No. Name
2
3
4
5
6
7
8
Description
Port for connecting to S-Video input port of a
TV.
Port for connecting to Composite video input
port of a TV.
Port for connecting to left audio channel input
port of a TV.
Port for connecting to right audio channel
input port of a TV.
10/100M Base-T port for connecting to service
provider's Ethernet port on wall or on xDSL
modem.
DC input port (DC 12V 1A).
Power switch.
