Page 2
Welcome Thank you for purchasing this product. For your cellular phone works properly, please follow the instructions in this manual. To prevent any possible incidents or malfunctions, please follow all safety warnings. Screen displays and illustrations in this user’s manual are designed to help you operate this phone to its optimum performance...
Important safety Precautions Failure to comply with the following precautions may be dangerous or illegal. Please carefully read and observe the terms below: Safe power on Do not use your mobile phone where it is forbidden to use or you might cause a disturbance or danger.
Page 6
Turn off when at a gasoline station Do not use your mobile phone at a filling station or around fuels or chemicals. Turn off around exposure Area Please observe related limitations and do not use your mobile phone near an area where explosions can occur.
Page 7
Waterproof Your mobile phone is not waterproof. Please keep it away from water. Backup Do remember to make a backup or keep a written record of all important information saved in your mobile phone Connect to other devices Please read the user manual of the device to get more detailed security instructions before connecting to other devices and do not connect to unmatched product.
Page 8
Introduction Packaging There are various accessories for your cellular phone. Your pack will include standard battery x 1, charger x 1, data cable x 1, and user manual x 1. Only use accessories and charging devices approved by the phone manufacturer, otherwise there is a risk of serious damage to health and property.
Page 9
Phone Display Key Headset Port Power Key Volume Key Back Key Menu Key USB Port Home Function Home Key Press to return to the Home screen from anywhere on your phone. Press and hold to bring up the recent ...
Function MENU Key Press to open a list of actions available in the current screen. Back Key Within a menu, press to return to the previous screen, or to dismiss a dialog box or menu. When the onscreen keyboard is open, ...
Icons & Symbols In idle mode, network and battery icons are displayed all the time. The rest of the icons appear if the feature is available. If the network symbol is not displayed, the network is currently unavailable. You may be in a bad reception area;...
Page 12
Receiving location Alarm is set data New text or multimedia Uploading data message Problem with text Phone is Downloading data connected via or multimedia An open Wi-Fi Missed call network is error Phone is Data is syncing connected via Problem with sign-in or sync Notifications When you see a notification in the status bar, touch the bar...
To close the Notification panel, touch and hold the bottom bar of the Notifications panel, then slide your finger up the screen. Getting Started Please read the safety instructions in the "Safety Information and Notices" section before use. In order to use your phone, you must insert a valid SIM card supplied by your operator or retailer.
Inserting the SIM Card Remove the back cover Make sure that the phone is turned off. You need to remove the back cover of your phone before you can insert the SIM card. Lift the back cover up to remove it (1). Insert the SIM card Make sure that the clipped corner of the SIM card is facing the correct direction and the metallic contacts are facing...
downwards. Slide the SIM card into the card slot until it stops (2).Please note that you can only use Micro Sim card for the SIM 2 card ‘s slot. Install the back cover Align and hook the back cover to the top of the battery slot and then press the back cover down until it locks into place (5).
Power on/off To power on the phone, press and hold the Power Key. Enter the PIN code if required (the 4 to 8 digit secret code of your SIM card). It is preconfigured and provided to you by your network operator or retailer. If you enter an incorrect PIN code 3 times in succession, your SIM card will be locked.
Charging the Battery Your phone is powered by a rechargeable battery. The new battery is partially charged. A sound alert will warn you when the battery level becomes low. To charge the battery, plug in the connector at the bottom of your phone (USB interface), and then plug the other end into an AC power socket.
Page 18
2. If you want to get the T-Flash card out, gently pull the SD card, then you can remove it from your phone. Note if you are going to remove your SD card, first you must remove it from your phone by selecting HOME, then tap the application tab to select Settings >...
Transfer files to the SD card To transfer music, picture, and other files from your computer to your phone’s SD card, you need to set the phone’s SD card into a USB drive Connect the phone to the computer using a USB cable. A notification icon appears in the status bar.
Touch screen Your mobile phone features a touch screen which provides a faster and more intuitive way for you to navigate through lists and menus. The controls on the touch screen change dynamically depending on the task you are performing Selection To select an item or button on the screen, touch the item with your fingertip.
Page 21
your finger to scroll will not choose or activate anything on the screen. Zoom in or out Zoom in / out on a picture when viewed in full screen, web page, or map: You can zoom in and out by placing two fingers on the screen at once and pinching them together (to room out) or spreading them apart (to zoom in) Pattern lock...
not select individual dots. Connect at least four dots. If you unlock your screen, and you want your pattern to be hidden as you draw it, clear the Make pattern visible check box. Screen sleep After a period of inactivity, your screen will go to sleep (display will turn black).
select a time. Pressing the Power Key can also make your phone sleep or awake immediately. Home Screen The Home screen is your starting point for using all the applications on your phone. You can customize your Home screen to display applications, shortcuts, and widgets as you like.
Add a Home screen item To create an application shortcut quickly, touch the application tab to reveal all the application icons, then touch & hold an application or widget icon and drag it to the home screen. Its shortcut is added to the Home screen.
Remove items from the Home screen To remove a shortcut or widget from your Home screen, touch and hold the item to enter “Remove mode”. The application tab turns into a Remove button. Drag the item to the Remove button. When the icon and application tab turn red, release it.
Manage Apps: Select to manage Apps. System Settings: Shortcut to the settings menu. Please refer to “Settings” section. Keyboard When you select or touch a field that requires text or numbers, the onscreen keyboard becomes available. Adjusting keyboard settings Before you start using the onscreen keyboard, we recommend you set the onscreen keyboard options such as vibrate and/or emit a sound when you touch a key,...
Page 27
Android Onscreen Keyboard Touch to open onscreen keyboard Touch to enter letters Touch to enter Touch to an upper case delete the Touch to switch previous to the numeric characters and symbol keyboard Note When you do not need the keyboard, you can close it by pressing BACK.
Smart Onscreen Keyboard Smart Onscreen keypad is an intelligent text editing mode for typing, which includes a comprehensive dictionary. It allows you to quickly enter text. When you enter the first or second letter, the word suggested may be displayed on the screen.
increase or decrease the volume. Speaker During a call, select Speaker on. Making an International Call Touch and hold the 0 key on the Dialer tab to enter "+". Enter the country code. Enter the area code (normally without the 0 before it), followed by the phone number.
During a call with the first caller, select Add call and then enter the second caller’s number using the keypad. Press the Call icon to dial the second party’s number. The first caller will be automatically placed on hold. This is a network-dependent feature. Please contact your service provider for more details.
conference call is established. During the multi-party call, you can answer a new incoming call or add a new member to the call by selecting Add call to dial the new member (the ongoing multi-party call should be put on hold first). Once the call is established, select Merge calls from menu options.
Answering a Second Call If you have activated Call Waiting, a new incoming call screen is shown to inform you when there is a second incoming call. You can: Drag the green phone icon to the right. The current call will be put on hold automatically.
Note the phone can connect to a Bluetooth hands-free headset or a Bluetooth car kit and use those devices to send and/or receive calls. Before you can use a Bluetooth hands-free headset or car kit, follow the steps as below. Turn on Bluetooth services Press HOME and tap the application tab.
To make your phone discoverable: Make sure you have turned Bluetooth on. Refer to the above chapter for details. Press HOME, and tap the application tab. Then select Settings > Wireless & Networks open Bluetooth . Select the Visibility timeout to set your phone visible time to other Bluetooth devices .
Touch a particular device in the list to pair with it. Once paired, you can select the file to send via Bluetooth. Rescan for Bluetooth devices If you want to update the list of Bluetooth devices, press Search For Devices. Function Menu How to Use Select application...
Clock Your mobile phone has a built-in alarm clock. You can separate alarms and choose whether or not the alarm should repeat. How to set an alarm To set an alarm: To open Alarm Clock, press HOME to return to the home screen, tap the application tab to enter the main menu, select “Clock”, and then touch the alarm icon...
Label: Touch it to set a name for the alarm. Finally, press Back Key to save the settings. In the alarm, verify that you’ve activated either Saturday or Sunday on the Repeat area. If they are set off, your alarm does not notify you on Saturday or Sunday.
Page 38
Note Browser automatically opens when you touch a web link in an email or text message. It may involve the transmission of large amounts of data through your service provider’s network. Contact your service provider for information about data transmission charges.
Set your home page You can set your home page from the settings screen: Press MENU and select Settings >general> Set Home Page to open the dialog box. You can select Current Page,Blank Page,Default page ,Most visited sites or Site Navigation to set as your home page .you can also select Other , Type the URL of the page you want to set as the homepage, and then touch OK.
and want to view them on the screen, please use the Windows function. while in the web page browsing , touch the in the bottom of the window . You will now see all web pages that you’ve opened. To add new windows, click “+”. To close the window, touch the “X”...
Page 41
Position your finger at the start of the text you want to copy and then drag to the end of the text you want to copy. Release your finger from the screen,touch icon in the right corner of the window and then select copy to copy the text.
To delete a bookmark in the bookmark screen, touch & hold the bookmark that you want to edit. The context menu will open, and select Delete Bookmark. Refresh the web page Press MENU in web page browsing and then choose Refresh.
Page 43
problem with a site’s security. Accept Cookies: Touch to set it on or off. If on, your phone will allow sites to save and read “cookie” data. Clear All Cookie Data: Touch to clear all “cookie” data. Remember From Data: Touch to set it on or off. If on, ...
Page 44
Force enable zoom:Override a website's request to control zoom behavior Text Size: Touch to define the text size, Tiny, Small, Normal, Large or Huge. Invert Screen rendering : Touch to activate/deactivate display pages in an inverted color. Advanced settings Set search engine: Touch to select a search engine ...
Page 45
Auto-Fit Pages: Check to have Browser optimize the presentation text and other elements of the webpage to fit your phone’s screen. Uncheck to view pages as designed for a computer screen. Block Pop-Ups: check to prevent websites from opening windows unless you request it.
Download web files and applications Before you download any files or applications using the browser, note the following: Before you can download Web applications, you must go to Settings > Security> Unknown sources, select the check box. All items downloaded from the Web are stored on your SD card or your phone, The browser will only allow you to download items that are supported by an application installed on the phone.
take pictures, as small dust particles can strongly affect the picture and video quality. To access this menu, press Home Key, , touch the application tab , and select Camera. Do not take photos of people without their permission. Do not take photos in a place where cameras are not allowed.
Touch to take a picture or Touch to shoot a video toggle between Touch to camera, change video and Settings panoramic view Recording a video In camera mode, press to Switch to video. You can change the capture video quality by touching...
Page 49
the related icons on the top of the screen. Touch to starting recording the video. Touch to stop recording. View your photos and videos To view the pictures and videos you have captured, as well as any you have stored on your SD card, please go to Gallery menu to view the details.
Turn On/Off FM radio In the FM radio menu, touch the icon to turn on FM. When the icon turns to , it indicates that the FM radio is switched on Auto search Your phone supports to auto scan the radio stations and the stations searched will be memorized in the channel list.
This menu gives you quick and easy access to the people you want to search. You can view and create contacts on your phone, and can also import contacts stored on your SIM card. To access this menu, press HOME, and touch the application tab, and then select Contacts.
your finger up or down to see more labels. Note To change a defaulted information label, ie; Home number to Work number, touch the information label button, then select another label on the menu. Touch a category of contact information, such as phone numbers and email addresses, to enter that kind of information about your contact.
Page 53
SMS or MMS to a contact. To open a contact’s details screen, simply touch their name from contacts. To dial a number of the contact, touch the contact’s name, then touch it again to dial. To call phone numbers, you switch automatically to the phone application as the number is called.
Favorites In the home screen, press the people icon . Tapping the Favorites icon can access your Favorite Contacts. How to set a favorite contact? Open your contacts. Touch a contact to view its details. Beside the Name field icon indicates contact favorites or not.
Page 55
Using call log options In the call log list, you can press the call log to access the following options: Call back: Touch to call the selected number. Send text message: Touch to send an SMS message to the selected contact.
Bluetooth headset or hands-free car kit. Before you can use your Bluetooth device, follow the following steps: Go to HOME, touch the application tab, and select Settings > Wireless & Networks to turn Bluetooth on. Get your headset or hands-free car device ready for pairing by following the manufacturer’s instruction.
Page 57
Touch to open camera In any view,touch to return to Main Gallery An Album of the Photos taken with the Built-in Camera Slide Left or Right to view more albums Select an album to view the pictures. Touch an album to open it and view its contents. The pictures and videos in the album are displayed in chronological order.
Image options You can do the following while in pictures. Share Touch Share icon at the top of the screen. In the menu that opens, touch the application to share the selected albums. The application that you select opens with the pictures from the selected albums or links attached to a new message.
Crop Select to crop the selected picture. Touch and hold an edge of the cropper to reveal the sizing arrows and then drag the edge in or out to size. Touch and drag the center of the cropper to move it within the picture. When you want to save the cropped area, select Save.
Page 60
Email Your mobile phone supports Email. Before using Email, you need to configure Email accounts. To Set up Email Press Home Key, touch the Application tab, and then touch Email. You can configure your Email account in just a few steps.
Page 61
Add recipients by typing an address in the To field. If you want to send the email to several recipients, separate the email addresses with a comma. Add as many as you wish. If you want to send a copy (Cc) or a blind copy (Bcc) of the email to other recipients, press Menu Key and then touch Add Cc/Bcc.
You can enter your signature in the text box, and then touch OK. To view your sent messages In the Inbox, press and then touch Sent. Read Email When you open a conversation for reading, the subject will appear in a box at the top of the screen. Here are some actions you can take on individual messages and conversation: Open an unread email...
as appropriate. Reply to or forward emails When you’re reading the email, you can either reply, reply to all, or forward the email. To reply to the email, press the Reply button To reply all, press Menu key to open the context menu and then select replay all.
Page 64
Signature: Touch to enter a signature that will appear at the end of your emails. Quick response: edit text that you frequently insert when composing emails. Inbox Check Frequency: When your phone is connected to network, you can set the Email check frequency here. The frequency can be set as Every 5/10/15/30/60 minutes.
General settings Auto-advance: Choose which screen to show after you delete a message. Message text size: this feature allows you to set the email text size. Reply all: touch to make"Replay all" the default for message replies. Ask to show pictures: After activating this function,...
slide it down to open the notifications panel. Touch the new message to open and read it. On the message list, touch the message you want to read. Note If a link is included in a message, touch the link to open Browser and view the web page.
You can press Menu Key and select Add Subject or touch to add An Attachment to convert it to a multimedia message. Touch Send when ready. View message details To view details about a particular message, touch and hold the message to open the option menu in the Read view. Touch View detail.
Text message With an SMS-compatible phone number, you can send and receive short message service (SMS) messages. An SMS-compatible number is a phone number that your service provider enables for SMS. You can send SMS messages to contacts that have SMS-compatible phone numbers.
Page 69
In the Type name or number field, you can enter the receiver’s number or email address by using the onscreen keyboard. In the Type text message field, you should enter the MMS content. To add a subject, press Menu key and touch Add Subject.
Note: If you want add more attachments, you should add a Slide Show first. Contact: List all the contacts stored in SD card ,tap to add contacts. In a new slide show, you can also press the Menu Key to access the following options: Preview: Touch to preview the slide;...
messaging services. How to access message settings? Press Home Key, touch the application tab and touch Messaging; Press Menu key to access the option menu and touch Settings to configure your message settings ,such as SMS,MMS,Notification and general. Music This menu allows you to listens to your favorite music. To open your music library, press Home key and touch the application tab, and then touch Play Music.
and mount the micro SD card. To organize your audio files, you can use the computer to create a music folder at the top level of the micro SD card. Use the computer to copy music and other audio files into the folder that you created on the micro SD card If you have created any playlists, create a subfolder for them in your music folder on the micro SD card and...
Your phone’s micro SD card is mounted as a drive on your computer. You can now copy files to and from the micro SD card. For more information, see the documenta- tion for your computer. During this time, you can’t access the micro SD card from your phone, so you can’t use applications that rely on the micro SD card, such as Camera, Gallery, and Music.
The following actions are available on the playback screen: Shuffle songs: Shuffle songs in random order. Touch to toggle shuffle on or off. When the icon is grey, shuffle is off. Go to any point in song: Slide fingertip in progress bar ...
playlist. Touch and hold the artist, album, or song to open the context menu. Touch Add to playlist. In the Add to playlist menu that opens, select New playlists to create a new playlist, or one of the existing playlists. Enter the name for your new playlist and then touch Save.
Page 76
Data roaming: Uncheck to prevent your phone from transmitting data on other carriers’ mobile networks when you leave an area where your phone can access your own carrier’s mobile networks. Airplane mode: When airplane mode is selected, all wireless connectivity is off.
Page 77
devices. Date usage: this feature allows you to count data usage and set mobile data limit. Tethering & portable hotspot In this menu, you can share your phone’s mobile data connection via USB or as a portable Wi-Fi hotspot. VPN settings ...
Audio profiles our phone provides 4 different profiles, including General, Meeting, Outdoor,and Silent profile. To add a new APN. Consult your carrier about how to use the tools on this screen. You can configure how your phone rings,vibrates,or alerts you in other ways when you receive communications and motion sound , ect.
Security You can configure settings that help secure your phone and its data. APPs This menu allows you to manage applications. Accounts Use the Accounts & Sync settings to add, remove, and manage your Google and other supported accounts. You also use these settings to control how and whether all applications send, receive, and sync data on their own schedules, and whether all applications can synchronize...
for the text on your phone and for configuring the onscreen keyboard, including words that you’ve added to its dictionary. Backup&reset This feature let you backup app data,wifi passwords,and other settings to google servers. And reset your phone . Battery Your phone supports Battery feature.
Use 24-hour format: Select to set 24-hour formats on or off. Choose Date format: Select from a variety of formats. Developer options If you're an application developer, you may be more concerned about this part of the set. Scheduled power on &off You can set your phone to automatically Power On or to Power Off up to scheduled times.
Sound recorder The sound recorder is a simple recording tool that provides all of the required functionalities for you to manage voice files. To start recording In any mode, press Home Key, touch the application tab and then touch Sound Recorder. Touch button to start recording.
Before upgrade please make sure device battery level is more than 30%. Note To ensure adequate battery upgrade process, it is recommended to connect via USB cable during the upgrade process. Troubleshooting Common issue Cause reason Shooting way Bad connection Using mobile phone in an Try to avoid.
Page 84
Common issue Cause reason Shooting way Related to the distance of Ask your operator the send basis of the to provide a map network. of your service area. Aftersound or It is caused by network Hang up and cacophony connection and it’s a redial the regional problem.
Page 85
Common issue Cause reason Shooting way When you cannot receive Please move to signals, your mobile an area where phone will continue to signal is strong send to find a basis. A lot or temporarily of battery power is used, turn off your so as to limit idle time.
Page 86
Common issue Cause reason Shooting way Feeble signal. Please move to an area where signal is stronger and try again. Cannot call Activate call barring Cancel call barring Activate fix dialing Cancel fix dialing Wrong PIN Enter the wrong PIN code Contact your code three times.
Common issue Cause reason Shooting way Cannot add Contacts memory is full. Delete some contact contacts. Cannot set Operator does not support Contact your some functions the function or you have operator. not applied the function. Safety Information and Notices Using the Mobile Phone and Charger Danger: Only use authorized battery and charger.
Warning: Do not bump, shake or tamper with the phone or charger. This may cause battery leakage, overheating, explosion or even fire. Do not place the battery, phone or charger near a microwave or high-voltage device. This may cause battery leakage, overheating, explosion or even fire;...
Page 89
Do not use the phone near electronic medical devices such as hearing aids, pacemakers and auto-control devices such as fire detectors and automatic doors. If you have to use your mobile phone near an electronic medical device such as a pacemaker, please contact your manufacturer or dealer for information about preventing interference.
can damage the mobile phone or the battery. Using the Battery Danger: Do not dispose of the battery into a fire. Doing so may cause battery explosion or even fire. If you have difficulties installing the battery, do not force the installation.
changed shape or color. If battery liquid leaks onto your skin or clothes, immediately wash the affected parts with water. If the battery begins to leak or emits a strange odor, properly dispose of the battery according to local regulations. Do not throw it into a fire. Caution: Do not leave the product or its battery inside a vehicle.
If liquid does spill onto the charger, immediately unplug the power cable to prevent overheating, fire or another type of breakdown. Do not use the charger in places with high humidity like a bathroom. This may cause a fire or other breakdown. Do not touch the charger, power cable or socket with wet hands.
Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Requirements for the Charger and AC Adapter Please confirm if the environment temperature is within the range of 0ºC ~40ºC while charging. Cleaning and Maintenance The mobile phone, the battery and the charger are not waterproof.
Specific Absorption Rate (SAR) information Your phone has been designed to comply with applicable safety requirements for exposure to radio waves. These requirements are based on scientific organizations through periodic and thorough evaluation of scientific studies. These guidelines include safety margins designed to assure the safety of all persons, regardless of age and health.
Page 95
Band Position SAR 10g(W/kg) GSM900 Head 0.62 GSM1800 Head 0.66 SAR data information for residents in countries/ regions that have adopted the SAR limit recommended by the Institute of Electrical and Electronics Engineers (IEEE), which is 1.6 W/kg averaged over one (1) gram of tissue.
Battery Informations Type Capacity Li-ion 2000 mAh • The battery life depends on many factors, including the SIM card, network conditions, settings, usage and enviorenment. • Making calls, turning on the backlight and music player will consume more battery power. •...
Battery, headset, USB data connector are in- warranty of 6 months after the date of purchase. This warranty shall apply to mobile phone and accessory under “i-mobile” brands that are purchased from Shop namely, I-mobile by Samart and Authorized Distributor or Authorized Service Center as appointed in Thailand only.
Page 99
Mobile phone and accessory are damaged due to the natural disaster. Mobile phone and accessory are repaired, changed parts, adjusted, modified, connected, customized without any authorization by i-mobile. Using of mobile phone and accessory together with, or connect with the mobile phone or accessory that...
Page 100
Damaging of the label, warranty sticker on the mobile will be deemed as termination of the warranty. i-Mobile will not assure provided that the software from i-mobile will be up to your wishes or the working process...
Page 102
Customer has already purchased. The warranty will not cover the damage that occurs from the use of any device under “i-mobile brand” with other products which are not the product of i-mobile. The warranty will not cover any expenses in the...
