Team Magic E4D Instruction & Setup Manual page 3

PARTS
503206
Hinge Pin Ball(POM)(4)
503115 Front Rear Hinge Pin Mount Set
503117
5x4mm Ball Stud (6)
503120
Hinge Pin Mont Nylon Ball Cap (4)
503125 Front Steering Block Set
503127
Steering Block 5x10mm Ball Stud (4)
503130
Front Lower Outer Hinge Pin (2)
503138 5x7mm Ball Stud (6)
503140
Long Ball Cup (6)
503141
Middle Shaft Mount
503144 Pulley O-Ring 7x2mm (10)
503145
Bumper Post Set
503152
Rear Hub Carrier (2)
503155 Ball Diff Pulley 35T
503156
Ball Diff Steel Ball 2.5mm (12)
503163
Spur Gear 110T
503169 Main Shaft Upper Mount Set
503180 Shock Spring Mount & Ball Cup (4)
503183
Shock Spring (2)
503191 New Shock Bladder (4)
503196 Lightweight Front Bulkhead Upper Mount
503197
Lightweight 17T Side Pulley
503202 Front Lightweight Ball Diff Outdrive Set
503203 New Ball Diff Plate (2)
503205
Rear Lightweight Ball Diff Outdrive Set
503210
Single Bell Crank Steering System
503212 New Wide Side Belt
503213
New Caster Block Ball Stud (4)
503214
Caster Block Lower Screw (4)
503215 Lightweight Caster Block Set (6 degree)
503218
Lightweight Rear Front Hinge Pin Mount
503222
Nylon 18T Center Pulley
503224 Lightweight Rear Bulkhead Upper Mount
503226
Special Servo Disc Ball Cup (2)
503236
Nylon 17T Center Pulley
503250 Shock Set (2)
503251
Front Nylon Shock Tower
503252
3.1x6.5x3mm Nylon Washer (6)
503253 Front Nylon Bulkhead Set
503254
Front Lower Arm Set
503255
Nylon Quick Release Battery Holder
503257 Upper Deck / Belt Tensioner Mount
503258
Belt Tensioner Set
503259
Front Lower Inner Hinge Pin (2)
503260 Lower Nylon Hinge Pin Mount 1.5 Degree
503263
Alum. Middle Shaft
503264
Ball Diff Screw & Spring Set
503265 Rear Lower Outer Hinge Pin (2)
503267
Motor Mount
503268
Rear Nylon Bulkhead Set
503269
Rear Lower Inner Hinge Pin (2)
503270
Nylon Main Shaft Left Mount
503271
Lower Nylon Hinge Pin Mount 2.5 Degree
503272
Alum. 7075 Main Shaft
503273 Spur Gear Holder
503274
Rear Nylon Shock Tower
503275
Servo Mount
503276 Front Chassis
Parts List
503277
Main Chassis
503278 Rear Chassis
503279 Rear Hub Carrier Nylon Wahser (4)
503280
3.1x6.5x5mm Nylon Washer (6)
503281 Nylon Front Upper Linkage (2)
503282 Nylon Steering Linkage (2)
503283
Nylon Rear Upper Linkage (2)
503250-1
Shock Cap Set (2)
503250-2 Shock Shaft & Piston Set (2)
503250-3
Shock Body Set (2)
503250-4
Shock Body Hardware Set (2)
503301 Drift Car Nylon Accessories
503302S
Drift Car Mounted Tire (5 Spoke, Silver)(4 pcs)
503303
Alum. Front/Rear CVA Shaft (2)
503304 Front Belt
503305
33T Pinion Gear
503306
Bumper Set (F/R)
503307 Front Body Post Set
503308
Battery Holder Screw (2)
503310
Rear Belt
503311 Rear Lower Arm Set
503312
Foam Bumper
503313
Servo Arm (Futaba) (2)
111007ST 3mm Steel Locknut (10)
111120
R6 R-clip (10)
111160
4mm Special Wheel Lock Nut (4)
115024 4mm Short Thread Ball Stud & Ball Cup (for 3mm rod) (5)
116206
2x10mm Pin (10)
116219
3x6.5x2mm Alum. Washer (6)
116222 3M Double Side Tape 3x13cm
126306 3x6mm Steel FH Screw (6)
126308
3x8mm Steel F.H. Screw (6)
126310
3x10mm Steel F.H. Screw (6)
130102 8.1x12x0.2mm Shim (10)
130115
3x8x1mm Alum. Washer (10)
150508
5x8x2.5mm Bearing (2)
150612 6x12x4mm Bearing (4)
150814
8x14x4mm Bearing (2)
151015
10x15x4mm Bearing (4)
151218 12x18x4mm Bearing (4)
126303S
3x3mm Set Screw (6)
126306BU
3x6mm Steel Button Head Screw (6)
126306S 3x6mm Set Screw (6)
126308BU
3x8mm Steel Button Head Screw (6)
126308C
3x8mm Steel Cap Screw (6)
126310BU 3x10mm Steel Button Head Screw (6)
126314BU
3x14mm Button Head Screw (6)
126318c
3x18mm Steel Cap Screw (6)
126403S 4x3mm Set Screw
150308TF
3x8mm Thrust Bearing Flat (1)
H6802
HR132JE 2 Channel AM Receiver 27MHz w/o Crystal
H6803 H.A.R.D. HS3003 Throttle Servo
H6804
H.A.R.D. JR Dual Mode ESC (w/reverse)
H6805
H.A.R.D. X3 Motor
K1005 Special 3mm Servo Holding Screw (5)
K6301
Black Grease (for thrust bearing as well, 4g)
K6302
Ball Diff Lube (4g)
61130
