  • Page 3 Recommended Tools Modelling / Craft knife Hex drivers/(2.5mm、2mm、1.5mm) Side cutters Styrene Glue Thread Lock Cross Wrench Cross head screwdriver (small) Long Nose Pliers Tips for Assembly It is recommended that that body parts are painted with Acrylic Lacquer, or Enamel. Test fit parts before applying glue and use glue sparingly.
  • Page 4 RC4WD will, at our discretion, replace the product, provided our inspection indicates that an original defect exists. RC4WD reserves the right to replace any product which is no longer available with a product of comparable value and function. If RC4WD determines the repair is not covered under warranty guidelines, we will contact you to discuss your options.
  • Page 5 6x6 Body Z-B0099-2/(H2) Z-B0099-3/(55mm) Z-B0099-5 Z-B0099-1 Z-B0099-4 6x6 Body Z-B0105-2 Z-B0105-3 Z-B0105-4 Z-B0105-1 Z-B0105-7 Z-B0105-5 Z-B0105-6...
  • Page 6 6x6 Body Z-B0101-2 Z-B0101-1 Z-B0101-3/(H12) 6x6 Body Z-B0103-3 Z-B0103-1 Z-B0103-4 Z-B0103-6 Z-B0103-5 Z-B0103-2...
  • Page 7 6x6 Body Z-B0095-1 Z-B0095-3 Z-B0095-2 6x6 Body Z-B0097-6 Z-B0097-3/(H15) Z-B0097-1 Z-B0097-4/(H10) Z-B0097-7 Z-B0097-2 Z-B0097-5...
  • Page 8 6x6 Body Z-B0091-8 Z-B0091-2 Z-B0091-1 Z-B0091-3 Z-B0091-4/(H7) Z-B0091-5/(31mm) Z-B0091-7 Z-B0091-6 6x6 Body Z-B0089-1 Z-B0089-3/(H8) Z-B0089-5/(65mm) Z-B0089-2/(H3) Z-B0089-4/(X5) Z-B0089-6...
  • Page 9 6x6 Body Z-B0087-1/(H9) Z-B0087-2/(H1) Z-B0087-4/(X2) Z-B0087-3/(X4) Z-B0087-7 Z-B0087-8 Z-B0087-9 Z-B0087-5/(X3) Z-B0087-6/(X1) (H5) (H6) (H4) 6x6 Body Z-B0093-2/(H13) Z-B0093-3/(H11) Z-B0093-4 Z-B0093-1/(H14) Z-B0093-5/(131mm) Z-B0093-6/(16mm) Z-B0093-7...
  • Page 10 viii 6x6 Body Z-B0085-1/(110mm) Z-B0085-2 Z-B0085-3 Z-B0085-4/(187mm) Z-B0085-5 Z-B0085-9 Z-B0085-10 Z-B0085-7 Z-B0085-8 Z-B0085-6 6x6 Body Z-B0107-1 Z-B0107-2 Z-B0107-3 6x6 Body Z-S1531-1 Z-S1531-2...
  • Page 11 6x6 Body Z-S1519-1 Z-S1519-2 Z-S1519-3 Z-S1519-5 Z-S1519-4 6x6 Body Z-S1523-1 Z-S1523-2 Z-S1523-5 Z-S1523-4 Z-S1523-3 6x6 Body Z-S1525-1 Z-S1525-2 Z-S1525-3 Z-S1525-4 6x6 Body Z-S1521-6 Z-S1521-7 Z-S1521-8/(423mm)
  • Page 12 6x6 Body Z-S1521-1 Z-S1521-2 Z-S1521-3 Z-S1521-4 Z-S1521-5 6x6 Body Z-S1527-1 Z-S1527-2...
  • Page 13 6x6 Body Z-S1529-1 Z-S1529-3 Z-S1529-2 Z-S1529-4 Tire Z-T0075 Z-W0119-1 Z-W0119-2 Z-W0119-3 Accessories Z-S0277 Z-B0017 Z-S0430 Z-S1546-6 Z-S0599 Z-C0050-1 Z-S0238 Z-S0075...
  • Page 14 Girde Z-C0046-1 Z-C0046-2 The Frame Z-S1534 Z-C0046-6 Z-S1542 Z-S1536 Z-C0050-2 Z-C0046-5 Z-C0046-7 Z-C0050-3 Z-C0046-3 Z-S1532...
  • Page 15 xiii The Frame Z-S1528-1 Z-S1530 Z-C0048 Z-S1538 Z-S1540-1 Z-S1546-5 Z-C0046-4 Z-S1546-1 Z-S1528-2 Z-S1546-3 Z-S1546-2 Z-S1546-4 Connecting Rod Z-S0807/(59mm) Z-S0399 Z-S1084/(52mm) Z-S0884/(50mm) Z-S0402...
  • Page 16 Connecting Rod Z-S1550/(71.5mm) Z-S0401 Z-S1552/(41mm) Z-S0398 Z-S0819/(70mm) Z-S0810/(104.5mm) Axle Z-S1540-3 Z-A0080 Z-S1540-4 Z-A0010 Z-S0795-2 Z-A0081 Z-S1544-1 Z-S0795-1 Z-S1540-2 Z-S1544-2 Shock Z-D0039...
  • Page 17 All of the hardware should be taken from Hardware Bag A/B/C/D. Z-S0916 M2.5X8 button head Z-S1516 M2X4 flat head Z-S0745 M3X4 button head Z-S1518 M2X6 flat head Z-S0960 M3X6 button head Z-S0648 M3X6 flat head Z-S0652 M3X8 button head Z-S0649 M3X8 flat head Z-S0653 M3X10 button head...
  • Page 18 Note : Attention to distinguish between adhesive and screw assembly. Assembly 1 Z-B0103-6 ① Z-B0103-1 Z-B0099-1 ② Z-B0089-3 Assembly 2 Z-S1531-1 Z-B0105-1...
  • Page 19 Assembly 3 Z-B0091-1 Z-B0105-1 Assembly 4 Z-B0105-1...
  • Page 20 Assembly 5 Z-B0101-2 Z-B0099-5 Z-B0105-4 Z-B0105-5 Assembly 6 Z-B0087-1 Z-B0091-4...
  • Page 21 Assembly 7 Z-S1529-4 Z-S0629 Z-S0653 Z-S0629 Z-S1529-1 Z-B0087-8 M3 nut Z-S1529-4 M3X7.2 Bushing Z-S0653 M3X10 button head “Z-S1529-4”&“Z-S1529-1” can be found in Bag 17. Assembly 8 “Z-S1529-2” can be found in Bag 17. Z-S0654 Z-S0629 Z-S1524 M3 nut Z-S0745 Z-S0629 Z-S1524 M3.1 X 3 Spacer Z-S0745...
  • Page 22 Assembly 9 Z-B0089-2 Z-B0099-2 Z-B0089-2 Assembly 10 Z-B0087-9 Z-B0087-7 Z-B0087-2...
  • Page 23 Assembly 11 Z-B0093-2 Z-B0101-3 Assembly 12 Z-B0093-1...
  • Page 24 Assembly 13 Z-B0097-3 Z-B0093-3 ① ② Z-B0097-4 Assembly 14 Z-B0085-7 Z-B0085-10 Assembling as shown 3 times.
  • Page 25 Assembly 15 Z-B0101-1 Assembly 16 Z-B0097-2 Z-B0099-4 Note: “Z-B0099-4” Does not need glue. Z-B0095-2...
  • Page 26 Assembly 17 “Z-S1519-2”&“Z-S1519-3” can be found in Bag 14. ② ① Z-S1522 Z-B0085-9 Z-B0085-6 Z-B0095-3 Z-S1522 M2.5X2 set screw Z-S1519-3 ③ Z-S1519-2 Assembly 18 Z-B0105-6 Z-S1519-1 “Z-S1519-1” can be found in Bag 14.
  • Page 27 Assembly 19 Z-S1519-5 “Z-S1519-5” can be found in Bag 14. Z-S1519-5 Assembly 20 Z-S1519-4 “Z-S1519-4” can be found in Bag 14. Z-S1519-4...
  • Page 28 Assembly 21 Assembly 22 Z-B0103-3 Z-B0103-2...
  • Page 29 Assembly 23 Z-B0105-2 Z-B0105-7 Z-B0105-3 Z-B0103-4 Z-B0103-5 Z-S1529-3 Z-S1518 Z-S1529-3 Z-S1518 Z-B0097-5 M2X6 flat head Z-S1518 “Z-S1529-3”can be found in Bag 17. Assembly 24...
  • Page 30 Assembly 25 Z-B0091-2 Z-B0097-6 Z-S1531-2 Z-S1531-2 Z-B0091-7 Z-B0107-1 Z-B0107-2 Z-B0091-2 Z-B0091-3 Assembly 26 Z-S1525-2 Z-B0097-7 Z-S1525-2 Z-S1520 Z-B0097-7 Note: Stick mirror(Z-S1525-4) Z-S1520 “Z-S1525-2” can be found in Bag 14. on after assembling. M1.4X3 flat head...
  • Page 31 Assembly 27 Note: Shown right side rear view mirror assembly. Repeat this for the left side. Z-B0091-6 Z-S1525-1 Z-B0091-6 Z-B0093-4 Z-S1525-1 Z-B0093-4 Z-S0927 Note: Stick mirror(Z-S1525-3) Z-S0927 on after assembling. M2X4 cap head Assembly 28...
  • Page 32 Assembly 29 Z-W0119-1 Z-W0119-2 Z-T0075 Z-W0119-3 Z-S1533 Z-S1533 M1.6X12 screw Note: Assemble six tires. Z-S1230 Z-S1230 M1.6 nut Assembly 30 Z-S1514 Z-S1514 Z-S1527-1 M4X25 button head Z-S0620 Note: Shown for installation purposes, not Z-S0620 included. M4 nut...
  • Page 33 Assembly 31 Z-S0916 Z-S1527-2 Z-S0916 M2.5X8 button head “Z-S1527-2” can be found in Bag 17. Z-S1527-2 Assembly 32 Z-S1521-5 Z-B0097-1 Z-S1521-4 Z-B0095-1 Z-S1521-3...
  • Page 34 Assembly 33 Z-B0099-3 Z-S1521-8 Z-B0085-4 Z-B0089-5 Z-B0085-4 Assembly 34 Z-B0085-8 Z-S1521-6 Z-B0085-8 Z-S1521-7...

  • Page 35: Z-S1525-1

    Assembly 35 Z-B0089-1 Z-S0649 Z-S1521-1 Z-S1521-2 Z-S0649 M3X8 flat head Assembly 36 Z-S1546-6 Z-S0308 Z-S0308 M3X10 set screw Z-S1546-6 “Z-S1546-6” can be found in Bag 18.

  • Page 36: Z-B0093-4

    Note: LED shown for installation Assembly 37 purposes, not included. Z-B0093-7 Z-S0927 Z-S1523-3 Z-S1523-4 Z-S1523-5 Z-S1523-5 Z-B0093-7 Z-B0107-3 Z-B0107-3 Z-S1523-1 Z-S1523-2 Z-S0927 “Z-S1523-1”&“Z-S1523-2”&“Z-S1523-3”&“Z-S1523-4” can be found in Bag 16. M2X4 cap head Assembly 38...
  • Page 37 Assembly 39 Z-B0091-5 Z-B0093-5 Z-B0093-6 Z-B0085-1 Z-B0085-4 Assembly 40 Z-B0089-4 Z-B0089-6 Z-B0087-4 Z-B0085-5 Z-B0087-6 Z-B0087-3 Z-B0085-5 Z-B0085-5 Z-B0087-5 Z-B0089-4 Z-B0085-2...
  • Page 38 Assembly 41 Z-S0652 Z-B0091-8 Z-S0629 Z-S0629 M3 nut Z-S0652 M3X8 button head Assembly 42 Z-B0085-3 Z-B0085-2...
  • Page 39 Assembly 43 “Z-S1540-2”&“Z-S1540-3”&“Z-S1540-4” can be found in Bag 28. Z-S1540-3 Z-S1540-2 Z-S1540-4 Z-S0648 Z-S0648 M3X6 flat head Assembly 44 Z-S0652 Z-A0080 Z-S0652 M3X8 button head...
  • Page 40 Assembly 45 Z-S0795-2 Z-S0649 Z-S0649 “Z-S0795-2” can be found in Bag 29. Z-A0010 M3X8 flat head Assembly 46 Z-S0655 Z-S0795-1 Z-S0655 “Z-S0795-1” can be found in Bag 29. M3X14 button head Assembly 47 Z-S0649 “Z-S1544-1” can be found in Z-A0081 Bag 21.
  • Page 41 Assembly 48 Z-S0655 Z-S1544-2 Z-S0655 “Z-S1544-2” can be found in Bag 21. M3X14 button head Assembly 49 Links can be found in Bag 23/24/25/26/27. Rod Ends can be found in Bag 31/32/33/34. Z-S0399 Z-S0807 M3X15mm 59mm Link Z-S0884 M3X15mm Make 2 50mm Link Z-S1084 Z-S0402...
  • Page 42 Assembly 51 “Z-S1528-1” can be found in Bag 19. Z-U0034 Z-S0960 Z-S0960 Z-S1528-1 M3X6 button head Assembly 52 “Z-S1528-2” can be found in Bag 19. Z-S0648 Z-S0648 Z-S1528-2 M3X6 flat head...
  • Page 43 Assembly 53 “Z-C0050-1”can be found in Bag 19. Z-C0050-1 Z-S0648 Z-C0050-1 Z-C0050-2 Z-S0648 M3X6 flat head Z-C0046-5 Z-S0652 Z-S0652 M3X8 button head Assembly 54 “Z-S1530” can be found in Bag 20. Z-S1530 Z-C0046-3 Z-S0653 Z-S0653 Install 2 sets as showing. M3X10 button head...
  • Page 44 Assembly 55 Z-C0046-3 Z-C0048 Z-C0046-1 Z-C0046-6 Z-S0652 Z-S0652 M3X8 button head Z-S0653 Z-S0653 M3X10 button head Assembly 56 “Z-C0046-4”&“Z-C0046-7” can be found in Bag 19. Z-C0046-2 Z-S1538 Z-C0046-7 Z-S0652 Z-S0652 Z-C0046-4 M3X8 button head Z-S0653 M3X10 button head Z-S0654 Z-S0654 Z-S0653 Z-S0653 M3X12 button head...
  • Page 45 Assembly 57 Z-S0648 Z-C0050-3 Z-S0648 M3X6 flat head Assembly 58 Z-S1532 Z-S1534 Rear Front...
  • Page 46 Assembly 59 “Z-S1536” can be found in Bag 20. Z-S1536 Z-S0648 Z-S0652 Z-S1532 Z-S1536 Z-S1532 Z-S0648 Z-S0648 M3X6 flat head Z-S0652 Z-S0652 M3X8 button head Assembly 60 Z-S1534 Z-S1536 Z-S1542 Z-S1542 Z-S1534 Z-S0648 M3X6 flat head Z-S0653 M3X10 button head Z-S0653 Z-S0652 Z-S0652...
  • Page 47 Assembly 61 “Z-S1540-1” can be found in Bag 20. Z-S1540-1 Z-S0653 Z-S0653 M3X10 button head Assembly 62 Z-U0029 Z-S0599 Z-S0599...
  • Page 48 Assembly 63 Z-S0804 Z-S0804 M3 Driveshaft Pin Assembly 64 Z-S0653 Z-S0653 M3X10 button head...
  • Page 49 Assembly 65 Z-S0804 Z-S0804 M3 Driveshaft Pin Assembly 66 Z-S1546-3 Z-S1546-4 Z-S0927 “Z-S1546-4” can be found in Bag 22. Install 2 sets as showing. Z-S0927 M2X4 cap head...
  • Page 50 Assembly 67 Z-S1546-5 “Z-S1546-5” can be found in Bag 22. Z-S1546-1 Z-S1546-2 Z-S1546-3 Z-S1518 Z-S1546-2 Z-S1546-3 Z-S1518 M2X6 flat head Assembly 68 Z-S0927 Z-S0927 Z-S0927 M2X4 cap head...
  • Page 51 Assembly 69 59mm Link Z-S0654 Z-S0654 M3X12 button head Assembly 70 71.5mm Link Z-S0657 Z-S0629 Z-S0629 Z-S0657 Z-S0629 M3 nut Z-S0657 M3X18 button head...
  • Page 52 Assembly 71 Z-D0039 Note: Must put shocks(Z-D0039) with color mark spring on the front axle. Z-S0600 Z-S0654 Z-S0600 M3 X 2 Spacer Z-S0600 Z-S0654 Z-S0654 M3X12 button head Assembly 72 Z-S0809 Z-S0654 Z-S0809 104.5mm Link Z-S0809 M3 X 1 Spacer Z-S0654 Z-S0654 M3X12 button head...
  • Page 53 Assembly 73 Z-S0895 Z-S0652 Z-S0652 M3X8 button head Z-S0895 M3X20 button head Assembly 74 Z-S0654 Z-S0654 Z-S0654 M3X12 button head...
  • Page 54 Assembly 75 Z-S0653 70mm Link Z-S0653 Z-S0653 M3X10 button head Assembly 76 52mm Link Z-S1367 Z-S0629 Z-S0629 M3 nut Z-S1367 M3X22 cap head...
  • Page 55 Assembly 77 Z-S0654 Z-S0654 Z-S0654 71.5mm Link M3X12 button head Assembly 78 Z-D0039 Z-S0654 Z-S0600 Z-S0600 M3 X 2 Spacer Z-S0600 Z-S0654 Z-S0654 M3X12 button head...
  • Page 56 Assembly 79 Z-S0656 Z-S0629 Z-S0629 M3 nut Z-S0654 Z-S0654 M3X12 button head Z-S0656 M3X16 button head Assembly 80 Z-S0654 Z-S0654 M3X12 button head...
  • Page 57 Assembly 81 50mm Link Z-S1367 Z-S0629 Z-S0629 M3 nut Z-S1367 M3X22 cap head Assembly 82 71.5mm Link Z-S0654 Z-S0654 Z-S0654 M3X12 button head...
  • Page 58 Assembly 83 Z-D0039 Z-S0654 Z-S0600 Z-S0600 M3 X 2 Spacer Z-S0654 Z-S0654 Z-S0600 M3X12 button head Assembly 84 Z-S0656 Z-S0629 Z-S0629 M3 nut Z-S0654 Z-S0629 M3X12 button head Z-S0656 Z-S0656 Z-S0654 M3X16 button head...
  • Page 59 Assembly 85 Z-S0125 Z-S0125 Z-S1548 M3X5 grub screw Assembly 86 Z-S0654 Z-S0654 M3X12 button head...
  • Page 60 Assembly 87 Z-S0125 Z-S0125 Z-S0583 Z-S0125 M3X5 grub screw Assembly 88 Z-S0804 Z-S0804 M3 Driveshaft Pin...
  • Page 61 Assembly 89 Note: Servo and servo horn are not included in this kit. Z-S0182 70mm Link Z-S0653 Z-S0653 M3X10 button head Assembly 90 Z-S0652 Z-S0652 M3X8 button head Z-S0653 Z-S0653 M3X10 button head...
  • Page 62 Assembly 91 Note: Servo is not included in this kit. Z-S0652 Z-S0652 M3X8 button head Assembly 92 Note: Servo horn is not included in this kit. Z-S0130 Z-S0653 Z-S0653 M3X10 button head...
  • Page 63 Assembly 93 Z-S0927 Z-S0927 M2X4 cap head Assembly 94 41mm Link Z-S0629 Z-S0629 M3 nut Z-S0653 Z-S0653 M3X10 button head Z-S0655 Z-S0655 M3X14 button head...
  • Page 64 Assembly 95 Note: Install pins and hex in the end of all axles. Z-S0238 Z-S0277 Z-S0277 Z-S0238 Assembly 96 Z-S0620 Z-S0620 Z-S0620 M4 nut...
  • Page 65 Assembly 97 Z-S0124 Z-S0430 Z-S0430 Note: Motor not included. Showing Z-S0124 installation method only. M3X3 grub screw Assembly 98 Z-S0651 Z-S0651 M3X6 button head...
  • Page 66 Assembly 99 Z-S0648 Z-S0648 M3X6 flat head Assembly 100 Note: Shackle not included. Shown for Z-S0075 installation method only. Z-S0075...
  • Page 67 Assembly 101 Z-S1529-3 Z-S1516 Z-S1516 M2X4 flat head Assembly 102...
  • Page 68 Assembly 103 Z-B0017 “Z-B0017” can be found in Bag 18 Z-B0017 Complete assembly 104...
  • Page 69 Before adjustment Please focus on third member direction. Disassembly 1 Disassembly 2...
  • Page 70 Disassembly 3 Adjust Reverse Assembly 1...
  • Page 71 Assembly 2 Assembly 3 Adjustment Please focus on third member direction.

  • Page 72: Optional Parts

    Outcry Crawler Speed Controller ESC with TurboBEC Z-E0035 Twister High Torque Metal Gear Digital Servo Z-S0130 Heavy Duty Metal Servo Arm for Futaba Type Servo(Blue) Z-R0006 RC4WD XR4 4-Channel 2.4Ghz Transmitter & Receiver Radio Z-E0006 Mayhem Extreme Power Metal Gear Servo Optional Parts Z-U0024...
