Airmax SW20 Owner's Manual

Cleaning Water Naturally
OWNER'S MANUAL FOR:
SW20 & SW40
Pond Series Shallow Water
Aeration Aeration Systems
1. System Components
Airmax Composite Cabinet
®
1
4
SilentAir™ LR Series Linear Diaphragm Compressor
2
6
3
ProAir 2 Weighted Diffuser
™
1
™
Air
1. Enhanced cooling system tunnels air flow evenly
2 through the cabinet with a high flow cooling fan &
high density air intake pre-filter.
2. Composite cabinet with removable top protects
components while providing easy access
3. Elevated base protects against damaging flood
water
3
4. Pre-wired electrical box simplifies electrical
connections for easy setup
Cabinet Size: 23"L x 17"W x 15"H
1. High efficiency, linear diaphragm compressor
1
2. Air Filter maximizes the life of the compressor
3. Rubber compressor mounts reduce noise and
vibration for silent operation
5
4. Airflow manifold simplifies airflow management to
individual diffusers
5. Heat-resistant,
⁄ " flex-tube protects
3
8
against high temperatures of the
4
compressor
2
1. PTFE non-stick membrane diffuser sticks provides
the synergy of air stones while being virtually
maintenance-free
2. Check valve prevents back pressure to
compressor
3. Weighted design keeps diffuser submerged while
maintaining an upright position during installation
3
Diffuser Size: 15"L x 9.25"W x 3.75"H
CONTENTS
System Components
Safety
Seasonal Operation
System Installation
Maintenance
Troubleshooting
Replacement Parts
Warranty
THANK YOU FOR CHOOSING
The Airmax Aeration System
®
You have purchased the most efficient and cost-effective
aeration system available on the market today!
6. Airline quick disconnects for easy
system removal and storage
EasySet
• Self-Weighted Airline: 3/8" 100' Roll (#510118), 5/8" 100'
Roll (#510119): Lead-free weighted airline is made of durable
PVC composite. Fish hook resistant and kink-free. Use from
pond's edge to diffuser.
• Direct Burial Airline (sold separately): 5/8" 100' Roll (#510120)
Flexible, yet kink-free. Bury from cabinet and compressor to
pond's edge when placing the cabinet and compressor away
from the pond.
* Depending on the type of
installation, additional
connector kits may be
required. See section 7 for
connector kits.
SECTION
1
2
3
4
5
6
7
8
™ AIRLINE
