DR. Heater DR-928 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Infrared Portable Space Heater
1500 Watts with
Two Heat Settings
Rotatable Air Outlet
Built in AM/FM Radio
Automatic Thermostat
Tip-Over Switch
Overheat Thermal Cut-Off
Protection
Room Temperature
LED Display
Precision Temperature
Control
Easy Push-Button Controls
Remote Control
SAVE THESE INSTRUCTIONS
Owner's Manual
PLEASE READ AND
Model No.: DR-928

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR-928 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DR. Heater DR-928

Summary of Contents for DR. Heater DR-928

  • Page 1 Two Heat Settings Rotatable Air Outlet Built in AM/FM Radio Automatic Thermostat Tip-Over Switch Overheat Thermal Cut-Off Protection Room Temperature LED Display Precision Temperature Control Easy Push-Button Controls Remote Control Model No.: DR-928 Owner’s Manual PLEASE READ AND SAVE THESE INSTRUCTIONS...

  • Page 2: Important Instructions

    CAUTION- CONGRATULATIONS! High temperature, keep electrical cords, drapery, and other he Dr. Infrared Heater you furnishings at least 3 feet (0.9m) from have just purchased is a the front and rear of the heater outlet. safe and powerful heater, designed to heat a room after a few IMPORTANT minutes of operation.
  • Page 3 locate the heater where it may fall pulling it from the outlet. Never into a bathtub or other water yank on the cord. container. 15. This heater includes an overheat 7. Do not run the cord under protection system that shuts off the carpeting and do not cover the heater when parts of the heater are cord with throw rugs, runners or...

  • Page 4: Operating Instructions

    deformation occurs, immediately The cord has a plug as shown at A in discontinue using the heater and Figure below. An adapter as shown contact Dr. Infrared Heater at C is available for connecting Authorized Service Center. three-blade grounding-type plugs to two-slot receptacles.
  • Page 5 4. SETTING THE TEMPERATURE AM/FM Radio Instructions To set the desired temperature: First step, connect the AM antenna to Press the button once until the connector in the rear of the the numeric temperature starts wooden case as bellow picture: flashing.

  • Page 6: How To Insert Batteries

    7. Connecting your iPOD 2. Press the “+” button to increase the You can connect your iPod, iPhone set time or the “–“ button to or other MP3 Players to the decrease the set time. auxiliary input on the heater. An auxiliary cable is included with The timer can be set from 1 hour to 12 your purchase.
  • Page 7 Store heater in a clean dry place when not in use. Product Specifications Cleaning the electrostatic Model#: DR-928 filter: Voltage: 120V, 60Hz The heater has an electrostatic filter Current: Maximum continuous located in the rear of the heater. The draw: 12.5 amps;...
  • Page 8 Features A. “Cool-Touch” cabinet H. Radio UP button B. Heater Power Button I. Radio DOWN button C. LED Temperature Display J. Radio SCAN button D. Air outlet oscillation K. LCD display. E. Decrease temperature button L. Radio power button F. Increase temperature button M.
  • Page 9 Note: There may be a trace of smoke or odor when the unit is first operated. Do not be alarmed. This indicates a drop of oil fell on the interior coils during the manufacturing process. It will quickly evaporate and should not re-occur. QUESTIONS AND ANSWERS Why does the blower keep running after I have turn off the power button?
  • Page 10 will also have an impact on heating time. Once the room has reached the desired temperature, it will cycle on and off accordingly. Can the heater be used in a bathroom? It is not recommended due to a high level of moisture in the bathroom. Can the heater be used in a basement or garage? Yes, but keep in mind that rooms with little insulation will not retain the heat as efficiently.
  • Page 11 What is the BTU Rating for the heater? The DR INFRARED HEATER MODEL DR-928 is approximately 5600 BTUs. The power cord feels warm to the touch, should I be concerned about it? It is normal for the heater’s plug and cord to feel warm to the touch. A plug or cord which becomes hot to the touch or becomes distorted in shape may be a result of a worn electrical outlet.
  • Page 12 area for advice. Removing or altering any part of the heater is unsafe and will also void your warranty. How long is the warranty? This heater comes with a 3 YEAR LIMITED COMPONENT WARRANTY. If your unit does not appear to be working properly, please contact our service center by calling 1-800-317-1688.
