EC1309V2
User Guide
The steps for cable connection are as follows:
Step 1
Use the audio cable to connect the audio output ports of STB
(Audio L and Audio R) with the corresponding audio input
ports of the TV.
Step 2
Select one of the following methods to connect the video
cable:
1.
2.
Step 3
Use Ethernet cable to connect the WAN port of STB with a
10/100M Base-T Ethernet port or with the Ethernet port of
the xDSL Modem.
Step 4
Insert the power plug of STB into the power socket.

Starting the EC1309V2

The procedure for starting the STB is as follows:
Step 1
Make sure that the network has been correctly connected
and is properly working.
Use the video cable to connect the VIDEO ports of STB
with the video input ports of the TV.
Use the S-Video cable to connect the S-VIDEO port of
STB with the S-Video input port of the TV.
3 Use STB for the First Time
13
