Summary of Contents for S2Konnect S-8180T
-
Page 2: User Manual
S2Konnect S-8180T Unmanaged Gigabit Ethernet Switch User Manual S2Konnect S-8180T... - Page 3 Copyright © S2Konnect GmbH, 2009. All rights reserved. This manual refers to the S2Konnect S-8180T Unmanaged Switches. Contents are subject to change without notice. Product and brand names are (registered) trademarks of their appropriate owners. If you have comments on this documentation, please send to:...
-
Page 4: Conventions
Used to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury. Example: dangerous voltage. Used to indicate a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. Example: electrostatic discharge. Used for additional information and advice. S2Konnect S-8180T... -
Page 5: Table Of Contents
Table of Contents Conventions Warning Notes Safety Precautions Avoiding injuries Avoiding damage 1 Installation of the S2Konnect Unmanaged Switch Installation on a Level Surface Installation on a Wall Installation in a Rack 2 Connection of the S2Konnect Unmanaged Switch Transmission Distances... -
Page 6: Table Of Figures
Figure 3 : Connection of the RJ-45 cable/plug Figure 4 : Connection of Switches Figure 5 : Front Panel of the S-8180T Figure 6 : Rear Panel of the S2Konnect Unmanaged Switches Figure 7 : Location of the LEDs S2Konnect S-8180T... -
Page 7: Safety Precautions
Safety Precautions To protect yourself from injuries and avoid damage to the S2Konnect S-8180T Unmanaged Switches, always observe the following safety instructions. Avoiding injuries Electrical current! Electrical current from power, phone, and communications cables can be hazardous. Never touch any electrical elements with bare hands. -
Page 8: Installation Of The S2Konnect Unmanaged Switch
The unit may be used for rack, wall or on table installation. Installation on a Level Surface To install the S2Konnect Unmanaged Switch on a table or similar, attach rubber feet on each marked location on the bottom of the device to avoid slipping of the device and scratches on the surface. -
Page 9: Installation In A Rack
Make sure that the wall is capable of supporting the S2Konnect Unmanaged Switch. The S2Konnect Unmanaged Switch must not be exposed to direct sunlight or be installed near heating vents. The location should be ventilated to prevent overheating. Installation in a Rack... -
Page 10: Connection Of The S2Konnect Unmanaged Switch
In order to connect the S2Konnect Unmanaged Switch to a network, proceed as follows: If possible, disconnect the S2Konnect Unmanaged Switch from the power supply. At one end of the cable connect the RJ-45 connector to the port on the S2Konnect Unmanaged Switch (see figure 3). -
Page 11: Connection To Other Switches
In order to connect two Switches with one another, proceed as follows: If possible, disconnect the Switches from the power supply. At one end of the cable connect the RJ-45 connector to the port on the S2Konnect Unmanaged Switch (see figure 4). -
Page 12: Features
The S2Konnect S-8180T Unmanaged Switches are designed for easy installation and high per- formance in environments with varying traffic loads and multiple users. Front Panel The front panel of the S2Konnect Unmanaged Switches consists of the power LED, link and status LEDs and RJ-45 ports. Figure 5. Front Panel of the S-8180T All 8 ports with RJ-45 connectors can negotiate full- and half-duplex modes automatically. -
Page 13: Rear Panel
You will also find the procedure for returning a switch for repair on that section. S2Konnect cannot accept any returned product without an RMA number on the outer packaging. The warranty does not apply to products that have been damaged by electrostatic discharge or... -
Page 14: Technical Specifications
S-8180T - 8 Port Gigabit Ethernet Switch Product Highlights 1.9 Million packets/second forwarding rate Up to 16 Gbit/s switching capacity Up to 4.000 MAC Addresses SysKonnect SK-8T08 compatible Features 8 Ports 10/100/1000Base-T, Auto MDI/MDI-X Auto-negotiation 128 KB packet buffer memory 2 priority queues per port Honors 802.1p values and honor IP DSCP values... - Page 15 S-8180T - 8 Port Gigabit Ethernet Switch RoHS, other RoHS compliant Dimension 44x266x162 mm, 1.7x10.5x6.4” (High, Width, Deep) Weight Unit 1,45 kg, packet 2,35 kg Warranty 2 Years Order numbers 100-001-001-008 Germany © Copyright 2009 S2Konnect All rights reserved. All brand and product names are trademarks S2Konnect GmbH or registered trademarks of their respective holders.
-
Page 16: Appendix A. License And Warranty Information
S2Konnect’s entire liability and your exclusive remedy shall be, at S2Konnect’s option, either return of the price paid, or repair or replacement of the SOFTWARE or HARD- WARE that does not meet S2Konnect’s Limited Warranty and which is returned to S2Konnect GmbH with a copy of your receipt. This Limited Warranty is void if failure of the SOFTWARE or HARDWARE has resulted from accident, abuse, or misapplication. -
Page 17: Europe
S2Konnect’s entire liability and your exclusive remedy shall be, at S2Konnect’s option, either return of the price paid, or repair or replacement of the SOFTWARE or HARD- WARE that does not meet S2Konnect’s Limited Warranty and which is returned to S2Konnect with a copy of your receipt. This Limited Warranty is void if failure of the SOFTWARE or HARDWARE has resulted from accident, abuse, or misapplication. -
Page 18: Deutschland, Schweiz, Österreich, Lichtenstein
Weitere Beschränkungen Sie dürfen die Software oder Hardware weder vermieten noch verleihen, aber Sie dürfen die Rechte aus diesem S2Konnect Lizenzund Kaufvertrag auf Dauer auf einen an- deren übertragen, vorausgesetzt, dass Sie alle Kopien der Software und das gesamte schriftliche Begleitmaterial übertragen und der Empfänger sich mit den Bestimmungen dieses Vertrages einverstanden erklärt.
