OSM Menus E - 13
The current color settings on your monitor were determined by focus
groups and end users' panels to be the most popular settings for the
majority of applications. NEC's Color Control system allows you to
change your on-screen colours by adjusting the monitor's red, green and
blue color guns individually. You can adjust colours to suit your individual
needs or preferences. You can also access five industry standard color
temperature settings.

Geometry Controls

The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
IN/OUT (pincushion): increases or decreases the curvature of the sides
either inward or outward.
LEFT/RIGHT (pincushion balance): increases or decreases the
curvature of the sides either to the left or right.
TILT (parallelogram): increases or decreases the tilt of the sides either to
the left or right.
ALIGN (trapezoidal): increases or decreases the bottom of the screen to
be the same as the top.
ROTATE (raster rotation): rotates the entire display clockwise or
counter clockwise.
Note on Controls in the Geometry Controls Menu:
EXIT: exits to the main menu.
Cursor / : moves the highlighted area up/down to select one of the choices.
Cursor +/-: moves the bar in the + or - direction to increase or decrease
the adjustment.
RESET: resets the current highlighted control to the factory setting.
Tools 1
Provides a list of optional adjustments which include the following:
MOIRE CANCELER: Moiré can be visible if large areas of dithered
colour are displayed (overall colour made from alternating pixels of
different colours). The Moiré Canceller allows you to minimize this
phenomenon, using the +/- CONTROL buttons. Select horizontal or vertical.
