Prestige 964 Cable Router
DOCSIS 2.0 and 1.1 Based
ZyXEL's Prestige 964 Cable Modem
leverages the DOCSIS 2.0 Advanced Time
Division Multiple Access (A-TDMA) and
synchronous Code Division Multiple
Access (S-CDMA) technologies with 3 times
upstream capacity than DOCSIS 1.1/1.0
systems. The Prestige 964 is interoperable
and backward compatible with DOCSIS 1.1
nd 1.0 system so cable operators can rapidly
deploy the Prestige 964 today for a timely
transition in continuous service without
interruption. The flexibility of Prestige 964
allows cable operators to maximize the
today's infrastructure investments and offer
higher bandwidth service for the tomorrow's
requirements concurrently.
Supporting static IP network and with DHCP
and NAT, Prestige 964 cable router is ideal
for business class customers to build up a
public and private network simultaneously.
The routing information uses a key-string
encrypted via an MD5 hash algorithm for
authentication with the CMTS. Text based
configuration file through telnet interface
make system deployment simplified and
TACACS+ server support also enables access
control for all interfaces.
Prestige 964 incorporates valuable
features such as simplified troubleshooting
with front panel status indicator LEDs,
built-in 5-port 10/100M auto-sensing,
auto MDI-X Ethernet switch, remote status
monitoring over the cable network, proven
reliability and quality, and easy plug & play
installation. What's more, Prestige 964 has
new compact stylish design to meet tight
space installation requirements and is priced
competitively.
B e n e f i t s
R
TM
DOCSIS 2.0 CableLab Certification
DOCSIS 1.1/1.0 backward compatible to current investment
Integrated A-TDMA and S-CDMA technology-capable of
providing up to 30 Mbps upstream data rate
Remote management via SNMP
5-port 10/100 Base-T Ethernet and USB connectivity
OS Compatibility
For Ethernet connectivity: Windows 95/98/2000/
R
ME/XP, Macintosh , Linux and UNIX
For USB connectivity drivers: Window 98/2000/ME/XP
Front panel LEDs and web-based diagnostic interface
for easy troubleshooting
Remote status monitoring over the cable network
Supports up to 32 users (1 via USB and up to 31 via
Ethernet or 32 users on Ethernet)
Dual bridge and router mode operation
DHCP and NAT support both public and private network on
the LAN ports simultaneously.
Support static IP network assignment ranging from a /30 to
a /24 IP addresses.
Static IP mode with enabled/disabled DHCP and NAT
configuration for Local Area Network
The text based configuration file make deployment simplified.
RIP support key-string encrypted with MD5 for authentication
with the CMTS
The TACACS+ server support allows access control to all
interfaces for MSO.
