Electra Alpha 9 SP R22 Service Manual

Alpha sp series indoor units outdoor units
Hide thumbs
Table of Contents

Advertisement

Quick Links

Alpha 9 SP R22
Alpha 12 SP R22
Alpha 9 SP EU R410A
Alpha 12 SP EU R410A
Alpha 9 SP ISR R410A
Alpha 12 SP ISR R410A
REFRIGERANT
R410A
SM ASP 1-E.2 GB
Alpha SP Series
Indoor Units
R22
AUGUST – 2008
CONTENT
Outdoor Units
CSP 9 R22
CSP 12 R22
CSP 9 R410A EU
CSP 12 R410A EU
CSPI 9 R410A RC
CSPI 9 R410A A2 RC
CSPI 12 R410A RC
CSPI 12 R410A A2 RC
COOLING ONLY
HEAT PUMP
