JBL L226W Technical Manual

Studio l series
Hide thumbs

Advertisement

Quick Links

Technical Manual
Studio
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
Nominal Impedance
Max Amp Power
Frequency Response
Sensitivity
Crossover Frequency
SYSTEM COMPONENTS:
Grille
Low-Frequency Transducer 6-1/2" (165mm) Aluminum cone
DC Resistance
High-Frequency Transducer 1" (25mm) Titanium-laminate
DC Resistance
Crossover Network
PACKAGING
12
Legend on Page 2
Release Date 2006
Discontinued Date XXXX
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
L Series
8 Ohms
125 Watts*
30Hz – 20kHz (–6dB)
89dB (2.83V @ 1 meter)
3000Hz (24dB/Octave)
329-060-05268-0WAE
(16PR80BYH-DW01-EP)
3.3 Ohms, ±10%
(10DM25BI-DT01-EP)
3.3 Ohms, ±10%
013-7600-05276-EP
15 16
17
18
14
13
AURAL SWEEP TEST SPECIFICATIONS:
System Aural Sweep Test
L.F. Aural Sweep Test
H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
External Dimensions
(W x H)
Mounting Cutout Size
(W x H)
Mounting Depth
Weight
WARRANTY:
Refer to Warranty Statement packed with each product.
*
The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
WIRING DIAGRAM
High-Frequency
Transducer
10DM25BI-DT01-EP
C1
R2
104-c05276a00V-e
R3
C3
L2
R4
C2
L226W
R1
Crossover
Network
013-7600-05276-EP
L226W SCHEMATIC
R2
-1.5dB
1.5 ohm
10w
0dB
+1.5dB
L1
300μH
C1
6.0V Input 30Hz to 20kHz
5.0V Input 30Hz to 4kHz
2.83V Input 2kHz to 20kHz
8-1/2" x 11" (216mm x 280mm)
7" x 9-1/2" (178mm x 241mm)
3-9/16" (90mm)
3.5 lb/1.6kg (each)
Low-Frequency
Transducer
16PR80BYH-DW01-EP
RED
+
BLK
R3
R4
C2
RED
.205
1.2 ohm
2.4 ohm
6.8μf
10w
10w
100V
L2
150μH
BLK
.110
100mm
.250
C2
RED
22μf
10μf
100v
100V
R1
5.1 ohm
10w
BLK
.205
100mm
7/07
