GSS25IFR
GE 25.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser
®
Dimensions and Installation Information (in inches)
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
Width (in.) G
Width with door open 90° inc. door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
† Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
For answers to your Monogram, ® GE Profile
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center ®
800.626.2000.
69-3/4
68-3/4
28
†
31-1/4
†
33-9/16
†
49-3/8
†
35-3/4
38-3/16
1/8
1
1
™ or
service,
A B
Front View
"94 SxS Refer
H
G
C
D
Top View
Listed by
Underwriters
Laboratories
R
Specification Created 1/05
E
F
R
310150
