Black Box LGC5150A-2A Quick Start Manual

LGC5150A-2A Quick Start Guide

Troubleshooting

• Check Type of Cable Used
A CAT5 or higher Ethernet cable is required for the
RJ-45 port. Make sure pins are not pulled out of the
connector's casing, which will cause damage to the
media converter's copper port.
• Check Fiber Type and Speed
Make sure fiber types match on both sides of the fiber
connection. Confirm that each end of the installation
is capable of supporting the desired speed.
• Using LFPT
When troublshooting media converters, first disable
any diagnosic features, such as LFPT. Disable the LFPT
front DIP switch.
To download the full user manual:
1. Go to www.blackbox.com
2. E nter the part number (LGC5150A, LGC5151A, or
LGC5152A) in the search box:
3. Click on the "Resources" tab on the product page,
and select the document you wish to download.
If you have any trouble accessing the Black Box site
to download the manual, you can contact our
Technical Support at 724-746-5500 or
info@blackbox.com.
724-746-5500 | blackbox.com
Black Box Tech
Support: FREE! Live.
24/7. Tech support
the way it should be.
Great tech support is just 60 seconds
away at 724-746-5500 or blackbox.com.
These SFPs work with the LGC5150A:
Product Description
Code
LFP401
SFP, 155-Mbps Fiber 850-nm MM, LC, 2 km
LFP402 SFP, 155-Mbps Fiber 1310-nm MM, LC, 2 km
LFP403 SFP, 155-Mbps Fiber 1310-nm, SM, LC, 30 km
LFP411
SFP, 1.25-Gbps Fiber 850-nm MM, LC, 300 m
LFP412 SFP, 1.25-Gbps Fiber, 1310-nm MM, LC, 2 km
LFP413 SFP, 1.25-Gbps Fiber 1310-nm SM, LC, 10 km
LFP414 SFP, 1.25-Gbps Fiber 310-nm SM, LC, 30 km
