Summary of Contents for Roksan Audio K3 DAC

  • Page 1 MANUAL K3 DAC...
  • Page 3 Congratulations on the purchase of your Roksan K3 DAC. Your audio component is designed and manufactured to the highest specifications and rigorously tested to offer many years of reliable and high quality musical enjoyment. Correct installation and operation of the product will have a significant influence on the performance of your audio sys-...

  • Page 4: Maintenance

    ROKSAN K3 DAC MANUAL UNPACKING Included in the packing of your K3 DAC product you will fi nd the following: • One mains lead fi tted with the correct mains power plug for your region • One Roksan R7 remote control After removing the product and the above items please retain ALL packing materials.

  • Page 5: General Cautions

    ROKSAN K3 DAC MANUAL Should you move to an area that has a different mains voltage or plug from that originally supplied, please contact your Roksan dealer for assistance. The mains fuses are located on the rear panel next to the IEC mains connector. They must only be replaced with a fuse of the type and rating as described on the fuse rating label on the rear panel.

  • Page 6: Installation

    ROKSAN K3 DAC MANUAL INSTALLATION K3 DAC – Front Panel View 1. AC Mains Power Switch 2. USB (B-type) input 3. IR receiver (for remote control) 4. USB input indicator (front input) 5. USB 2 input indicator (rear input) 6. Optical Toslink input indicator 7.
  • Page 7 20. AC Mains Fuse Holder SETUP Although it is an internally complex and sophisticated product, the K3 DAC has been designed to make it very easy for the customer to quickly connect and enjoy extremely high quality music reproduction. Following the instructions below will ensure fuss-free set-up.

  • Page 8: Connecting A Computer Via Usb

    Standard convention – Right Channel – Red; Left Channel – Black or White. DIGITAL INPUT: A variety of digital sources can be connected to the K3 DAC via a number of inputs (XLR, Coaxial, Optical & USB), depending on the availability of digital output connector type on the source.

  • Page 9: Windows Operating System

    To select as your current Playback Device: • Navigate to Control Panel > All Control Panel Items > Sound and select the Playback Tab • Select “ROKSAN K3 DAC USB Audio 2.0/1.0” (You can right-click and “Set as Default Device” if desired)

  • Page 10: Dsd Playback

    CD quality to the receiver in the DAC with a range of up to 150 metres*. The K3 DAC wireless function is only possible with Roksan’s K-LINK technology and a K-LINK transmitter.
  • Page 11 fi er and the transmitter to indicate pairing was successful. • Pairing has to be completed with ten seconds of the Wireless Input light of the K3 DAC blin- king twice per second, otherwise you will have to repeat the process from step 3.
  • Page 12 ROKSAN K3 DAC MANUAL K3 DAC WIRELESS LED STATUS • OFF - another input is selected • ON solid - paired and operational • ON, but blinks once per second - not paired • ON, blinking three times per second - entering pairing mode (pairing mode starts two seconds later) •...
  • Page 13 ROKSAN K3 DAC MANUAL WINDOWS OPERATING SYSTEM The driver can only be installed on PCs using Windows 7 onwards, and therefore the USB trans- mitter will not work on PCs with older versions of Windows. For the primary use on each computer: •...
  • Page 14 To pair the USB transmitter, the USB device has a recessed pairing button. The paring procedu- re is the same for the analogue transmitter. Please refer to the previous ‘Paring K-LINK Transmit- ters to the K3 DAC’ section for details. GUARANTEE There are no user serviceable parts inside your Roksan analogue product.

  • Page 15: Specifications

    ROKSAN K3 DAC MANUAL SPECIFICATIONS Digital Inputs • 1x XLR AES3/SPDIF balanced up to 192kHz resolution • 1x RCA/Coaxial SPDIF up to 192kHz resolution* • 1x TOSLINK optical up to 192kHz resolution* • 1x Front panel USB type ‘B’ connector for computer •...
  • Page 16 ROKSAN AUDIO LIMITED +44 (0)20 8900 6801 www.roksan.co.uk Jubliee Close Townsend Lane London, NW9 8TR United Kingdom All specifications are liable to change without notice. E&OE...
