Downloaded from
www.Manualslib.com
R
F
EGULATORY
ACTORS
W
R
IRELESS
EMOTE
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications to this device may void your authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the use is encouraged to try to correct
the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
S
I
AFETY
NSTRUCTIONS
You must keep safety in mind while using this device. Keep these
and any other instructions for future reference.
I
NSTALLATION
Observe Warnings: Carefully follow all warnings on the device
and in the operating instructions.
Heat: DO NOT place the device near heat sources such as radiators, stoves, heat
registers, or other appliances that produce heat.
C
U
ARE AND
SE
Cleaning: DO NOT use liquid, abrasive, solvent, or aerosol cleaners. Use a damp cloth
for cleaning.
When Not in Use: Remove the batteries if this device is to be
left unattended or unused for a long period of time.
Refer servicing to qualified personnel when a solid object
or liquid has fallen onto or into the device.
DO NOT attempt to service this device. Refer all
servicing to qualified personnel. Opening covers other
than the battery cover will void the warranty.
manuals search engine
C
ONTROL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 301 IR 123271 and is the answer not in the manual?

Questions and answers

Related Manuals for Dish Network 301 IR 123271

Summary of Contents for Dish Network 301 IR 123271

  • Page 1 EGULATORY ACTORS IRELESS EMOTE ONTROL This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Remote Control Basics........2 Models Supported by this Guide ......2 UHF and IR Signals ..........3 Installing Batteries..........3 Converting the 4.0 Remote Control ....4 Setting Up to Control the Satellite Receiver ..5 Checking the Remote Address ......7 Setting Up to Control Other Devices ....

  • Page 3: Remote Control Basics

    IR-controlled DISH Network receivers. • 4.0 - Infrared/Ultra-High Frequency Pro (IR/UHF Pro). For use with appropriate UHF Pro-controlled DISH Network receivers. The 4.0 remote can be converted to one of three different remote types used on a DISH 322 receiver:...

  • Page 4: Uhf And Ir Signals

    NSTALLING ATTERIES The remote control requires AAA batteries. When you replace old batteries, you should replace all of the batteries. Use batteries of the same kind, for example, alkaline or carbon zinc, and don’t mix batteries of different kinds. Alkaline batteries last longer. 1.

  • Page 5: Converting The 4.0 Remote Control

    4.0 R ONVERTING THE EMOTE ONTROL By replacing the key at the bottom of the 4.0 remote, this remote can be converted to look and work like a 3.0 IR or to operate like a second UHF Pro remote to control the side of the DISH 322 receiver.

  • Page 6: Setting Up To Control The Satellite Receiver

    5. If you are converting the remote to operate like a second UHF Pro remote to control the side of the DISH 322 receiver, then get the green 1 UHF Pro key provided separately. Install this key in the remote with the UHF Pro marking showing.
  • Page 7 1. For DISH 322 receivers only: If you are using a 4.0 Remote control with the green 1 UHF Pro key installed, perform the steps a. through e. below. If not, then go to step 2. a. Open the TV1 UHF Pro Setup screen by pressing MENU-6-1-8 on the remote control.

  • Page 8: Checking The Remote Address

    5. Press the POUND (#) button. If you entered the address correctly, the SAT mode button will flash three times. 6. Press the RECORD button. If you are using the 4.0 remote with the green 1 key (no UHF Pro marking), point the remote control at the receiver when you press the RECORD button.

  • Page 9: Setting Up To Control Other Devices

    ETTING P TO ONTROL THER EVICES To use the remote to control other devices (such as a TV, VCR, DVD player, tuner, or amplifier), you must first program it to control these other devices. You can do this by either following the instructions in Setting Up Using Device Code Tables on page 8, or the Setting Up Using Device Codes Scan procedure described on page 9.

  • Page 10: Setting Up Using Device Codes Scan

    For example, hold the TV mode button for a TV until all of the other mode buttons light. When you let go, the TV mode light will flash. 4. Only for the AUX mode, Use a number button to enter 0 for a second TV, or 1 for a second VCR or DVD player, or 2 for a tuner or amplifier.

  • Page 11: Checking The Device Codes

    3. Only for the AUX mode, use the number buttons to enter 0 for a second TV, 1 for a second VCR or DVD player, or 2 for a tuner or amplifier. Then press the STAR (*) button. 4. Press the blank POWER button. 5.

  • Page 12: Switching Between Tv And Device Volume Control

    For AUX mode, the first group of flashes tells you what the AUX mode controls. A quick flash (zero) before the three-digit code is for a TV; one regular flash is for a VCR or DVD player; and two flashes is for a tuner or amplifier. For example, if the TV code is 570, the AUX mode button flashes once quickly, pauses, flashes five times, pauses, flashes seven times, pauses, and flashes once quickly.

  • Page 13: Remote Control Operation

    2. Press the POUND (#) button. 3. Press the plus (+) side of the VOLUME button. 4. Press the 0 number button. 5. Press the POUND (#) button. The TV mode button flashes three times. 6. Press the SAT mode button. 7.

  • Page 14: Controlling The Satellite Receiver

    ONTROLLING THE ATELLITE ECEIVER UTTON Press this button to set the remote to SAT (“satellite”) mode to control the receiver. The SAT mode button’s back light stays lit for about two seconds to show you’ve set the remote to SAT mode. Make sure you keep the remote in SAT mode to use the buttons following buttons.
  • Page 15 UTTON Press this button to turn the TV sound on or off. Note: You must set up the remote to control the TV for the MUTE button to work. See Setting Up to Control Other Devices on page 8. UTTON Press this button to open the Main Menu.
  • Page 16 RROW UTTONS • Change channels - Press the UP or DOWN arrow button to change channels. • Open the Browse Banner - Press the RIGHT arrow button. • Show Themes - Press the LEFT arrow button. • Move around within the Program Guide, menus, and Browse Banner - Press the UP, DOWN, LEFT, and RIGHT arrow buttons.
  • Page 17 TV B UTTON • When you watch a program, press this button to briefly display the Program Banner. • When you use a menu, press this button to cancel and go back to watch a program. ANCEL UTTON Press this button to cancel and go back to the previous menu or to watch a program.
  • Page 18 Enter menu options - For an option with a number, you can press the number for that option instead of highlighting and selecting the option. • Enter numbers in a blank - Highlight the place where you need to enter the number. Press a number button(s) (or, you can use the UP/DOWN arrow buttons to enter the number).
  • Page 19 SING THE ECOVER UTTON Use this procedure works only if you have accidentally changed the TV channel or video input. It does not recover lost satellite signal. Note: RECOVER will first try to tune your TV to channel 3, then channel 4, and then other video inputs with each press of the RECOVER button.

  • Page 20: Controlling A Tv (Or A Second Tv)

    TV ( ONTROLLING A OR A ECOND Only the buttons described here control a TV. Some of the buttons described heremay not control your TV. See your TV user’s manual for information about the TV’s features. You can set up the remote to control a second TV in AUX mode, the same way it controls the first TV in TV mode.
  • Page 21 OLUME UTTON Press this button to raise (+) or lower (-) the TV sound volume. RROW UTTONS Use these buttons to change channels on the TV. Note: These buttons do not change the channels on the TV if the remote control is in limited mode. ELECT UTTON The SELECT button works as the ENTER button for a TV.

  • Page 22: Controlling Avcr

    VCR ( ONTROLLING A OR A ECOND OR A LAYER Only the buttons described here control a VCR or DVD player. Some of the buttons we tell you about here may not control your VCR. See your VCR or DVD player user’s manual for information about the features.
  • Page 23 RROW UTTONS Use these buttons to change channels on the VCR. Note: If you are using the remote control in Limited Mode, the VCR will not change channels. TV B UTTON For VCR/DVD combinations only: Press the VIEW TV button to switch between VCR and DVD functions.

  • Page 24: Controlling A Tuner Or Amplifier

    ONTROLLING A UNER OR MPLIFIER Only the buttons described here control a tuner or amplifier. Some of the buttons described here may not control your tuner or amplifier. See the device user’s manual for information. UTTON You must first set up the remote to control the device. See Setting Up to Control Other Devices on page 8.
  • Page 25 RROW UTTONS Use these buttons to change channels on the tuner or amplifier. ELECT UTTON This button works as the INPUT SELECT button for the tuner or amplifier. Downloaded from www.Manualslib.com manuals search engine...

  • Page 26: Device Codes

    526, 627, 652, 654, Apex 743, 744, 745 658, 665, 670, 672 Archer Dimensia 645, 650 Audiovox 620, 657, 662, 672 DISH Network Bell & Howell 590, 669, 675 Dixi 566, 620 Broksonic 752, 659, 661, 748 Dumont 501, 627, 652...
  • Page 27 Codes Codes Electrohome 526, 573, 651, 652, JC Penney 505, 506, 516, 525, 654, 656, 659, 660, 526, 543, 546, 631, 665, 670, 709, 728 645, 646, 650, 652, 653, 654, 658, 659, Emerson 526, 534, 536, 541, 664, 667, 668, 670, 573, 590, 627, 636, 673, 676, 678, 680, 642, 648, 652, 654,...
  • Page 28 Codes Codes Megatron 627, 654 Philco 505, 506, 525, 536, 568, 573, 610, 651, Memorex 590, 627, 653, 654, 652, 653, 654, 655, 659, 675, 720 656, 659, 660, 664, 665, 666, 669, 671, 504, 505, 506, 542, 672, 674, 677, 723, 571, 573, 627, 652, 724, 729 653, 654, 656, 660,...
  • Page 29 Codes Codes Samsung 505, 506, 516, 523, Tatung 509, 651, 663, 698 526, 566, 573, 612, Technics 508, 673, 676 627, 647, 652, 653, 654, 655, 656, 658, Techwood 523, 573, 652, 654, 659, 664, 665, 667, 660, 676 669, 670, 679, 680, Teknika 504, 505, 512, 516, 704, 717, 730, 738...

  • Page 30: Vcr Codes

    VCR C ODES CODES Programming in AUX Emerson 505, 506, 508, 509, 511, 512, 534, 559, mode : In most cases use these 568, 588, 590, 618, codes to program in VCR mode; 676, 678 however, if programming in Finlandia AUX mode, press 1 before Finlux 549, 556, 588...
  • Page 31 CODES CODES Logik 589, 681, 685 Philips 554, 556, 585, 678 Luxor Pioneer 562, 573, 574, 575, 576, 600, 674, 680, Portland 546, 677 Magnasonic Proscan 605, 607 Magnavox 527, 533, 554, 556, 678, 679, 685 Proton Marantz 554, 556, 581, 585, Quasar 554, 678, 679, 747, 592, 594, 600, 602,...

  • Page 32: Tv/Vcr Combo Codes

    DVD P LAYER ODES CODES Programming in AUX Sylvania 554, 556, 567, 588, 678, 679 mode : In most cases use these codes to program in VCR mode; Symphonic 588, 594, 683 however, if programming in Tandy 581, 588 AUX mode, press 1 before Tashiko 588, 676 entering the VCR code.

  • Page 33: Tuner/Amplifier Codes

    DVD Players Codes Tuner/ Codes Amplifier Philips 640, 641 Pioneer 665, 718, 719 Goldstar 677, 690 Proscan Harmon/Kardon 640, 672, 751 Qwestar 721, 723 Hitachi 717, 754 627, 650, 666, 690, 742, 749 Sampo 637, 683, 703, 725 Samsung 651, 652, 667, 668, Kenwood 649, 676, 691, 726, 691, 740, 741...

  • Page 34: Dvd/Vcr Combo Codes

    Tuner/ Codes Amplifier Yamaha 663, 730, 731, 732, 733, 745, 747 DVD/VCR C OMBO ODES Programming for combination equipment Use VCR mode to control VCR and DVD functions; however, if programming in AUX mode, press 1 before entering the DVD/ VCR code.

  • Page 35: Troubleshooting

    ROUBLESHOOTING What’s What’s Wrong What You Can Do Happening While you do • If you don’t press Start over again. a remote any button procedure, the for 20 seconds in remote control a programming “times out.” sequence, the remote “times out.” •...
  • Page 36 What’s What’s Wrong What You Can Do Happening When you • Maybe you’re • Remember, the remote control uses press a button trying to control a IR signals to control all devices on the remote device and except for the receiver (when using control, the you’re not the UHF antenna).

  • Page 37: Limited Warranty

    Proof of Purchase to be out of warranty. This warranty extends only to the original user of the DISH Network remote control (“you,” “your”) and is limited to the purchase price of the remote control.
  • Page 38 lightning, electrical or telephone line surges, fire, flood, or other acts of Nature; accident; misuse; abuse; repair or alteration by other than our factory service; negligence; commercial or institutional use; improper or neglected maintenance; equipment sold AS IS or WITH ALL FAULTS;...
  • Page 39 CCESSORY ARRANTY An accessory is any DISH Network branded equipment, displaying the DISH Network logo, excluding the receiver, Smart Card, cables and hookups, and non-mechanical components. A one-year warranty becomes effective upon the activation of the DISH system or date of purchase, if bought separately.

  • Page 40: If You Need Help

    1. Review this User Guide. 2. See Troubleshoot the Remote on page 34. 3. Call the Customer Service Center at 1-800-333-DISH (3474). Have the date of purchase and your customer account number ready. 4. A Representative will help you. 5. If the representative finds you should return the remote control, you’ll get a telephone number to call for a Return Authorization (RA) number.
  • Page 41 Notes Downloaded from www.Manualslib.com manuals search engine...
  • Page 42 Notes Downloaded from www.Manualslib.com manuals search engine...
  • Page 43 Notes Downloaded from www.Manualslib.com manuals search engine...
  • Page 44 Notes Downloaded from www.Manualslib.com manuals search engine...
  • Page 45 Notes Downloaded from www.Manualslib.com manuals search engine...
  • Page 46 Technical Publications, 94 Inverness Terrace East, Englewood, Colorado 80112 Part Number: 142926 Printed in the United States of America. DISH Network is a registered trademark of EchoStar Satellite L.L.C. For information about DISH Network, visit our website at www.dishnetwork.com. Downloaded from www.Manualslib.com...
