- Page 1 G950 residential gate opener for swing gates Toll free helpline Please have your serial number and model name available before calling. Australia 1800 638 234 New Zealand 0800 653 667 United Kingdom 0800 073 0112...
-
Page 2: Site Requirements
WARNING Incorrect installation can lead to severe injury. Follow all installa- tion instructions. Merlin Garage Openers Limited does not accept responsibility for damage or injury result- Index ing from installing this opener. Before installing the drive remove or disable any equipment, such as locks, that is not needed for powered operation. - Page 3 Level and square the gate The gate hinge pivot points should be per- fectly parallel to a plumb line. When closed, the gate leaves should line up evenly and not bind against each other. The leaves should not be damaged or bent. Gate stops It is recommended that any of the follow- ing are used:...
- Page 4 Battery power with trickle charging Due to the high cost of long runs of heavy cable, it may be more economic in some instal- lations to operate the gates from a larger battery, which is charged from a remotely located trickle charger.
- Page 5 NOTE The Merlin M122 wired push-button and M128 wireless push-button are not waterproof, and are only rated for interior use. The Merlin KWF1 keyed switch is not intended for use fully exposed to weather in gate installations. Merlin does not warranty any items used outside their published ratings or intended use.
-
Page 6: Installation Clearances
Installation clearances Standard side-room vs. Restricted side-room The standard side room requirement is 550 mm. If less than this is available, it is possible to shorten the secondary arm (the one that attaches to the gate). Do not shorten it to less than 350 mm. Take care that the attachment point between the gate and the secondary arm does not foul on the output shaft. - Page 7 This is useful where the gate must open further than 90 degrees, or where the gate must open out- wards. Contact Merlin for side-mounting covers. Out-swinging gates This also requires side-mounting covers. It may be necessary to fabricate longer primary arms for some installations.
- Page 8 Connecting the board wiring antenna wire 27/40 MHz only Merlin M001 coaxial antenna (must remove if connector (for MCX plug only) using 433 MHz) Standard antenna wire (must remove if using M001) DC in + Motor 1 OP DC in –...
- Page 9 Connecting the motor wiring Motor 1 is the left hand motor when facing out of the driveway. If Motor 1 is on the right hand side, reverse the polarity of the motor wires. If a single opener is fitted, use the Motor 1 terminals. If a single opener is fitted on the right hand side, reverse the polarity of the motor wires.
-
Page 10: Board Adjustments
Left hand motor: rotate the bottom cam anticlockwise until it actuates the switch. Right hand motor: rotate the top cam clockwise until it actuates the switch. Re-tighten the limit cam cap-screw. Open the gates Operate the motors until their output shafts are in the correct position to engage with their primary arms. -
Page 11: Receiver Setup
Common access remotes are only available in the full-sized remote controls. Adding an external antenna Only connect a Merlin M001 external antenna with MCX co-axial connector to the receiver card. This antenna, cable and connector is tuned to give the best performance. -
Page 12: Setting Up The Board
Setting up the board Receiver status LED Motor 1 open delay (double-flash = RTL Auto-close timer (max = clockwise) (min = clockwise) single-flash = normal) 2 – 5 sec 6 – 210 sec if jumper ON Motor 2 close delay LEARN button (max = clockwise) (hold 1s, release... -
Page 13: Optional Extras
You can fit any sensor beams with relay contact outputs that can be configured as open contacts when obstructed and closed contacts when OK. Merlin M103 sensor beams require three wires for the receiver beam and two wires for the transmitter beam. -
Page 14: Troubleshooting
Troubleshooting Remote controls will not function while gate is moving The total load on the power supply may be exceeding its capacity. Measure the voltage into the board. If less than 9V dc when the motors are under load, then a higher capacity power supply must be fitted, or some accessories removed, or separate power supplies provided for the accessories. -
Page 15: Maintenance
Maintenance In an area where ant or insect infestation is likely, regularly spray around the opener and any electrical installation with insecticide. In normal conditions it is not expected that any additional lubrication or service is required. Keep the path of the gate free from debris and foliage. -
Page 16: Specifications
Specifications Mains power required 220 V to 240 V ac, 50 Hz, earthed Extra Low Voltage supply (optional) 4 A per motor at 12 V dc Rated load max 300 N (approx 30 kg force) at right an- gles to the end of the primary arm Stand-by power consumption max 0.5 W Operating power consumption...
