Pfaff ambition 1.0 Owner's Manual page 7

Top parts
20. Presser foot pressure dial
21. Thread guides
23. Hole for auxiliary spool pin
24. Bobbin winder lever and bobbin
spindle
25. Take-up lever
26. Thread tension discs
27. Thread tension dial
28. Bobbin winder tension disc
29. Bobbin thread cutter
Rear side
30. Main switch, connectors for power cord and
foot control
31. Handle
32. Presser foot lift
33. IDT
™ system
The accessory tray features special compartments
for presser feet and bobbins, plus space for needles
tray so they are easily accessible.
36. Removable tray for presser feet
37. Removable bobbin holder
20 21
25 26 27
30
36
37
22 23 24
28
31
32
35
29
33
34
7
