In the event of a malfunction detected by the control
system, an error message will be displayed indicating the
type of problem.
SELECTION NOT AVAILABLE
"Failure name"
At the end of dispensing, the display indicates for a few
seconds the request to pick up the drink and the machine
is preset for the next selection.
DRINK READY

SURFING MODE

The interaction between system and user occurs through
the following components:
- Liquid crystal display (LCD) 2 lines of 16 characters.
- External direct selection push-button panel which takes on
the following functions when in "Filler" and "Technician"
mode (see Fig. 20):
Fig. 20
Scroll buttons " " and " ":
To move to the next or previous menu option and change
the values (up or down).
Confirm button " ":
To move from a menu to a sub-menu, or to confirm the
current information on the display.
Exit key " ":
to return from a sub-menu to the higher level menu, or to
clear the data on the display.
It is also used for going from "Technician" mode to "Filler"
mode and vice versa.
With the door open, the presence of the magnet on the
decaffeinated coffee door cannot be detected correctly.
The first line on the display indicates, after the number, the
active function of the menu.
© by N&W GLOBAL VENDING SpA
TAKE

FILLER MENU

When pressing once the programming button located on the
coin mechanism compartment, the machine goes into
"Filler menu" mode.
Fig. 21
1 - Contacolpi meccanico
2 - Pulsante lavaggio
3 - Pulsante ingresso programmazione
4 - Copertura scheda pulsanti
The display presents the first item of the "filler" menu with
a series of numbers next to it, identifying the level of the
current menu.
Press the confirm button " " to access the menu.
Press the exit button " " to return to the previous menu.
FILL>
STATISTICS
17
FILL>
Print statistics
FILL>
Display statistics
FILL>
Reset statistics
