SERVICE
PRIMA
© Whirlpool EMEA
Whirlpool EMEA
Customer Services
Service Information
Built-in Oven
LPR 9022
8579 208 15510
Last Modification: 08/28/10
This document is only intended for qualified technicans who are aware of the
respective safety regulations.
Subject to modifications
LPR 9022
2
3
4
5
6
9
10
12
www.scc-service.com
Advertisement
Related Manuals for Prima LPR 9022
Summary of Contents for Prima LPR 9022
-
Page 1: Table Of Contents
Whirlpool EMEA SERVICE LPR 9022 Customer Services Service Information PRIMA Built-in Oven LPR 9022 8579 208 15510 Last Modification: 08/28/10 Spare Part List Exploded View Dimensional Sketch Technical Data Wiring Diagram Service Bulletin 4812 715 40304 Service Bulletin 4812 715 40185 Service Bulletin 4812 715 40332 This document is only intended for qualified technicans who are aware of the... -
Page 2: Spare Part List
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 2 of 14 Customer Services Spare Part List 12NC Description 040 0 4812 417 19339 Hinge 047 0 4812 417 19137 Hinge run.mech. 110 0 4819 498 58588 Handle door 110 1 4819 462 48443 Rubber 121 3... -
Page 3: Exploded View
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 3 of 14 Customer Services Exploded View © Whirlpool EMEA www.scc-service.com... -
Page 4: Dimensional Sketch
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 4 of 14 Customer Services Dimensional Sketch © Whirlpool EMEA www.scc-service.com... -
Page 5: Technical Data
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 5 of 14 Customer Services Technical Data Electrical base data Rated voltage ................... 230 V~ Main connection . -
Page 6: Wiring Diagram
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 6 of 14 Customer Services Wiring Diagram © Whirlpool EMEA www.scc-service.com... - Page 7 8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 7 of 14 Customer Services Wiring Diagram © Whirlpool EMEA www.scc-service.com...
- Page 8 8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 8 of 14 Customer Services Legend © Whirlpool EMEA www.scc-service.com...
-
Page 9: Service Bulletin 4812 715 40304
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 9 of 14 Customer Services Service Bulletin 4812 715 40304 AUTHOR: Sabine Wilky Last Update: 05/04/10 VERSION: 1.0 TITLE: spontaneous glass break, outer door glass SUBJECT: Under certain circumstances it can happen, that the outer door glass breaks. This can happen every time e.g. during heating up, opening the door, cooling down. -
Page 10: Service Bulletin 4812 715 40185
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 10 of 14 Customer Services Service Bulletin 4812 715 40185 AUTHOR: Jochen Hohl Last Update: 07/01/09 VERSION: 1.0 TITLE: Spring used to fix the thermostat on the back of the cavity CAUSE If part breaks or is lost REMEDIAL ACTION Exchange with spare part... - Page 11 8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 11 of 14 Customer Services © Whirlpool EMEA www.scc-service.com...
-
Page 12: Service Bulletin 4812 715 40332
8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 12 of 14 Customer Services Service Bulletin 4812 715 40332 AUTHOR: Pasquale Lattuca Last Update: 07/01/09 VERSION: 1.0 TITLE: Sharp edges. SUBJECT: Due to the gap between Door frame & Door, can it happen that customers cut their finger. REMEDIAL ACTION Fill the gap with heatresistant silicon. - Page 13 8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 13 of 14 Customer Services © Whirlpool EMEA www.scc-service.com...
- Page 14 8579 208 15510, 08/28/10 Whirlpool EMEA SERVICE page 14 of 14 Customer Services © Whirlpool EMEA www.scc-service.com...
