USER GUIDE
SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE •
Harvest-1 Cycle
Temperature control terminals 2 and 3 are open - 2 and 1
close.
No power to the compressor or condenser fan.
ON
OFF
black
SWITCH
black
LIMIT
SWITCH
black
(Hold Switch In Normal Position)
black
FAN
MOTOR
COMP.
OVER
START
LOAD
RELAY
WATER
C FILL NC
SWITCH
black
orange
black
MOLD HEATER
If bin arm is down, power goes through bin arm switch to
the ice maker motor. If bin arm is up, the ice maker will
not harvest.
HARVEST-1 CYCLE
black
brown
black
blue
ICE
orange
MAKER
MOTOR
black
ground
WATER
white
VALVE
HOLD
C
SWITCH
NC NO
yellow
2
TEMP.
red NO C
BIN
CONTROL
3
1
SWITCH
orange
Troubleshooting - Extended 5
u-line.com
SERVICE
UL183-5
