Specifications - J5create JUH410 User Manual

USB 3.0 MULTI-ADAPTER

Specifications

Interface
Host Interface
Video Interface
USB Port
Power Jack
Power
Power Mode
Functions
Display
Physical Specifications
Dimensions
Weight
USB 3.0 Male Type-A connector
VGA-DB 15 pin Female connector
USB 3.0 Female connector x 3 Ports
DC 5V (3.5mm)
Bus-powered or Self-Powered
*** When you connect with high power-consumption
external HDD or USB devices that need bus power
more than 150mA. We recommend you to attach the
AC/DC power adapter included in your devices, or
purchase JUH410 AC/DC power adapter. (sold
separately)
Video Playback: 1080P
Display resolution: 2048 x 1152 @ 32bit
Display Modes: Primary, Extended, Mirror
Display Rotation: 0°, 90°, 180°, 270°
Main body: 42.9(W)x 87(H)x14.2(D) mm
Cable length: 14.8 cm
Approximately 61.5 g (including cable)
4
USER MANUAL
