ISL9000A Evaluation Board User Guide
Description
The ISL9000A Evaluation Board is designed to provide a
complete platform for demonstrating the performance of the
ISL9000A Low Dropout Regulator IC (LDO). It is designed to
show the small space required for all the components, while
providing room to access the signals.
The layout is intended to minimize thermal effects, to better
evaluate current limits and voltage regulation accuracy. In an
actual implementation, the area for heat sinking may be
smaller, so thermal effects may make the operation slightly
different.
The ISL9000A evaluation board constitutes a complete dual
voltage regulator solution. The PCB board is 2 inches by 3
inches, however, the actual charger components easily fit
within a 0.9x1.6 cm area (components on one side),
demonstrating the space saving advantage of the ISL9000A in
limited space applications.
A voltage source can be connected to the two pin connector
(J2, default) or to the banana jacks (not populated). For
monitoring the output, test instruments can be connected to
the five pin connector (J13, default) or to the banana jacks or
scope probe jacks (not populated). Additional test points
provide a convenient way to monitor the POR outputs and the
signal on the bypass capacitor. This can be especially
important when testing the LDO in a temperature chamber.
Several ground pins provide reference points for test leads.
Additional "kelvin" test points are provided for VIN, VO1, VO2,
and GND to monitor the actual performance of the IC. This
removes the voltage drops across the PCB traces that occurs
at higher currents.
The board has a jumper block for enabling each of the two LDO
outputs. A shunt can be placed on J3 or J4 between "ENx" and
"LOW" pins to provide a 100kΩ pull-down on each EN pin of
the device. If J3 or J4 "HI" pins are floating, the respective LDO
output will be off, while connecting "HI" to "ENx" will enable
the output.
When it is desired that an LDO always be enabled, connect a
shunt between "ENx" and "HI" on J3 or J4. In this case the
shunt between "ENx" and "LOW" is not needed.
If an external enable signal that drives both high and low is
used to enable the LDO outputs, both shunts can be removed
from ENx.
A jumper (J10) connects the CPOR input to a 10nF capacitor
for POR timing. The jumper can be removed and replaced by a
different capacitor to ground for different power on timing
requirements.
June 27, 2012
AN1767.0
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774

Ordering Information

PART
NUMBER
ISL9000AIRNNZ-EVZ
ISL9000AIRNJZ-EVZ
ISL9000AIRNFZ-EVZ
ISL9000AIRNCZ-EVZ
ISL9000AIRMNZ-EVZ
ISL9000AIRMMZ-EVZ
ISL9000AIRMGZ-EVZ
ISL9000AIRLLZ-EVZ
ISL9000AIRKNZ-EVZ
ISL9000AIRKKZ-EVZ
ISL9000AIRKJZ-EVZ
ISL9000AIRKFZ-EVZ
ISL9000AIRKPZ-EVZ
ISL9000AIRKCZ-EVZ
ISL9000AIRJNZ-EVZ
ISL9000AIRJMZ-EVZ
ISL9000AIRJRZ-EVZ
ISL9000AIRJCZ-EVZ
ISL9000AIRJBZ-EVZ
ISL9000AIRGPZ-EVZ
ISL9000AIRGCZ-EVZ
ISL9000AIRFJZ-EVZ
ISL9000AIRFDZ-EVZ
ISL9000AIRFCZ-EVZ
ISL9000AIRPLZ-EVZ
ISL9000AIRPPZ-EVZ
ISL9000AIRCJZ-EVZ
ISL9000AIRCCZ-EVZ
ISL9000AIRBLZ-EVZ
ISL9000AIRBJZ-EVZ
ISL9000AIRBCZ-EVZ
ISL9000AIRBBZ-EVZ
The board also provides a connector (JP1, not populated)
which can connect to a logic analyzer/pattern generator for
controlling and monitoring the output response. The connector
provides both enable inputs and POR outputs.
Finally, a daughter card connector and a jumper (J14 and J9,
not populated) allow specially assembled boards containing
untrimmed LDOs to be programmed to custom voltage levels
after board assembly. This is done at the factory, so no
additional information will be provided in this document.
Copyright Intersil Americas Inc. 2012. All Rights Reserved.
|
Intersil (and design) is a trademark owned by Intersil Corporation or one of its subsidiaries.
All other trademarks mentioned are the property of their respective owners.

Application Note 1767

VO1 VOLTAGE VO2 VOLTAGE
(V) (V)
3.3 3.3
3.3 2.8
3.3 2.5
3.3 1.8
3.0 3.3
3.0 3.0
3.0 2.7
2.9 2.9
2.85 3.3
2.85 2.85
2.85 2.8
2.85 2.5
2.85 1.85
2.85 1.8
2.8 3.3
2.8 3.0
2.8 2.6
2.8 1.8
2.8 1.5
2.7 1.85
2.7 1.8
2.5 2.8
2.5 2.0
2.5 1.8
1.85 2.9
1.85 1.85
1.8 2.8
1.8 1.8
1.5 2.9
1.5 2.8
1.5 1.8
1.5 1.5
