Work-Shed Vac
1100W
Instruction Manual
3 Year Replacement Warranty
WVG-951
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
113
www.ozito.com.au
To view the full range visit:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Work-Shed Vac WVG-951 and is the answer not in the manual?

Questions and answers

Related Manuals for Ozito Work-Shed Vac WVG-951

Summary of Contents for Ozito Work-Shed Vac WVG-951

  • Page 1 WVG-951 WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. www.ozito.com.au To view the full range visit:...

  • Page 2: Specifications

    SPECIFICATIONS – MODEL NO. WVG-951 Motor: 1100W Input: 220 - 240V ~ 50Hz Max. vacuum: 15.5 Kpa Hose length: Hose diameter: 64mm Tank capacity: 20 litres KNOW YOUR PRODUCT 1. Extension tubes 6. Castor wheels 2. Motor securing clips 7. 2m Hose 3.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS…………………………………………. Page 1 KNOW YOUR PRODUCT………………………………… Page 1 INTRODUCTION…………………………………………. Page 3 SAFETY INSTRUCTIONS………………………………… Page 3 ADDITIONAL SAFETY RULES…………………………… Page 6 ASSEMBLY………………………………………………… Page 6 OPERATION ……………………………………………… Page 7 MAINTENANCE …………………………………………. Page 9 SPARE PARTS …………………………………………….. Page 9 CONTENTS ………………………………………………. Page 10 WARRANTY………………………………………………..

  • Page 4: Introduction

    The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
  • Page 5 GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool" in all of the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 6 GENERAL POWER TOOL SAFETY WARNINGS d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS FOR VACUUM CLEANERS This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 8: Operation

    ASSEMBLY (cont.) Hose and Attachments Insert the smaller end of the hose (7) into the matching vacuum inlet (5) on the front of the tank body. Secure by pushing and slightly rotating the hose end. Fit the two extension tubes (1) together then insert the remaining end of the hose into the larger end of the joined extension tubes (1).
  • Page 9 OPERATION (cont.) Vacuuming Liquid 1. Disconnect the unit from the power supply. 2. Release the two motor securing clips and lift the motor from the top of the tank. If the cartridge filter (with the rubber seal) has been previously assembled, remove it. Fit the foam filter over the bracket.

  • Page 10: Maintenance

    When necessary replacement motor filters are available through Ozito Industries. • Do not oil the motor. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the product by an unauthorised person or by mishandling of the product. SPARE PARTS Limited spare parts are available subject to availability.

  • Page 11: Contents

    Reuse of recycled material decreases pollution in the environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice. CONTENTS 1 x Work-Shed Vac WVG-951 4 x Castor wheels 1 x Hose 1 x Foam filter...

  • Page 12: Warranty

    If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations. • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175...
