Touch operation : Press one time on the "up" key (Appear the first "*" ),Then press one time on the
"down" key (Appear the second "*" ) , Press one time on the "up" key again (Appear the third "*" ) ,
Press one time on the "down" key again (Appear the fourth "*" ) . At last press "OK" key to do the
password authentication .
Runner operation : Turn to the left 1 bar (Appear the first "*" ), then turn to the right 1 bar (Appear the
second "*" ), Turn to the left 1 bar again (Appear the third "*" ), Turn to the right 1 bar again (Appear the
fourth "*" ) . At last press runner key to do the password authentication .
option
Touch screen adjustment
Reset calibration (Zero calibration)
Guangzhou Best Stage Light Equipment Co.' Ltd
instruction
After entering the calibration interface, Follow
the cross cursor
corresponding position. If the four locations to
the correct data is received. Then complete the
calibration and save the calibration data. If the
calibration fails , This process will continue the
cycle ,then can at any time by pressing the "OK"
button to interrupt calibration.
After entering the sub-interface, Can be
adjusted x-axis, Y-axis to the motor's reset
position. To compensate
installation error.
With address code and channel value different ,
reset calibration not support One-digit Two-digit
Three-digit edited respectively. Not support long
press too . And must be in 1 unit step-by-step
calibration .
Pay attention : Don't reset calibration when the
motor work. If motor is working ,Please stop it
then start to reset calibration.
If necessary, Please reset operation one time
before reset calibration .
5
