4K DIGITAL PROJECTOR
SRX-T615
INSTALLATION MANUAL
1st Edition (Revised 1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRX-T615 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony SRX-T615

Summary of Contents for Sony SRX-T615

  • Page 1 4K DIGITAL PROJECTOR SRX-T615 INSTALLATION MANUAL 1st Edition (Revised 1)
  • Page 2 Dette utstyret kan kobles til et IT-strømfordelingssystem. でください。 : NETWORK コネクター 上記のポートについては本書の指示に従ってください。 For safety, do not connect the connector for periph- eral device wiring that might have excessive volt- age to the following port. : NETWORK connector Follow the instructions for the above port. SRX-T615...

  • Page 3: Table Of Contents

    Setting of This Unit ..........2-14 (E) 2-2-1. Operation Method of Setting ......2-14 (E) 2-2-2. Owner Information ........2-15 (E) 2-2-3. Network ............2-16 (E) 2-2-4. PC Communication ........2-17 (E) 2-2-5. Profi le .............2-18 (E) 2-2-6. Signal Input from Optional Board ....2-18 (E) 1 (E) SRX-T615...

  • Page 4: Manual Structure

    Manual Structure Purpose of this manual This manual is the installation manual of 4K Digital Projector SRX-T615. This manual is intended for use by trained system and service engineers, and de- scribes the information for installation of this unit. Related manuals The following manuals are prepared for this unit.

  • Page 5: Installation

    Color Adjustment Tool with the (Refer to Section 2-6.) correction (CSC adjustment). 2D lens installed. (Refer to Section 2-6.) Perform edge blending adjustment. Perform color space (Refer to Section 2-7.) correction (CSC adjustment). (Refer to Section 2-6.) 1-1 (E) SRX-T615...

  • Page 6: Required Equipment/Tools

    . LKRL-Z511 . LKRL-Z514 . LKRL-Z519 . LKRL-A502 . LKRL-A503 Regarding the selection of lens, contact your local Sony Sales Office/Service Center. 3D lens filter LKRA-005 etc. Lamp Prepare one of the following lamps in accordance with the installation environment.

  • Page 7: External Dimensions

    Left side view (Refer to the optional lens list.) Intake Air Intake Input/output Heat terminal exhaust LKRL LIST LKRL REMARKS Z511 258-297 Z514 230-283 Z519 A502 Including in 3D lens filter A503 Including in 3D lens filter 1-3 (E) SRX-T615...
  • Page 8 Top view Right side view Rear view Heat exhaust Air Intake Air Intake Air Intake Intake Air Intake Air Intake Heat exhaust Air Intake Bottom view 10-M8 (for fixing the projector) AC power cable Unit: mm 1-4 (E) SRX-T615...

  • Page 9: Installation Of Carrying Handle

    1. Loosen the nut in the direction of the arrow A, then insert the handle arm in the direction of the arrow B. 2. Tighten the nut to fix the handle arm. 3. Attach the handle arm to the adjuster of other three portions by repeating steps 1 and 2. Adjuster Handle arm 1-5 (E) SRX-T615...
  • Page 10 4. Insert the pipe (long) into the handle arms, then fix the pipe with the two M8 bolts. 5. Attach the pipe (long) on the other side in the same way. M8 bolts Handle arm Pipe (long) Handle arm Pipe (long) Pipe (long) 1-6 (E) SRX-T615...
  • Page 11 1. Loosen the nut in the direction of the arrow A, then insert the handle arm in the direction of the arrow B. 2. Tighten the nut to fix the handle arm. 3. Attach the handle arm to the adjuster of other three portions by repeating steps 1 and 2. Adjuster Handle arm 1-7 (E) SRX-T615...
  • Page 12 4. Insert the pipe (short) into the handle arms, then fix the pipe with the two M8 bolts. 5. Attach the pipe (short) on the other side in the same way. M8 bolts Pipe (short) Pipe (short) Pipe (short) 1-8 (E) SRX-T615...

  • Page 13: Connection

    1-1-5. Connection Left side of this unit External reproduction device External reproduction device HDMI cable 1-9 (E) SRX-T615...

  • Page 14: Installation Of Duct

    Attach the 8-inch duct to the duct connecting portion on the rear side of the top portion of this unit. . When attaching the duct, be careful not to bend the duct for exhausting the air smoothly. . For the required exhaust air volume, refer to “1-1-2. Required Equipment/Tools”. 8-inch duct Rear side Duct connecting portion 1-10 (E) SRX-T615...

  • Page 15: Installation Of Lens

    If you raise the lens fixing lever without pushing the lock button, the lock button and lens fixing lever will be damaged. Be sure to push the lock button and check that the lock is released before raising the lever. Lens fixing lever Lock button 1-11 (E) SRX-T615...
  • Page 16 2. Attach the lens to this unit while firmly holding the lens not to drop it and aligning the position. When attaching the lens to this unit, insert it straight. 3. Lower the lens fixing lever to fix the lens. Lens Lens fixing lever Lens Lens fixing lever 1-12 (E) SRX-T615...

  • Page 17: Installation Of 3D Lens Filter (In The Case Of Lkra-005)

    2. Attach the filter bracket (B) assembly with the two screws supplied with the 3D lens filter. Filter bracket (A) assembly PSW6 x 8 Filter bracket (A) assembly PSW6 x 8 PSW6 x 8 Filter bracket (A) assembly PSW6 x 8 Filter bracket (B) assembly 1-13 (E) SRX-T615...
  • Page 18 3. Attach the 3D filter (R) assembly with the two knobs. Knob 3D filter (R) assembly Knob 1-14 (E) SRX-T615...
  • Page 19 4. Release the lock plate in the direction of the arrow, then hook it on the position pin. 5. Attach the 3D filter (L) assembly with the two knobs. Knob Position pin Knob Lock plate 3D filter (L) assembly 1-15 (E) SRX-T615...

  • Page 20: Installation Of Lamp

    1. Loosen the screw (with drop-safe), lower the two hooks, and then remove the intake grille (A) in the direction of the arrow A. Screw (with drop-safe) Hooks Intake grille (A) 2. Lower the lamp door latch to open the lamp door. Lamp door Lamp door latch 1-16 (E) SRX-T615...
  • Page 21 . Push near the PUSH mark of the lamp to insert it securely. 4. Attach the remaining lamps by repeating steps 2 and 3. PUSH Lamp PUSH mark Connector contact portion 5. To install the intake grille (A), reverse the removal procedure. 1-17 (E) SRX-T615...

  • Page 22: Connection Of Power Cord

    1. Remove the four screws, then remove the terminal block cover. Terminal block cover Screws 2. Remove the screw, then remove the cable clamp. 3. Remove the screw, then remove the ground terminal. Ground terminal Screw Cable clamp Screw 1-18 (E) SRX-T615...
  • Page 23 6. Route the power cord through the hole on the bottom of the terminal block, then fix each terminal with the screw as shown in the illustration. 7. Fix the power cord using the cable clamp and screw. 8. Attach the terminal block cover. Ground terminal Power cord Screws Screw Cable clamp 1-19 (E) SRX-T615...

  • Page 24: Adjustment Of Projector Tilt

    To raise the height of this unit . Rotate counterclockwise direction (3): To lower the height of this unit 3. Fix the adjuster by tightening the nut toward the adjuster pipe. Example of tilted projector Adjuster pipe Adjuster 1-20 (E) SRX-T615...

  • Page 25: Adjustment

    Microsoft Windows XP support has ended. Do not connect PC on which Windows XP is installed to the projector. 2-1-2. Connection Connect this unit and PC using a LAN cable or RS-232C cable. Left side of this unit When connecting using an RS-232C cable (cross cable) When connecting using a LAN cable 2-1 (E) SRX-T615...

  • Page 26: Startup

    5. If you want to display the [SERVICE] screen or the [SETTING] screen, type the password in the password entering window and click the [OK] button. Password (Initial setting) . [SERVICE] screen: service . [SETTING] screen: setting Type the password using the lowercase characters. To exit the menu Select “Quit” from the [File] menu. 2-2 (E) SRX-T615...

  • Page 27: Control Window

    Adjusts the image masking according to the screen shape by the eight adjusting point respectively. And adjustment value is displayed by pointing the cursor at each adjusting point ((1) to (8)). Screen example (1) [RESET] button [BLENDING] button (3) (7) 2-3 (E) SRX-T615...
  • Page 28 Displays the location. . Name: Displays the owner name. (Lamp bulb): The color changes according to the time of the lamp used. 0% to 80%: White 80% to 100%: Yellow 100% or more: . Warning Info: Displays warning information. 2-4 (E) SRX-T615...
  • Page 29 2. [PICTURE CONTROL] tab Screen example [PICTURE CONTROL] tab 3. [COLOR CONFIG.] tab [COLOR CONFIG.] tab Screen example 2-5 (E) SRX-T615...
  • Page 30 In this case, however, the power consumption decreases. Clicking the [+] button, the numeric value in- creases. Clicking the [_] button, the numeric value decreases. . [Level1]/[Level2]/[Level3]: Switches the luminance adjustment filter on the image. Level 3 indicates the brightest state. 2-6 (E) SRX-T615...
  • Page 31 Do not change the values of the reference projector except for “Centering”. Adjust the reference projector only for “Centering” adjustment. Screen example Items Adjust each item by using the [_]/[+] buttons. 2-7 (E) SRX-T615...
  • Page 32 V (vertical). H: The image expands in the right direction with the [+] V: The image expands in the upper direction with the [+] button. button. Fix the center. V: [+] button Fix the center. H: [+] button 2-8 (E) SRX-T615...
  • Page 33 H: The image moves in the left direction with the [+] button. H: The image moves in the right direction with the [+] button. H: [+] button H: [+] button Fix the center and right end. Fix the center and left end. 2-9 (E) SRX-T615...
  • Page 34 1 [WHITE BALANCE] 2 [REGISTRATION ADJUST] 3 [LAMP CONTROL & INFORMATION] 4 [AIR FILTER TIMER] 5 [FAN CONTROL & INFORMATION] 6 [MAINTENANCE TIMER] 7 [COLOR SPACE CONVERTER] 8 [VERSION INFORMATION] 9 [ZONE] button (MAIN version 3.19.0600 or later) 2-10 (E) SRX-T615...
  • Page 35 Therefore, the number of lamps is maintained at all times. The function does not operate when “6” is selected in [Lamp Number Select] or when lamp power is defective. 2-11 (E) SRX-T615...
  • Page 36 . Installation at an altitude of 501 to 1000 m: Set to “Mode2”. . Installation at an altitude of 1001 to 1500 m: Set to “Mode3”. When installing at an altitude of 1501 m or more, contact your local Sony Sales Office/Service Center. During use of a 330 W lamp .

  • Page 37: Function Memory

    If you select [File] → [Save Log] on the menu bar of the control screen, the communication log between SRX Controller and this unit (from the startup of SRX Controller to that point of time) can be stored up to 5 MB. 2-13 (E) SRX-T615...

  • Page 38: Setting Of This Unit

    Setting item 2. Click the setting item on the left side of the [SETTING] screen to display the item that you want to set. 3. After setting the items, click the [APPLY] button. The setting is registered. 2-14 (E) SRX-T615...

  • Page 39: Owner Information

    Type the name of owner. [Organization] : Type the name of organization. [Projector] [Region] : Type the region that the unit is installed. [Location] : Type the installation location. [Name] : Type the arbitrary name. [Memo] : Type a memo. 2-15 (E) SRX-T615...

  • Page 40: Network

    . [Obtain a DNS server address automatically]: Sets whether automatically obtain a DNS server from DHCP server. . [Specify a DNS server address]: Type the IPv6 address of DNS server when DNS server is not automatically obtained. [LAN Setting] [MAC Address] : Display the MAC address. 2-16 (E) SRX-T615...

  • Page 41: Pc Communication

    Type the TCP port number. [Time-out]: Select the time of the communication time-out. [Network Block Reboot] [REBOOT] button: Click this button to reboot the network CPU. After setting PC Communication, a reboot of the network CPU is required. 2-17 (E) SRX-T615...

  • Page 42: Profi Le

    In the case of using an optional board, if you change an input signal at the optional board, it sometimes appears noise on a screen. It is recommended to perform the masking for approximately 5 seconds in advance. 2-18 (E) SRX-T615...

  • Page 43: Lens Adjustment

    5. Adjust the image position in the horizontal direction by rotating the H shift knob. 6. Tighten the three V shift lock screws and three H shift lock screws. V shift lock screws (3 pcs) Lens shift V shift knob block H shift lock screws (3 pcs) H shift knob 2-19 (E) SRX-T615...
  • Page 44 (scope, HD). . When you want to perform the H shift, adjust the image position with scope (horizontally longest field angle), then correct the image center position with other field angles (flat, HD). 2-20 (E) SRX-T615...
  • Page 45 H shift When completely aligned: 0 % (no shift) When deviated by about 2 mm: 7% (Maximum adjustment range) V shift When completely aligned: 0 % (no shift) When deviated by about 5.5 mm: 35% (Maximum adjustment range) 2-21 (E) SRX-T615...

  • Page 46: Position Adjustment (Electric Shift Using Srx Controller)

    V shift and H shift with the lens shift block. 1. Click the [INSTALLATION] tab. 2. Adjust the [V Shift] or [H Shift] using [_] and [+] buttons in the [ELECTRIC SHIFT FUNCTION]. [INSTALLATION] tab Screen example [ELECTRIC SHIFT FUNCTION] 2-22 (E) SRX-T615...

  • Page 47: Position Adjustment (Adjusting The Projector Tilt And Direction)

    Click the adjustment point and adjust the horizontal and vertical directions using [_] and [+] buttons or by direct entry. . [+] : Setting value is increased. . [_] : Setting value is decreased. Click [Reset] to return to the original masking amount. 2-23 (E) SRX-T615...

  • Page 48: Brightness Adjustment

    [INSTALLATION] tab Screen example [LAMP POWER] 4. Select an appropriate luminance level from the three levels in the [LAMP POWER]. t Level 3 is the brightest level. 5. Perform the fine adjustment using [+] and [_] buttons. 2-24 (E) SRX-T615...

  • Page 49: Image Adjustment (3D Lens)

    The current state enters a 3D mode. 3. Click the [INSTALLATION] tab. [INPUT SELECT] [INSTALLATION] tab Screen example [TEST PATTERN] 4. Click the “Frame Adjust” radio button in [Single 3D] of [TEST PATTERN]. A test signal is displayed. 2-25 (E) SRX-T615...
  • Page 50 (magenta image) is projected from the upper lens by rotating the optical axis adjust- ment screw. 7. Tighten the four optical axis adjustment lock screws. (Tightening torque: 2.0 N.m) Optical axis adjustment screw Optical axis adjustment lock screws (4 pcs) The green light beam is output from the upper lens. 2-26 (E) SRX-T615...

  • Page 51: Lens Filter Adjustment (In The Case Of Lkra-005)

    3D lens filter position (depth direction) adjustment 1. Loosen the knobs and position pins. 2. Move the 3D lens filters in the depth direction. 3. Tighten the knobs and position pins. Knobs Position pins Knobs Position pins 3D lens filters 2-27 (E) SRX-T615...
  • Page 52 3D lens filter tilt adjustment 1. Loosen the two adjustment screws. 2. Tilt the 3D lens filter. 3. Tighten the adjustment screws. Adjustment screw (this screw is also attached on the other side.) 3D lens filter 2-28 (E) SRX-T615...

  • Page 53: Zoom/Focus Adjustment

    Zoom ring (image for left eye) Zoom lock screw (image for left eye) Focus ring (image for left eye) Focus lock screw (image for left eye) The 3D lens filters are not shown in the illustration for the sake of clarity. 2-29 (E) SRX-T615...

  • Page 54: Position Adjustment (Adjust Image Using Srx Controller)

    (Refer to Section 1-7.) In the case that the H shift amount is insufficient, change this unit installation position in order to project the image obliquely. Perform the mask processing because a keystone occurs when this unit is tilted. 2-30 (E) SRX-T615...

  • Page 55: Alignment Of The Horizontal Position Of

    2. Click the “Right” radio button in [Image Select] of [SINGLE 3D ADJUST]. 3. Adjust the position of the image for the right eye in the horizontal direction in the [H Adjust] of the [Position Adjust]. Screen example [SINGLE 3D ADJUST] 2-31 (E) SRX-T615...
  • Page 56 (V Tilt) and the image shape in the vertical direction (V Bow) can be adjusted. In the case of increasing H Tilt (+) In the case of increasing V Tilt (+) In the case of increasing V Bow (+) 2-32 (E) SRX-T615...

  • Page 57: Image Mapping

    2. Select the image mapping corresponding to the type of contents, the field angle of contents, and the type of a screen in [SINGLE 3D ADJUST]. The image size can be adjusted using the [+] and [_] buttons of [Size] when you select the item beginning with Scope. 2-33 (E) SRX-T615...

  • Page 58: Brightness Adjustment

    4. Select an appropriate luminance level from the three levels in the [LAMP POWER]. t Level 3 is the brightest level. 5. Perform the fine adjustment using [+] and [_] buttons. 6. Check the brightness using the luminance meter. 2-34 (E) SRX-T615...

  • Page 59: Registration Adjustment

    The [SERVICE] screen is displayed. [ZONE] button [SERVICE] tab Screen example Confirm the MAIN version. [REGISTRATION ADJUST] [VERSION INFORMATION] 2. Click the [ZONE] button. The [ZONE REGISTRATION ADJUST] screen is displayed. Screen example [Test Pattern] [Zone Adjust] 2-35 (E) SRX-T615...

  • Page 60: Color Space Conversion (Csc Adjustment)

    Perform the gamma adjustment of this unit using a gamma adjustment tool (PCAB-G). . Perform gamma and uniformity adjustments before CSC adjustment when changing the number of lamps. The color may subtly vary depending on the number of lamps. 2-36 (E) SRX-T615...

  • Page 61: Correcting The Color Space "Srgb (709)

    When adjusting color space DCDM or AdobeRGB, purchase an optional trimming filter kit and perform the adjustment after replacement of a trimming filter. A correct color does not appear even if you perform adjustment before replacement. When replacing the trimming filter, contact your local Sony Sales Office/Service Center. 2-37 (E) SRX-T615...

  • Page 62: Correcting The Color Space "Single 3D

    10. Click the [OFF] button in [Left] of [CUT OFF]. 11. Click the [COLOR CONFIG.] tab, and then set [Color Space] for the left eye and right eye. [COLOR CONFIG.] tab Screen example [Color Space] [Color Space] 2-38 (E) SRX-T615...

  • Page 63: Edge Blending Adjustment

    In this section, an example of horizontal blending of the blending width 512 on the right side is explained. 1. Start the SRX Controller, then click the [SERVICE] tab. (Refer to Section 2-1-3.) The [SERVICE] screen is displayed. [MASKING ADJUST/EDGE BLENDING] [SERVICE] tab Screen example 2-39 (E) SRX-T615...
  • Page 64 A green line is displayed at the start point of blending and a red line is displayed at the end point. It is recommended to set [Upper] and [Lower] to “256” or “512”. 7. When the setting is completed, click the [CLOSE] button. 2-40 (E) SRX-T615...

  • Page 65: Correction Of Distortion After Edge Blending Adjustment

    [MASKING ADJUST/EDGE BLENDING] [SERVICE] tab Screen example 2. Click the [BLENDING] button of [MASKING ADJUST/EDGE BLENDING]. The [BLENDING DISTORTION ADJUST screen is displayed. [BLENDING DISTORTION ADJUST] Screen example The marks ◊ in [BLENDING DISTORTION ADJUST] indicate the adjustment points. 2-41 (E) SRX-T615...
  • Page 66 5. Adjust the images at the adjustment points 8, !' and @/ in the same way. The entire image is moved. 6. If the misregistration between the images still remains, perform the fine adjustment at other adjust- ment points. 7. Repeat steps 1 to 6 with the other projector. 2-42 (E) SRX-T615...

  • Page 67: Color Matching Of Edge Blending

    1. Perform the following with the SRX Controller of the projector B. (1) Start the SRX Controller, then click the [SERVICE] tab. (Refer to Section 2-1-3.) The [SERVICE] screen is displayed. [MASKING ADJUST/EDGE BLENDING] [SERVICE] tab Screen example 2-43 (E) SRX-T615...
  • Page 68 4. Visually adjust R (Red), G (Green) and B (Blue) of the projector B using the [_]/[+] buttons. 5. Adjust [Level2] to [Level8] by repeating steps 3 and 4. 6. After completing the adjustment, click “Off” of the radio button in [Test Pattern]. 7. Click the [CLOSE] button. 2-44 (E) SRX-T615...
