Sharp LC-32D65E Service Manual page 14

LC-32D65E/RU, LC-37D65E/RU
5. Remove the Speaker (L)
1
6. Remove the 4 lock screws
7. Remove the 7 lock screws
8. Remove the 1 lock screws
4
5
6
, (R) .
2
, the 3 hooks and detach the POWER/INVETER Unit.
3
, the 1 lock screw and detach the MAIN Unit.
4
5
, and detach the Control Cover Ass'y from the MAIN Unit.
6
MAIN Unit
Control Cover Ass'y
2 Speaker(R)
POWER/
INVERTER
Unit
2 – 3
3
POWER
PWB
Holder
1 Speaker(L)
