Table of Contents

Advertisement

Quick Links

TABLE OF CONTENTS
1
Before driving
2
When driving
Interior
3
features
Maintenance
4
and care
When trouble
5
arises
Vehicle
6
specifications
7
For owners
Index
PRIUS_U_(L/O_0802)
Adjusting and operating features such as door locks,
mirrors, and steering column.
Driving, stopping and safe-driving information.
Air conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience.
Cleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information.
What to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident.
Detailed vehicle information.
Reporting safety defects for U.S. owners and seat belt
instructions for Canadian owners.
Alphabetical listing of information contained in this
manual.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRIUS 2008 and is the answer not in the manual?

Questions and answers

Rick
January 18, 2025

Dash light on but want start

0
1 comments:
Mr. Anderson
February 3, 2025

If your 2008 Toyota Prius won't start but the dash light is on, the hybrid system immobilizer may not have been deactivated. Additionally, if the "READY" light does not come on when you press the power switch with the shift lever in "P" and the brake pedal pressed, it could indicate a problem requiring immediate contact with a Toyota dealer.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Toyota PRIUS 2008

Summary of Contents for Toyota PRIUS 2008

  • Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. Driving, stopping and safe-driving information. When driving Air conditioning and audio systems, as well as other in- Interior terior features for a comfortable driving experience. features Cleaning and protecting your vehicle, performing do-it- Maintenance...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Index 1-7. Theft deterrent system..81 Before driving Immobilizer system....81 Alarm ........84 Theft prevention labels 1-1. Hybrid system ....22 (U.S.A.)....... 86 Hybrid system ...... 22 1-8. Safety information ....87 1-2. Key information ....34 Correct driving posture ..
  • Page 3 Headlight switch 3-2. Using the air conditioning (Type B) ......153 system and Fog light switch ....156 defogger......201 Windshield wipers and Automatic air conditioning washer (Type A) ....158 system (Vehicles with AUX adapter)......201 Windshield wipers and washer (Type B) ....
  • Page 4 TABLE OF CONTENTS Index Using the AUX adapter ..268 Using the steering Maintenance and care switches ......269 4-1. Maintenance and care ..346 3-4. Using the hands-free Cleaning and protecting the system......272 vehicle’s exterior....346 Hands-free system (for Cleaning and protecting the cellular phone) ....
  • Page 5 When trouble arises Vehicle specifications 5-1. Essential information ..416 6-1. Specifications ....462 If your vehicle needs to be Maintenance data (fuel, oil towed ........ 416 level, etc.)......462 If you think something is Fuel information....472 wrong ........ 423 Tire information ....
  • Page 6 Pictorial index Exterior Windshield wipers P. 158 Turn signal light P. 140 Outside rear view mirror P. 73 Hood P. 361 Side marker light/Parking light P. 150 Headlight P. 150  Fog light P. 156 PRIUS_U_(L/O_0802)
  • Page 7 Rear window wiper P. 162 Rear window defogger P. 217 Fuel filler door P. 78 Back door P. 54 Side door P. 51 Licence plate lights P. 150 Tire P. 379 ●Rotation ●Replacement P. 438 Turn signal light P. 140 ●Inflation pressure P.
  • Page 8 Pictorial index Interior Bottle holder P. 326 Seat belt P. 64 Driver airbag P. 89 Head restraint P. 62 Floor mat P. 335 Power window switch P. 75 Auxiliary box P. 327 Front passenger airbag P. 89 Glove box P. 323 Armrest P.
  • Page 9 Interior light Personal light P. 320 P. 320 Overhead console box P. 324 Vanity mirror P. 330 Interior light P. 320  SRS curtain shield airbag P. 89  Garage door opener switches P. 339 Anti-glare inside rear view mirror P.
  • Page 10 Pictorial index Interior Door lock switch P. 51 Power rear view mirror control switch P. 73 ITYPP005 Window lock switch P. 75 Power window switches P. 75 PRIUS_U_(L/O_0802)
  • Page 11 Auxiliary box P. 327 Cup holders P. 325 Power outlet P. 332  AUX adapter P. 268 Cup holders P. 325  : If equipped PRIUS_U_(L/O_0802)
  • Page 12 Pictorial index Instrument panel Gauges and meters P. 143 Windshield wipers and washer switch P. 158 “P” position switch P. 137 Headlight switch P. 150 Turn signal lever P. 140 Auxiliary box P. 327  Fog light switch P. 156 Power outlet P.
  • Page 13 Touch screen P. 186 Navigation system Km/h or MPH button P. 144 Clock P. 331 Audio system P. 219 Trip meter reset button P. 144 Emergency flashers  : If equipped : Refer to “Navigation System Owner’s Manual”. PRIUS_U_(L/O_0802)
  • Page 14 Pictorial index Instrument panel “INFO” button P. 27 “POWER” switch P. 130  Telephone switch P. 272 Climate emote control switches P. 215  Cruise control switch P. 164 Talk switch P. 284 Key slot P. 130, 450 PRIUS_U_(L/O_0802)
  • Page 15 Audio remote control switches P. 269 Climate remote control switches P. 215 Instrument panel light control P. 144  : If equipped : Refer to “Navigation System Owner’s Manual”. PRIUS_U_(L/O_0802)
  • Page 16 Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehi- cle. This vehicle should not be modified with non-genuine Toyota prod- ucts.
  • Page 17 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle. Perchlorate Material Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
  • Page 18 In the event of that your vehicle must be disposed of, the hybrid battery must be disposed of your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, they may cause electric shock that can result in death or serious injury.
  • Page 19 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 20 PRIUS_U_(L/O_0802)

  • Page 21: Before Driving

    Before driving 1-1. Hybrid system ....22 1-5. Opening and closing the Hybrid system ....22 windows and moon roof ....... 75 Power windows ....75 1-2. Key information....34 Keys ........34 1-6. Refueling......78 Opening the fuel tank cap .. 78 1-3.

  • Page 22: Hybrid System

    1-1. Hybrid system Hybrid system Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
  • Page 23 1-1. Hybrid system ■ When stopped/during take-off The gasoline engine stops when the vehicle is stopped. During take-off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the motor is used. ■...
  • Page 24 After the 12 volt battery has discharged or has been changed or removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. PRIUS_U_(L/O_0802)
  • Page 25 You may hear cooling fan sounds coming from the air intake vents behind ● the rear seat. ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS_U_(L/O_0802)
  • Page 26 1-1. Hybrid system High voltage components Air conditioning compressor Hybrid battery (Traction bat- tery) High voltage cables (orange color) Service plug Power control unit Caution label Electric motor (Traction motor) Take care when handling the hybrid system, as it contains a high volt- age system (about 500V at maximum) as well as parts that become extremely hot when the hybrid system is operating.
  • Page 27 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Energy monitor/consumption screen You can view the status of your hybrid system on the touch screen (P.
  • Page 28 1-1. Hybrid system ■ Energy monitor How to display on the touch screen: Press STEP Touch on the “Information” screen. STEP If the “Consumption” screen is displayed, touch How to display with steering switch: Press STEP If the “Consumption” screen is displayed, press Touch screen Type A Type B...
  • Page 29 1-1. Hybrid system Touch screen Type A Type B When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Full Hybrid battery (trac- tion battery) status PRIUS_U_(L/O_0802)
  • Page 30 1-1. Hybrid system ■ Consumption How to display on the touch screen: Press STEP Touch on the “Information” screen. STEP If the “Energy Monitor” screen is displayed, touch How to display with steering switch: Press STEP If the “Consumption” screen is displayed, press Type A Fuel consumption in the past 30 minutes...
  • Page 31 If a warning light comes on or a warning message is displayed, or the 12 volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” light does not come on, contact your Toyota dealer. PRIUS_U_(L/O_0802)
  • Page 32 1-1. Hybrid system CAUTION ■ High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12 volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. Never touch, disassemble, remove or replace the high voltage parts, ●...
  • Page 33 1-1. Hybrid system CAUTION ■ Road accident cautions Observe the following precautions to reduce the risk of injury. Pull your vehicle off the road, put the shift lever in “P”, apply the parking ● brake, turn the hybrid system off. Do not touch the high voltage parts, cables and connectors.

  • Page 34: Key Information

    1-2. Key information Keys The following keys are provided with the vehicle. Vehicles with smart entry & start system Electronic keys • Operating the smart key system (P. 36) • Operating the wireless remote control function (P. 49) Mechanical keys Key number plate Vehicle without smart entry &...
  • Page 35 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 449) NOTICE ■...

  • Page 36: Opening, Closing And Locking The Doors And Back Door

    1-3. Opening, closing and locking the doors and back door Smart key system (if equipped) The following operations can be performed simply by carrying the electronic key, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the side doors (P.
  • Page 37 1-3. Opening, closing and locking the doors and back door Locking and unlocking the doors (front door handles only) Press the lock button to lock the door. Grip the handle to unlock the door. Make sure to touch the sensor on the back of the handle.
  • Page 38 1-3. Opening, closing and locking the doors and back door Locking and unlocking the back door Press the lock button to lock the door. Press the open switch to unlock the door. The door cannot be unlocked for 3 seconds after the door is locked. PRIUS_U_(L/O_0802)
  • Page 39 1-3. Opening, closing and locking the doors and back door Antenna location and effective range ■ Antenna location Antennas outside cabin Antennas inside cabin Antenna outside back door PRIUS_U_(L/O_0802)
  • Page 40 1-3. Opening, closing and locking the doors and back door ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 3ft. (1 m) of an outside front door handles.
  • Page 41 1-3. Opening, closing and locking the doors and back door To disable smart key system If you do not intend to drive your vehicle for a long time, push the can- cel switch to deactivate the smart entry and start system. Disabled Enabled KE Y...
  • Page 42 1-3. Opening, closing and locking the doors and back door ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
  • Page 43 1-3. Opening, closing and locking the doors and back door ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. Turn the “POWER” switch OFF. STEP When the indicator on the key surface is turned off, push and hold STEP for approximately 5 seconds while pushing the button on...
  • Page 44 1-3. Opening, closing and locking the doors and back door ■ Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. When the entry function has not been used for 2 weeks or more ●...
  • Page 45 1-3. Opening, closing and locking the doors and back door ■ Note for the smart key system Even when the electronic key is within the effective range (detection ● areas), the system may not operate properly in the following cases. •...
  • Page 46 1-3. Opening, closing and locking the doors and back door ■ Alarms and warning indicators A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures according to which warning light comes on. (P.
  • Page 47 ● ■ When the electronic key battery is fully depleted P. 396 ■ Customization that can be configured at Toyota dealer Settings (e.g. smart key system) can be changed. (Customizable features P. 488) ■ Certification for the smart key system For vehicles sold in the U.S.A.
  • Page 48 (P. 39) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.

  • Page 49: Wireless Remote Control

    1-3. Opening, closing and locking the doors and back door Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle and the back door from outside the vehicle. Locks all doors Unlocks all doors Sounds alarm (push and hold) (P.
  • Page 50 If the wireless remote control does not function or if it only operates very close to the vehicle, the battery may be low. (P. 396) ■ Customization that can be configured at Toyota dealer Settings (e.g. 2-step unlocking function) can be changed. (Customizable features P. 488) ■...

  • Page 51: Doors

    1-3. Opening, closing and locking the doors and back door Doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Smart key system P. 37 ■ Wireless remote control P. 49 ■...
  • Page 52 1-3. Opening, closing and locking the doors and back door Locking the front doors from the outside without a key Move the inside lock button to the lock position. STEP Close the door while pulling the door handle. STEP Vehicles with smart key system The door cannot be locked if the “POWER”...
  • Page 53 Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (P. 450) ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features P. 488) CAUTION ■...

  • Page 54: Back Door

    1-3. Opening, closing and locking the doors and back door Back door The back door can be opened using the back door opener. ■ Back door opener Press the open switch to unlock the door. ■ Smart key system P. 38 PRIUS_U_(L/O_0802)
  • Page 55 1-3. Opening, closing and locking the doors and back door ■ Luggage compartment light ITY13P015 ■ When closing the back door Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it. ITY13P014 ■...
  • Page 56 1-3. Opening, closing and locking the doors and back door CAUTION ■ Caution while driving Keep the back door closed. This not only keeps personal belongings from being thrown out, but also pre- vents exhaust gases from entering the vehicle. ■...

  • Page 57: Adjustable Components (Seats, Mirrors, Steering Wheel)

    1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever ■ Flattening seatbacks Move the seat forward and remove the head restraint. After returning seat to its original position, be certain to replace the head restraint.
  • Page 58 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Reclining adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.

  • Page 59: Rear Seats

    1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats Seatback angle adjustment button Press the button down until the lock is completely released. Folding down rear seatbacks ■ Before folding down rear seatbacks Stow the rear center seat belt buckle. PRIUS_U_(L/O_0802)
  • Page 60 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Folding down rear seatbacks Remove the seat belt from the STEP guide. In case you do not remove the seat belt from the guide, the seat belt might be locked when you fold down the rear seatbacks.
  • Page 61 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdo- men or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.

  • Page 62: Head Restraints

    1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints ■ Vertical adjustment Vertical adjustment Push and hold the lock release button when lowering the head restraint. Lock Removal release button Grip head restraint and remove while holding the lock release button.
  • Page 63 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. ●...

  • Page 64: Seat Belts

    1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 65 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to...
  • Page 66 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around fully.
  • Page 67 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, personalized seat belt extender is available from your Toyota dealer free of charge. PRIUS_U_(L/O_0802)
  • Page 68 Do not attempt to install, remove, modify, disassemble or dispose of a seat ● belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
  • Page 69 If the pretensioner has activated, the seat belt becomes locked: it cannot ● be further extended, nor will it return to the stowed position. The seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Using a seat belt extender Do not wear the seat belt extender, if you can fasten the seat belt without ●...

  • Page 70: Steering Wheel

    1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position while the “POWER” switch is in ACCESSORY or ON mode. Hold steering STEP wheel and press the lever down. Adjust to the ideal STEP position by moving the steering wheel verti-...

  • Page 71: Anti- Glare Inside Rear View Mirror

    1-4. Adjustable components (seats, mirrors, steering wheel) Anti- glare inside rear view mirror Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In the “AUTO” mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light.
  • Page 72 1-4. Adjustable components (seats, mirrors, steering wheel) ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure correct functioning of the sen- sors, do not touch or cover the sensors. CAUTION ■ While driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, or result- ing in death or serious injury.

  • Page 73: Outside Rear View Mirrors

    1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “POWER” switch is in ACCESSORY or ON mode. Select a mirror to adjust Left Right Adjust the mirror Right Down Left Folding the mirrors...
  • Page 74 1-4. Adjustable components (seats, mirrors, steering wheel) ■ When the mirrors are fogged up (vehicle with mirror defoggers) Turn on the mirror heaters to defog the mirrors. (P. 217) CAUTION ■ While driving Observe the following precautions. Failing to do so may result in losing control of the vehicle and cause an acci- dent, resulting in death or serious injury.

  • Page 75: Opening And Closing The Windows And Moon Roof

    1-5. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) :Pushing the switch in the opposite direction will stop window travel partway.
  • Page 76 The indicator on the switch changes from a flashing pattern to being on when initial settings are complete. ■ Customization that can be configured at Toyota dealer Settings (e.g. linked door lock operation) can be changed. (Customizable features P. 488)
  • Page 77 1-5. Opening and closing the windows and moon roof CAUTION ■ When closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body ●...

  • Page 78: Refueling

    1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the “POWER” switch OFF and ensure that all the doors and windows are closed. ■ Opening the fuel tank cap Open the fuel filler door.
  • Page 79 1-6. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap clockwise until you hear a click. The cap will revolve slightly in the opposite direction once released. ■ Fuel types Use unleaded gasoline. (87 Octane Rating [Research Octane Number 91] or higher) ■...
  • Page 80 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.

  • Page 81: Theft Deterrent System

    1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if the key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicle with smart key sys- tem: The indicator light flashes after...
  • Page 82 1-7. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type of immobilizer system. ■ Conditions that may cause the system to malfunction If the grip portion of the key is in contact with a metallic object. ● If the key is in close proximity to or touching a key to the security system ●...
  • Page 83 1-7. Theft deterrent system NOTICE ■ For proper system operation Do not modify, remove or disable the hybrid vehicle immobilizer system. If any unauthorized changes or modifications are made, the proper operation of the system cannot be guaranteed. PRIUS_U_(L/O_0802)

  • Page 84: Alarm

    1-7. Theft deterrent system Alarm (if equipped) The system sounds the alarm and flashes the vehicle lights when an attempt to steal the vehicle is detected. ■ Triggering the alarm The alarm is triggered in the following situations. ● A locked door or back door is unlocked or opened in any way other than using the entry function, wireless remote door lock function or using the mechanical key.
  • Page 85 1-7. Theft deterrent system ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following Nobody is in the vehicle. ● The windows are closed before the alarm is set. ●...

  • Page 86: Theft Prevention Labels (U.s.a.)

    1-7. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. PRIUS_U_(L/O_0802)

  • Page 87: Safety Information

    1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 88 1-8. Safety information CAUTION ■ While driving Do not adjust the position of the driver’s seat. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...

  • Page 89: Srs Airbags

    1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 90 1-8. Safety information Airbag system components Front passenger airbag Side and curtain shield airbag sensor (if equipped) Side airbag (if equipped) Front airbag sensor Curtain shield airbag (if equipped) Airbag sensor assembly SRS warning light “AIR BAG ON” and “AIR BAG OFF”...
  • Page 91 1-8. Safety information Your vehicle is equipped with “ADVANCED AIRBAGS” designed based on US motor vehicle safety standards (FMVSS208). The air- bag system controls airbag deployment power for the driver and front passenger. The driver airbag system consists of the driver seat’s position sensor etc.
  • Page 92 1-8. Safety information ■ Operating conditions (front airbags) The SRS front airbags will deploy if the severity of the frontal impact is ● above the designed threshold level, comparable to an approximate 15 mph (25 km/h) collision, when the vehicle impacts straight into a fixed barrier that does not move or deform.
  • Page 93 1-8. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or ●...
  • Page 94 1-8. Safety information ■ Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags [if equipped]) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 95 1-8. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the 12 volt battery cables before contacting your Toyota dealer. Any of the SRS airbags have been inflated.
  • Page 96 1-8. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts ● properly. The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 97 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 98 1-8. Safety information CAUTION ■ SRS airbag precautions Do not sit on the edge of the seat or ● lean against the dashboard. Do not allow a child to stand in front of ● the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 99 If the areas where the SRS airbags are stored, such as the steering wheel ● pad and front pillar garnish, are damaged or cracked, have them replaced by your Toyota dealer. Do not place anything, such as a cushion, on the front passenger’s seat ●...
  • Page 100 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.

  • Page 101: Front Passenger Occupant Classification System

    1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light “AIR BAG OFF”...
  • Page 102 1-8. Safety information Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the right side...
  • Page 103 1-8. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the right side passenger seats Devices Curtain shield airbag in the front Activated...
  • Page 104 1-8. Safety information ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the right side passenger seats Devices Curtain shield airbag in the front...
  • Page 105 1-8. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger’s seat belt tab has not been left inserted ●...
  • Page 106 Do not kick the front passenger seat or subject it to severe impact. Other- ● wise, the SRS warning light may come on to indicate a malfunction on the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the ●...

  • Page 107: Child Restraint Systems

    1-8. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 108 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
  • Page 109 1-8. Safety information CAUTION ■ Child restraint precautions Never install a rear-facing child restraint system on the front passenger ● seat even if “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.

  • Page 110: Installing Child Restraints

    1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the outboard rear seats using a seat belt or a child restraint lower anchor belt. Attach the top strap when install- ing a child restraint. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except...
  • Page 111 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
  • Page 112 1-8. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 113 1-8. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 114 1-8. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with child restraint lower anchorages Type A Widen the gap between STEP the seat cushion and seatback slightly.
  • Page 115 1-8. Safety information Type B Widen the gap between STEP the seat cushion and seatback slightly. Latch the buckles onto STEP the anchorages. If the child restraint has a top strap, the top strap should be latched onto the anchorage. For owners in Canada: The symbol on a child restraint system indicates the presence of...
  • Page 116 1-8. Safety information Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top strap. Make sure the top strap is securely latched. Reinstall the head restraint. STEP ITY18P041 ■ Laws and regulations pertaining to anchorages Anchorages conform to FMVSS225 or CMVSS210.2.
  • Page 117 1-8. Safety information CAUTION ■ When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be injured or even killed in the event of sudden braking or an accident.
  • Page 118 1-8. Safety information CAUTION ■ Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of a colli- sion.

  • Page 119: When Driving

    When driving 2-1. Driving procedures ..120 2-3. Operating the lights and Driving the vehicle.... 120 windshield wipers ..150 Headlight switch Power (ignition) switch ..130 (Type A) ......150 Transmission....136 Headlight switch Turn signal lever (Type B) ......153 (Type A) ......

  • Page 120: Driving Procedures

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the hybrid system (P. 131) ■ Driving With the brake pedal depressed, shift the shift lever to “D”. STEP (P. 136) Release the parking brake.
  • Page 121 ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: For the first 180 miles (300 km): ●...
  • Page 122 2-1. Driving procedures Avoid repeated acceleration ● Repeated acceleration consumes hybrid battery (traction battery) power, resulting in poor acceleration. Battery power can be restored by driving with the accelerator pedal slightly released. Push the “P” position switch when parking ● In the “N”...
  • Page 123 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. PRIUS_U_(L/O_0802)
  • Page 124 2-1. Driving procedures CAUTION ■ When driving the vehicle Do not under any circumstances shift the shift lever to “R”, “N” or push the ● “P” position switch while the vehicle is moving. Doing so can cause significant damage to the transmission and may result in a loss of vehicle control.
  • Page 125 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and ● reduce your ability to control the vehicle, resulting in an accident. Sudden changes in engine speed, such as engine braking caused by ●...
  • Page 126 Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 127 2-1. Driving procedures CAUTION ■ When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to hybrid system overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 128 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
  • Page 129 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function ● Changes in quantity and quality of engine oil, transmission fluid for the ●...

  • Page 130: Power (Ignition) Switch

    2-1. Driving procedures Power (ignition) switch Modes can be switched by pressing the “POWER” switch when car- rying the electronic key on your person. (The hybrid system can be started in any mode by operating the switch at the same time as depressing the brake pedal.) ■...
  • Page 131 2-1. Driving procedures ■ Starting the hybrid system (vehicle with smart key system) Check that the parking brake is set. STEP Turn off unnecessary lights and accessories. STEP Check that the shift position is set in “P”. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Press the “POWER”...
  • Page 132 2-1. Driving procedures ■ Starting the hybrid system (vehicle without smart key sys- tem) Check that the parking brake is set. STEP Turn off unnecessary lights and accessories. STEP Check that the shift position is set in “P”. STEP Insert the key into the key slot STEP and firmly with the brake pedal depressed.
  • Page 133 2-1. Driving procedures Press the “POWER” switch. STEP After a few seconds, the “READY” light will flash and READY come on with a beep sound. POWER The vehicle can move when the “READY” light is on, even if the hybrid system is stopped. ITY21P002 PRIUS_U_(L/O_0802)
  • Page 134 ■ If the “READY” light does not come on If the “READY” light does not come on when you press the power switch with the shift lever in “P” and the brake pedal pressed, contact your Toyota dealer immediately. ■...
  • Page 135 2-1. Driving procedures CAUTION ■ When starting the hybrid system Always start the hybrid system while sitting in the driver’s seat. Do not press the accelerator pedal while starting the hybrid system under any circum- stances. Doing so may cause an accident resulting in death or serious injury. ■...

  • Page 136: Transmission

    2-1. Driving procedures Transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever You can operate the shift lever only in “D”. Keep the shift lever in “N” for a while after you shift it to that position. The shift lever always returns to this original position after shifting...
  • Page 137 2-1. Driving procedures ■ Shift position uses Shift position Function Parking the vehicle or starting the hybrid system Reversing Neutral Normal driving Engine braking position : Shown only while in “D” position. Changing shift ranges in “P” position With the brake pedal pressed down, push the “P”...
  • Page 138 If the system malfunctions The following conditions, there is some problem in the system. Immediately stop the vehicle in a safe place and contact your Toyota dealer. The indicator on the “P” position switch flashes. However, this does not ●...
  • Page 139 2-1. Driving procedures ■ Alarms The following table describes circumstances and correction procedures when only alarms are sound. Alarm Situation Correction procedure The transmission will The driver attempts to shift not move out of the “P” out of the “P” position with- position, so press the out pressing the brake brake pedal before...

  • Page 140: Turn Signal Lever (Type A)

    2-1. Driving procedures Turn signal lever (Type A) Left turn Right turn Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever.

  • Page 141: Turn Signal Lever (Type B)

    2-1. Driving procedures Turn signal lever (Type B) Left turn Right turn Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever.

  • Page 142: Parking Brake

    2-1. Driving procedures Parking brake Sets the parking brake (Depressing the pedal again releases the parking brake.) : Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. U.S.A. Canada ITY21P007 NOTICE ■...

  • Page 143: Instrument Cluster

    2-2. Instrument cluster Gauges and meters The following gauges and meters illuminate when the “POWER” switch is in ON mode. Shift position indicator Displays the shift position Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Odometer Displays the total distance the vehicle has been driven.
  • Page 144 2-2. Instrument cluster Odometer/trip meter and trip meter reset button Odometer Trip meter A Trip meter B : Pushing and holding the but- ton will reset the trip meter. MPH or km/h button The speed units can be selected MPH or km/h. km/h km/h ITY22P003...
  • Page 145 2-2. Instrument cluster NOTICE ■ To prevent damage to the hybrid system and its components The hybrid system may be overheating if the high coolant temperature warn- ing light is displayed on the touch screen. In this case, immediately stop the vehicle in a safe place.

  • Page 146: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Touch screen (Type A) ITY22P006 PRIUS_U_(L/O_0802)
  • Page 147 2-2. Instrument cluster Touch screen (Type B) ITY22P007 PRIUS_U_(L/O_0802)
  • Page 148 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator SRS airbag on-off indi- (P. 140) cator (P. 101) Headlight high beam Recirculate mode indi- indicator (P. 150) cator (P.
  • Page 149 Have the vehicle inspected by your Toyota dealer immediately if this occurs.

  • Page 150: Operating The Lights And Windshield Wipers

    2-3. Operating the lights and windshield wipers Headlight switch (Type A) The headlights can be operated manually or automatically. The side marker, park- ing, tail, license plate and instrument panel Canada U.S.A. lights turn on. The headlights and all lights listed above turn The headlights and all the lights listed above (if equipped)
  • Page 151 ■ If the indicator flashes... It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization Settings (e.g. light sensor sensitivity) can be changed. (P. 488) PRIUS_U_(L/O_0802)
  • Page 152 2-3. Operating the lights and windshield wipers NOTICE ■ To prevent 12 volt battery discharge Do not leave the lights on longer than necessary if the hybrid system is not running. PRIUS_U_(L/O_0802)

  • Page 153: Headlight Switch (Type B)

    2-3. Operating the lights and windshield wipers Headlight switch (Type B) The headlights can be operated manually or automatically. The side marker, park- ing, tail, license plate and instrument panel Canada U.S.A. lights turn on. The headlights and all lights listed above turn The headlights and all the lights listed above (if equipped)
  • Page 154 ■ If the indicator flashes... It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization Settings (e.g. light sensor sensitivity) can be changed. (P. 488) PRIUS_U_(L/O_0802)
  • Page 155 2-3. Operating the lights and windshield wipers NOTICE ■ To prevent 12 volt battery discharge Do not leave the lights on longer than necessary if the hybrid system is not running. PRIUS_U_(L/O_0802)

  • Page 156: Fog Light Switch

    2-3. Operating the lights and windshield wipers Fog light switch (if equipped) The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Type A ITY23P004 PRIUS_U_(L/O_0802)
  • Page 157 2-3. Operating the lights and windshield wipers Type B PRIUS_U_(L/O_0802)

  • Page 158: Windshield Wipers And Washer (Type A)

    2-3. Operating the lights and windshield wipers Windshield wipers and washer (Type A) Wiper intervals can be adjusted for intermittent operation (when “INT” is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation ITY23P005 Wash/wipe operation Wipers operate automatically.
  • Page 159 2-3. Operating the lights and windshield wipers ■ The windshield wiper and washer can be operated when The “POWER” switch is in ON mode. ■ Intermittent windshield wiper interval (“INT”) mode Intermittent windshield wiper interval adjustment (increase) Intermittent windshield wiper interval adjustment (decrease) ITY23P008 ■...

  • Page 160: Windshield Wipers And Washer (Type B)

    2-3. Operating the lights and windshield wipers Windshield wipers and washer (Type B) Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation ITY23P012 Wash/wipe operation Wipers operate automatically.
  • Page 161 2-3. Operating the lights and windshield wipers ■ The windshield wiper and washer can be operated when The “POWER” switch is in ON mode. ■ Intermittent windshield wiper interval mode Intermittent windshield wiper interval adjustment (decrease) Intermittent windshield wiper interval adjustment (increase) ITY23P014 ■...

  • Page 162: Rear Window Wiper And Washer (Type A)

    2-3. Operating the lights and windshield wipers Rear window wiper and washer (Type A) Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion ITY23P006 ■ The rear window wiper and washer can be operated when The “POWER”...

  • Page 163: Rear Window Wiper And Washer (Type B)

    2-3. Operating the lights and windshield wipers Rear window wiper and washer (Type B) Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion ITY23P015 ■ The rear window wiper and washer can be operated when The “POWER”...

  • Page 164: Using Other Driving Systems

    2-4. Using other driving systems Cruise control (if equipped) Use the cruise control to maintain a set speed without using the accelerator. ■ Set the vehicle speed Turn the “ON-OFF” button ON. STEP Push the button once more to deactivate the cruise control. Accelerate or decelerate to STEP the desired speed and press...
  • Page 165 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. PRIUS_U_(L/O_0802)
  • Page 166 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Keep the “ON-OFF” button off when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause seri- ous or fatal accident.

  • Page 167: Rear View Monitor System

    2-4. Using other driving systems Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle while reversing. The image is displayed in reverse on the screen. This allows the image to appear in the same manner as that of the rear view mirror.
  • Page 168 2-4. Using other driving systems ■ Rear view monitor system camera In the following cases, it may be difficult to see the images on the screen, even when the system is functioning correctly. • In the dark (e.g. at night). •...
  • Page 169 Conditions which may affect the rear view monitor system If the back of the vehicle is hit, the camera’s position and mounting angle ● may change. Contact your Toyota dealer. Rapid temperature changes, such as when hot water is poured on the ●...

  • Page 170: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 171 2-4. Using other driving systems ■ Sounds and vibrations caused by the ABS, BA and Enhanced VSC A sound may be heard from the hybrid system compartment when the ● hybrid system is started or just after the vehicle begins to move. This sound does not indicate that a malfunction has occurred in any of these systems.
  • Page 172 In addition, make sure that the tires are inflated to the speci- fied tire pressure level. The ABS and Enhanced VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. PRIUS_U_(L/O_0802)

  • Page 173: Driving Information

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the back door whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far forward as possible helps maintain vehicle balance.
  • Page 174 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 176) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Example on your vehicle...
  • Page 175 2-5. Driving information CAUTION ■ Storage precautions Do not place anything on the package tray behind the rear seatback. ● Such items may be thrown about and possibly injure people in the vehicle during sudden braking or in an accident. Do not drive with objects on top of the instrument panel.

  • Page 176: Vehicle Load Limits

    Even if the number of occupants are within the seating capacity, do not exceed the total load capacity. ■ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ■ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.

  • Page 177: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 178 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions. ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 179 2-5. Driving information Regulations on the use of snow chains ● Regulations regarding the use of tire chains vary according to loca- tion and type of road. Always check local regulations before install- ing chains. ● Use SAE Class “S” type radial tire chains, with the exception of radial cable chains or V-bar type chains.
  • Page 180 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.

  • Page 181: Trailer Towing

    Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.

  • Page 182: Dinghy Towing

    2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. ITY25P002 NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. PRIUS_U_(L/O_0802)
  • Page 183 2-5. Driving information PRIUS_U_(L/O_0802)
  • Page 184 3-1. Using the touch screen ......186 Touch screen ....186 Setting the touch screen (Vehicles with AUX adapter) ......191 Setting the touch screen (Vehicles without AUX adapter) ......196 3-2. Using the air conditioning system and defogger ....201 Automatic air conditioning system (Vehicles with AUX adapter) ......

  • Page 185: Interior Features

    Interior features 3-3. Using the audio system. 219 3-4. Using the hands-free Audio system type (Vehicle system ......272 with AUX adapter)..219 Hands-free system (for cellular phone) ....272 Audio system type (Vehicle ® without AUX adapter)..222 Using the Bluetooth phone ......

  • Page 186: Using The Touch Screen

    v3-1.Using the touch screen Touch screen By touching the screen with your finger, you can control the audio system and air-conditioning, adjust the screen display etc. Vehicles with navigation system Vehicles without navigation system (Type A) PRIUS_U_(L/O_0802)
  • Page 187 3-1. Using the touch screen Vehicles without navigation system (Type B) The “Information” screen shown in the above illustration is displayed when is pressed. Switches Page “CLIMATE” P. 201, 208 “AUDIO” P. 219, 222 “INFO” (Displaying the “Informa- P. 186 tion”...
  • Page 188 3-1. Using the touch screen The initial screen Vehicles with navigation system and vehicles without navigation system (Type A) If the “POWER” switch is set to ACCESSORY or ON mode, the initializing screen will be dis- played for a few seconds as the system starts up.
  • Page 189 3-1. Using the touch screen Outside temperature display The outside temperature is shown ranging from -22 °F (-30 °C) up to 122 °F (50 °C) at the upper right of the energy consumption or energy monitor screen or the upper left/right of the air conditioner screen.
  • Page 190 3-1. Using the touch screen ■ To avoid damaging the touch screen Touch the screen lightly with your finger. If there is no response, remove ● your finger from the screen and try again. Remove any dirt on the screen by wiping with a soft cloth. Do not use ●...

  • Page 191: Setting The Touch Screen (Vehicles With Aux Adapter)

    3-1. Using the touch screen Setting the touch screen (Vehicles with AUX adapter) You can change the touch screen to your desired settings. Language settings The language used for all voice guidance, messages and touch screen switches may be changed. Press STEP Touch...
  • Page 192 3-1. Using the touch screen STEP Touch Adjusting the display Press STEP Adjust the display as desired using STEP If you do not touch the screen for 20 seconds, the system will return to the previous screen. Contrast Weaker Stronger Brightness Darker Brighter...
  • Page 193 3-1. Using the touch screen ■ “Day Mode” When the headlights are turned on, the screen dims. However the screen can be switched to “Day Mode”. The screen will stay in “Day Mode” when the headlights are turned on until is touched again.
  • Page 194 3-1. Using the touch screen Screen settings Press STEP Touch on the “Information” screen. STEP The following screen settings can be changed. Automatic transition 20 seconds after air-conditioning or audio system use, the system will return the display to the previ- ous screen.
  • Page 195 3-1. Using the touch screen ■ Setting automatic transition Touch on the “Screen Setting” screen. STEP Press STEP ■ Setting the switch color Touch on the “Screen Setting” screen. STEP Press STEP ■ To delete personal data Touch the on the “Screen Setting” screen. STEP Touch STEP...

  • Page 196: Setting The Touch Screen (Vehicles Without Aux Adapter)

    3-1. Using the touch screen Setting the touch screen (Vehicles without AUX adapter) You can change the touch screen to your desired settings. Language settings The language used for all voice guidance, messages and touch screen switches may be changed. Press STEP Touch...
  • Page 197 3-1. Using the touch screen Adjusting the display Press STEP Adjust the display as desired using STEP If you do not touch the screen for 20 seconds, the system will return to the previous screen. ITY31P013 Contrast Weaker Stronger Brightness Darker Brighter PRIUS_U_(L/O_0802)
  • Page 198 3-1. Using the touch screen ■ “Day Mode” When the headlights are turned on, the screen dims. However the screen can be switched to “Day Mode”. The screen will stay in “Day Mode” when the headlights are turned on until is touched again.
  • Page 199 3-1. Using the touch screen Screen settings Press STEP Touch on the “Information” screen. STEP The following screen settings can be changed. Automatic transition 20 seconds after air-conditioning or audio system use, the system will return the display to the previ- ous screen.
  • Page 200 3-1. Using the touch screen ■ Setting automatic transition Touch on the “Screen Setting” screen. STEP Press STEP ■ Setting the switch color Touch on the “Screen Setting” STEP screen. Press STEP PRIUS_U_(L/O_0802)

  • Page 201: Using The Air Conditioning System And Defogger

    3-2. Using the air conditioning system and defogger Automatic air conditioning system (Vehicles with AUX adapter) Airflow and outlets are automatically adjusted according to the tem- perature setting. Press to display the air conditioning operation screen. Passenger compartment temperature display Outside temperature display Temperature control Air conditioning...
  • Page 202 3-2. Using the air conditioning system and defogger Using the automatic mode Press STEP indicator located in the instrument panel. The air conditioning system will begin to operate. Air outlets and fan, and automatically switches between outside air and recirculated air modes are automatically adjusted according to the temperature setting.
  • Page 203 3-2. Using the air conditioning system and defogger ■ Adjusting the fan speed Touch any switch of (decrease  increase) on the operating screen. Press to turn the fan off. ■ Changing the air outlets Touch any mode on the operat- ing screen.
  • Page 204 3-2. Using the air conditioning system and defogger Air flows to the feet. ITY32P005 Air flows to the feet and the windshield defogger operates. ITY32P006 PRIUS_U_(L/O_0802)
  • Page 205 3-2. Using the air conditioning system and defogger ■ Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle) and (introduces air from outside the vehicle) modes each time the but- ton is pressed. ●...
  • Page 206 3-2. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front outlets Direct air flow to the left or right, up or down Turn the knob to open or close the vent ITY32P008 ■...
  • Page 207 3-2. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.

  • Page 208: Automatic Air Conditioning System (Vehicles Without Aux Adapter)

    3-2. Using the air conditioning system and defogger Automatic air conditioning system (Vehicles without AUX adapter) Airflow and outlets are automatically adjusted according to the tem- perature setting. Press to display the air conditioning operation screen. Outside temperature display Passenger compartment Air conditioning ON/OFF temperature display switch...
  • Page 209 3-2. Using the air conditioning system and defogger Using the automatic mode Press STEP indicator located in the instrument panel. The air conditioning system will begin to operate. Air outlets and fan, and automatically switches between outside air and recirculated air modes are automatically adjusted according to the temperature setting.
  • Page 210 3-2. Using the air conditioning system and defogger ■ Adjusting the fan speed Touch any switch of (decrease  increase) on the operating screen. Press to turn the fan off. ■ Changing the air outlets Touch any mode on the operat- ing screen.
  • Page 211 3-2. Using the air conditioning system and defogger Air flows to the feet. ITY32P005 Air flows to the feet and the windshield defogger operates. ITY32P006 PRIUS_U_(L/O_0802)
  • Page 212 3-2. Using the air conditioning system and defogger ■ Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle) and (introduces air from outside the vehicle) modes each time the but- ton is pressed. ●...
  • Page 213 3-2. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front outlets Direct air flow to the left or right, up or down Turn the knob to open or close the vent ITY32P008 ■...
  • Page 214 3-2. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.

  • Page 215: Using The Steering Wheel Climate Remote Control Switches

    3-2. Using the air conditioning system and defogger Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Automatic mode Temperature control Recirculated air mode Windshield defogger mode Rear window and outside rear view mirror defogger mode...
  • Page 216 3-2. Using the air conditioning system and defogger Changing the recirculated air mode Press . (P. 205212) Using the windshield defogger mode Press . (P. 205, 212) Using the rear window and outside rear view mirror defogger mode Press . (217) PRIUS_U_(L/O_0802)

  • Page 217: Rear Window And Outside Rear View Mirror Defoggers

    3-2. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. (vehi- cles with mirror defoggers) Type A Press the button.
  • Page 218 3-2. Using the air conditioning system and defogger ■ Operating conditions The “POWER” switch must be in the ON mode. CAUTION ■ When the outside rear view mirror defoggers are on (vehicles with mir- ror defoggers) Do not touch the rear view mirror surfaces, as they can become very hot and burn you.

  • Page 219: Using The Audio System

    3-3. Using the audio system Audio system type (Vehicle with AUX adapter) CD and CD changer and AM/FM radio Press to display the audio operation screen. AUDIO This illustration below is for a vehicle equipped with the CD changer player. ITY33P001 Vehicles with navigation system Vehicles without navigation system...
  • Page 220 3-3. Using the audio system CD player:Plays audio CDs, CD text, MP3 discs and WMA discs. Title Page Using the radio P. 225 Using the CD player P. 239 Playing MP3 and WMA discs P. 254 Optimal use of the audio system P.
  • Page 221 3-3. Using the audio system CAUTION ■ For vehicles sold in the U.S.A. and Canada Part 15 of the FCC Rules ● FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. Laser products ●...

  • Page 222: Audio System Type (Vehicle Without Aux Adapter)

    3-3. Using the audio system Audio system type (Vehicle without AUX adapter) CD and AM/FM radio Press to display the audio operation screen. AUDIO ITY33P002 PRIUS_U_(L/O_0802)
  • Page 223 3-3. Using the audio system CD player:Plays audio CDs and CD text. Title Page Using the radio P. 234 Using the CD player P. 247 Optimal use of the audio system P. 266 Using the steering wheel switches P. 269 ■...
  • Page 224 3-3. Using the audio system NOTICE ■ To prevent 12 volt battery discharge Do not leave the audio system on longer than necessary when the engine is not running. ■ To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system. PRIUS_U_(L/O_0802)

  • Page 225: Using The Radio (Vehicle With Aux Adapter)

    3-3. Using the audio system Using the radio (vehicle with AUX adapter) Press to choose either an AM or FM band. When you press while listening to the radio, the following AUDIO audio control screen appears. Preset stations Scan for receivable stations (AM mode only)
  • Page 226 3-3. Using the audio system ® Setting station presets (excluding XM satellite radio) TUNE FILE Search for desired stations by turning the dial or press- STEP ing  or  on Touch and hold one of the preset stations (1 - 6) until you hear STEP a beep.
  • Page 227 3-3. Using the audio system ■ Scanning all radio stations within range AM station Touch on the screen or press STEP SCAN “SCAN” appears on the screen and all stations with reception will be played for a few seconds each. When the desired station is reached, touch or press STEP...
  • Page 228 3-3. Using the audio system The type of program changes each time the button is pressed. ● ROCK ● EASYLIS (Easy listening) ● CLS/JAZZ (Classical music and Jazz) ● R & B (Rhythm and Blues) ● INFORM (Information) ● RELIGION ●...
  • Page 229 3-3. Using the audio system ■ Traffic announcement Touch on the screen. “TRAF SEEK” appears on the dis- play, and the radio will start seek- station broadcasting traffic program information. If no traffic program station is found, “NOTHING” appears on the display.
  • Page 230 3-3. Using the audio system ® ■ Scanning XM satellite radio channels ● Scanning channels in the current category Touch on the screen or press STEP SCAN “SCAN” appears on the screen. When the desired channel is reached, touch STEP press the button once again.
  • Page 231 3-3. Using the audio system ■ When the 12 volt battery is disconnected All preset stations are erased. ■ Reception sensitivity Maintaining perfect radio reception at all times is difficult due to the con- ● tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
  • Page 232 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM satellite radio. The radio is being updated with the latest encryp- ®...
  • Page 233 3-3. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 438-9677 (Canada).

  • Page 234: Using The Radio (Vehicle Without Aux Adapter)

    3-3. Using the audio system Using the radio (Vehicle without AUX adapter) Press to choose either an AM or FM band. When you press while listening to the radio, the following AUDIO audio control screen appears. Presser stations Scan for receivable Display audio stations...
  • Page 235 3-3. Using the audio system Setting station presets Search for desired stations by turning the dial or STEP TUNE pressing  or  on Touch and hold one of the preset stations (1 - 6) until you hear STEP a beep. Scanning radio stations ■...
  • Page 236 3-3. Using the audio system ■ Scanning all radio stations within range AM station Touch on the screen or press STEP SCAN “SCAN” appears on the screen and all stations with reception will be played for a few seconds each. When the desired station is reached, touch or press STEP...
  • Page 237 3-3. Using the audio system The type of program changes each time the button is pressed. ● ROCK ● EASYLIS (Easy listening) ● CLS/JAZZ (Classical music and Jazz) ● R & B (Rhythm and Blues) ● INFORM (Information) ● RELIGION ●...
  • Page 238 3-3. Using the audio system ■ Traffic announcement Touch on the screen. “TRAF SEEK” appears on the dis- play, and the radio will start seek- station broadcasting traffic program information. If no traffic program station is found, “NOTHING” appears on the display.

  • Page 239: Using The Cd Player (Vehicle With Aux Adapter)

    3-3. Using the audio system Using the CD player (Vehicle with AUX adapter) Insert a CD or press with a CD inserted. When you press while listening to a CD, the following audio AUDIO control screen appears. Display track list Select CD Display audio Random playback...
  • Page 240 3-3. Using the audio system Loading a CD ■ Loading a CD (CD player without changer) Insert a CD. ■ Loading a single CD (CD player with changer) Press STEP When the indicator changes from flashing amber to green, STEP insert a CD after the CD player door opens.
  • Page 241 3-3. Using the audio system ■ Ejecting all CDs (CD player with changer) Press and hold until you hear a beep, then remove the CDs. Selecting, fast forwarding and scanning tracks ■ Selecting a track Press  to move up and  to move down using until the desired track number appears on the screen.
  • Page 242 3-3. Using the audio system Selecting a CD (CD player with changer only) ■ To select a CD to play Touch the desired disc number (1 - 6) on the screen. ■ To scan loaded CDs Touch and hold on the screen until you hear a beep. STEP The first 10 seconds of the first track on each CD will be played.
  • Page 243 If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. Up to 13 letters can be displayed. ■ Error messages Refer to the following table and take the appropriate measures. If the prob- lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures •...
  • Page 244 3-3. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used. ■...
  • Page 245 3-3. Using the audio system NOTICE ■ Discs and adapters that cannot be used Do not use the following types of discs, 3 in. (8 cm) disc adapters or dual discs. Doing so may damage the player and render the disc insert/eject function unusable.
  • Page 246 3-3. Using the audio system NOTICE ■ Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. ● Do not apply oil to the player. ●...

  • Page 247: Using The Cd Player

    3-3. Using the audio system Using the CD player (Vehicle without AUX adapter) Insert a CD or press with a CD inserted. When you press while listening to a CD, the following audio AUDIO control screen appears. Display audio control screen CLIMATE DISPLAY Select CD...
  • Page 248 3-3. Using the audio system Loading a CD ■ Loading a single CD Insert a CD. Ejecting CDs ■ Ejecting a CD Press and remove the CD. Selecting, fast forwarding and scanning tracks ■ Selecting a track Press  to move up and  to move down using until the desired track number appears on the screen.
  • Page 249 3-3. Using the audio system Displaying the disc and track title Touch on the screen. Random playback ■ Current CD Touch on the screen. Songs are played in random order until random playback is canceled. Repeating a track or a disc ■...
  • Page 250 If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. Up to 29 letters can be displayed. ■ Error messages Refer to the following table and take the appropriate measures. If the prob- lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures •...
  • Page 251 3-3. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used. ■...
  • Page 252 3-3. Using the audio system NOTICE ■ Discs and adapters that cannot be used Do not use the following types of discs, 3 in. (8 cm) disc adapters or dual discs. Doing so may damage the player and render the disc insert/eject function unusable.
  • Page 253 3-3. Using the audio system NOTICE ■ Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. ● Do not apply oil to the player. ●...

  • Page 254: Playing Mp3 And Wma Discs

    3-3. Using the audio system Playing MP3 and WMA discs (if equipped) Insert an MP3 or WMA disc or press with a disc inserted. When you press during playback of the disc, the following AUDIO audio control screen appears. Display audio Display folder list control screen Search playback...
  • Page 255 3-3. Using the audio system Loading, ejecting and selecting MP3 and WMA discs Refer to the section entitled “Using the CD player” for details. (P. 239) Selecting a folder ■ Selecting a folder Touch “FOLDER ” or “ ” on the screen to select the previ- ous/next folder.
  • Page 256 3-3. Using the audio system Selecting and scanning files ■ Selecting one file at a time TUNE FILE Turn the dial or press  or  on to select the desired file. ■ Selecting a file from the file list Touch on the screen to turn the folder list on.
  • Page 257 3-3. Using the audio system ■ Selecting a desired file by cueing the files in the folder Touch on the screen. When the desired file is reached, touch once again. File repeat Touch on the screen. Folder repeat Touch and hold on the screen until you hear a beep.
  • Page 258 3-3. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 259 3-3. Using the audio system Compatible disc formats ● The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 level 1, level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
  • Page 260 3-3. Using the audio system MP3 and WMA playback ● When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
  • Page 261 3-3. Using the audio system ■ CD-R and CD-RW discs CD-R/CD-RW discs that have not been subject to the “finalizing process” ● (a process that allows discs to be played on a conventional CD player) cannot be played. It may not be possible to play CD-R/CD-RW discs recorded on a music ●...

  • Page 262: Optimal Use Of The Audio (Vehicle With Aux Adapter)

    3-3. Using the audio system Optimal use of the audio (Vehicle with AUX adapter) Press on the panel to display the audio/video control screen. AUDIO Operating the radio and CD player (type A) Adjust sound quality and balance Adjust the ASL ITY33P019 Operating the radio and CD player (type B) Adjust sound...
  • Page 263 3-3. Using the audio system Adjusting sound quality and balance Touch on the screen. STEP Adjust the settings, referring to STEP the following table. Once you have finished, touch Sound quality Display Level Touch mode High-pitched -5 to 5 tones Mid-pitched tones -5 to 5...
  • Page 264 3-3. Using the audio system Setting DSP The following features can be set as desired by touching on the screen. Type B only ■ Turning Automatic Sound Levelizer (ASL) Type A Touch ASL automatically adjusts the volume and tone quality according to the noise level as you drive your vehicle.
  • Page 265 3-3. Using the audio system ■ Trademark owned by SRS Labs, Inc.   The audio systems utilize SRS FOCUS and SRS TruBass audio enhancement technologies, under license from SRS Labs, Inc., in all mode except AM radio mode.  FOCUS, TruBass, SRS and symbols are trademarks of SRS Labs, Inc.

  • Page 266: Optimal Use Of The Audio System (Vehicle Without Aux Adapter)

    3-3. Using the audio system Optimal use of the audio system (Vehicle without AUX adapter) Press on the panel to display the audio/video control screen. AUDIO Operating the radio and CD player Adjust sound quality and balance ITY33P023 Adjusting sound quality and balance Touch on the screen.
  • Page 267 3-3. Using the audio system Sound quality Display Level Touch mode High-pitched -5 to 5 tones Low-pitched -5 to 5 tones Front/rear F7 to R7 volume balance Left/right volume L7 to R7 balance : The sound quality level is adjusted individually in each radio or CD mode. ■...

  • Page 268: Using The Aux Adapter

    3-3. Using the audio system Using the AUX adapter (if equipped) This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connect the portable STEP audio device. Press STEP ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls.

  • Page 269: Using The Steering Switches

    3-3. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Volume Power on, select audio source Radio: Select radio stations CD: Select tracks, discs and folder Turning on the power Press when the audio system is turned OFF.
  • Page 270 3-3. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Hold down the button to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode. STEP Press or ...
  • Page 271 3-3. Using the audio system ■ Canceling automatic selection of a radio station Push the same switch. CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. PRIUS_U_(L/O_0802)

  • Page 272: Using The Hands-Free System

    3-4.Using the hands-free system Hands-free system (for cellular phone) The hands-free system is a function that allows you to use your mobile phone without touching it. ® ® This system supports Bluetooth mobile phones. Bluetooth is a wireless data system that allows the mobile phone to wirelessly con- nect to the hands-free system and make/receive calls.
  • Page 273 3-4. Using the hands-free system Status display You can check such indicators as signal strength and battery charge on the “Telephone” screen. Connection status Battery charge 1 2 3 Call area Signal strength ITY34P003 Indicators Conditions Blue: Good Yellow: Bad Connection status : Not connected : Full...
  • Page 274 3-4. Using the hands-free system ■ When using the hands-free system The audio system and voice guidance are muted when making a call. ● If both parties speak at the same time it may be difficult to hear. ● If the received call volume is overly loud, an echo may be heard. ●...
  • Page 275 3-4. Using the hands-free system ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models Compatible with HFP (Hands Free Profile) Ver. 1.0 and OPP (Object Push Profile) Ver. 1.1. ® If you cellular phone does not support HFP, you cannot enter the Bluetooth phone.
  • Page 276 3-4. Using the hands-free system FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth, for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.

  • Page 277: Using The Bluetooth ® Phone

    3-4. Using the hands-free system ® Using the Bluetooth phone Telephone screen ® Bluetooth Connection Status Character Deletion Display Last Person Called Make A Call ITY34P004 To display the screen shown above, press , then touch on the “Information” screen. ®...
  • Page 278 3-4. Using the hands-free system Touch STEP ITY34P005 Touch STEP ITY34P006 Input the passkey displayed on STEP screen into your phone. If the message “Bluetooth con- nection successful” is displayed, registration is complete. If the message “Bluetooth con- nection failed. Please check the “Passkey”...
  • Page 279 3-4. Using the hands-free system ® Bluetooth phone connection There are two connection methods available—automatic and man- ual. Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose one of the following methods. STEP Automatic connection If the “POWER”...
  • Page 280 3-4. Using the hands-free system Making a call ® Once the Bluetooth phone is registered, you can make a call using the following procedure. ■Dialing Press STEP Touch on the “Information” screen. STEP Inputting the phone number. STEP To delete the input phone num- ber, touch To dial the last input phone num- ber, touch...
  • Page 281 3-4. Using the hands-free system ■Dialing from the phone book You can dial a number from the phone book data imported from your mobile phone. Up to 1000 entries may be stored in the phone book. (P. 301) Press STEP Touch on the “Information”...
  • Page 282 3-4. Using the hands-free system ■Dialing from history You can make a call from past dialed numbers or received calls. Up to 5 numbers are stored, with the last recent number being deleted to make room for a new number. Press STEP Touch...
  • Page 283 3-4. Using the hands-free system ■Calling using speed dial You can make a call using numbers registered from the phone book and call history. (P. 292) Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose the desired number to STEP make a call.
  • Page 284 3-4. Using the hands-free system ■Calling using voice recognition Using voice recognition, you can call by name from the “Phone Book” screen, call by number from the “Telephone” screen, and send tones from the “Call” screen.(P. 288) Talk switch ITY34P015 ●Calling by name from the “Phone Book”...
  • Page 285 3-4. Using the hands-free system ●Calling by number from the “Telephone” screen Press the talk switch. STEP ITY34P017 Following the system guidance, wait until the beep and then STEP say the desired number. Following the system guidance, press the talk switch. STEP Following the system guidance, wait until the beep and then STEP...
  • Page 286 3-4. Using the hands-free system ■ Made/Received call history list If you make a call to or receive a call from a number registered in the ● phone book, the name is displayed in the call history. If you make multiple calls to the same number, only the last call made is ●...
  • Page 287 3-4. Using the hands-free system ■ To display the voice recognition operating guide After pressing the talk switch, STEP press . If the “Com- mand List” screen is display- ing, press Press STEP ITY34P020 ■ To cancel voice recognition Press and hold the talk switch. ●...
  • Page 288 3-4. Using the hands-free system ■To refuse a call Touch and hold ■To adjust the received call volume Press the . You can also adjust the volume using the steering switches. ■ International calls Received international calls may not be displayed correctly, depending on the mobile phone in use.
  • Page 289 3-4. Using the hands-free system ■Inputting a key When using phone services such as an answering service or a bank, you can store phone numbers and code numbers in the phone book. Touch STEP Input the number. STEP If repeated tone symbols stored in the phone book, are displayed on the right side of the screen.
  • Page 290 3-4. Using the hands-free system ■ Transferring calls It is not possible to transfer from hands-free to the mobile phone while ● driving. If you transfer from the mobile phone to hands-free, the hands-free ● screen will be displayed, and you can operate the system using the screen.

  • Page 291: Setting The Hands-Free System

    3-4. Using the hands-free system Setting the hands-free system You can speed dial, register in and edit the phone book, and set the ® Bluetooth phone. Settings screen Connection Method ITY34P024 To display the screen shown above, press , touch the “Information”...
  • Page 292 3-4. Using the hands-free system Registering/Deleting a speed dial item ■Registering a speed dial item You can register a number from the phone book or the call history. Up to 17 entries may be stored. Press STEP Touch on the “Information” screen. STEP Touch the switch on the “Telephone”...
  • Page 293 3-4. Using the hands-free system Select the number to be regis- STEP tered. ITY34P027 Press the desired switch. STEP The last dialed number will be registered in position 6. ITY34P028 ■Deleting a speed dial item Press STEP Touch on the “Information” screen. STEP Touch the switch on the “Telephone”...
  • Page 294 3-4. Using the hands-free system ■ To delete all speed dial items Follow the steps for “Deleting a speed dial item” to “STEP 5”. In the “Speed Dial” section of the “Speed Dial Settings” screen, touch the . A confir- mation message will be displayed.
  • Page 295 3-4. Using the hands-free system Input the number and touch STEP ITY34P031 Touch the desired switch. STEP ITY34P032 ■Editing a speed tone Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Speed Tone”...
  • Page 296 3-4. Using the hands-free system Touch the switch to be edited. STEP ITY34P033 Input the name and touch STEP Input the number and touch STEP ■Deleting a speed tone Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings”...
  • Page 297 3-4. Using the hands-free system Setting the volume Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch to lower or STEP raise the volume. Voice Volume: Change speaker volume Ring Volume: Change the ring volume ITY34P034...
  • Page 298 3-4. Using the hands-free system Changing the screen settings The following settings can be changed. “Incoming Call Display” The incoming call screen set- tings can be changed. “Auto Answer” When a call is received, the system automatically switches to the talking screen after the ITY34P035 set period of time, meaning you can speak without press-...
  • Page 299 3-4. Using the hands-free system ■“Incoming Call Display” settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Select the desired switch. STEP : The hands-free screen is displayed when a call is received, and you can operate the system from that screen.
  • Page 300 3-4. Using the hands-free system ■“Show Bluetooth connection status at startup” settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Show Bluetooth connection sta- STEP tus at startup”...
  • Page 301 3-4. Using the hands-free system Phone book settings Up to 1000 names, 2 items per name, can be registered. ■Transferring mobile phone data Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch STEP...
  • Page 302 3-4. Using the hands-free system overwrite data, touch STEP To add to existing data, touch ITY34P038 Transfer will begin. If you wish to STEP cancel the transfer before fin- ished, touch Transfer complete when “Transfer completed” dis- played. If “Transfer failed” is displayed, ITY34P039 restart the process from the beginning.
  • Page 303 3-4. Using the hands-free system Touch the in the “Phone STEP Book” section. ITY34P040 PRIUS_U_(L/O_0802)
  • Page 304 3-4. Using the hands-free system Choose the switch to register. STEP :Input the name on the “Name” screen. Input the number(s) on the “Telephone Number” screen. When you touch , the “Select Icon” screen will appear. ITY34P041 Choose the desired icon. •...
  • Page 305 3-4. Using the hands-free system ■Add history data to a registered entry Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose the desired number from the list. STEP To choose from the received call history, touch then select the desired number.
  • Page 306 3-4. Using the hands-free system ■Editing phone book data Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Phone Book” section of the “Phone Book STEP Management”...
  • Page 307 3-4. Using the hands-free system ■ To delete all data Follow the steps “Deleting phone book data” to “STEP 5”. In the “Phone Book” section of the “Phone Book Management” screen, touch . To delete all data within a group, touch , then select the group to delete.
  • Page 308 3-4. Using the hands-free system Changing the phone book group name settings ■Registering a group name Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch the switch in the “Group Name” section of the STEP “Phone Book Management”...
  • Page 309 3-4. Using the hands-free system ■Deleting a group name Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch the switch in the “Group Name” section of the STEP “Phone Book Management”...
  • Page 310 3-4. Using the hands-free system Deleting the history Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Select the data to delete from the list. STEP To delete data from the received calls history, touch , then select the data to delete.
  • Page 311 3-4. Using the hands-free system Changing the security settings You can disable certain hands-free system functions. Use the secu- rity settings when you do not wish other people to see the registered data, for example when having the vehicle valet parked at a hotel. To enable or disable security, the security code (4 digits) is required.
  • Page 312 3-4. Using the hands-free system Input the current security code, STEP and touch ITY34P048 Input the new security code, and touch STEP A confirmation message will appear. If everything is correct, STEP touch ■Enabling security Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone”...
  • Page 313 3-4. Using the hands-free system ■Setting the security code to default Press STEP Touch on the “Information” screen. STEP Touch ; on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch on the “Phone Book Lock” screen. STEP Input the security code on the “Security Code”...
  • Page 314 Be sure to choose a number difficult for strangers to guess. ● Do not forget the security code. Even your Toyota dealer will be unable to ● disable the security. If you do forget the code, initialize all personal data.
  • Page 315 3-4. Using the hands-free system Select the phone to be use, then STEP touch If no phones are registered, “Empty” will be displayed. If “Bluetooth connection suc- cessful” is displayed, registration was successful. ITY34P050 ® If another Bluetooth phone is already connected, a confirmation message is displayed.
  • Page 316 3-4. Using the hands-free system ® ■To change the Bluetooth settings You can change the device name and passkey. Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP To change the device name, STEP touch in the “Device...
  • Page 317 3-4. Using the hands-free system ® ■To delete the Bluetooth settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Bluetooth Telephone” section of the STEP “Bluetooth Settings”...

  • Page 318: Using The Interior Lights

    3-5. Using the interior lights Interior lights list Illuminated entry system: The various lights automatically turn on/ off according to the presence of the electronic key, whether the doors are locked/unlocked, whether the doors are open/closed, and the “POWER” switch mode. ITY35P001 Front personal lights (P.
  • Page 319 “DOOR” position, the lights will go off automati- cally after 20 minutes. ■ Customization that can be configured at Toyota dealer Setting (e.g. The time elapsed before lights turn off) can be changed. Customizable features  P. 488)
  • Page 320 3-5. Using the interior lights Interior lights Front “ON” “OFF” “DOOR” The interior lights are turned on/ off by the illuminated entry sys- tem. Rear “ON” “OFF” “DOOR” The interior lights are turned on/ off by the illuminated entry sys- tem.
  • Page 321 3-5. Using the interior lights ■ Customization that can be configured at Toyota dealer. Settings can be changed. (Customizable features P. 488) PRIUS_U_(L/O_0802)

  • Page 322: Using The Storage Features

    3-6. Using the storage features List of storage features Overhead console Auxiliary box Glove box Cup holders Console box Bottle holder PRIUS_U_(L/O_0802)
  • Page 323 3-6. Using the storage features Glove box Push the button. ■ Glove box light The glove box light turns on when the headlight switch is on. CAUTION ■ While driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Console box Lift the lid while pulling the lever.
  • Page 324 3-6. Using the storage features CAUTION ■ While driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items. Push the lid.
  • Page 325 3-6. Using the storage features Cup holders Front open, press down release the front cup holder lid. Rear To open, press in and release the rear cup holder on the arm- rest. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders.
  • Page 326 3-6. Using the storage features Bottle holders PRIUS_U_(L/O_0802)
  • Page 327 3-6. Using the storage features Auxiliary box Type A Push the button. Type B Push the lid. Type C Lift the tray and pull it forward. PRIUS_U_(L/O_0802)
  • Page 328 3-6. Using the storage features ■ Removing the separate tray (type A) Pull up. ITY36P011 CAUTION ■ While driving Keep the auxiliary boxes closed. Injuries may result in the event of an acci- dent or sudden braking. PRIUS_U_(L/O_0802)

  • Page 329: Other Interior Features

    3-7. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. ITY37P001 PRIUS_U_(L/O_0802)

  • Page 330: Vanity Mirror

    3-7. Other interior features Vanity mirror Slide the cover. ON: The light turns on when the cover is opened. OFF: Turns the light off. PRIUS_U_(L/O_0802)

  • Page 331: Clock

    3-7. Other interior features Clock Adjusts the hour Adjusts the minutes. ITY37P003 ■ The clock is displayed when The “POWER” switch is in ACCESSORY or ON mode. ■ When the 12 volt battery is disconnected The time display will automatically be set to 1:00. ■...

  • Page 332: Power Outlet

    3-7. Other interior features Power outlet The power outlet can be used for 12V accessories that run on less than 10A. Instrument panel Rear console box ■ The power outlet can be used when The “POWER” switch is in ACCESSORY or ON mode. PRIUS_U_(L/O_0802)
  • Page 333 3-7. Other interior features NOTICE ■ To avoid damaging the power outlet Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. ■ To prevent the fuse from being blown Do not use an accessory that uses more than 12V/10A.

  • Page 334: Armrest

    3-7. Other interior features Armrest Pull the armrest down for use. ITY37P006 NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. PRIUS_U_(L/O_0802)

  • Page 335: Floor Mats

    3-7. Other interior features Floor mats Securely place a mat that matches the size of the space on the car- pet. Secure the floor mat using the hooks provided. CAUTION ■ When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.

  • Page 336: Luggage Compartment Features

    3-7. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ITY37P008 ■ Auxiliary box Turn knob STEP “UNLOCK” position and open the lid. LOCK UNLOCK LOCK UNLOCK ITY37P009 Hold the lid open by inserting STEP the support rod into the slot.
  • Page 337 3-7. Other interior features ■ Luggage cover (If equipped) Adjust the cover so that “TOP” STEP is facing upwards. ITY37P011 Pull out the luggage cover and STEP secure it to the hook brackets. ITY37P012 ■ Removing the luggage cover The luggage cover can be removed by following the procedure below. Lift it up.
  • Page 338 3-7. Other interior features ■ Stowing the luggage cover Remove the side deck boards and STEP open the auxiliary box. Adjust the cover so that “TOP” is facing STEP ITY37P015 CAUTION ■ While driving To avoid injury, always return the cargo hooks to their positions when they are not in use.

  • Page 339: Garage Door Opener

    3-7. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manufac- ...
  • Page 340 3-7. Other interior features Press and hold down one of the STEP  buttons on the HomeLink the button on the transmitter. When the indicator light on the  HomeLink changes from a slow to a rapid flash after 20 seconds, you can release both buttons.
  • Page 341 3-7. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the  heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door STEP opener motor.
  • Page 342  the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 343 3-7. Other interior features ■ Before programming Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the ●  HomeLink ■ Certification for the garage door opener This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.
  • Page 344 3-7. Other interior features PRIUS_U_(L/O_0802)
  • Page 345 Maintenance and care 4-1. Maintenance and care ....... 346 Cleaning and protecting the vehicle’s exterior .... 346 Cleaning and protecting the vehicle’s interior ..... 348 4-2. Maintenance ....351 Maintenance requirements ....351 General maintenance..353 Emission inspection and maintenance (I/M) programs......

  • Page 346: Maintenance And Care

    4-1. Maintenance and care Cleaning and protecting the vehicle’s exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 347 4-1. Maintenance and care ■ To prevent paint deterioration and corrosion on the body Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads • If you see coal tar or tree sap on the paint surface •...

  • Page 348: Cleaning And Protecting The Vehicle's Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle’s interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 349 Wipe the window in strokes running parallel to the heater wires. ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available.
  • Page 350 4-1. Maintenance and care NOTICE ■ Cleaning detergents Do not use the following types of detergent, as they may discolor the vehicle interior or cause streaks or damage to painted surfaces. Non-seat portions: Organic substances such as benzine or gasoline, alka- ●...

  • Page 351: Maintenance

    It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 352 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date ● with the latest service information. They are well informed about the operations of all systems on your vehicle.

  • Page 353: General Maintenance

    “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
  • Page 354 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven pedal Accelerator pedal effort or catching)? Automatic transmission • Can the vehicle be hold securely on an “Park” mechanism incline with the shift lever in “P”? • Moves smoothly? Brake pedal •...
  • Page 355 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? Fluid leaks • Is there any leakage after parking? • Inflation pressure is correct? • Tire surfaces not worn or damaged? Tire •...

  • Page 356: Emission Inspection And Maintenance (I/M) Programs

    If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...

  • Page 357: Do-It-Yourself Maintenance

    Brake fluid level (P. 373) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
  • Page 358 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (P. 365) • Rag or paper towel, funnel (used only for adding engine oil) • Fuse with same amperage rating Fuses (P. 398) as original ...
  • Page 359 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury. ■ When working on the engine compartment: Keep hands, clothing, and tools away from the moving fan and engine ●...
  • Page 360 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment.

  • Page 361: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. ITY43P001 Lift the hood catch and lift the STEP hood. ITY43P002 Hold the hood open by insert- STEP...

  • Page 362: Positioning A Floor Jack

    4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear ITY43P005 PRIUS_U_(L/O_0802)
  • Page 363 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack ● such as the one shown in the illustra- tion.

  • Page 364: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank Inverter coolant reservoir (P. 378) (P. 371) Brake fluid reservoir Fuse box (P. 398) (P. 373) Radiator (P. 373) Engine oil filler cap Condenser (P. 373) (P. 367) Electric cooling fans Engine coolant reservoir Engine oil level dipstick (P.
  • Page 365 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the cover Front ■ Installing the clips Push up center portion Insert Press Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground.
  • Page 366 4-3. Do-it-yourself maintenance Hold a rag under the end and STEP pull the dipstick out. Wipe the dipstick clean. STEP Reinsert the dipstick fully. STEP Holding a rag under the end, pull the dipstick out and check STEP the oil level. Wipe the dipstick and reinsert it fully.
  • Page 367 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 368 4-3. Do-it-yourself maintenance ■ Recommended viscosity SAE 5W-30 is the best choice for good fuel economy, and good starting in cold weather. : If SAE 5W-30 oil is not avail- able, SAE 10W-30 oil may be used. However, it should be replaced with SAE 5W-30 at the Outside temperature next oil change.
  • Page 369 Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp. qt./600 miles (1.0 L per ● 1000 km). If the vehicle consumes more than this amount, contact your Toyota dealer. ■ Resetting the engine oil maintenance data (U.S.A. only) Perform the following steps: Turn the “POWER”...
  • Page 370 Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
  • Page 371 4-3. Do-it-yourself maintenance Engine/power control unit coolant The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the engine is cold. Engine coolant reservoir Reservoir cap FULL If the level is on or below the “LOW”...
  • Page 372 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, engine coolant filler cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
  • Page 373 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
  • Page 374 4-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
  • Page 375 4-3. Do-it-yourself maintenance 12 volt battery ■ Location The 12 volt battery is located in the right-hand side of luggage compartment. ■ 12 volt battery exterior Make sure that the 12 volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp PRIUS_U_(L/O_0802)
  • Page 376 With the shift lever in “P” and the “POWER” switch in the OFF mode, ● open and close any door, then attempt to start the hybrid system. If the system will not start even after multiple attempts at both methods, con- tact your Toyota dealer. PRIUS_U_(L/O_0802)
  • Page 377 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the 12 volt battery A 12 volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near 12 volt battery: Do not cause sparks by touching the 12 volt battery terminals with tools.
  • Page 378 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the 12 volt battery Never recharge the 12 volt battery while the hybrid system is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work, the washer tank may be empty.

  • Page 379: Tires

    ■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (P. 429) The compact spare tire is not equipped with a tire pressure warning valve and transmitter.
  • Page 380 4-3. Do-it-yourself maintenance Installing tire pressure warning valves and transmitters When replacing tires or wheels, tire pressure warning valves and transmitters must also be installed. When new tire pressure warning valves and transmitters are installed, new sensor ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initial- ized.
  • Page 381 4-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system Park the vehicle in safe place and turn the “POWER” switch to STEP OFF mode. While the vehicle is moving, initialization is not performed. Adjust the tire inflation pressure to the specified cold tire infla- STEP tion pressure level.
  • Page 382 A tire goes flat repeatedly or cannot be properly repaired due to the ● size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 383 4-3. Do-it-yourself maintenance ■ Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
  • Page 384 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the warning ●...
  • Page 385 4-3. Do-it-yourself maintenance ■ Tire pressure warning system certification For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 386 Do not mix tires of different makes, models, tread patterns or tread- ● wear. Do not use tire sizes other than those recommended by Toyota. ● Do not mix radial, bias-belted, or bias-ply tires. ●...
  • Page 387 4-3. Do-it-yourself maintenance NOTICE ■ Driving on rough roads Take particular care when driving on roads with loose surfaces or pot- holes. These conditions may cause losses in tire inflation pressure, reducing the cushioning ability of the tires. In addition driving on rough roads may cause damage to the tires themselves, as well as the vehicle’s wheels and body.

  • Page 388: Tire Inflation Pressure

    4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 470) ITY43P019 PRIUS_U_(L/O_0802)
  • Page 389 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended STEP...
  • Page 390 Reduced safety ● Damage to the drive train ● If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
  • Page 391 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear ● Uneven wear ● Poor handling ●...

  • Page 392: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 393 4-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.

  • Page 394: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the “POWER” switch to OFF mode. STEP Open the glove box slide off STEP the damper. Lift the glove box to discon- STEP nect the claws at the bottom...
  • Page 395 4-3. Do-it-yourself maintenance Remove the air conditioning filter from the filter case and replace it with a new one. “ UP” marks shown on the filter and the filter case should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.

  • Page 396: Key Battery

    4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Small Phillips-head screwdriver ● Lithium battery (CR2032) ■ Replacing the battery Take out the mechanical key. STEP Remove the cover.
  • Page 397 The operational range is reduced. ● ■ Use a CR2032 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera ● stores. Replace only with the same or equivalent type recommended by a Toy- ● ota dealer.

  • Page 398: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “POWER” switch to OFF mode. STEP Remove the engine compartment cover if necessary. STEP P.
  • Page 399 4-3. Do-it-yourself maintenance Luggage compartment Remove the cover. After a system failure, see “Fuse layout and amperage rat- STEP ings” (P. 401) for details about which fuse to check. Remove the fuse with the pull- STEP out tool. PRIUS_U_(L/O_0802)
  • Page 400 Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer. PRIUS_U_(L/O_0802)
  • Page 401 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Driver’s side instrument panel Fuse Ampere Circuit Power windows 30 A 40 A Rear window defogger M/HTR Outside rear view mirror heater 15 A Windshield wiper 30 A RR WIP Rear wiper 15 A Washer 20 A...
  • Page 402 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Touch screen, power windows, air ECU-B 15 A conditioning system Hybrid system 7.5 A Tail lights, license plates light, TAIL 10 A parking lights Touch screen, clock, audio sys- PANEL 7.5 A tem, instrument panel lights A/C (HTR) Air conditioning system 10 A...
  • Page 403 4-3. Do-it-yourself maintenance ■ Engine compartment Fuse Ampere Circuit SPARE 30 A Spare SPARE 15 A Spare 7.5 A Daytime running light system 10 A H-LP RH LO Right-hand headlight (low beam) 15 A 10 A H-LP LH LO Left.hand headlight (low beam) 15 A H-LP HI RH 10 A...
  • Page 404 4-3. Do-it-yourself maintenance Fuse Ampere Circuit ABS-1 25 A Anti-lock brake system ETCS 10 A Electronic throttle control system BATT FAN 10 A Battery cooling fan Turn signal lights, emergency 10 A flasher Audio system, interior lights, Smart key system, gauge and DOME 15 A meter, turn signal lights, luggage...
  • Page 405 4-3. Do-it-yourself maintenance ■ Luggage compartment Fuse Ampere Circuit DC/DS-S Inverter and converter MAIN 120 A Hybrid system PRIUS_U_(L/O_0802)
  • Page 406 Never use a fuse of a higher amperage rating than indicated, or use any ● other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. ● Never replace a fuse with a wire, even as a temporary fix.

  • Page 407: Light Bulbs

    4-3. Do-it-yourself maintenance Light bulbs You may replace the following bulbs yourself. For more information about replacing other light bulbs, contact your Toyota dealer. ■ Prepare a replacement light bulb. Check the wattage of the light bulb being replaced. (P. 471) ■...
  • Page 408 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlights (vehicles with halogen bulbs) Unplug the connector. STEP ITY43P040 Remove the rubber cover. STEP ITY43P041 Release bulb retaining STEP spring. ITY43P042 PRIUS_U_(L/O_0802)
  • Page 409 4-3. Do-it-yourself maintenance Remove the bulb. STEP ITY43P043 ■ Parking and front side marker lights Turn the bulb base counterclock- STEP wise. ITY43P044 Remove the light bulb. STEP ITY43P045 PRIUS_U_(L/O_0802)
  • Page 410 4-3. Do-it-yourself maintenance ■ Front turn signal lights Turn the bulb base counterclock- STEP wise. ITY43P046 Remove the light bulb. STEP ITY43P047 PRIUS_U_(L/O_0802)
  • Page 411 4-3. Do-it-yourself maintenance ■ Back-up lights, tail and rear side maker lights Open the back door and remove STEP the cover. ITY43P048 Turn the bulb base counterclock- STEP wise. Rear turn signal light Back-up light Tail and rear side marker light Remove the light bulb.
  • Page 412 Remove the upper trim board. STEP ITY43P051 Turn the bulb base counterclock- STEP wise. ITY43P052 Remove the light bulb. STEP ITY43P053 ■ Front fog lights If the high mounted stoplight has burnt out, have it replaced by your Toyota dealer. PRIUS_U_(L/O_0802)
  • Page 413 LED light bulbs The tail, tail/stop and high mounted stoplights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. If two or more LEDs in a stoplight burn out, your vehicle may not conform to local laws (SAE).
  • Page 414 Doing so could result in electric shock and death or serious injury. ■ High-intensity discharge (HID) headlights Contact your Toyota dealer before replacing high-intensity discharge ● headlights (including light bulbs). Do not touch the high-intensity discharge headlight’s high voltage socket ●...

  • Page 415: When Trouble Arises

    When trouble arises 5-1. Essential information ..416 If your vehicle needs to be towed ......416 If you think something is wrong ......423 Event data recorder ..424 5-2. Steps to take in an emergency ....426 If a warning light turns on or a warning buzzer sounds...

  • Page 416: Essential Information

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 417 5-1. Essential information Towing eyelet ITY51P001 ■ Emergency towing procedure Release the parking brake. STEP Put the shift lever in “N”. STEP Turn the “POWER” switch to ACCESSORY (hybrid system off) or STEP ON mode hybrid system operating). CAUTION ■ While towing Use extreme caution when towing the vehicle.
  • Page 418 5-1. Essential information Installing towing eyelet Remove the eyelet cover using a STEP flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration. ITY51P002 Insert the towing eyelet into the STEP hole and tighten partially by hand.
  • Page 419 5-1. Essential information CAUTION ■ Installing towing eyelet to the vehicle Make sure that towing eyelet is installed securely. If not securely installed, towing eyelet may come loose during towing. This may lead to accidents that cause serious injury or even death. Towing with a sling-type truck ITY51P005 NOTICE...
  • Page 420 5-1. Essential information Towing with a wheel lift-type truck From front Release the parking brake. ITY51P006 From rear Use a towing dolly under the front wheel. ITY51P007 PRIUS_U_(L/O_0802)
  • Page 421 5-1. Essential information NOTICE ■ To prevent causing serious damage to the transmission Never tow this vehicle with any of the wheels in contact with the ground. ■ To prevent damaging the vehicle Do not tow the vehicle with the “POWER” switch OFF. ●...
  • Page 422 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. ITY51P008 PRIUS_U_(L/O_0802)

  • Page 423: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)

  • Page 424: Event Data Recorder

    5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is a system to record data in a crash or a near car crash event.
  • Page 425 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained ●...

  • Page 426: Steps To Take In An Emergency

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light and warning buzzer...
  • Page 427 Hybrid system warning light Indicates a malfunction in the hybrid system. Have the vehicle inspected by your Toyota dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
  • Page 428 5-2. Steps to take in an emergency Warning light Warning light/Details Vehicle stability control system warning light (if equipped) Indicates a malfunction in the Enhanced VSC system. Automatic headlight leveling system warning light (if equipped) Indicates a malfunction in the automatic headlight level- ing system.
  • Page 429 When the light comes on: Adjust the tire inflation Low tire inflation pressure. pressure. When the light stays on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. PRIUS_U_(L/O_0802)
  • Page 430 “N” position. If this light comes on with the “READY” light on in this The hybrid battery is dis- case, have the system charged. checked by your Toyota dealer. High coolant temperature warning light P. 456 Indicates high engine cool-...
  • Page 431 5-2. Steps to take in an emergency :Driver’s and front passenger’s seat belt reminder buzzer: The driver’s and front passenger’s seat belts reminder sounds to alert the driver and front passenger that his or her seat belt is not fastened. The buzzer sounds intermittently for 10 seconds after the vehicle has reached a speed of at lest 12 mph (20 km/h).
  • Page 432 5-2. Steps to take in an emergency Warning Alarm Details Correction procedure light The lock button has Exterior alarm: been pressed while One beep Turn the hybrid sys- the hybrid system is (sounds for 2 tem OFF. not OFF and the shift seconds) position is in “P”.
  • Page 433 ● If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■ Power steering warning light When the voltage is low or drops, the power steering warning light may come on.
  • Page 434 If a window tint that affects the radio wave signals is installed. ● If there is a lot of snow or ice on the vehicle, in particular around the ● wheels or wheel housings. If non-genuine Toyota wheels are used. ● If tire chains are used. ● PRIUS_U_(L/O_0802)
  • Page 435 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. • Avoid abrupt maneuvering and braking. If the vehicle tires deterio- rate, you could lose control of the steering wheel or the brakes.
  • Page 436 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 437 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).

  • Page 438: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
  • Page 439 5-2. Steps to take in an emergency ■ Compact spare tire The compact tire saves space in your luggage compartment, and its lighter weight helps to enhance fuel economy and per- mits easier installation in case of a flat tire. The compact spare tire is designed for temporary emer- gency use only.
  • Page 440 5-2. Steps to take in an emergency Taking out the jack. Open the auxiliary box. STEP (P. 336) ITY52P002 Unlock the tightening strap. STEP After storing the jack, make sure it is securely held by the tightening strap. ITY52P003 PRIUS_U_(L/O_0802)
  • Page 441 5-2. Steps to take in an emergency Taking out the spare tire Loosen the center fastener that STEP secures the spare tire. ITY52P004 Replacing a flat tire Chock the tires. STEP ITY52P005 Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire...
  • Page 442 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). ITY52P006 Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground.
  • Page 443 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 444 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) ITY52P013 Stow the flat tire, tire jack and all tools. STEP ■...
  • Page 445 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or ●...
  • Page 446 5-2. Steps to take in an emergency CAUTION ■ When using the spare tire Remember that your spare tire is specifically designed for use with ● your vehicle. Do not use your spare tire on another vehicle. Do not use two spare tires simultaneously. ●...
  • Page 447 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning ● valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.

  • Page 448: If The Hybrid System Will Not Start

    ● One or both of the 12 volt battery terminals may be discon- nected. ● The 12 volt battery may be discharged. (P. 451) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. PRIUS_U_(L/O_0802)

  • Page 449: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using master key and the key number stamped on your key number plate. PRIUS_U_(L/O_0802)

  • Page 450: If The Electronic Key Does Not Operate Properly

    5-2. Steps to take in an emergency If the electronic key does not operate properly If the electronic key 12 volt battery is discharged, the doors can be opened by the mechanical key. The engine system can be still started by following the procedure. Locking and unlocking the doors Using the mechanical key in order to perform the following...

  • Page 451: If The Vehicle 12 Volt Battery Is Discharged

    You can call your Toyota dealer, or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
  • Page 452 5-2. Steps to take in an emergency Connecting the jumper cables. STEP ITY52P017 Exclusive jump starting terminal on your vehicle. Positive (+) battery terminal on the second vehicle. Negative (-) battery terminal on the second vehicle. Connect the jumper cable to ground on your vehicle as shown in the illustration.
  • Page 453 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the hybrid system when the battery is discharged The hybrid system cannot be started by push-starting.
  • Page 454 5-2. Steps to take in an emergency ■ When the 12 volt battery is removed or discharged The following systems must be initialized.  Power windows ( P. 75) ●  Tire pressure warning system ( P. 380) ● The hybrid system may not start. (P. 448) ●...
  • Page 455 5-2. Steps to take in an emergency NOTICE ■ To prevent damaging the vehicle Do not pull- or push-start the vehicle, because the three-way catalytic con- ● verter may overheat and become a fire hazard. The exclusive jump starting terminal is to be used when charging the 12 ●...

  • Page 456: If Your Vehicle Overheats

    5-2. Steps to take in an emergency If your vehicle overheats The following may indicate that your vehicle is overheating: The high engine coolant temperature warning light comes on: The engine may be overheating. Follow the correction procedure as described blow. Correction procedures Stop the vehicle in a safe place and turn off the automatic air STEP...
  • Page 457 Water can be used in an emer- gency measure if coolant is unavailable. (P. 467) ITY52P019 Have the vehicle checked at your nearest Toyota dealer as soon as possible. ■ Overheating In the following situations, your vehicle may be overheating.
  • Page 458 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the hybrid system has cooled down before adding engine/power control unit coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the hybrid system.

  • Page 459: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the hybrid system. Set the parking brake and push the STEP “P”...
  • Page 460 5-2. Steps to take in an emergency PRIUS_U_(L/O_0802)

  • Page 461: Vehicle Specifications

    Vehicle specifications 6-1. Specifications....462 Maintenance data (fuel, oil level, etc.) ...... 462 Fuel information ....472 Tire information ....475 6-2. Customization ....488 Customizable features ..488 6-3. Initialization ....491 Items to initialize ....491 PRIUS_U_(L/O_0802)

  • Page 462: Specifications

    6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 175.0 in. (4445 mm) Overall width 67.9 in. (1725 mm) Overall height 58.7 in. (1490 mm) Wheelbase 106.3 in. (2700 mm) Front 59.3 in. (1505 mm) Tread Rear 58.3 in.
  • Page 463 6-1. Specifications Vehicle identification The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 464 6-1. Specifications Engine Model 1NZ-FXE Type 4-cylinder in line, 4-cycle, gasoline   Bore and stroke 2.95 3.33 in. (75.0 84.7 mm) Displacement 91.4 cu. in. (1497 cm 44 - 88 lbf(196 - 392 N, 20 - 40 kgf)* Idler assembly Drive belt tension Water pump Crankshaft...
  • Page 465 6-1. Specifications Electric motor (Traction motor) Type Permanent magnet synchronous motor Maximum output 50 kW Maximum torque 400 N•m (40.8 kgf•m, 295 ft•lbf) Hybrid battery (Traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 28 modules Overall voltage 201.6 V PRIUS_U_(L/O_0802)
  • Page 466 3.9 qt. (3.7 L, 3.3 lmp.qt.) without filter 3.6 qt. (3.4 L, 3.0 lmp.qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and viscosity shown below. Recommended oil viscosity Outside temperature :5W-30 is an oil that provides optimal levels of fuel efficiency.
  • Page 467 9.0 qt. (8.6 L, 7.5 lmp.qt.) Power control unit 2.9 qt. (2.7 L, 2.4 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life organic acid technology Do not use plain water alone.
  • Page 468 Toyota Genuine ATF WS NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. PRIUS_U_(L/O_0802)
  • Page 469 6-1. Specifications Brakes Pedal clearance 3.98 in. (101.0 mm) Min. Pedal free play Less than 0.04 - 0.24 in. (1.0 - 6.0 mm) Brake pad wear limit 0.04 in. (1.0 mm) Parking brake pedal 6  9 clicks travel Parking brake lining wear 0.04 in.
  • Page 470 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels P195/55R16 86V, P185/65R15 86S, Tire size T125/70D16 96M (spare) Front and rear tire inflation Front tire: pressure 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold tire Rear tire: inflation pressure) 33 psi (230 kPa, 2.3 kgf/cm...
  • Page 471 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Discharge bulbs  Halogen bulbs  60/55 Front fog lights 9006 Parking/front side marker  lights Exterior Front turn signal lights  Rear turn signal lights  Back-up lights 7440 Tail lights/rear side marker ...

  • Page 472: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
  • Page 473 Toyota allows the use of oxygenate blended gasoline where the oxygen- ● ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no ● lower than 87.
  • Page 474 6-1. Specifications NOTICE ■ Notice on gasoline quality Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction. Do not use gasohol other than that stated here. ●...

  • Page 475: Tire Information

    6-1. Specifications Tire information Typical tire symbols Tire size (P. 478) DOT and Tire Identification Number (TIN) (P. 477) Location of tread wear indicators (P. 379) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
  • Page 476 6-1. Specifications Summer tire or all season tire (P. 383) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire.
  • Page 477 6-1. Specifications Typical DOT and tire identification number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year :The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
  • Page 478 6-1. Specifications Tire size ■ Typical tire size information Standard tire The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Spare tire Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits)
  • Page 479 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 480 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 481 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 482 6-1. Specifications Tire related term Meaning Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb...
  • Page 483 6-1. Specifications Tire related term Meaning The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation in the bead A pneumatic tire in which the ply cords that extend to the beads are laid at alternate angles...
  • Page 484 6-1. Specifications Tire related term Meaning The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or Intended outboard...
  • Page 485 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
  • Page 486 6-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Snow tire Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and which...
  • Page 487 6-1. Specifications Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...

  • Page 488: Customization

    Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
  • Page 489 6-2. Customization Customized Item Function Default setting setting Operation indicator (Emergency flashers) Operation indicator Wireless (Buzzer) remote control Panic function  P. 49) Buzzer sounds when pushing with any door not closed Driver’s door unlocked in 1- All doors Door lock Unlocking using a key step, all doors unlocked...
  • Page 490 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation when the doors are unlocked Illumination Operation after the  P. 318) “POWER” switch turned OFF Front/rear personal All lights Corresponding lights turned on when a light only...

  • Page 491: Initialization

    6-3. Initialization Items to initialize After reconnecting or performing maintenance on the 12 volt battery, the following items must be initialized for normal system operation. Item When to initialize Reference • After reconnecting or changing the Power window 12 volt battery P.
  • Page 492 6-3. Initialization PRIUS_U_(L/O_0802)

  • Page 493: For Owners

    For owners Reporting safety defects for U.S. owners ....494 Seat belt instructions for Canadian owners (in French) ..... 495 PRIUS_U_(L/O_0802)

  • Page 494: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 495: Seat Belt Instructions For Canadian Owners (In French)

    Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. PRIUS_U_(L/O_0802)
  • Page 496 PRIUS_U_(L/O_0802)

  • Page 497: Index

    Index Abbreviation list ..... 498 Alphabetical index....500 What to do if......506 For details of equipment related to the navigation sys- tem and touch screen, such as the air conditioning and audio systems, refer to the “Navigation System Owner’s Manual”. PRIUS_U_(L/O_0802)

  • Page 498: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electronic Power Steering GAWR Gross Axle Weight Ratings Emission inspection and maintenance Light Emitting Diode Methylcy clopentadienyl Manganese Tricarbonyl M + S Mud and Snow...
  • Page 499 PRIUS_U_(L/O_0802)

  • Page 500: Alphabetical Index

    Alphabetical index Alphabetical index A/C..........201 Back-up lights Wattage......... 471 ABS ...........170 Air conditioning system Back door ........54 Air conditioning filter....394 Back door........ 54 Automatic air conditioning Wireless remote control ..49 system ........201 Smart key system ....36 Steering wheel climate Battery remote control switches ..215 Checking .......
  • Page 501 Alphabetical index Child safety Doors Airbag precautions ....96 Door lock .....36, 49, 51 Child restraint system... 107 Rear door child protector..52 Child-protectors ...... 52 Driver’s seat belt reminder How your child should wear light .........429 the seatbelt ......67 Driving Installing child restraints ..
  • Page 502 Alphabetical index Engine compartment cover..365 Garage door opener ....339 Engine/power control unit Gas station information ..512 coolant Gauges........143 Capacity ........467 Glove box ......... 323 Checking .......371 Preparing and checking Hands-free system before winter .......177 (for cellular phone)....272 Engine oil Head restraints......
  • Page 503 Alphabetical index Interior lights Meter Interior lights......320 Instrument panel light Switch........320 control .........144 Wattage ........ 471 Meters ........143 Mirrors Inside rear view mirror.....71 Jack Side mirror heater ....217 Positioning the jack ....362 Side mirrors......73 Replacing the wheel ..... 438 Vanity mirrors ......330 Jack handle......
  • Page 504 Alphabetical index Rear view monitor system ..167 Side mirror Adjusting and folding....73 Rear window defogger ....217 Replacing Smart key system Electronic key battery....396 Antenna location .....39 Fuses ........398 Entry function ......36 Light bulbs......407 Starting the hybrid system ..130 Reporting safety defects for Spare tire Inflation pressure ....
  • Page 505 Alphabetical index Tires Warning buzzers Chains ........179 Brake system ......426 Checking ......379 Open door ......429 Compact spare tire ....439 Seat belt reminder....429 If you have a flat tire ..... 438 Warning lights Inflation pressure....470 Anti-lock brake Information ......

  • Page 506: What To Do If

    What to do if... What to do if... A tire punctures If you have a flat tire P. 438 Hybrid system immobilizer system P. 81 The engine does not start If the engine will not start P. 448 P. 451 If the 12 volt battery is discharged The high coolant temperature warning light comes on.
  • Page 507 What to do if... Instrument cluster ITYPP011 Touch screen ITYPP013 PRIUS_U_(L/O_0802)
  • Page 508 What to do if... ■ Warning lights Brake system warning Charging system warn- light (red indicator) ing light P. 427 Malfunction indicator lamp P. 426 P. 427 ABS warning light Driver’s seat belt reminder light /VSC warning light P. 429 Front passenger’s seat belt reminder light P.
  • Page 509 What to do if... PRIUS_U_(L/O_0802)
  • Page 510 PRIUS_U_(L/O_0802)
  • Page 511 PRIUS_U_(L/O_0802)
  • Page 512 (L, Imp.qt.) Engine oil capacity With filter 3.9 (3.7, 3.3) (Drain and refill) Without filter 3.6 (3.4, 3.0) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil P. 466 Recommended oil viscosity: SAE 5W-30 PRIUS_U_(L/O_0802)

Table of Contents

Save PDF
