Hotpoint HSS22GFT Dimension Manual

HSS22GFT – Hotpoint
®
A B
Front View
Specification Revised 6/07
410131
"94 SxS Refer
22.0 Cu. Ft. Side-by-Side Refrigerator with Dispenser
C
D
H
G
E
F
Top View
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
Width (in.) G
Width with door open 90° with door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
Total volume and shelf
area are calculated by Listed by
the Association of Home Underwriters
Appliance Manufacturers' Laboratories
standards.
67-1/2
66-1/2
28
31-1/4
33-9/16
49-3/8
33-1/2
33-5/8
1/8
1
1
