WET & DRY
VACUUM
1250W 20L
INSTRUCTION MANUAL
SPECIFICATIONS
Mains Voltage:
220 – 240V ~ 50Hz
Input Power:
1250W
Suction Power Max.:
180 mbar
Air Flow:
68 l/s
Tank Capacity:
20 l
IP Rating:
IP24
Product weight:
4.7 kg
ozito.com.au
WHAT'S IN THE BOX
Adapter
Crevice Tool
Floor Tool
Castors x 4
Suction Hose Ø36mm x 1.5m
Extension Tubes x 3
Filter Bag
Foam
Dust Bag
Filter
VWD-1220
Advertisement
Table of Contents
Related Manuals for Ozito VWD-1220
Summary of Contents for Ozito VWD-1220
-
Page 1: Instruction Manual
Input Power: 1250W Suction Power Max.: 180 mbar Air Flow: 68 l/s Suction Hose Ø36mm x 1.5m Tank Capacity: 20 l IP Rating: IP24 Product weight: 4.7 kg ozito.com.au Extension Tubes x 3 Filter Bag Foam Dust Bag Filter VWD-1220... -
Page 2: Product View
KNOW YOUR PRODUCT SETUP & PREPARATION WET & DRY VACUUM 1. ASSEMBLY 1. Handle 8. Motor Securing Clips 2. Motor 9. Vaccum Inlet Assembling the Castors 3. Suction Hose 10. Tank 1. Turn the container upside down. 4. Extension Tubes 11. -
Page 3: Fitting The Filter
2. FITTING THE FILTER Mounting the Cable Hook IMPORTANT! NEVER USE THE WET AND DRY VACUUM CLEANER WITHOUT A FILTER! ALWAYS ENSURE THAT THE FILTERS ARE PERFECTLY SECURE! 1. Press the cable hook for the cable store into the mount on the base of the unit. Fitting the Foam Filter - Vacuuming Liquid 2. A fter use, the power cable can... -
Page 4: Fitting Hoses & Nozzles
Suction Tools COMBUSTIBLE LIQUIDS. Floor Tool The floor tool is for vacuuming solids and liquids over medium to large areas. Blowing Connect the suction hose to the blow outlet on the wet and dry vacuum cleaner. Crevice Tool The crevice tool is designed for cleaning crevices and edges. VWD-1220... -
Page 5: Spare Parts
Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. For further information, or any parts not listed here, visit www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486... - Page 6 TH-VC 1820 S for Kit Artikel-Nr.: 2342166 Wet/Dry Vacuum Cleaner (elect) Ident-Nr.: 11011 Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No.
-
Page 7: Electrical Safety
The electric motor has been designed for 230V and 240V only. Always check that the power Always use an approved extension lead suitable for the power input of this tool. Before use, supply corresponds to the voltage on the rating plate. inspect the extension lead for signs of damage, wear and ageing. Replace the extension lead if Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and damaged or defective. New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension... -
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1213...
