Summary of Contents for thomann Limit 2/2
- Page 1 Limit 2/2 limiter user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 07.12.2015, ID: 288549...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 6 Features............................... 10 Installation..............................11 Starting up..............................14 Connections and operating elements................... 15 Technical specifications........................20 Cleaning............................... 22 Protecting the environment......................23 Limit 2/2... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device, include the manual for the next owner. - Page 5 General notes Warning signs Type of danger Warning – high-voltage. Warning – danger zone. Limit 2/2...
-
Page 6: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used to limit the dynamics of signals from audio devices and musical instruments. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 7 They could swallow the pieces and choke! Never let children unattended use electrical devices. DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Limit 2/2...
- Page 8 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
- Page 9 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. Limit 2/2...
-
Page 10: Features
Features Features The limiter is ideal to protect sensitive amplifier inputs against overloading. The digital signal processors reduce the dynamics of the input signal by an adjustable value. Both stereo chan‐ nels are processed interdependently and compressed by the same ratio. The channel with the higher dynamic controls both channels. -
Page 11: Installation
Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. Limit 2/2... - Page 12 Installation XLR connections for signal in Balanced XLR chassis sockets serve as signal inputs. XLR chassis plugs serve as signal outputs. and outputs Drawing and table indicate the XLR pin assignment. Ground, shielding Signal (+) Signal (–) Phone plugs for signal in and Drawings and tables indicate the pin assignment for 1/4"...
- Page 13 Installation Signal (+) Signal (–) Ground, shielding Rack mounting The unit has been designed for rack mounting in a standard 19-inch rack; it occupies one rack unit. Limit 2/2...
-
Page 14: Starting Up
Starting up Starting up Connect the line outputs (left and right) of the audio device whose level is to be limited (for example, your mixer) to the inputs of the limiter. Connect the outputs of the limiter to the line inputs of your amplifier. -
Page 15: Connections And Operating Elements
Connections and operating elements Connections and operating elements Front panel Limit 2/2... - Page 16 Connections and operating elements 1 OUTPUT LEVEL The LED chains indicate the output level of the left and right channel. 2 INPUT CLIP This LED indicates an excessive input level overloading the input. If this happens, reduce the output level of the con‐ nected device.
- Page 17 9 dBu (bypass, no limiting) and –22 dBu. To protect the switch against unintended adjusting, refit the plastic cover. 6 POWER This LED indicates that the unit is turned on. Limit 2/2...
- Page 18 Connections and operating elements Rear panel limiter...
- Page 19 10 IEC chassis connector with fuse holder. Always make sure that the slide switch (9) is et to the correct position before you connect the mains voltage here. 11 Main switch to turn the device on or off. Limit 2/2...
-
Page 20: Technical Specifications
Technical specifications Technical specifications Inputs XLR chassis sockets, 1/4" phone sockets Maximum input level +9 dBu Outputs XLR chassis plugs, 1/4" phone sockets Maximum output level +9 dBu THD in ‘Bypass’ mode (–6dbFS) < 0.01 % Frequency response, ±0,5 dB 20 Hz…20 kHz Signal-to-noise ratio >... - Page 21 Technical specifications Power consumption 10.5 W Fuse T500mAL250V (bei 115 V) | T 250mAL250V (bei 230 V) Dimensions (W × D × H) 482 mm × 175 mm × 44 mm Weight 2.5 kg Limit 2/2...
-
Page 22: Cleaning
Cleaning Cleaning Fan grids The fan grids of the device must be cleaned on a regular basis to remove dust and dirt. Before cleaning, switch off the device and disconnect AC-powered devices from the mains. Use a lint- free damp cloth for cleaning. Never use solvents or alcohol for cleaning. limiter... -
Page 23: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Limit 2/2... - Page 24 Notes limiter...
- Page 25 Notes Limit 2/2...
- Page 26 Notes limiter...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
