  • Page 1 User Manual (detailed) Operating Guide - Technical 020-000664-03 DWU951/DHD951/DWX951 DWU851/DHD851/DWX851 DXG1051...
  • Page 3 Projector DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual (detailed) Operating Guide – Technical Example of computer signal Resolution (H x V) H. frequency (kHz) V. frequency (Hz) Rating Signal mode 720 x 400 37.9 85.0 VESA TEXT 640 x 480 31.5 59.9 VESA...
  • Page 4 Reduced Blanking *1) Supported except for HDMI input. *2) Only for DXG1051. *3) Only for DWX951, DHD951, DWU951, DWX851, DHD851 and DWU851. *4) Only for DWU951 and DWU851, but except for HDMI input. NOTE (1600x1200) or up to W-UXGA (1920x1200) for DWU951/DWU851 composite sync or a sync on G.
  • Page 5 1440 x 900 13.5 WXGA+ (60Hz) 1680 x 1050 11.5 1050 WSXGA+ (60Hz) 1600 x 1200 1200 UXGA (60Hz) W-UXGA (60Hz) 1920 x 1200 0.208 0.519 12.47 0.312 1200 Reduced Blanking DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 6: Monitor Out

    Connection to the ports NOTICE COMPUTER IN1 or IN2 (COMPUTER IN for DHD951/DHD851) MONITOR OUT port. DWU951 / DWX951 / DXG1051 / DWU851 / DWX851 DHD951 / DHD851 COMPUTER IN1 (COMPUTER IN for DHD951/DHD851), MONITOR OUT ⑪ ⑫ ⑬ ⑭...
  • Page 7 Connection to the ports DWU951 / DWX951 / DXG1051 / DWU851 / DWX851 COMPUTER IN2 R/CR/PR, G/Y, B/CB/PB, <Computer signal> DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 8 Connection to the ports DWU951 / DWX951 / DXG1051 / DWU851 / DWX851 DHD951 / DHD851 HDMI 1, HDMI 2 ② ④ ⑥ ⑧ ⑩ ⑫ ⑭ ⑯ ⑱ HDMI connector ① ③ ⑤ ⑦ ⑨ ⑪ ⑬ ⑮ ⑰...
  • Page 9 Connection to the ports DWU951 / DWX951 / DXG1051 / DWU851 / DWX851 DHD951 / DHD851 VIDEO CONTROL ⑨ ⑧ ⑦ ⑥ D-sub 9pin plug ⑤ ④ ③ ② ① Signal Signal Signal Ground DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical...
  • Page 10 Connection to the ports DWU951 / DWX951 / DXG1051 / DWU851 / DWX851 DHD951/ DHD851 HDBaseT ② ④ ⑥ ⑧ ① ③ ⑤ ⑦ Signal Signal Signal HDBaseT0+ HDBaseT2+ HDBaseT3+ HDBaseT0- HDBaseT2- HDBaseT3- HDBaseT1+ HDBaseT1- ② ④ ⑥ ⑧ ①...
  • Page 11 Connection to the ports DWU951 / DWX951 / DXG1051 / DWU851 / DWX851 DHD951/ DHD851 WIRELESS PORT ④ ③ ② ① Signal - Data + Data Ground REMOTE CONTROL DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 12 Connection to the ports DHD951 / DHD851 480i, 576i DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 13 CD (1) (1) − RD(2) (2) RD TD (3) (3) TD (4) − DTR (4) DSR (6) (6) − RTS (7) (7) RTS DTS (8) (8) CTS (9) − RI (9) DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 14: Communication Settings

    ( [Action] Set functional code to byte number 7 and 8. <SET < EXECUTE above For byte number 9 to 12, refer to 20 ). command table ( DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 15: Response Code / Error Code

    3. Response code / Error code (1) ACK reply: 06h (2) NAK reply: 15h (3) Error reply: 1Ch + 0000h (4) Data reply: 1Dh + xxxxh NOTE command or data. DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 16 WIRELESS port HDBaseT port LAN or HDBaseT port ・LAN cable (CAT-5e or greater) ・For HDBaseT connection - CAT-5e or greater - shielded type (connectors included) - straight cable - single cable DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 17: Communication Port

    Network Control Port2 (Port: 9715) [Enable] [Authentication] is required. Default setting is “Enable”. Network Control [Network Control Port1 (Port: 23)] and Re-enter [Network Control Port2 (Port: 9715)]. Default setting is blank. DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 18: Command Control Settings

    RS-232C command Connection ID 0×02 0×0D 13 bytes 1 byte 1 byte [Header] 02, Fixed [RS-232C commands] 12 ). Refer to RS-232C Communication command format [Check Sum] [Connection ID] NOTE code. DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 19 (5) Authentication error reply: 1Fh + 0400h + ××h (6) Projector busy reply: 1Fh + ××××h + ××h Automatic Connection Break Authentication commands to send. password (example) a572f60c (example) “a572f60c” “e3d97429adffa11bce1f7275813d4bde” NOTE DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 20: Wireless Port

    WIRELESS port LAN port LAN port ・LAN cable (CAT-5e or greater) - CAT-5e or greater - shielded type (connectors included) - straight cable - single cable RS-232C cable (cross) RS-232C DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 21 Network Bridge Communication Communication settings SERVICE menu. Item Condition BAUD RATE Start bit Stop bit NOTE 7.4 Transmission method Network Guide. DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 22 01 00 07 24 01 00 BE EF 06 00 2B 93 01 00 07 24 02 00 BE EF 06 00 78 92 02 00 07 24 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 23 01 00 12 23 12 00 VIDEO BE EF 06 00 16 26 01 00 12 23 01 00 BE EF 06 00 B5 27 02 00 12 23 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 24 01 00 02 23 01 00 BE EF 06 00 75 23 02 00 02 23 00 00 Execute BE EF 06 00 01 27 06 00 16 23 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 25 01 00 80 30 02 00 Ramp BE EF 06 00 0B FA 01 00 80 30 03 00 BE EF 06 00 C8 FA 02 00 80 30 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 26 00 00 Decrement BE EF 06 00 CB FE 05 00 97 30 00 00 User GAMMA Execute BE EF 06 00 2C C3 06 00 57 70 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 27 02 22 00 00 Increment BE EF 06 00 D3 72 04 00 02 22 00 00 Decrement BE EF 06 00 02 73 05 00 02 22 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 28 BE EF 06 00 26 71 05 00 09 22 00 00 Execute BE EF 06 00 EC D9 06 00 27 70 00 00 Reset *) Supported except for DXG1051. DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 29: Auto Image

    1D 22 01 00 HDMI 2 FORMAT BE EF 06 00 32 74 01 00 1D 22 02 00 BE EF 06 00 61 75 02 00 1D 22 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 30 01 00 11 20 03 00 BE EF 06 00 A2 D6 01 00 11 20 02 00 BE EF 06 00 F1 D7 02 00 11 20 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 31 0B 20 00 00 Decrement BE EF 06 00 5E D1 05 00 0B 20 00 00 Execute BE EF 06 00 98 D8 06 00 20 70 00 00 Reset DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 32 48 21 00 00 Execute BE EF 06 00 D5 94 06 00 49 21 00 00 Execute BE EF 06 00 91 94 06 00 4A 21 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 33 00 00 EDGE Execute BE EF 06 00 B0 8D 06 00 31 31 00 00 EDGE Execute BE EF 06 00 8C 96 06 00 40 31 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 34 60 31 02 00 MODE MODE-3 BE EF 06 00 0B 9C 01 00 60 31 03 00 BE EF 06 00 C8 9C 02 00 60 31 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 35: Eco Mode

    BD 20 04 00 - HDMI 2 BE EF 06 00 62 B7 01 00 BD 20 FF 00 BE EF 06 00 A1 F6 02 00 BD 20 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 36 01 00 05 30 0E 00 BE EF 06 00 07 D6 01 00 05 30 0F 00 BE EF 06 00 C4 D3 02 00 05 30 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 37 01 00 04 30 00 00 BE EF 06 00 9B D3 01 00 04 30 01 00 BE EF 06 00 38 D2 02 00 04 30 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 38: Osd Message

    01 00 2B 22 00 00 BE EF 06 00 4A 7B 01 00 2B 22 01 00 BE EF 06 00 E9 7A 02 00 2B 22 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)

  • Page 39: Auto Search

    01 00 0D 33 18 00 BE EF 06 00 57 5E 01 00 0D 33 A8 00 BE EF 06 00 A4 21 02 00 0D 33 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 40 01 00 01 36 3B 00 BE EF 06 00 06 03 01 00 01 36 40 00 BE EF 06 00 F5 32 02 00 01 36 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 41 01 00 03 36 3B 00 BE EF 06 00 BE 02 01 00 03 36 40 00 BE EF 06 00 4D 33 02 00 03 36 00 00 DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 42 Execute BE EF 06 00 C9 C2 06 00 03 35 00 00 IMAGE-3 Delete Execute BE EF 06 00 BD C3 06 00 04 35 00 00 IMAGE-4 Delete DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 43 31 = HDMI 1 32 = DVI-D Input Source inquiry 33 = HDMI 2 DHD851) 36 = HDBaseT 30 = AV Mute off AVMT AV Mute 31 = AV Mute on DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
  • Page 44 31 = AV Mute on Error Status inquiry 11 12 23 31 32 33 36 37 51 CHRISTIE inquiry DXG1051 DWX951 DHD951 DWU951 DWX851 DHD851 DWU851 Class Information inquiry 1 NOTE DWU951/DHD951/DWX951/DXG1051/ DWU851/DHD851/DWX851 User's Manual - Technical 020-000664-03 Rev. 1 (09-2014)
