Tool Grinding Attachment - Work Sharp Ken Onion Edition User Manual

12

Tool Grinding Attachment

Hub Fastener
(Left-Handed Thread)
Ball Detent
Platen Grind
1. Install pulley drive hub onto tool using provided Left-Hand Thread Hub Fastener –
turn LEFT to tighten and
Be sure the drive pulley is properly aligned onto the keyed motor shaft.
2. Install metal Tool Grinding Attachment by pressing inward and rotating forward.
3. Push in and turn tensioner to install / uninstall belt. Use tracking lever to center belt
on pulley.
Tracking Lever
Slack Grind
P Push lock release lever and rotate knife
s sharpening cassette to position shown,
p pull outward to remove cassette.
RIGHT to loosen, do not over-tighten
Quick Lock
Tensioner
fastener.
