- Page 1 E C O L O G I C A L C O O L E R S HOLIDAY II User’s Manual www.viesa.ca / 1-888 438-8444...
- Page 2 IMPORTANT Installation requires an experienced mechanic with specific knowledge in the installation of the VIESA Ecological Cooler. Installation, disassembly, repairs and maintenance must be performed by an Authorized Installer. Authorized Installer must use proper protective equipment when installing the system.
- Page 3 Function To lower the inside temperature of the caravan’s cabin using evaporative cooling. Operation The unit is equipped with an electrovalve that is activated by two sensors located at the front and back of the unit. The electrovalve allows passage of water from pressurized pipes to the unit where a tank tray stores it.
- Page 4 BOARD INDICATIONS Important: before switching on the equipment: With parked vehicle: Open one of the windows 2 to 3 cms. With the vehicle in motion: Open one of the windows 2 to 3 cms and close all other air entrances to the cabin so that hot air does not enter from the exterior.
- Page 5 DISPLAY INDICATIONS DRYING SYSTEM SELF POWER ON OR ACTIVATED SELF POWER OFF TURBO BLOWER ON TIME/ TURBO BLOWER SPEED LEVELS AUTO TURBO BLOWER BATTERY LEVEL DISCONNECTION WATER CYCLE SHORT-CIRCUIT IN THE WATER ACTIVATED PUMP OR IN THE TURBO BLOWER NOT ENOUGH OR ELECTROVALVE/ CHANGE THE WATER IN THE EVAPORATOR WARNING...
- Page 6 The equipment has 25 speed levels, which can be changed by pressing In case the turbo blower is disconnected, will turn on and the system will make a sound. The symbol will turn off after the problem is solved and the equipment is restarted by pressing Power Note: the water pump will not work if the turbo blower is disconnected.
- Page 7 FUNCTIONS With the key the user has access to different functions: Menu Time setting Self power on Self power off Working hours Note: The functions are in 24H format. Set Time To set the equipment clock. Press until is displayed and then press Menu The hour blinks, press to set the hour.
- Page 8 Self Power Off It allows to power off the equipment automatically at an established time. AUTO Select with until and oFF appear, press and then to program Menu the time (it changes from 30 to 30 minutes). To deactivate this function follow the instructions above and press until oFF appears.
- Page 9 FAILURE INFORMATION When there is a failure, it will be displayed on the screen and an alarm will sound. Turbo blower disconnected Turbo blower with excessive consumption Pump in short-circuit or with excessive consumption Electrovalve in short-circuit or with excessive consumption Low level of water in the tank of the caravan or shut-off valve closed.
-
Page 10: General Recommendations
During short stops leave the equipment on so as to keep the cabin fresh. WATER AND/ OR AIR Use only clean water. Use the drying mode to avoid bad smells when restarting the equipment. At the end of the season, close the original VIESA shut-off valve and activate the filter drying cycle. -
Page 11: Limited Warranty
LIMITED WARRANTY This limited warranty is provided to the original buyer only and covers the VIESA ECOLOGICAL CAB COOLER (the "Product") manufactured by Col-Ven S.A. (the "Manufacturer") and distributed by RCR Systems Limited (the "Distributor"). The warranty period is two years from date of original purchase by the buyer. During this period, if the product is found to be defective in mechanical or electrical materials or workmanship during normal use, it will be repaired or replaced at no charge to the buyer. - Page 12 USER’S MANUAL VIESA HOLIDAY II REVISION 003 1-2012 P.O.Box 1352 – 1500 Avenue Road Toronto, Ontario M5M 0A1 CANADA Ruta 11 Km.814 - Guadalupe Norte Prov. de Santa Fe (S3574XAB) ARGENTINA ORDER ON-LINE www.viesa.ca / 1-888 438-8444...
