SCALE RADIO CONTROLLED ELECTRIC POWERED
T
T
OPERATION AND ASSEMBLY INSTRUCTIONS
The SAPAC TL 2000 is supplied in 2 versions –
One is an
RTF
- "Ready To Fly" version, which includes the Brushed motor with the
R/C equipment & servos Installed, ESC & LiPo Battery + 12 Vlt. Charger, or all you
need to fly except an optional 240 to 12 Vlt adapter and 8 x AA batteries for the
The
RX READY
version includes the Motor + Servos installed with ESC and a LiPo
Battery and 12 Volt DC. Balance Charger – No TX or RX.
This model requires a minimum of a 4 Channel radio system.
These models are simple to assemble, factory built in Injection Moulded Foam and are great
Please read carefully and follow instructions
to ensure correct assembly of this model aircraft.
L
2
0
0
0
-
L
2
0
0
0
-
A
d
v
a
n
c
A
d
v
a
n
c
Transmitter
fun to fly.
This model is not a toy.
S
e
m
i
S
c
S
e
m
i
S
c
e
d
T
r
a
i
n
e
d
T
r
a
i
n
1
a
l
e
a
l
e
e
r
e
r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Sapac TL 2000

Summary of Contents for Sapac TL 2000

  • Page 1 SCALE RADIO CONTROLLED ELECTRIC POWERED OPERATION AND ASSEMBLY INSTRUCTIONS The SAPAC TL 2000 is supplied in 2 versions – One is an - “Ready To Fly” version, which includes the Brushed motor with the R/C equipment & servos Installed, ESC & LiPo Battery + 12 Vlt. Charger, or all you...
