Summary of Contents for Pfaff 1025
- Page 4 Parts of your sewing machine Some safety rules a) Be careful to avoid finger injuries 30 Carrying handle 31 Hinged top cover by the needle when sewing. 32 Hand wheel b) Make sure you unplug the power 33 Stop motion knob cord whenever you want to change the 34 Master switch needle, sewing foot, bobbin or needle...
- Page 5 Opening the hinged top cover Removing the carrying case cover Also fold the handle toward the rear. Swing To lift off the carrying case cover, fold the cover 31 backwards. On Model 1027 a handle to the rear, as indicated byan arrow. stitch chart is found on the inside of this Then lift the cover off.
- Page 7 Electrical connection Foot control Take the foot control out of the machine. Place the foot control under the table. Press Push plug B into the machine socket and down the pedal, and the machine starts plug C into the wall outlet. Press master sewing.
- Page 9 Threading the needle Disengaging the sewing mechanism Thread the needle from front to back. Before you start winding the bobbin, disen gage the sewing mechanism. Hold the hand wheel steady and turn the stop motion knob toward you. After bobbin winding, tighten the knob again by turning it away from you.
- Page 11 Removing bobbin case and bobbin Inserting the bobbin Insert the filled bobbin into the bobbin case Open free arm cover 48. Pull out latch K, so that the thread unreels toward the back then lift out the bobbin case, release the (A>.
- Page 13 Presser bar lifter Thread cutter Lever 42 has three positions: The thread cutter is an oblique slot located The sewing foot is raised. (Before you at the back of the presser bar. Raise the remove the work, turn the hand wheel sewing foot.
- Page 16 Finger-tip controls of model 1027 10 Elastic triple straight stitch 1 6 Elastic triple zigzag stitch, 5 mm Straight stitch 5-mm zigzag stitch 11 Pullover stitch 17 Elastic triple zigzag stitch, 3.5 mm Blindstitch 3.5-mm zigzag stitch 1 2 Closed overlock stitch 1 8 Elastic triple zigzag stitch, 2 mm Joining stitch 2-mm zigzag stitch...
- Page 18 Selecting stretch stitches Selecting utility stitches (red symbols) (white symbols) Push the desired button and turn the stitch Push the desired button and turn the stitch length control as far as it will go (red symbol). length control to the number indicating the desired stitch length (1 —6 on model 1027, or 1—4 on model 1025).
- Page 22 Special sewing feet Buttonhole settings A Blindstitch foot Push button 1 9 (A). Regulate the stitch Blindstich guide E is adjusted by turning density in the buttonhole range of the stitch screw D. length control (B). Attach the buttonhole B Zipper foot foot.
- Page 23 Sewing buttonholes Pull the bottom of the buttonhole foot for 4 Push button 20 and keep it depressed ward as far as it will go. until the machine has sewn 4 to 6 bar- 1 Sew first buttonhole seam. Turn hand tacking stitches.
- Page 24 Sewing feet A Normal sewing foot E Zipper foot B Clear-view foot F Blindstitch foot C Buttonhole foot G Darning foot D Hemmer foot H Guide 98-694 563-00 98-694 98-694 401-00...
- Page 25 Changing the light bulb Cleaning and oiling Push the light bulb up, turn it toward A Tilt needle plate 38 up at the back (A) and and pull it out. Insert the new bulb so that take it out (B). Clean the machine feed and its pins slide in slots C.
- Page 26 Remedy: rCa use: 1. Machine skips stitches Push needle up as far as it will go, its Needle not inserted correctly. flat shank side facing toward the back. Insert system 1 30/705 H needle. Wrong needle used. Insert new needle. Needle bent or blunt.
- Page 27 Cause: Remedy: 4. Seam is not uniform Tension out of adjustment. Check upper and lower tensions. Thread too thick, knotty or hard. Use first-class thread only. Bobbin thread wound unevenly. During bobbin winding, do not hold thread in hand, but pass it through the bobbin tension stud.
