Table Of Contents - NAD Original instructions Service Manual

Advertisement

FRONT PANEL / REAR PANEL VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ALIGNMENT PROCEDURE / ALIGNMENT POINTS . . . . . . . . . . . . . . . . . . . . . . . . 5
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PCB LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCHEMATIC DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-21
IC BLOCK DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
ELECTRICAL PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-28
EXPLODED VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
EXPLODED VIEW PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
PACKING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
SERVICE SAFETY PRECAUTIONS
1. Replacing the Fuses
CAUTION:
FOR CONTINUED PROTECTION AGAINST THE RISK OF FIRE REPLACE ONLY
WITH SAME TYPE OF FUSE.
REFERENCE NO.
F1*AH
F2*AH
F1*C
F2*C
NOTE:
*AH : North American model only
*C : European model only
2. Safety-check out (North American model only)
Parts marked with the symbol
Replace only with parts recommended by the manufacturer.
Before returning the product to the customer, make leakage current or resistance measurements
to determine that exposed parts are acceptably insulated from the supply circuit.
CONTENTS
PART NUMBER
DESCRIPTION
5100-2510-1C
Fuse 250mA 250V Time Lag UL/CSA
5120-0061-0
Fuse 12A 250V Time Lag 6.3x32mm UL/CSA
5120-0035-0
Fuse 100mA 250V Time Lag LBC VDE/SEMKO
5120-0025-0
Fuse 6.3A 250V Time Lag HBC VDE/SEMKO
!
are critical with regard to the risk of fire and electric shock.
