Confidentiality Notice .....................................................................................................................3
Product Overview ............................................................................................................................3
System Requirements and Limitations ................................................................................................. 4
Tips for VoIP Subscribers ...................................................................................................................... 5
Features and Functions .......................................................................................................................... 5
Operation .........................................................................................................................................6
Autodial Emergency Call ....................................................................................................................... 6
All Models ............................................................................................................................................................ 6
Placing a Telephone Call using Keypad ................................................................................................ 6
Models 398-702CB, 398-702RT, and 398-702TP ................................................................................................ 6
Receiving a Call ....................................................................................................................................... 6
Multicast Broadcast ................................................................................................................................ 7
Monitoring and Reporting ..................................................................................................................... 7
Installation ....................................................................................................................................10
General Information ............................................................................................................................. 10
Safety Guidelines ................................................................................................................................... 10
Station Placement .................................................................................................................................. 10
Security Hardware ................................................................................................................................ 10
Removal and Replacement Installation (All Models) ........................................................................ 11
Setup ..............................................................................................................................................14
Field Wire Installation .......................................................................................................................... 14
Power .................................................................................................................................................................. 14
Network Cable .................................................................................................................................................... 15
I/O ....................................................................................................................................................................... 16
Recommended Cabling ....................................................................................................................................... 17
VoIP Telephone Input Contacts .......................................................................................................... 17
VoIP Telephone Output Contacts ....................................................................................................... 17
Strobe Connection ................................................................................................................................. 18
Status Indication ................................................................................................................................... 19
Power .................................................................................................................................................................. 19
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
V
ISIT WWW
G A I - T R O N I C S ® C O R P O R A T I O N
A H U B B E L L C O M P A N Y
T
C
A B L E O F
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
O N T E N T S
Pub. 42004-461D
Advertisement
Table of Contents
Related Manuals for GAI-Tronics RED ALERT 397-700CB
Summary of Contents for GAI-Tronics RED ALERT 397-700CB
-
Page 1: Table Of Contents
VoIP Telephone Output Contacts ....................... 17 Strobe Connection ..........................18 Status Indication ........................... 19 Power .................................. 19 GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS... - Page 2 Service ..............................20 Troubleshooting ............................ 21 Specifications ..........................22 Replacement and Optional Parts ......................23 GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS...
-
Page 3: Confidentiality Notice
GAI-Tronics product or system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party. -
Page 4: System Requirements And Limitations
. 42004-461D 4 of 23 IP R ANDS FREE ETRO ELEPHONES Model Description Ramtel Flush-Mount VoIP Telephone, weatherproof brushed stainless steel front panel, 398-702RT autodial push button, (off-hook) button, 12-button Braille keypad, and HELP CALL CALL LED. RECEIVED WHEN LIT Code Blue is a registered trademark of Code Blue Corporation. -
Page 5: Tips For Voip Subscribers
. 42004-461D 5 of 23 IP R ANDS FREE ETRO ELEPHONES Tips for VoIP Subscribers If you have or are thinking of subscribing to an interconnected VoIP service, you should: Provide your accurate physical address to your interconnected VoIP service provider to ensure that emergency services can quickly be dispatched to your location. -
Page 6: Operation
. 42004-461D 6 of 23 IP R ANDS FREE ETRO ELEPHONES Operation Autodial Emergency Call All Models To place an emergency call: 1. Press the HELP push button to place an immediate call to a preprogrammed emergency number, typically a security office or 911. 2. -
Page 7: Multicast Broadcast
When making a Multicast call, the SIP server will send a paging request to a specific IP address and expect multiple telephones to accept and play the subsequent audio. GAI-Tronics VoIP telephones can be programmed for up to eight Multicast addresses to permit the receipt of Multicast broadcasts from different sources or to enable zoning of broadcasts. - Page 8 . 42004-461D 8 of 23 IP R ANDS FREE ETRO ELEPHONES Figure 1. Model 397-700CB Figure 2. Model 397-700RT Figure 3. Model 397-700TP Figure 4. Model 398-702CB f:\standard ioms - current release\42004 instr. manuals\42004-461d.doc 02/15...
- Page 9 . 42004-461D 9 of 23 IP R ANDS FREE ETRO ELEPHONES Figure 5. Model 398-702RT Figure 6. Model 398-702TP f:\standard ioms - current release\42004 instr. manuals\42004-461d.doc 02/15...
-
Page 10: Installation
All of the telephones described in this manual are vandal resistant. The front panel for each telephone covered in this manual is attached to its enclosure with security screws. A GAI-Tronics Model 233-001 Security Screwdriver or Torx T-25 security head tip (sold separately) is required for installing the telephone. -
Page 11: Removal And Replacement Installation (All Models)
. 42004-461D 11 of 23 IP R ANDS FREE ETRO ELEPHONES Removal and Replacement Installation (All Models) ® The appropriate RED ALERT retrofit models are designed to replace Code Blue, Ramtel, or Talk-A- Phone telephones utilizing a six-hole mounting pattern, as follows: 1. - Page 12 . 42004-461D 12 of 23 IP R ANDS FREE ETRO ELEPHONES Figure 7. Back Box for Ramtel (RT) and Code Blue (CB) f:\standard ioms - current release\42004 instr. manuals\42004-461d.doc 02/15...
- Page 13 . 42004-461D 13 of 23 IP R ANDS FREE ETRO ELEPHONES Figure 8. Back Box for Talk-A-Phone (TP) f:\standard ioms - current release\42004 instr. manuals\42004-461d.doc 02/15...
-
Page 14: Setup
. 42004-461D 14 of 23 IP R ANDS FREE ETRO ELEPHONES Setup Field Wire Installation After all the field wires are pulled through the rear enclosure, install all connections as indicated below. Refer to Figure 9 for wiring details. Refer to Table 5 on page 17 for the recommended conductor sizes. : Consult the National Electrical Code (NFPA 70), Canadian Standards Association (CSA 22.1), and local codes for the specific requirements regarding your installation. -
Page 15: Network Cable
. 42004-461D 15 of 23 IP R ANDS FREE ETRO ELEPHONES Network Cable Connect a Cat5 or Cat5e UTP cable with an RJ45 connector between the Local Area Network (LAN) and the VoIP PCBA. Figure 9. VoIP Telephone PCB Assembly f:\standard ioms - current release\42004 instr. -
Page 16: I/O
. 42004-461D 16 of 23 IP R ANDS FREE ETRO ELEPHONES Inputs Four auxiliary inputs have been provided for customer use. Terminations for these inputs are provided on terminal block P12. Table 3. Auxiliary Inputs – P12 Label Function Input 4 Common Input 3 Common... -
Page 17: Recommended Cabling
. 42004-461D 17 of 23 IP R ANDS FREE ETRO ELEPHONES Recommended Cabling Table 5. Recommended Cabling Cable Use Size Cat5 or Cat5e UTP cable with an RJ45 connector Power Two-conductor, No. 22 AWG is typical Inputs Two-conductor, No. 22 AWG is typical Output contacts Two or three-conductor, No. -
Page 18: Strobe Connection
HELP push button is pressed. The relay can remain energized for the duration of the emergency call. In most applications, this output is used to operate a GAI-Tronics Model 530-001/531A Strobe (sold separately). For connection details, please refer to Figure 10 or the Model 530-001/531A installation instructions included with the strobe (GTC Pub. -
Page 19: Status Indication
The installer should ensure that the network is configured to allow VoIP communications (using the SIP protocol) between the desired locations before attempting to configure the GAI-Tronics VoIP Telephones. The general sequence for set up of the VoIP telephone is as follows: VoIP PCBA Setup The easiest way to get started is to make a network connection to the unit and log on via a web browser. -
Page 20: Maintenance
VoIP Telephone requires depot service, contact your Regional Service Center for a return authorization number (RA#). Equipment should be shipped prepaid to GAI-Tronics with a return authorization number and a purchase order number. If the equipment is under warranty, repairs will be made without charge. -
Page 21: Troubleshooting
. 42004-461D 21 of 23 IP R ANDS FREE ETRO ELEPHONES Troubleshooting Table 6. Troubleshooting Problem Possible Solution Low volume If the volume is low, increase the volume level in the telephone’s programming configuration. High volume If the volume is high, decrease the volume level in the telephone’s programming configuration. -
Page 22: Specifications
. 42004-461D 22 of 23 IP R ANDS FREE ETRO ELEPHONES Specifications Power Network power............. Power-over-Ethernet, 802.3af compliant (via RJ45) Local power requirements ....................24–48 V dc, 6 watts Network ................10/100 BaseT Ethernet RJ45, Cat5 or Cat5e UTP Static IP provisioning or DHCP STUN client (NAT traversal) Call control signaling .............. -
Page 23: Replacement And Optional Parts
. 42004-461D 23 of 23 IP R ANDS FREE ETRO ELEPHONES Model 397-700CB Panel ..................11.75 H 8.50 W inches (298.4 215.9 mm) Back box (depth from mounting surface) ..............2.48 inches (63.0 mm) Weight ........................... 6.0 lbs. (2.7 kg) Model 398-702TP Panel .................. - Page 24 Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
