24VDC/250mA POWER SUPPLY
FEATURES:
24 VOLT DC "B" BATTERY POWER SUPPLY
INPUT THERMAL FUSE PROTECTED
FLOATING OUTPUT
THROUGH GROUND CONNECTION
RECEPTACLE MOUNT
PROVIDES 6 VALCOM POWER UNITS
DESCRIPTION:
Receptacle mount, 24 Vdc 250 mA, class 2, unfiltered "B" Battery power supply.
INPUT
Voltage/Frequency
Power
BTU/Hr
Connection
OUTPUT
Voltage
Current
Protection
Connections
5614 Hollins Road
Roanoke, Virginia 24019
E-Mail: support@valcom.com
VP-324
SPECIFICATIONS:
105-120 Vac, 60 Hz
18 Watts
61 BTU/Hr
2 Prong AC Plug
24 Vdc Unregulated,
Unfiltered, Floating
250 mA
Short Circuit Protection
Over-Voltage Protection
Screw Terminals
SPECIFICATIONS
REGULATORY
UL, cUL Listed
ENVIRONMENT
Temperature
Humidity
MOUNTING
Receptacle
DIMENSIONS AND WEIGHT
3.0" (7.62 cm) H x 2.5" ( 6.35 cm) W
x 2.0" (5.08 cm) D
Weight: .93 lbs (.42 kg)
Phone: 540-563-2000
www.valcom.com
TECHNICAL
°
°
32 - 122
F (0 - 50
C)
0-85% Non-condensing
Fax: 540-362-9800
