 666 Once the engine starts, have the vehicle checked at any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional, as soon as possible. : Vehicles with DPF system...
Page 667 8-2. Steps to take in an emergency  Starting the engine when the battery is discharged (vehicles with an automatic transmission) The engine cannot be started by push-starting.  To prevent battery discharge  Turn off the headlights and the audio system while the engine is off. ...
Page 668 8-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions  Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery:  Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 669: If Your Vehicle Over Heats
After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional. LC150_OM_OM60K29E_(EE)
Page 670 8-2. Steps to take in an emergency The coolant level is satisfactory if it is between the “FULL” and “LOW”/“F” and “L” lines on the reservoir. Reservoir “FULL” or “F” “LOW” or “L” Radiator cap (if equipped) Add coolant if necessary. (P. 524) Water can be used in an emergency if coolant is unavailable.
Page 671 Stop the engine immediately and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. If the fans are operating: Have the vehicle inspected at the nearest authorized Toyota dealer or repairer, or another duly qualified and equipped professional. CAUTION ...
Page 672: Engine Stalls(Diesel Engine Only))
10 seconds and try step again. If the engine still does not start, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.
Page 673: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow: Stop the engine. Set the parking brake and put the shift lever in P (automatic transmission) or N (manual transmission).
Page 674 8-2. Steps to take in an emergency CAUTION When attempting to free a stuck vehicle  If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear, to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 675 Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...676 Fuel information ....702 9-2. Customization Customizable features ..705 9-3. Items to initialize Items to initialize ....715 LC150_OM_OM60K29E_(EE)
Page 676 9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights 4780 mm (188.2 in.) 5-door models 4950 mm (194.9 in.) Overall length 4335 mm (170.7 in.) 3-door models 4505 mm (177.4 in.) Overall width 1885 mm (74.2 in.) 4, 6 1835 mm (72.2 in.) 5, 6 1845 mm (72.6 in.)
Page 677 9-1. Specifications Except for 2-seat models 2900 kg (6393 lb.) 1GR-FE engine 2-seat models 2830 kg (6239 lb.) Gross 2TR-FE engine 2850 kg (6283 lb.) vehicle mass 2990 kg (6592 lb.) 5-door models 2980 kg (6571 lb.) 1KD-FTV 2890 kg (6371 lb.) engine 3-door models 2600 kg (5732 lb.)
Page 678 “W” as the last letter and 1KD-FTV engine. : The model code is indicated on the manufacturer’s label. (P. 680) : To distinguish the vehicle category, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. LC150_OM_OM60K29E_(EE)
Page 679 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the front right frame.
Page 680 9-1. Specifications This number is also on the manufacturer’s label on the left- hand side center pillar. Engine number  The engine number is stamped on the engine block as shown. 1GR-FE engine 2TR-FE engine   1KD-FTV engine  LC150_OM_OM60K29E_(EE)
Page 681 9-1. Specifications Engine Gasoline engine  Model 1GR-FE 2TR-FE 6-cylinder V type, 4-cylinder in line, Type 4-cycle, gasoline 4-cycle, gasoline 94.0  95.0 mm 95.0  95.0 mm Bore and stroke (3.70  3.74 in.) (3.74  3.74 in.) Displacement 3956 cm (241.4 cu.in.) 2694 cm (164.4 cu.in.)
Page 682 9-1. Specifications Fuel Gasoline engine  EU area: Unleaded gasoline conforming Fuel type European standard EN228 only Except EU area: Unleaded gasoline only 1GR-FE engine: 95 or higher Research octane number 2TR-FE engine: 91 or higher Vehicles with sub fuel Fuel tank 150 L (39.6 gal., 33.0 Imp.gal.) tank system...
Page 683: Lubrication System
 : The model code is indicated on the manufacturer’s label. (P. 680) “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
Page 684 9-1. Specifications Recommended viscosity (SAE): SAE 0W-20 is filled into your Toyota vehicle at manufactur- Preferred ing, and the best choice for good fuel economy and good starting in cold weather. If SAE 0W-20 oil is not avail- able, SAE 5W-30 oil may be used.
Page 685  : The model code is indicated on the manufacturer’s label. (P. 680) “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 686 9-1. Specifications Recommended viscosity (SAE): If you use SAE 10W-30 or a higher viscosity engine oil in extremely low temperatures, the engine may become difficult to start, so SAE 5W-30 engine oil is recommended. Temperature range anticipated before next oil change Oil viscosity (10W-30 is explained here as an example): •...
Page 687 Engine oil selection  “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
Page 688 9-1. Specifications For Russia: If you use SAE 10W-30 or a higher viscosity engine oil in Preferred extremely low temperatures, the engine may become difficult to start, so SAE 0W-20, 5W-20 or 5W-30 engine oil is recom- mended. Temperature range anticipated before next oil change Oil viscosity (0W-20 is explained here as an example): •...
Page 689 9-1. Specifications How to read oil container labels: Either or both API registered marks are added to some oil contain- ers to help you select the oil you should use. API Service Symbol Top portion: “API SERVICE SN” means the oil quality designa- tion by American Petroleum Institute (API).
Page 690 Engine oil selection (vehicles with DPF catalytic converter  : To determine whether or not your vehicle has a DPF system, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”.
Page 691  verter : To determine whether or not your vehicle has a DPF system, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 692 9-1. Specifications Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 693 With manual transmission Without rear heater  13.2 L (13.9 qt., 11.6 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • A similar high-quality eth- ylene glycol-based non-sili- Coolant type cate, non-amine, non-nitrite, and non-borate coolant with...
Page 694 Toyota Genuine Differential Gear Oil LT Oil type and viscosity 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equiva- lent of matching quality to satisfy the above specification.
Page 695 Oil type and viscosity Gear Oil LT 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equiva- lent of matching quality to satisfy the above specification. Please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details.
Page 696 Recommended gear oil viscosity SAE 75W NOTICE  Manual transmission gear oil (6-speed models) Using manual transmission gear oil other than “TOYOTA Genuine Transfer Gear oil LF SAE 75W” may cause occurrences of gear noise or other types of deterioration. LC150_OM_OM60K29E_(EE)
Page 697 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details.
Page 698 9-1. Specifications Brakes With automatic transmission  Left- 101 mm (4.0 in.) Min. hand 1GR-FE With manual transmission  drive 94 mm (3.7 in.) Min. 1KD-FTV engines Pedal Right- clear- hand 101 mm (4.0 in.) Min. ance drive With automatic transmission ...
Page 699 9-1. Specifications Tires and wheels 17-inch tires (type A)  Tire size P245/70R17 108S, 245/70R17 110S Front tire Rear tire Tire inflation pressure kPa (kgf/cm or bar, kPa (kgf/cm or bar, (Recommended cold tire psi) psi) inflation pressure) 220 (2.2, 32) 220 (2.2, 32) 17 ...
Page 700 9-1. Specifications 17-inch tires (type D)  Tire size 265/65R17 112S Front tire Rear tire Tire inflation pressure kPa (kgf/cm or bar, kPa (kgf/cm or bar, (Recommended cold tire psi) psi) inflation pressure) 200 (2.0, 29) 200 (2.0, 29) 17  7 1/2J Wheel size Wheel nut torque 112 N•m (11.4 kgf•m, 83 ft•lbf)
Page 701 9-1. Specifications Light bulbs Light bulbs Type Headlights Low beam (halogen bulbs High beam Front fog lights Front turn signal lights Front position lights (halogen bulbs Exterior Rear turn signal lights Back-up lights Rear fog lights License plate lights Running board lights Personal/interior lights Front Rear (without personal lights)
Page 702: Fuel Information
9-1. Specifications Fuel information  Gasoline engine 1GR-FE engine  EU area: Your vehicle must use only unleaded gasoline conforming to Euro- pean standard EN228. For optimum engine performance, select unleaded gasoline with a Research Octane Number of 95 or higher. Except EU area: Your vehicle must use only unleaded gasoline.
Page 703 48 or higher. *: To determine whether or not your vehicle has a DPF system, con- tact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional. ...
Page 704 “E50” or “E85” and fuel containing a large amount of ethanol should not be used. The use of these fuels will damage the vehicle’s fuel system. In case of any doubt, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 705: Customizable Features
The settings of these fea- tures can be changed by using the steering wheel switches or at any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional. It is also possible to customize certain vehicle features yourself using the menu switch and the “ENTER”...
Page 706 Settings that can be changed using the menu switch and the “ENTER” switch Settings that can be changed by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional Definition of symbols: O = Available, – =Not available Door lock (P.
Page 707 9-2. Customization Smart entry & start system and wireless remote control   P. 154, 127) Customized Function Default setting setting Operation signal (buzzer) Level 7 Level 1 to 6 Operation signal (Emer- gency flashers) Time elapsed before the 60 seconds automatic door lock func- tion is activated if a door is 30 seconds...
Page 708 9-2. Customization  Wireless remote control ( P. 127)  Customized Function Default setting setting Wireless remote control – Driver’s door doors unlocked in one Unlocking operation unlocked in one step, all doors step unlocked in two steps  Driving position memory P.
Page 709 9-2. Customization  Interior lights ( P. 477)  Customized Function Default setting setting Time elapsed before the 15 seconds 7.5 seconds interior lights turn off 30 seconds Operation after the engine switch is turned to the “LOCK” position (without a –...
Page 710 9-2. Customization Exterior lights (P. 477)  Customized Function Default setting setting Time elapsed before the 15 seconds 7.5 seconds exterior lights turn off 30 seconds Running board lights – Operation when approach the vehicle with – the electronic key on your person Operation when the doors unlocked...
Page 711 9-2. Customization Meters (P. 106)  Customized Function Default setting setting Sensitivity of the ambient light sensor used for dim- Standard -2 to 2 – ming the meter lights etc. Sensitivity of the ambient light sensor used Standard -2 to 2 –...
Page 712 9-2. Customization  Toyota parking assist-sensor P. 313)  Customized Function Default setting setting Detection distance of the Near – front center sensor Detection distance of the Near – rear center sensor Buzzer volume Level 5 Level 1 to 5 –...
Page 713 9-2. Customization Multi-information display (P. 110, 115)  Default Customized set- Function setting ting French German Spanish Italian Japanese Language English Simplified Chinese Traditional Chinese Russian Turkish km (km/L) Units (L/100km) mph (MPG) Driving Indicator Light Turn-by-turn navigation Back door Back door Vehicle image mounted spare...
Page 714 9-2. Customization  In the following situations, customize mode will automatically be turned off.  A warning message appears after the customize mode screen is displayed.  The engine switch is turned to the “LOCK” position (without a smart entry & start system) or turned off (with a smart entry &...
Page 715 9-3. Items to initialize Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference • When rotating the tires •...
Page 716 9-3. Items to initialize LC150_OM_OM60K29E_(EE)
Page 717: Index
Index What to do if... (Troubleshooting) .....718 Alphabetical index ......722 For vehicles with a navigation system or a multimedia sys- tem, refer to the “Navigation system owner’s manual” for information regarding the equipment listed below. • Navigation system • Hands-free system (for cellular phone) •...
Page 718: What To Do If... (Troubleshoot Ing)
You lose your keys  If you lose your keys or mechanical keys, new genuine keys or mechanical keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 129)  Vehicles with a smart entry & start system If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 719 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without a smart entry & start system)  Vehicles with a manual transmission Do you turn the key with the clutch pedal depressed firmly? (P.
Page 720 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped  Vehicles without a smart entry & start system It is locked to prevent theft of the vehicle if the key is removed from the engine switch.
Page 721 What to do if... (Troubleshooting) An alarm is activated and the horn sounds (if equipped)  Did anyone inside the vehicle open a door during setting the alarm? The sensor detects it and the alarm sounds. (P. 92) To stop the alarm, turn the engine switch to IGNITION ON mode or start the engine.
Page 722: Alphabetical Index
Alphabetical index Alphabetical index Alarm .......... 92 Alarm ........92 A/C..... 453, 459, 468, 470 Warning buzzer..... 595 Air conditioning filter....558 Anchor brackets ......72 Active Traction Control ..361 Antennas (smart entry & start system)......154 (Anti-lock Brake System)..361 Anti-lock brake system Function ........
Page 723 Alphabetical index Center differential CD player........402 Back door ......... 141 Chains........388 Back-up lights Child restraint system....58 Replacing light bulbs..... 578 Baby seats, definition....59 Wattage......... 702 Baby seats, installation ... 72 Battery ........532 Child seats, definition....59 Battery checking ....
Page 724 Alphabetical index Child-protectors.......136 Diesel particulate filter Back door child-protector system........266 lock ........144 Differential ......696 Cleaning Dimension ........ 677 Aluminum wheels....508 Display Exterior........507 Multi-information Interior........511 display ......110, 115 Seat belts ......512 Trip information..... 111, 116 Clock .........
Page 725 Alphabetical index Emergency flashers ....585 Engine Eco Driving Indicator..113, 120 Accessory mode ... 242, 247 Electronic key ......125 Compartment ......521 Battery-saving function ..157 Engine switch....241, 244 If the electronic key does Hood ........520 not operate properly ...
Page 726 Alphabetical index Fuel ........... 683 Capacity........ 683 Flat tire......623, 642 Fuel gauge......106 Floor mats ........33 Fuel pump shut off system..594 Fluid If you run out of fuel and Automatic transmission..696 the engine stalls ....673 Brake........
Page 727 Alphabetical index Hands-free system Identification (for cellular phone)....442 Engine........681 Head restraints......193 Vehicle ........680 Headlights ........ 268 Ignition switch Light switch ......268 (engine switch) ....241, 244 Replacing light bulbs..571, 572 Ignition switch light....477 Wattage.........
Page 728 Alphabetical index Keyless entry Lever Smart entry & start Auxiliary catch lever....520 system ......131, 141 Hood lock release lever ..520 Wireless remote Shift lever......252 control......131, 141 Turn signal lever ....264 Keys .......... 125 Wiper lever......280 Battery-saving function ..
Page 729 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance .......517 Maintenance data ....677 Odometer........106 Maintenance requirements.......514 Engine oil ......684 Malfunction indicator Front differential oil ....695 lamp ........595 Rear differential oil....696 Manual transmission ....259 Opener Manual headlight leveling Back door......
Page 730 Alphabetical index Parking assist sensors.... 313 Radiator ........531 Parking assist monitor .... 334 Radio......... 398 Parking brake ......265 Radio data system....399 Operation ......265 RDS ........... 399 Parking brake engaged Rear fog lights ......278 warning buzzer ....595 Replacing light bulbs.....
Page 731 Sensor Automatic headlight Seat belts........37 system ........ 275 Adjusting the seat belt..... 38 Inside rear view mirror ..200 Automatic Locking Toyota parking Retractor....... 39 assist-sensor ...... 313 Child restraint system Rain-sensing windshield installation......71 wipers ......... 284 Cleaning and maintaining Service reminder indicators ..
Page 732 Alphabetical index Steering wheel ......196 Heater idle up switch ..455, 464 Adjustment ......196 Height control button Audio switches ...... 394 Ignition switch ....241, 244 Steering wheel position Intrusion sensor cancel memory....... 189 switch ........95 Stop/tail lights Light switches .......
Page 733 Alphabetical index Tools ......... 624, 643 Top strap ........78 Tachometer ......106 Towing Tail lights ........268 Emergency towing ....588 Light switch ......268 Towing eyelet......588 Talk switch Trailer Sway Control ..... 362 Telephone switch..... 430 Trailer towing ......228 Theft deterrent system Trailer Sway Control....
Page 734 Alphabetical index Toyota parking assist-sensor ...... 600 Warning buzzers ...... 595 Windshield washer fluid ..599 Brake system ......595 Warning reflector holder..490 Downshifting ......258 Washer........280 Fuel system......598 Checking....... 536 Key reminder......602 Preparing and checking Open back door ....
Page 735 Alphabetical index LC150_OM_OM60K29E_(EE)
Page 736 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 520 P. 292 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 520 P. 292 P. 700 Vehicles with sub 150 L (39.6 gal., 33.0 Imp.gal.) Fuel tank fuel tank system capacity Vehicles without sub...

Save PDF
