- Page 1 Installation guide COMBI E Before installing read this guide first...
- Page 2 13 amp socket, water supply and waste. The Quooker tank must be fitted in an upright position. If the tank is to be fitted in a cabinet with drawers, an optional bracket can be purchased to suspend the tank from the cabinet wall.
- Page 3 Users The Quooker tap can be used by children above the age of eight and people with diminished physical, sensory or intellectual abilities provided they are supervised or have been instructed on the safe use of the device. Inform people who are unfamiliar with the Quooker system about safe use and the possible dangers associated with the use of the boiling-water tap.
-
Page 4: Declaration Of Conformity
Declaration of conformity Quooker B.V., Staalstraat 13, 2984 AJ Ridderkerk (The Netherlands) herewith declares, on our own responsibility, that the product Quooker COMBI E is in accordance with the conditions of the following directives: - 2006/95/EC Low voltage Directive, - 2004/108/EC Electromagnetic Compatibility Directive,... -
Page 5: Technical Specifications
Technical specifications Tank COMBI E Voltage 230 V Wattage* 2200 W Capacity 7 litres Heating-up time* 20 minutes Standby power consumption* 10 W Tank height 47 cm Tank diameter 20 cm Min. mains pressure 200 kPa (2 bar) Max. mains pressure 600 kPa (6 bar) Max. -
Page 6: Contents Of The Pack
Fusion tap, small washers, brass fixing plate, fixing nut, white tap support (for thin work tops) and two inlet hose screens 3. Quooker inlet combination, waste hose, Quooker drill bit, PVC connector and large fibre washers 4. Mixing valve 5. - Page 7 Overview of Quooker COMBI E installation It is recommended that you install the Quooker in the following order: A. Drilling hole B. Fitting boiling-water tap C. Connecting water D. Connecting waste E. Connecting tank Note: Bear in mind that the tank, inlet combination, mixing valve and socket must remain accessible for servicing.
- Page 8 Overview of Fusion tap installation It is recommended that you install the Quooker in the following order: A. Drilling hole B2. Fitting boiling-water tap C. Connecting water D. Connecting waste E2. Connecting tank with Fusion tap Note: Bear in mind that the tank, inlet combination, mixing valve and socket...
- Page 9 Drilling hole • Note: The tap hole for the Nordic boiling-water tap should be 32 mm in diameter. The Fusion tap hole should be 35 mm in diameter. • For drilling the hole for the Fusion tap, see step 3 below. •...
- Page 10 Fitting Nordic tap • Note: The total length of the hose between the boiling-water tap and tank is only 70 cm. The tank must therefore be fitted close to the tap. Extension hoses are available in different lengths but are not normally required. •...
- Page 11 Position the brass fixing plate around the hoses. Screw the fixing nut onto the tap thread. Adjust the position of the tap to ensure that the Quooker logo is facing the user. When the handle is in the cold position, it will be parallel to the edge of the work top.
-
Page 12: Connecting Water
Connecting water • Note: The COMBI E operates under mains water pressure and must always be fitted with the supplied inlet combination and pressure reducing valve. • The boiling-water tap must be installed according to the locally applicable regulations. • The inlet combination will release drips of expansion water while the water in the tank is heating up in order to regulate the pressure inside the tank. -
Page 13: Inlet Combination
Connecting waste The Quooker tank releases expansion water via the inlet combination which is fed into the grey funnel. The funnel is connected to the waste pipe via the supplied waste hose. The drilling kit, also supplied, can be used to make a connection to the waste pipe. -
Page 14: Electrical Connection
Connecting tank with Nordic tap • The Quooker tank is supplied with a UK 3 pin plug and requires a standard 13 amp earthed socket. • If the mains lead is damaged it should be replaced by the manufacturer, their agent or a qualified technician to prevent hazard. - Page 15 Connecting tank with Fusion tap • The Quooker tank is supplied with a UK 3 pin plug and requires a standard 13 amp earthed socket. • If the mains lead is damaged it should be replaced by the manufacturer, their agent or a qualified technician to prevent hazard.
-
Page 16: Switching Off
Close the main shut-off valve or the stop valve on the inlet combination (small grey knob). Check that the Quooker is depressurized by opening the Nordic boiling-water tap or the boiling-water handle of the Fusion tap again. If it is depressurized, no water should flow out of it. - Page 17 Q U O O K E R U K L T D 3 Waterpark Hall Montpellier Mews Salford M7 4ZY (UK) P +44 (0)207 9233355 F +44 (0)207 9001590 E-mail info@quooker.co.uk Internet quooker.co.uk...
