Sharp LC-32D65E Service Manual page 105

NO. PARTS CODE
[4] DUNTKE685FM01/FM03 (MAIN Unit)
SC1501
QSOCZA171WJZZY
SC1502
QSOCZA171WJZZY
SC1504
QSOCNA716WJZZ
SC2401
QSOCNA715WJZZ
SC2601
QCNCWA671WJQZY
SC4401
QSOCJA004WJZZQ
SC5301
QSOCZA072WJZZQ
SC9301
QCNCWA562WJQZY
TH2001
VHHM1103J03-1Y
TU7501
RTUDAA019WJQZ
!
VA8101
RH-VXA194WJZZY
VA8102
RH-VXA194WJZZY
X1301
RCRSCA086WJZZY
X2001
RCRSC0032TAZZY
X7501
RCRSCA112WJZZY
X8102
RCRSCA174WJQZY
X8702
RCRSCA086WJZZY
N
VRK-SA1JF000JY
N
GCOVAC895WJ1A
N
PSPAZB313WJKZ
N
QEARPA318WJFW
N
XBPSN20P14JS0
[5] DUNTKE687FM01/FM03 (LED Unit)
C101
VCKYCY1HF103ZY
C102
VCEASX1CN106MY
C103
VCEASY1CN107MY
C104
VCKYTV1CF225ZY
D102
RH-PX0421CEZZY
D103
RH-PX0421CEZZY
D104
RH-EXA092WJZZY
IC101
VHiGA1S100W-1Y
P102
QPLGNA330WJZZY
Q102
VS2SC3928AR-1Y
Q103
VS2SC3928AR-1Y
Q104
VS2SC3928AR-1Y
Q105
VS2SC3928AR-1Y
R103
VRS-CY1JF161JY
R105
VRS-CJ1JF103JY
R106
VRS-CY1JF223JY
R107
VRS-CY1JF393JY
R110
VRS-CY1JF103JY
R113
VRS-CY1JF000JY
R114
VRS-CY1JF161JY
R115
VRS-CY1JF821JY
R116
VRS-CY1JF273JY
R120
VRS-CY1JF101JY
RMC101
RRMCUA053WJZZ
SLD101
PSLDPA076WJFW
PRICE NEW PART
RANK MARK
DELIVERY
Socket 23Pin (HDMI 2/TMDS Input6)
AF J
Socket 23Pin (HDMI 1/TMDS Input5)
AF J
Socket 17Pin(Black)
AM J
Socket 11Pin
AL J
Plug 41Pin(LW)
AH J
Socket 68Pin
AV N J
Socket 23Pin (HDMI 3/TMDS Input 7)
AH J
Connector 60Pin(To PC Card)
AF J
Thermistor
AC J
TUNER
N S
Varistor AVRL161A1R1NTB
AC J
Varistor AVRL161A1R1NTB
AC J
Crystal 27MHz
AG J
Crystal, 32.768kHz
AG J
Crystal
AE R
Crystal
AG J
Crystal 27MHz
AG J
Resistor 0 1/16W Metal Composition
AB J
CI Coin Cover
AF N R
Spacer (TRIDENT IC)
AC J
Earth Plate N
AK N R
Screw, x2 (CARD SLOT)
AB J
AA J Capacitor 0.01 50V Ceramic
Capacitor 10 16V Electrolytic
AC J
Capacitor 100 16V Electrolytic
AC J
Capacitor 2.2 16V Ceramic
AB J
Photo Diode CL-165HR/YG-D-T
AD J
AD J Photo Diode CL-165HR/YG-D-T
Zener Diode UDZSNPTE-1712B
AB J
IC GA1A1S100WP
AE J
Plug 10Pin(RA)
AD J
Transistor 2SC3928A-T112-1R
AB J
Transistor 2SC3928A-T112-1R
AB J
Transistor 2SC3928A-T112-1R
AB J
Transistor 2SC3928A-T112-1R
AB J
Resistor 160 1/16W Metal Oxide
AA J
Resistor 10k 1/16W Metal Oxide
AA J
Resistor 22k 1/16W Metal Oxide
AA J
Resistor 39k 1/16W Metal Oxide
AA J
Resistor 10k 1/16W Metal Oxide
AA J
Resistor 0 1/16W Metal Oxide
AA J
AA J Resistor 160 1/16W Metal Oxide
Resistor 820 1/16W Metal Oxide
AA J
Resistor 27k 1/16W Metal Oxide
AA J
Resistor 100 1/16W Metal Oxide
AA J
IR Receiver module
AE J
Shield Case (IR Receiver)
AD J
