EC1309V2
User Guide
1
2
3
Rear Panel
No.
Name
1
Power indicator.
If the indicator is in green, it indicates that the
STB is in active mode.
If the indicator is in red, it indicates that the STB is
in standby mode.
Link indicator.
If the indicator is in green, it indicates that the
STB is connected to the network.
If the indicator is in red, it indicates that the STB is
disconnected from the network.
Infrared indicator.
If the indicator blinks, it indicates that the STB is
receiving signals from the remote control.
Description
USB 2.0 port, allow optional features as
requested by operator.
3
1 EC1309V2
