User Guide (English)
Introduction
Load virtually any sample via standard SD card* and assign it to any of the MPX8's eight backlit
velocity- and pressure-sensitive pads. It's that simple. Use it in the studio. Use it live on stage
or on air. MPX8 packs proven Akai Pro technology into a compact, durable design that's built to
perform.
Box Contents
•
MPX8
•
MPX8 Sample Kit Editor (download)
•
Loop Library (download)
•
USB Cable
Support
For complete system requirements, compatibility information, and product registration, visit the
Akai website: www.akaipro.com.
For additional product support, visit www.akaipro.com/support.
Quick Start / Connection Diagram
Headphones
✝
Monitors
✝
•
USB Power Adapter
•
1/8"-to-MIDI Adapters (2)
•
User Guide
•
Safety & Warranty Manual
✝
SD card
USB cable to USB
power adapter
or
USB cable to
computer
2
* SD card sold separately.
✝
Sold separately.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Akai MPX8
Summary of Contents for Akai MPX8
- Page 1 User Guide (English) Introduction Load virtually any sample via standard SD card* and assign it to any of the MPX8’s eight backlit velocity- and pressure-sensitive pads. It’s that simple. Use it in the studio. Use it live on stage or on air. MPX8 packs proven Akai Pro technology into a compact, durable design that’s built to perform.
- Page 2 (downloadable for free from www.akaipro.com/mpx8) to load samples onto an SD card. If you choose to load samples to an SD card without using the MPX8 Editor, please see the Using Your Own Samples section of this manual to make sure they are formatted properly.
-
Page 3: Operation
SD card (sold separately). Message: Displays information about MPX8's current state. This will show an error message if MPX8 cannot execute a command. Sample Name: Displays the name of the selected sample from MPX8's internal sample library or an inserted SD card (sold separately). -
Page 4: Editing Kits
Up to 512 files can be stored in the root directory of the card. • You can assign up to 30 MB's worth of samples onto MPX8's pads at a time (the sample library on your SD card can be larger, of course). Also, please note that a sample's size will be rounded up when loaded (e.g., a 2.1 MB sample on the SD... -
Page 5: Saving Kits
Kit. Press the Volume + button (Yes) to save the kit or the Volume – button (No) to cancel. MPX8 will save the Kit to the next available User Kit number (e.g., if you have 12 User Kits already... -
Page 6: Restoring Default Settings
(e.g., a 2.1 MB sample on the SD card will be treated as a 3 MB sample when it is assigned to a pad). Restoring Default Settings To restore MPX8's default settings, which will reset all Internal Kits to their defaults, press and hold both Volume +/– buttons while switching MPX8's power on. -
Page 7: Midi Implementation Chart
Appendix (English) MIDI Implementation Chart Manufacturer: Akai Professional Model: MPX8 Version: 1.0 Transmit/Export Recognize/Import Remarks 1. Basic Information MIDI channels Responds to notes Note numbers 0-127 0-127 assigned to pads Program change Bank Select response? (Yes/No) If yes, list banks utilized in remarks column... - Page 8 Internal Kits Pad 5: 808 HH C Pad 6: 808 HH O Pad 7: 808 Tom Pad 8: Crash Kit 1 • • Tune: 0 • Tune: 2 • Tune: 0 Tune: 0 • • Rev: 2 • Rev: 4 •...
- Page 9 Pad 5: Bass1 C2 Pad 6: SynthStb Pad 7: ABass C2 Pad 8: SynthStb Kit 5 • • Tune: 0 • Tune: 2 • Tune: 3 Tune: -1 • • Rev: 2 • Rev: 4 • Rev: 3 Rev: 2 •...
-
Page 10: Technical Specifications
Technical Specifications Pads 8 pads (velocity-sensitive and pressure-sensitive) Kits 8 Internal Kits 99 User Kits possible (on optional SD card, sold separately) Internal Sounds 16-bit mono WAV with a sample rate of 48, 44.1, 32, 22.05, or Supported File Format 11.205 KHz SD or SDHC up to 32 GB capacity (FAT16 or FAT32 file format) Supported SD Cards...
