FRONT PANEL / REAR PANEL VIEW

FRONT PANEL CONTROLS
1. POWER SWITCH
2. INFRA-RED RECEIVER
3. TAPE MONITOR
The graphic symbol of a lightning flash with an arrow point
within a triangle signifies that there is dangerous voltage
within the unit and it posses a hazard to anyone removing
the cover to gain access to the interior of the unit. Only
qualified service personnel should make such attempt.
REAR PANEL CONNECTIONS
15
1. RIGHT BALANCED CD INPUT
2. RIGHT VIDEO INPUT
3. RIGHT AUX INPUT
4. RIGHT TUNER INPUT
5. RIGHT TAPE INPUT/OUTPUT
9 8 7
Dual Mono Integrated Amplifier S300
IR TAPE MONITOR TUNER
1 2 3
4. VOLUME CONTROL
5. INPUT SELECTOR
6. INPUT INDICATOR
1 2 3 4
14
6. LEFT TAPE INPUT/OUTPUT
7. LEFT TUNER INPUT
8. LEFT AUX INPUT
9. LEFT VIDEO INPUT
10. LEFT BALANCED CD INPUT
6
NA D
AUX
4 5
5 6 7
13
3
VIDEO CD
7. TAPE MONITOR INDICATOR
8. INFRA-RED INDICATOR
9. POWER INDICATOR
The graphic symbol of an exclamation point within
an equilateral triangle warns a user of the device
that it is necessary to refer to the instruction
manual and its warnings for proper operation of
the unit.
8 9 10
12 11
11. AC INLET
12. LEFT SPEAKER OUTPUT
13. GROUND TERMINAL
14. RIGHT SPEAKER OUTPUT
15. NAD LINK INPUT/OUTPUT
