Sharp CD-BA200 Service Manual page 4

CD-BA200
Front speaker
CP-BA200
1. Super Tweeter
2. Tweeter
3. Bass Reflex Duct
4. Woofer
5. Subwoofer
6. Main Speaker (Woofer, Tweeter and Super Tweeter)
Wire
7. Subwoofer Wire
Remote Control
1. Remote Control Transmitter LED
CD Control section
2. Disc Number Select Buttons
3. Memory Button
4. Pause Button
5. Clear Button
6. Track Down/Review Button
7. Track Up/Cue Button
8. Disc Skip Button
9. Play/Repeat Button
10. Stop Button
11. Random Button
Tuner control section
12. Preset Up/Down Buttons
Tape control section
13. (TAPE 1) Play Button
14. (TAPE 2) Record Pause Button
15. (TAPE 1/2) Stop Button
16. (TAPE 2) Play Button
17. (TAPE 2) Rewind Button
18. (TAPE 2) Fast Forward Button
Common section
19. Equalizer Mode Selector Button
20. Function Selector Buttons
21. On/Stand-by Button
22. Extra Bass Button
23. Volume Up/Down Buttons
1
2
3
2
3
4
5
6
7
13 14
19
20
21
22
– 4 –
4
5
1
8
9
10
11
12
15 17
16 18
23
6
7
