INSTRUCTION MANUAL
Mi6 Mini Voice Recorder
SB-VR9000
Revised: July 8, 2013
Thank you for purchasing from SafetyBasement.com! We appreciate your business.
We made this simple manual to help you enjoy your new product as quickly and easily as
possible.
Be sure to check the TECH SUPPORT tab on your product page at SafetyBasement.com
for the latest available manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-VR9000 and is the answer not in the manual?

Questions and answers

Related Manuals for SB SB-VR9000

Summary of Contents for SB SB-VR9000

  • Page 1 INSTRUCTION MANUAL Mi6 Mini Voice Recorder SB-VR9000 Revised: July 8, 2013 Thank you for purchasing from SafetyBasement.com! We appreciate your business. We made this simple manual to help you enjoy your new product as quickly and easily as possible. Be sure to check the TECH SUPPORT tab on your product page at SafetyBasement.com...

  • Page 2: Product Reference

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 PRODUCT REFERENCE What’s Included with Your Mi6 Mi6 Recorder Wall Charger Audio Cable Phone Phone Ear Buds External USB Cable Line Adapter Microphone Page 2 www.SafetyBasement.com Phone: 877-345-2336 Fax: 888-236-2524...
  • Page 3 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 PRODUCT REFERENCE Microphone Status Light Display STOP / REC / PLAY Buttons Speaker USB Port (on bottom) Left Side External Hold SD Card Power Microphone Switch Slot Switch Port Right Side Volume + / -...

  • Page 4: Connecting To A Pc

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 CHARGING Before you use your Mi6 recorder, you should charge it for several hours. You can do this by connecting your Mi6 to your computer’s USB port, or use the included wall adapter.

  • Page 5: Power On And Off

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 QUICK START - RECORD Need to start recording immediately? Turn the Power Switch ON. In fact, leave the Power Switch ON all the time. You should only turn it OFF when you are not going to use your Mi6 for an extended period of time.
  • Page 6 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 SETTINGS Volume + / - Prev Next Buttons Erase “M” Button PLAY The Mi6 has a number of settings you can customize to your particular needs. You will use the buttons noted above to enter these settings, make changes and save your settings.
  • Page 7 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 MODES There are several MODES available to you with the Mi6. You can see the Modes by pressing the M button, between the Next and Prev buttons on the right side of the device.

  • Page 8: Set The Date And Time

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 SET THE DATE AND TIME You’ll first want to set the Date and Time for your Mi6. Remember, your Date and Time will RESET when you turn OFF the Main Power Switch. Button presses are shown in RED.
  • Page 9 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 FORMAT & QUALITY The settings most users may want to adjust next is related to the Format and Quality of your recordings. FORMATS available are: MP3 and PCM. MP3 is a compressed format, good quality using less space.
  • Page 10 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 OTHER DEVICE SETTINGS You’ve adjusted the settings most people use on the Mi6. Here are the rest of the device settings under MODE / SETTINGS. EQ: Equalizer settings during playback PLAY MODE: Do you want to Repeat Playback or Randomize? 1.
  • Page 11 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 OTHER DEVICE SETTINGS JUMP SETTINGS: Not used LANGUAGE: Set the Language for Menus 1. M to Mode Menu 2. NEXT/PREV to SETTINGS. PLAY. 4. NEXT/PREV to LANGUAGE. 5. PLAY 6. NEXT/PREV to highlight the Language you want.
  • Page 12 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 OTHER RECORD SETTINGS You’ve adjusted the settings most people use on the Mi6. Here are the rest of the settings under MODE / RECORD SETTINGS. We will address a few in depth.
  • Page 13 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 OTHER RECORD SETTINGS RECORD SENSITIVITY: Set the sensitivity level for Voice Activated recording. 1. M to Mode Menu 2. NEXT/PREV to RECORD SETTINGS. PLAY. 4. NEXT/PREV to RECORD SENSITIVITY. 5. PLAY 6. NEXT/PREV to highlight the sensitivity level you need.

  • Page 14: Timer Recording

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 TIMER RECORDING You can set the Mi6 to record a single event, or recurring event. First, set the length of the recording for the event. Then, set the timer. This is done in the RECORD SETTINGS mode.
  • Page 15 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 DISPLAY ICONS - PLAYBACK PLAY MODE SD / INTERNAL VOLUME BATTERY MEMORY LEVEL LEVEL Class FileName123456_ABCD.MP3 FILE NAME 0:05 001/001 3:23 CURRENT FILE TIME IN LENGTH FILE PROGRESS BAR PLAYBACK CURRENT FILE /...
  • Page 16 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 RECORDING - PHONE ADAPTER We covered how to record quickly earlier in the manual using the internal mic. Now we’re going to record with the Phone Adapter. You will need the Phone Adapter, the...
  • Page 17 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 RECORDING - PHONE ADAPTER You must now changed the RECORD SOURCE to use the Phone Adapter. Set the Source to Line-In. 1. M to Mode Menu 2. NEXT/PREV to RECORD SETTINGS. PLAY.
  • Page 18 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 PLAYBACK - “MUSICPLAY” MODE You playback your MP3 and music files Remember, you can change the EQ using the MUSICPLAY and MUSIC settings for playback! modes. To LOOP your playback, press the...

  • Page 19: Ebook Reader

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 PLAYBACK - “VOICE” MODE You playback your recorded files using DELETE A FILE during PLAYBACK or VOICE mode. from the LIST: VOICE - Plays the files you recorded 1. HOLD A/B. A Delete File menu will using the internal or external / line-in appear.
  • Page 20 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 WHERE ARE YOUR FILES? Use the included USB cable to connect your Mi6 to your PC. Be sure you are NOT recording before plugging in your cable. You do NOT need to turn off your Mi6 to connect to your PC.
  • Page 21 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 WHERE ARE YOUR FILES? This is our list of voice recordings. Note that we were recording in MP3 mode. recordings from the internal microphone are in this folder. Use standard Windows and Mac techniques to COPY, MOVE and DELETE your files.
  • Page 22 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 MORE MEMORY - SD CARDS Your Mi6 includes 4GB of internal memory. You can also add a Micro SD memory card, with up to 32GB additional space. That’s 8x the amount of space and time shown in the chart earlier in the manual.
  • Page 23 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 SUGGESTED SOFTWARE Your Windows PC or Mac has built-in software that will play most of the files created by devices like yours. However, if you are having problems playing your files, or need more options, please download and try these programs.

  • Page 24: Device Specifications

    PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 DEVICE SPECIFICATIONS Audio Formats PCM, MP3 Audio Encoding PCM: 1411, 1024, 256 Kbps MP3: 160, 128, 96 Kbps See chart for recording times. Page 24 www.SafetyBasement.com Phone: 877-345-2336 Fax: 888-236-2524...
  • Page 25 PRODUCT MANUAL Mi6 Mini Voice Recorder : SB-VR9000 DEVICE SPECIFICATIONS Memory Built In 4 GB Memory Expansion up to 32 GB Micro SD card Battery Type Internal Rechargeable Charger Type via USB port Please check our site for the latest available manual for this product.
