- Page 1 rtfm. read first - then unpack Zuerst Lesen - dAnn AusPAcKen d’ABord Lire - ensuite deBALLer BiKe mAnuAL...
- Page 2 Welcome to good times. yt-industries.com...
- Page 3 RAHMEN / FRAME / CADRE FEDERGABEL / SUSPENSION FORK / FOURCHE Oberrohr / Toptube / Tube Supérieur Unterrohr / Downtube / Tube Oblique Gabelkrone / Crown / Té Sitzrohr / Seattube / Tube de selle Standrohr / Stanchions / Plongeur Kettenstrebe / Chainstay / Base Tauchrohr / Casting / Fourreaux Sitzstrebe / Seatstay / Hauban...
- Page 4 MONTAGE WERKZEUG ASSEMBLY TOOLS OUTILS DE MONTAGE Drehmomentschlüssel Inbusaufsatz Gr. 5 und 6 Torque wrench with Allen key adapter size 5 and 6 Clé dynamométrique avec insert Clé Allen, taille 5 et taille 6 Inbus Größe 5 und Größe 6 Allen key size 5 and 6 Clé...
- Page 5 TIP: been implemented correctly and to the full extent. Please save the YT Industries BikeBox including the packaging material. This way, you can repack your You may reach us by email at: service@yt-industries.com...
- Page 6 ASSEMBLY INSTRUCTIONS STEP STEP STEP STEP STEP STEP OPEN BIKEBOX REMOVE BIKE REMOVING THE PACKAGING Separate the packaging tape using wire cutters or a box cutter. a a b b Pull the bike out of the box. Remove the protective packaging using the appropriate tool. Just make sure that you do not damage the BikeBox.
- Page 7 INSTALLING/SECURING INSTALLING THE WHEELS STEP STEP STEP STEP STEP STEP INSTALLING THE HANDLEBAR 06 A THE SADDLE FORK MANITOU Remove the handlebar clamp on the stem by removing all screws using Loosen the seat clamp by loosening the screw using an Allen wrench. Turn the bicycle upside down.
- Page 8 ASSEMBLY INSTRUCTIONS STEP STEP STEP STEP INSTALLING THE WHEELS - FORK MANITOU 06 A 06 B Insert the front wheel into the fork. Make sure that the end caps are Slide the lightly greased axle through the hub until the thread engages Turn the bicycle upside down.
- Page 9 STEP STEP INSTALLING THE WHEELS - FORK MARZOCCHI INSTALLING THE WHEELS - FORK ROCK SHOX 06 C Slide the lightly greased axle through the hub and tighten it Remove the front axle by opening the quick release lever and unscrewing it. Now the front axle can be inserted.
- Page 10 ASSEMBLY INSTRUCTIONS SCHRITT SCHRITT SCHRITT SCHRITT INSTALLING PEDALS FULLY ASSEMBLED BIKE Apply suffi cient grease to the pedal thread. You’re fi nished! Congratulations! Your bike is now fully assembled. Excess grease can be wiped away after the pedals have been installed. Please note the following information for adjusting your bike.
- Page 11 Adjustments after assembly YOU CAN FIND DETAILED INFORMATION ABOUT YOUR BIKE IN THE “SAFETY FIRST” BICYCLE MANUAL. ADJUSTING THE SUSPENSION ELEMENTS CHECK BEFORE EVERY RIDE: IMPORTANT GENERAL INFORMATION: (REAR SHOCK AND SUSPENSION FORK) - that the seatpost and wheels are fi rmly secured in the frame and fork We are not liable for property damage or personal injury resulting from the operation of The suspension elements that we use allow for a variety of adjustments.
- Page 12 TORQUE CHART 33 - 41 Nm Bottom bracket 9,5 Nm Brake caliper screw to frame and fork 2,5 - 4 Nm Shifter 6 Nm Disc brake bolts to hub 8 - 10 Nm Rear derailleur (fi xing bolt) 4 - 5 Nm Rear derailleur (clamp bolt) 2,8 - 3,4 Nm Brake lever...
- Page 14 GmbH ZWEIBRÜCKENSTRASSE 2 ZWEIBRÜCKENSTRASSE 2 91301 FORCHHEIM 91301 FORCHHEIM GERMANY GERMANY PHONE +49 (0) 9191 . 73 63 05 0 +49 (0) 9191 . 73 63 05 0 +49 (0) 9191 . 73 63 05 55 +49 (0) 9191 . 73 63 05 55 MAIL service@yt-industries.com...
