TRIM ADJUSTMENT
FORWARD/BACKWARD TRIM
When the quad-copter veers
forward/backward unintentionally,
you can correct it by pressing
the trim button in the opposite
direction until it evens out.

TROUBLESHOOTING

Symptom Possible Cause
1. Communication between controller and
Movie-Drone
aircraft was not synchronized during set up
does not
2. Battery power depleted on aircraft,
respond
controller or both.
Response to
1. Controller battery power nearly depleted.
control inputs
intermittent
or erratic
The
1. The aircraft was not on level ground
Movie-Drone
during synchronization.
will not hover
or strafe
2. Trim settings are incorrect.
correctly
SIDEWAYS TRIM
When the quad-copter veers to
the left or right side unintentionally,
you can correct it by pressing the
trim button in the opposite direction
until it evens out.
6
LEFT/RIGHT TRIM
When the quad-copter keeps
spinning left or right unintentionally,
you can correct it by pressing the
trim button in the opposite direction
until it evens out.
Potential Solution
1. To synchronize, turn on controller, then
turn on aircraft and place it on level
ground. Move throttle stick all the way
forward, then all the way back.
2. Charge aircraft and/or replace
batteries in controller.
1. Replace batteries in controller.
1. Re-synchronize aircraft and controller.
2. Reset the trim buttons on the controller
and re-trim flight controls.
