12.WHEEL KIT
1.Install the two wheels on the
generator using two bolts .
2.Install the crutches on the under frame.
2.Install the handrails on the right frame.

13.PARTS LIST AND DIAGRAM

13.1 CRANKCASE ASSY

NO. PARTS NO.
QJ182QDP.01-11
1
2 157.5-10
3 157.5-9
QJ150FMG.5-8
4
5 GB5787-86
6 QJ182QDP.01.04
7 157-1-6-13
QJ182QDP.01-01
8
9 QJ168QDJ.01-05
10 QJ168QDJ.01-03
11 GB5787-86
QJ182QDP.01.01
12
13 QJ168QDJ.01-04
14 QJ182QDP.01-03
15 GB/T276-94
16 GB/T276-94
17 QJ182QDP.01-10
18 QJ182QDP.01-05
19 QJ182QDP.01-09
QJ182QDP.01-08
20
21 GB5787-86
22 QJ182QDP.01.03
23 QJ182QDP.01.02
WHEELS
DESCRIPTION
Buse, locating
SPACER, drain
BOLT, drain
DOWEL PIN
BOLT M6 12
Sensor Assy, Fuel level
NUT
COVER, CRANKCASE
SEAL WASHER
PLUG, ADD OIL
BOLT M8 40
OIL SEAL 52 34 8
OIL LEVEL STICK
SPACER, CRANKCASE
Bearing6202 15 35 11
Bearing6207 35 72 17
Pin
ELECTRONIC SWITCH
CLIP, Cord
SEAL GASKET, rubber
BOLT M6 25
OIL SEAL
CRANKCASE ASSY
Warranty and Service Questions ?
Missing or Damaged parts
Call 866 797 2738
BOLTS
QTY
2
2
2
2
4
1
1
1
2
1
7
2
1
1
2
1
1
1
1
1
2
1
1
- 14 -
HANDRAILS
CRUTCHES
